INSTALLATION MANUAL NeatCharge Included Parts Product Information (continued)Product Information GT-NPD-IM-1885-001-R01 www.humanscale.com Humanscale Corporation 1114 6th Ave. 15th Floor New York, NY 10036 For our terms and conditions please go to https://www.humanscale.com/about/legal-information/terms-conditions.cfm © 2020 Humanscale Corporation. The text and artwork are copyrighted materials. All rights reserved. The Humanscale mark and logo are trademarks of Humanscale Corporation and are registered in the United States and certain other countries. Product Name: NeatCharge Model #: WE9012C-X Input: 100-240VAC 50/60Hz 24V 1A Max Wireless Output Power 10W Charging Distance: 15mm to 30mm (0.6”-1.2”) Qi compatible devices Weight: 7.94 ounces (225g) Operating Temperature: 32°F to 95°F (0°C to 35°C), humidity 10 to 90% Storage Temperature: -4°F to 176°F (-20°C to 80°C), humidity 5 to 95% FCC ID: 2AYH2-WE9012C IC: 26837-WE9012C CAUTION • Remove all objects from the charging area before charging compatible mobiles, including phone cases, pop sockets, coins, keys, rings, staples, paper clips, RFID cards, credit cards, and any other metal objects. Metal objects on or near the charging area may become hot and cause burns. • Be sure the surface is clear of dust and other debris before charging. • Wireless charging is temperature sensitive. Do not use the Product outside of its operating temperature range and do not store the Product outside of its storage temperature. Do not keep the Product in high-temperature environments, including intense sunlight or other forms of heat. Keep product away from res and open ames. • Do not disassemble the Product or attempt to re-purpose or modify it in any manner. • If the Product is intended by Purchaser to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior to use. Failure to do so is sole responsibility of Purchaser, who agrees to indemnify Humanscale for any unintended use/misuse by a minor. • Product is intended for home, ofce and general indoor use only. Do not use near medical or industrial equipment or on board an aircraft • This product contains magnets. KEEP THIS PRODUCT AWAY FROM CHILDREN. SEEK IMMEDIATE MEDICAL ATTENTION IF A MAGNET IS SWALLOWED OR INHALED. • DO NOT USE THIS PRODUCT IF YOU HAVE A PACEMAKER OR IMPLANTED MEDICAL DEVICE. Wireless charging can affect the operation of an implanted peacemaker or other medical devices. FCC Statement This device complies with Part 15 and Part 18 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. CAN ICES-003(B)/NMB-003(B) This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s): RSS-216, RSS-102, and SPR-002 at 0cm. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Changes or modications to this device not expressly approved by Humanscale may void the user's authority to operate this equipment. North America: +1 800 400 0625 Europe: +353 (0)1 858 0910 Asia Pacic: +852 2581 0570 Locator Magnets Double-Sided Adhesive Sticker Mounting Screws AC AdapterCharger Locator Template Charging Location Sticker Cable Clips Tools Required Drill with #2 Phillips Head Driver Bit Pencil Note STEP 1: STEP 2: Choose a charging location on the desk, making sure there is space beneath for the charger. Clean and dry the surface before placing the charging location sticker. Remove adhesive backing and place the charging location sticker on work surface in the desired location. Place a stack of 2 included magnets on the power symbol in the center of the location sticker. STEP 3: STEP 5: Using a pencil, trace around the edge of the template, then remove the template and magnets. Charger does not work at close range. The work surface thickness must be at least 15mm (0.6”) and no more than 30mm (1.2”). Beneath the work surface, use the third magnet to nd the location of the upper magnets. When they are aligned, adjust the position to make sure the upper magnets are still centered on the sticker. STEP 4: Center the locator template on the lower magnet and hold the template against the work surface, making sure to not move the magnet. STEP 7: Plug in power cable and AC adapter. If needed, cable clips can be used to manage…

Text truncated - open the document above for the full version.

(NINGBO UNITED WIN LONG ENTERPRISES CO., LTD.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AYH2-WE9012C Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram .pdf, Schematics .pdf , Operation Description .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Short-term confidentiality requested: 180 days Exhibit Type File Name External Photos, Internal Photos, Test Setup Photos, User Manual External Photos .pdf, Internal Photos .pdf, Test Setup Photos .pdf, User Manual.pdf Sincerely, Tequila Hu / BD Manager NINGBO UNITED WIN LONG ENTERPRISES CO., LTD.

NINGBO UNITED WIN LONG ENTERPRISES CO., LTD. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: January 11, 2021 SUBJECT: FCC Application for FCC ID: 2AYH2-WE9012C To Whom It May Concern: We, the undersigned, hereby authorize Tony Wei at EMTEK(NINGBO) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK(NINGBO) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Tequila Hu / BD Manager NINGBO UNITED WIN LONG ENTERPRISES CO., LTD.

External photos: ---The End---

Label Location

Internal photos: ---The End--- Antenna

Report No.ES201211048W02 Page 1 of 13 Ver.1.0 TEST REPORT $二维码$ Product Name : NeatCharge Model Number : WE9012C-X FCC ID : 2AYH2-WE9012C Prepared for : NINGBO UNITED WIN LONG ENTERPRISES CO., LTD. Address : Room Z503A, Building 1, East Union Zone, Development Zone，Ningbo, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES201211048W02 Date(s) of Tests : December 11, 2020 to January 12, 2021 Date of Issue : January 13, 2021 Report No.ES201211048W02 Page 2 of 13 Ver.1.0 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ............................................................................................. 4 2. GENERAL INFORMATION ................................................................................................... 5 2.1. DESCRIPTION OF DEVICE (EUT) ....................................................................................................................... 5 2.2. DESCRIPTION OF TEST FACILITY ........................................................................................................................ 6 2.3. MEASUREMENT UNCERTAINTY .......................................................................................................................... 6 3. MEASURING DEVICE AND TEST EQUIPMENT ................................................................. 7 3.1. FOR MPE MEASUREMENT ................................................................................................................................ 7 4. RF EXPOSURE..................................................................................................................... 8 4.1. MEASURING STANDARD .................................................................................................................................... 8 4.2. REQUIMENTS ................................................................................................................................................... 8 4.3. TEST CONFIGURATION ...................................................................................................................................... 9 4.4. LIMITS ........................................................................................................................................................... 10 4.5. MEASURING RESULTS ..................................................................................................................................... 11 Report No.ES201211048W02 Page 3 of 13 Ver.1.0 TEST REPORT DESCRIPTION Applicant : NINGBO UNITED WIN LONG ENTERPRISES CO., LTD. Address : Room Z503A, Building 1, East Union Zone, Development Zone，Ningbo, China Manufacturer : NINGBO WENERGY ELECTRONIC TECHNOLOGY CO., LTD. Address : No 777, West Zhongguan Road, Qihang building, Stand B, 3rd floor, Zhenhai district EUT : NeatCharge Model Name : WE9012C-X Trademark : N/A Measurement Procedure Used: FCC Part 1(1.1310) and Part 2(2.1091) KDB 680106 D01 RF Exposure Wireless Charging App v03 The device described above is tested by EMTEK (SHENZHEN) CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and EMTEK (SHENZHEN) CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of EMTEK (SHENZHEN) CO., LTD. Date of Test : December 11, 2020 to January 12, 2021 Prepared by : Sewen Guo /Editor Reviewer : Joe Xia/Supervisor Approved & Authorized Signer : Lisa Wang/Manager Report No.ES201211048W02 Page 4 of 13 Ver.1.0 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results MPE FCC Part 1(1.1310) and Part 2(2.1091) KDB 680106 D01 RF Exposure Wireless Charging App v03 Pass Note: N/A is an abbreviation for Not Applicable. Report No.ES201211048W02 Page 5 of 13 Ver.1.0 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Product: NeatCharge Model Number: WE9012C-X Sample Number: 1# Power Supply: DC24V from adapter Modulation: Ask Adapter: M/N: QS-2401000U Input: AC 100-240V, 50/60Hz, 1.5A Max Output: DC 24V, 1A Frequency Range: 110kHz~135KHz Antenna Type: Integral Antenna(Induction coil) Antenna Gain: 0 dBi Operating Temperature: 0°C ~ +35°C Date of Received: December 11, 2020 Report No.ES201211048W02 Page 6 of 13 Ver.1.0 2.2. Description of Test Facility Site Description EMC Lab. : Accredited by CNAS The Certificate Registration Number is L2291. The Laboratory has been assessed and proved to be in compliance with CNAS-CL01 (identical to ISO/IEC 17025:2017) Accredited by FCC Designation Number: CN1204 Test Firm Registration Number: 882943 Accredited by A2LA The Certificate Number is 4321.01. Accredited by Industry Canada The Conformity Assessment Body Identifier is CN0008 Name of Firm : EMTEK (SHENZHEN) CO., LTD. Site Location : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China 2.3. Measurement Uncertainty MPE : ±2 % Report No.ES201211048W02 Page 7 of 13 Ver.1.0 3. MEASURING DEVICE AND TEST EQUIPMENT 3.1. For MPE Measurement Used Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval  E-Field Probe(100kHz-3GHz) Narda EF0391 2304/03 May 20, 2020 1 Year  Broadband Field Meter Narda NBM-550 232421 May 20, 2020 1 Year  Exposure Level Tester(1Hz-400KHz) Narda ELT-400 C-0012 May 20, 2020 1 Year Report No.ES201211048W02 Page 8 of 13 Ver.1.0 4. RF EXPOSURE 4.1. Measuring Standard FCC Part 1(1.1310) and Part 2(2.1091) 4.2. Requiments Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These …
