2AYIFRF320ARobotic Lawn Mower Charging Station

鸾 SGS North Am的caInc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Declaration Applicant Legal Business Name Address Grantee Code Jiaxing Mogo Intelligent Technology Co.,Ltd No.1-129, Zhenbei Road, Internet Town, Wuzhen Tow n , Tongxiang City,Jiaxing C i t y , Zhejiang Province,China 2 AYIF FCC ID 2A YIFRF320A Authorized Contact Name Xinliang Bao Contact Ema仆 [email protected] Contact Phone 十86-21 55830749 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a ) in accordance with 47CFR2.911 (d), all of the statements herein and the exhibits attached hereto are true and cor「ect to the best of my knowledge and belief. b ) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2)compliance statement labeling pursuant to the applicable rules, (3)compliance of the equipment with the applicable technical rules, c ) if the Applicant is not the actual manufacturer of the equipment, appropriate a「rangementshave been made with the manufactu飞「to ensu「e that production units of this equipment will continue to comply with the FCC's technical requirements. d ) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has「ead,understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e ) in accordance with 1S017065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, unde「stood,accepts and agrees to abide by the post market surveillance requirements. (1)the Applicant unde「stands,accepts and agrees that a sample may be requested for surveillance testing (2)the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED (3) the Applicant shall, upon request by SGS, at the Applicant's expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, softwa「e, accessories or other hardware or software『equiredfo「evaluation,review, certification and audit surveillance of products certified by SGS Q neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a "party" for these purposes g ) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, lnc.(TCB) terms and conditions Link to CFRs: htt s·/lwww.fcc. ov/wireless/bureau-divisions/technolo ies-s stems-and-innovation-d1v1sion/rules-re ulations-title-47 Link to KDBs: https·l/apps.fcc qov/oetcf/kdb/index.cfm Link to RSP-100: htt s:l/www.ic. c.ca/eic/site/smt-st.nsf/en /sf01130.html Applicant Signatu「e: Date: 炉伈"'1B/Jllfl- 2021-05-10 Print Name: Xinliang Bao Title: PM 'NOTE: This declaration cannot be signed by a n Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Rev:0.0

J旧xingMogo Intelligent Technology Co.,Ltd TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2AYIFRF320A To whom it may concern: Date: 2021-05-10 We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners「elatingto application fo r e q uipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) Where our agent signs the application for certification on ou「behalf,I acknowledge that all responsib山ty for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Jiaxing Mogo Intelligent Technology Co.,Ltd This authorization is valid until further written notice from the applicant. Name Xinliang Bao Title:PM Signatu r e : )0 仇 气 {6 e,,., On behalf of Company: Jiaxing Mago Intelligent Technology Co.,Ltd Telephone:+8602155830749

To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States Jiaxing Mogo Intelligent Technology Co.,Ltd From: Jiaxing Mogo Intelligent Technology Co.,Ltd No.1-129, Zhenbei Road, Internet Town, Wuzhen Town, Tongxiang City, Jiaxing City, Zhejiang Province,China Regarding: Confidentiality Request regarding application for FCC ID : 2 AYIFRF320A LONG TERM CONFIDENTIAL/TY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission's rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions NII Software Security Info The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: ｀气归 Printed Name Xinliang Bao Title: PM Company Name: Jiaxing Mago Intelligent Technology Co.,Ltd

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 External Photos Applicant: Jiaxing Mogo Intelligent Technology Co., Ltd Address of Applicant: No.1-129, Zhenbei Road, Internet Town, Wuzhen Town, Tongxiang City, Jiaxing City, Zhejiang Province,C hina Equipment Under Test (EUT): Product Name: Robotic Lawn Mower Charging Station Model No.: RF320A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 11 Internal Photos Applicant: Jiaxing Mogo Intelligent Technology Co., Ltd Address of Applicant: No.1-129, Zhenbei Road, Internet Town, Wuzhen Town, Tongxiang City, Jiaxing City, Zhejiang Province,China Equipment Under Test (EUT): Product Name: Robotic Lawn Mower Charging Station Model No.: RF320A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 11 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 11 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400299805 Page: 1 of 11 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF Exposure Report Application No.: SHEM2104002998CR FCC ID: 2AYIFRF320A IC : 26829-RF320A Applicant: Jiaxing Mogo Intelligent Technology Co., Ltd Address of Applicant: No.1-129, Zhenbei Road, Internet Town, Wuzhen Town, Tongxiang City, Jiaxing City, Zhejiang Province , China Manufacturer: Jiaxing Mogo Intelligent Technology Co., Ltd Address of Manufacturer: No.1-129, Zhenbei Road, Internet Town, Wuzhen Town, Tongxiang City, Jiaxing City, Zhejiang Province, China Equipment Under Test (EUT): EUT Name: Robotic Lawn Mower Charging Station Model No.: RF320A Trade mark: ROCKFIRE Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2021-04-07 Date of Test: 2021-05-07 to 2021-06-09 Date of Issue: 2021-06-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400299805 Page: 2 of 11 Revision Record Version Description Date Remark 00 Original 2021-06-12 / Authorized for issue by: Bill Wu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400299805 Page: 3 of 11 2 Contents Page 1 COVER PAGE................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION .......................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS ......................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................................. 5 3.4 TEST FACILITY .............................................................................................................................................. 6 4 TEST STANDARDS AND LIMITS ............................................................................................................... 7 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ................................................................................ 7 4.2 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: .................................................................................... 7 5 MEASUREMENT AND CALCULATION .................................................................................................... 8 5.1 MAXIMUM TRANSMIT POWER ........................................................................................................................ 8 5.2 MPE CALCULATION ...................................................................................................................................... 9 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400299805 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Power supply: DC 30V by adapter Charging adapter: Model:GM95-310250-1FE Input:100-240V~50/60Hz 2.5A Output:31V 2.5A 3.2 Technical Specifications BLE Antenna Gain: 2.5dBi (Provided by manufacturer) Antenna Type: PIFA Antenna Channel Spacing: 2MHz Modulation Type: GFSK Number of Channels: 40 Operation Frequency: 2402MHz to 2480MHz 2.4G WiFi Antenna Gain: 2.5dBi (Provided by manufacturer) Antenna Type: PIFA Antenna Channel Spacing: 5MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 802.11n(HT40):7 Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz Date Rate: 802.11b:1/2/5.5./11Mbps 802.11g:6/9/12/18/24/36/48/54Mbps 802.11n:MCS0-MCS7 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400299805 Page: 5 of 11 5G WiFi Operation Frequency: Band Mode Frequency Range(MHz) Number of channels UNII Band I 802.11a/n(HT20) 5180-5240 4 802.11n(HT40) 5190-5230 2 UNII Band III 802.11a/n(HT20) 5745-5825 5 802.11n(HT40) 5755-5795 2 Modulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Date Rate: 802.11a:6/9/12/18/24/36/48/54Mbps 802.11n:MCS0-MCS7 Channel Spacing: 802.11a/n(HT20): 20MHz 802.11n(HT40): 40MHz Antenna Gain: 2.5dBi (Provided by manufacturer) Antenna Type: PIFA Antenna S/N: RF320AB8N1 Firmware Version: V1.1.0 916MHz Antenna Gain: 0dBi (Provided by manufacturer) Antenna Type: Integral Antenna Modulation Type: FSK Number of Channels: 1 Operation Frequency 916MHz 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China. Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 1 1.6dB Bandwidth Test Mode Test Channel EBW[MHz] Limit Verdict 1MHz 2MHz BLE 2402 0.70 1.14 0.5 PASS BLE 2440 0.67 1.15 0.5 PASS BLE 2480 0.68 1.14 0.5 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 2 6dB Bandwidth_BLE_2402_1MHz 6dB Bandwidth_BLE_2440_1MHz 6dB Bandwidth_BLE_2480_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 3 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 4 6dB Bandwidth_BLE_2402_2MHz 6dB Bandwidth_BLE_2440_2MHz 6dB Bandwidth_BLE_2480_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 6 2.Occupied Bandwidth Test Mode Test Channel OBW[MHz] Limit Verdict 1MHz 2MHz BLE 2402 1.04 2.06 --- PASS BLE 2440 1.03 2.06 --- PASS BLE 2480 1.04 2.06 --- PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 7 Occupied Bandwidth_BLE_2402_1MHz Occupied Bandwidth_BLE_2440_1MHz Occupied Bandwidth_BLE_2480_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 8 Occupied Bandwidth_BLE_2402_2MHz Occupied Bandwidth_BLE_2440_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 9 Occupied Bandwidth_BLE_2480_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 10 3.Maximum peak conducted output power Test Mode Test Channel Power[dBm] Limit Verdict 1MHz 2MHz BLE 2402 9.92 10.06 30 PASS BLE 2440 10.12 10.49 30 PASS BLE 2480 9.17 7.67 30 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 11 Maximum peak conducted output power_BLE_2402_1MHz Maximum peak conducted output power_BLE_2440_1MHz Maximum peak conducted output power_BLE_2480_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 12 Maximum peak conducted output power_BLE_2402_2MHz Maximum peak conducted output power_BLE_2440_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 13 Maximum peak conducted output power_BLE_2480_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 14 4.Maximum Peak power spectral density Test Mode Test Channel PSD[dBm/3kHz] Limit[dBm/3kHz] Verdict 1MHz 2MHz BLE 2402 -6.02 -7.17 8.00 PASS BLE 2440 -5.83 -7.39 8.00 PASS BLE 2480 -7.25 -10.73 8.00 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 15 Maximum Peak power spectral density_BLE_2402_1MHz Maximum Peak power spectral density_BLE_2440_1MHz Maximum Peak power spectral density_BLE_2480_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 16 Maximum Peak power spectral density_BLE_2402_2MHz Maximum Peak power spectral density_BLE_2440_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 17 Maximum Peak power spectral density_BLE_2480_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 18 5.Band-edge for RF Conducted Emissions Test Mode Test Channel Carrier Power[dBm] Max. Spurious Level [dBm] Limit [dBm] Verdict BLE(1MHz） 2402 9.55 -49.10 -10.45 PASS BLE(1MHz） 2480 8.08 -49.21 -11.93 PASS BLE(2MHz） 2402 9.50 -23.18 -10.50 PASS BLE(2MHz） 2480 7.29 -52.97 -12.71 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 19 Band-edge for RF Conducted Emissions_BLE_2402_Hopping Off_1MHz Band-edge for RF Conducted Emissions_BLE_2480_Hopping Off_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 20 Band-edge for RF Conducted Emissions_BLE_2402_Hopping Off_2MHz Band-edge for RF Conducted Emissions_BLE_2480_Hopping Off_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 21 6.RF Conducted Spurious Emissions Test Mode Test Channel StartFre [MHz] StopFre [MHz] RBW [kHz] VBW [kHz] Pref[dBm] Max. Level [dBm] Limit [dBm] Verdict BLE(1MHz) 2402 30 10000 100 300 9.38 -53.17 <-10.62 PASS BLE(1MHz) 2402 10000 26000 100 300 9.378 -43.698 <-10.622 PASS BLE(1MHz) 2440 30 10000 100 300 9.63 -54.18 <-10.37 PASS BLE(1MHz) 2440 10000 26000 100 300 9.629 -44.121 <-10.371 PASS BLE(1MHz) 2480 30 10000 100 300 8.31 -53.90 <-11.69 PASS BLE(1MHz) 2480 10000 26000 100 300 8.308 -44.456 <-11.692 PASS BLE(2MHz) 2402 30 10000 100 300 9.37 -54.12 <-10.63 PASS BLE(2MHz) 2402 10000 26000 100 300 9.368 -44.344 <-10.632 PASS BLE(2MHz) 2440 30 10000 100 300 9.86 -53.99 <-10.14 PASS BLE(2MHz) 2440 10000 26000 100 300 9.861 -43.740 <-10.139 PASS BLE(2MHz) 2480 30 10000 100 300 7.33 -53.73 <-12.67 PASS BLE(2MHz) 2480 10000 26000 100 300 7.331 -44.020 <-12.669 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 22 RF Conducted Spurious Emissions_BLE_2402_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 23 RF Conducted Spurious Emissions_BLE_2440_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 24 RF Conducted Spurious Emissions_BLE_2480_1MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 25 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 26 RF Conducted Spurious Emissions_BLE_2402_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 27 RF Conducted Spurious Emissions_BLE_2440_2MHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM210400299801 28 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 1 1.6dB Bandwidth Test Mode Test Channel Ant EBW[MHz] Limit Verdict 11B 2412 Ant1 10.04 0.5 PASS 11B 2437 Ant1 10.02 0.5 PASS 11B 2462 Ant1 10.03 0.5 PASS 11G 2412 Ant1 16.49 0.5 PASS 11G 2437 Ant1 16.50 0.5 PASS 11G 2462 Ant1 16.46 0.5 PASS 11N20SISO 2412 Ant1 17.63 0.5 PASS 11N20SISO 2437 Ant1 17.65 0.5 PASS 11N20SISO 2462 Ant1 17.63 0.5 PASS 11N40SISO 2422 Ant1 36.33 0.5 PASS 11N40SISO 2437 Ant1 36.33 0.5 PASS 11N40SISO 2452 Ant1 36.33 0.5 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 2 6dB Bandwidth_11B_2412_Ant1 6dB Bandwidth_11B_2437_Ant1 6dB Bandwidth_11B_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 3 6dB Bandwidth_11G_2412_Ant1 6dB Bandwidth_11G_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 4 6dB Bandwidth_11G_2462_Ant1 6dB Bandwidth_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 5 6dB Bandwidth_11N20SISO_2437_Ant1 6dB Bandwidth_11N20SISO_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 6 6dB Bandwidth_11N40SISO_2422_Ant1 6dB Bandwidth_11N40SISO_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 7 6dB Bandwidth_11N40SISO_2452_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 8 2.Occupied Bandwidth Test Mode Test Channel Ant OBW[MHz] Limit[MHz] Verdict 11B 2412 Ant1 14.70 --- PASS 11B 2437 Ant1 14.71 --- PASS 11B 2462 Ant1 14.68 --- PASS 11G 2412 Ant1 16.67 --- PASS 11G 2437 Ant1 16.67 --- PASS 11G 2462 Ant1 16.65 --- PASS 11N20SISO 2412 Ant1 17.72 --- PASS 11N20SISO 2437 Ant1 17.75 --- PASS 11N20SISO 2462 Ant1 17.73 --- PASS 11N40SISO 2422 Ant1 35.85 --- PASS 11N40SISO 2437 Ant1 35.83 --- PASS 11N40SISO 2452 Ant1 35.81 --- PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 9 Occupied Bandwidth_11B_2412 Occupied Bandwidth_11B_2437 Occupied Bandwidth_11B_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 10 Occupied Bandwidth_11G_2412 Occupied Bandwidth_11G_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 11 Occupied Bandwidth_11G_2462 Occupied Bandwidth_11N20SISO_2412 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 12 Occupied Bandwidth_11N20SISO_2437 Occupied Bandwidth_11N20SISO_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 13 Occupied Bandwidth_11N40SISO_2422 Occupied Bandwidth_11N40SISO_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 14 Occupied Bandwidth_11N40SISO_2452 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 15 3.Maximum conducted (average) output power Test Mode Test Channel Ant Level [dBm] 10log(1/x) Factor[dB] Power [dBm] Limit [dBm] Verdict 11B 2412 Ant1 16.12 0.00 16.12 30 PASS 11B 2437 Ant1 16.71 0.00 16.71 30 PASS 11B 2462 Ant1 16.86 0.00 16.86 30 PASS 11G 2412 Ant1 12.53 0.00 12.53 30 PASS 11G 2437 Ant1 12.94 0.00 12.94 30 PASS 11G 2462 Ant1 13.04 0.00 13.04 30 PASS 11N20SISO 2412 Ant1 12.58 0.00 12.58 30 PASS 11N20SISO 2437 Ant1 12.74 0.00 12.74 30 PASS 11N20SISO 2462 Ant1 13.21 0.00 13.21 30 PASS 11N40SISO 2422 Ant1 12.81 0.00 12.81 30 PASS 11N40SISO 2437 Ant1 12.98 0.00 12.98 30 PASS 11N40SISO 2452 Ant1 12.95 0.00 12.95 30 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 16 Maximum conducted (average) output power_11B_2412_Ant1 Maximum conducted (average) output power_11B_2437_Ant1 Maximum conducted (average) output power_11B_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 17 Maximum conducted (average) output power_11G_2412_Ant1 Maximum conducted (average) output power_11G_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 18 Maximum conducted (average) output power_11G_2462_Ant1 Maximum conducted (average) output power_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 19 Maximum conducted (average) output power_11N20SISO_2437_Ant1 Maximum conducted (average) output power_11N20SISO_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 20 Maximum conducted (average) output power_11N40SISO_2422_Ant1 Maximum conducted (average) output power_11N40SISO_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 21 Maximum conducted (average) output power_11N40SISO_2452_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 22 4.Maximum(average) power spectral density Test Mode Test Channel Ant Level [dBm/3kHz] 10log(1/x) Factor[dB] PSD[dBm/3kHz] Limit[dBm/3kHz] Verdict 11B 2412 Ant1 -16.52 0.00 -16.52 8.00 PASS 11B 2437 Ant1 -15.92 0.00 -15.92 8.00 PASS 11B 2462 Ant1 -15.74 0.00 -15.74 8.00 PASS 11G 2412 Ant1 -21.98 0.00 -21.98 8.00 PASS 11G 2437 Ant1 -21.64 0.00 -21.64 8.00 PASS 11G 2462 Ant1 -21.31 0.00 -21.31 8.00 PASS 11N20SISO 2412 Ant1 -22.20 0.00 -22.20 8.00 PASS 11N20SISO 2437 Ant1 -21.62 0.00 -21.62 8.00 PASS 11N20SISO 2462 Ant1 -21.20 0.00 -21.20 8.00 PASS 11N40SISO 2422 Ant1 -25.09 0.00 -25.09 8.00 PASS 11N40SISO 2437 Ant1 -24.99 0.00 -24.99 8.00 PASS 11N40SISO 2452 Ant1 -24.97 0.00 -24.97 8.00 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 23 Maximum(average) power spectral density_11B_2412_Ant1 Maximum(average) power spectral density_11B_2437_Ant1 Maximum(average) power spectral density_11B_2462_An…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 31 Band-edge for RF Conducted Emissions_11G_2462_Ant1 Band-edge for RF Conducted Emissions_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 32 Band-edge for RF Conducted Emissions_11N20SISO_2462_Ant1 Band-edge for RF Conducted Emissions_11N40SISO_2422_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 33 Band-edge for RF Conducted Emissions_11N40SISO_2452_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 34 6.RF Conducted Spurious Emissions Test Mode Test Channel Ant StartFre [MHz] StopFre [MHz] RBW [kHz] VBW [kHz] Pref[dBm] Max. Level [dBm] Limit [dBm] Verdict 11B 2412 Ant1 30 10000 100 300 6.32 -50.47 <-23.68 PASS 11B 2412 Ant1 10000 26000 100 300 6.316 -43.963 <-23.684 PASS 11B 2437 Ant1 30 10000 100 300 7.00 -50.21 <-23.00 PASS 11B 2437 Ant1 10000 26000 100 300 7.004 -43.782 <-22.996 PASS 11B 2462 Ant1 30 10000 100 300 7.19 -51.51 <-22.81 PASS 11B 2462 Ant1 10000 26000 100 300 7.191 -43.781 <-22.809 PASS 11G 2412 Ant1 30 10000 100 300 -1.69 -54.19 <-31.69 PASS 11G 2412 Ant1 10000 26000 100 300 -1.693 -44.015 <-31.693 PASS 11G 2437 Ant1 30 10000 100 300 -1.10 -52.96 <-31.10 PASS 11G 2437 Ant1 10000 26000 100 300 -1.104 -43.618 <-31.104 PASS 11G 2462 Ant1 30 10000 100 300 -1.01 -53.78 <-31.01 PASS 11G 2462 Ant1 10000 26000 100 300 -1.014 -44.133 <-31.014 PASS 11N20SISO 2412 Ant1 30 10000 100 300 -1.26 -53.97 <-31.26 PASS 11N20SISO 2412 Ant1 10000 26000 100 300 -1.258 -42.629 <-31.258 PASS 11N20SISO 2437 Ant1 30 10000 100 300 -0.99 -53.25 <-30.99 PASS 11N20SISO 2437 Ant1 10000 26000 100 300 -0.986 -43.954 <-30.986 PASS 11N20SISO 2462 Ant1 30 10000 100 300 -0.43 -53.96 <-30.43 PASS 11N20SISO 2462 Ant1 10000 26000 100 300 -0.429 -43.184 <-30.429 PASS 11N40SISO 2422 Ant1 30 10000 100 300 -4.17 -53.77 <-34.17 PASS 11N40SISO 2422 Ant1 10000 26000 100 300 -4.173 -43.919 <-34.173 PASS 11N40SISO 2437 Ant1 30 10000 100 300 -4.07 -53.57 <-34.07 PASS 11N40SISO 2437 Ant1 10000 26000 100 300 -4.073 -43.993 <-34.073 PASS 11N40SISO 2452 Ant1 30 10000 100 300 -3.94 -53.40 <-33.94 PASS 11N40SISO 2452 Ant1 10000 26000 100 300 -3.943 -43.976 <-33.943 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 35 RF Conducted Spurious Emissions_11B_2412 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 36 RF Conducted Spurious Emissions_11B_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 37 RF Conducted Spurious Emissions_11B_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 38 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 39 RF Conducted Spurious Emissions_11G_2412 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 40 RF Conducted Spurious Emissions_11G_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 41 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 42 RF Conducted Spurious Emissions_11G_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 43 RF Conducted Spurious Emissions_11N20SISO_2412 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 44 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 45 RF Conducted Spurious Emissions_11N20SISO_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 46 RF Conducted Spurious Emissions_11N20SISO_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 47 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 48 RF Conducted Spurious Emissions_11N40SISO_2422 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 49 RF Conducted Spurious Emissions_11N40SISO_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 50 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 51 RF Conducted Spurious Emissions_11N40SISO_2452 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 52 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210400299802 53 7.Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] 10lo…
