2AYHS-DM01Transmitter

Transmitter Function Description Specification Transmitter Type：ST-L-Transmitter Transmitter Power : 6V (CR2016*2) Factory Code：Steel-Line Code Operating Freq : 433.92MHz Modulation Type : ASK 1.Learn the transmitter to the opener. 2.When opener is without limit position Key 1–Open / travel toward up limit position Key 2–Limit position confirm Key 3–Close / travel toward down limit posit ion 3.When the opener is with limit position Key 1–When the door is fully closed, press the first time to open the door, press the second time to stop, press The third time is closing. When the door is fully open, press the first time to close the door, press the second time to open the door, pressThe third time is a stop.When the door is in the middle, press the first time to close the door, press the second time to open the door, press The third time is a stop. The second and third keys have the same functions as the first key。 DM01 Transmitter User’s Manual 1 2 3 FC C STATEMENT : Th is device complies with Part 15 of the FCC Rules. Operation is subject to the following two co nditions: This device may not cause harmful interference, and Th is device must accept any interference received, including interference that may cause u ndesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NO TE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio f requency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference w ill not occur in a particular installation. If this equipment does cause h armful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Inc rease the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. RF warning statement: T he device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

FCCID:2AYHS-DM01

LabelLocationOnEUT Label ProductName:Transmitter ModelNo.:DM01 FCCID:2AYHS-DM01 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2AYHS-DM01 ANT

version01 DECOMOTIONLIMITED DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.: DM01 FCCID:2AYHS-DM01 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: 433.92MHz: ModelNo.ofantenna:DM01 Typeofantenna:PCBAntenna Gainoftheantenna:0dBi Frequencyrange:433.92MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:DECOMOTIONLIMITED Address:7F,NO.1402-2,ZHONGZHENGRD,TAOYUANDISTTaoyuanTaiwan33045 City:Taiwan ZIP/Postalcode:33045 Country:China Place:ChinaDate:2020-12-30 Signature:

FCCID:2AYHS-DM01 RFEXPOSUREEVALUATION EUTSpecification EUTTransmitter ModelNameDM01 Frequencyband (Operating) WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.32GHz/5.50GHz~5.70GHz WLAN:5.745GHz~5825GHz Others(433.92MHz) DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Max.outputpower80.25dBuV/m(-15.01dBm)(0.032mW) Antennagain0dBi EvaluationappliedMPEEvaluation SAREvaluation StandardRequirement PortableDevice Accordingto§15.247(i)and§1.1307b(1),systemsoperatingundertheprovisionsofthissection shallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradiofrequency energylevelsinexcessoftheCommission’sguidelines.SeeKDB447498D01GeneralRF ExposureGuidanceV6,section4.3.1. The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparation distances≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR, 16 where ·f(GHz)istheRFchanneltransmitfrequencyinGHz ·PoweranddistanceareroundedtothenearestmWandmmbeforecalculation17 ·Theresultisroundedtoonedecimalplaceforcomparison Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50 mmandfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. FCCID:2AYHS-DM01 MeasurementResult Channel Frequency (MHz) MaxOutput power (dBm) Maxtune-up tolerance Outputpower (dBm) MaxOutput power(mW) Calculation Value (Note1) Threshold Value 433.92-15.01 -15.01 ± 1 0.040.00533.0 EIRP=E-104.8+20logD=80.25-104.8+20log3=-15.01dbm Note1:CalculationValue=[(max.powerofchannel,mW)/(min. testseparationdistance,mm)]·[√f(GHz)]. Foxexample:0.04/5*√0.43392=0.0053≤3.0 AccordingtoKDB447498D01V6,thresholdatwhichnoSARrequiredis≤3.0for1-gSAR, separationdistanceis5mm,andnosimultaneousSARmeasurementisrequired. StandardApplicable Accordingto2.1093thisisaportabledevice.AccordingtoKDB447498D01V6,AppendixA SARtestexclusionthresholdsforbelowtable,thepowerlevel22mWat5mm. MeasurementResult: ThisisaportabledeviceandtheMax.peakoutputpoweris-15.01dBm(0.032mW)lowerthan lowthreshold22mWat5mmingeneralpopulationcategory; TheSARmeasurementisnotnecessary.
