2AYJFI18Watch Phone

2. Device Layout Watch Face: Watch Back: 1. Package and Product Parameters Package Contents: Product Parameters: Product: Watch Phone Model: W1818AO Battery: Lithium Polymer Battery 3.85V 680mAh Camera: Front Camera 5MP, Rear Camera 8MP Charge Input: DC 5V 1200mA Working Temperature: 0~35 Working Humidity: Noncondensable 15%~93% Front Camera Speaker Touch Screen On/Off Mic Lock Button SIM Card Deck Rear Camera Charging Contactor Base 3. Choose and Install the SIM Step 1: Choose the Right SIM Card The Size of SIM Card: supports Standard Nano-SIM card only [as picture (1)]. Step 3: Install the SIM Card 1. Open up the SIM card deck with a SIM card picker. 2. Put the Nano-SIM card on the card deck with the gold chip facing upward. 3. Insert the SIM card deck into the watch’s back. 5. Download the App & Bind the Watch Step 1: Download/Install the App 1. Scan the QR code on the right. 2. Go to Google Play or Apple App Store and search for “imoo” or “Watch Phone” to download the App. Step 2: Bind the Watch 1. Open the App, register or log in. 2. Slide the watch interface to find Bind Code and scan the QR code or enter the bind code manually to bind the watch. Get the Bind Code: 4. Power On 1. If the new watch cannot be turned on, it is probably out of power. Please plug in the charging cable until the watch is turned on automatically. 2. For general abnormal conditions (e.g., blank screen), press On/Off button for 10 seconds to restart the watch phone. Power On: Press On/Off button for 2 seconds to power on the watch phone. 1. Tap Bind Code on More interface to get the bind code. 2. Scan the QR code or enter the Bind Code manually. Bind Code 6. Charge 1. As shown below, please flip up the watch through the lock button to find the charging contactors of the watch. 8. Basic Operation Turn on the screen: Tap the screen or press On/Off button to turn it on. Turn off the screen: 1. Press On/Off button to turn off the screen when the home screen is on; 2. Cover the screen with your hand to turn it off; 3. You can set the “Screen Timeout” in “Display & Brightness” of the “Watch Settings” on More interface. When the time is up, the screen will be turned off. Wallpaper: Long press the home screen to enter Wallpaper. Slide left or right to view more and select one as your wallpaper. Slide left from the home screen to enter More interface, slide up or down to choose corresponding features. Bind Code Chat Add FriendsSteps Warranty Card (The First Invoice: User Invoice) User’s Data Warranty Data Product Data User’s Name: _______________ Telephone: ____________ Kid’s Grade: ___________ Name of Sales or Service Center: _________________________ Cause of Machine Repair: _____________________ Handled by: ________________ Telephone: ____________ Handled on: _______________________ (DD/MM/YYYY) Product Model: ________________________ Machine No.: __________________________ Date of Purchase: ______________________ ( DD/MM/YYYY) Site of Sales: ____________ (Store) ______________________ _________________________________ (Address) Warranty Card (The Second Invoice: Sales Invoice) User’s Data Warranty Data Product Data User’s Name: _______________ Telephone: ____________ Kid’s Grade: ___________ Name of Sales or Service Center: _________________________ Cause of Machine Repair: _____________________ Handled by: ________________ Telephone: ____________ Handled on: _______________________ (DD/MM/YYYY) Product Model: ________________________ Machine No.: __________________________ Date of Purchase: ______________________ ( DD/MM/YYYY ) Site of Sales: ____________ (Store) ______________________ _________________________________ (Address) Material Code: 5211764 Version: V1.0 Charging (90%) 2. Then align the charging contactors on the watch with the charging contactors on the charging cable until “Charging” is shown on the screen. 1 Watch Phone Z6 11 1Manual Charging Cable SIM Card Picker 1 2 3 Please activate “Caller ID” function and enable GPRS data network. Step 2: Activate “Caller ID” function & data plan 45 6 7. OTA Upgrade When binding a watch, the App will detect the watch's version to check if it needs to be upgraded. If needed, the watch will be upgraded automatically when charging. System Updating... Remark: There may be risks for informal root or system upgrade. 7 8 FCC SAR statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). T hese requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body CMHK Slide right from the home screen to enter “Call”. Slide from top to bottom to check the status bar and some important push notifications. Family Chat Add Friends Chat Slide right from Chat interface. After entering each feature, you can slide right to exit the feature, as shown on the left. You can also press the On/Off button to go back to the home screen. 9. Basic Features Select a contact to make a voice call or video call. Video calls may consume a lot of network data. We suggest you make video calls when connected to a WLAN network. If the App cannot receive the video call, please check whether Notifications has been enabled or whether the call was intercepted by the system. Call Mum Sister Family Chat Add Friends Chat Chat Send voice messages: Tap “Hold to Talk” to record, and release your finger to send your voice message. Play voice messages: Unread voice messages will be shown on the screen. Tap to play voice messages. Add friends: Tap “Face-to-face Making Friends” on Add Friends …

Text truncated - open the document above for the full version.

GUANGDONG GENIUS TECHNOLOGY CO., LTD. Date: 4/20/2021 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AYJFI18 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Keny Xu in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with GUANGDONG GENIUS TECHNOLOGY CO., LTD. This authorization is valid until further written notice from the applicant. Print Name: Senhua Huang Title: Manager Signature: On behalf of Company: GUANGDONG GENIUS TECHNOLOGY CO., LTD. Telephone: 0769-85540888 E-mail: [email protected]

GUANGDONG GENIUS TECHNOLOGY CO., LTD. TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2AYJFI18 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Part List Tune up procedure The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within 0 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. Delete any document that is NOT included in your application External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Senhua Huang Title: Manager Signature: On behalf of Company: GUANGDONG GENIUS TECHNOLOGY CO., LTD. Telephone: 0769-85540888 E-mail: [email protected]

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name GUANGDONG GENIUS TECHNOLOGY CO., LTD. Address No.168, Middle Road Of East Gate Xiaobian Community,Chang'an Town，Dongguan City, Guangdong，China Grantee Code 2AYJF FCC ID 2AYJFI18 Authorized Contact Name Senhua Huang Contact Email [email protected] Contact Phone 0769-85540888 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 4/20/2021 Print Name: Senhua Huang Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 Appendix Photographs of EUT Constructional Details for SZCR2104020587AT FCC ID: 2AYJFI18 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 Appendix Photographs of EUT Constructional Details for SZCR2104020587AT FCC ID: 2AYJFI18 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 EUT Constructional Details (EUT Photos) BT/WIFI/GPS antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 GSM/WCDMA/LTE antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210500067001 Page: 1 of 100 SAR TEST REPORT Application No.: KSEM2105000670CR Applicant: GUANGDONG GENIUS TECHNOLOGY CO., LTD. Address of Applicant: No.168, Middle Road Of East Gate, Xiaobian Community,Chang'an Town,Dongguan City,Guangdong ,China Manufacturer: GUANGDONG GENIUS TECHNOLOGY CO., LTD. Address of Manufacturer: No.168, Middle Road Of East Gate, Xiaobian Community,Chang'an Town,Dongguan City,Guangdong ,China Factory: GUANGDONG GENIUS TECHNOLOGY CO., LTD. Address of Factory: No.168, Middle Road Of East Gate, Xiaobian Community,Chang'an Town,Dongguan City,Guangdong ,China Product Name: Watch Phone Model No.(EUT): W1818AO Trade mark: imoo FCC ID: 2AYJFI18 Standard(s) : FCC 47CFR §2.1093 Date of Receipt: 2021-05-06 Date of Test: 2021-05-31 to 2021-06-08 Date of Issue: 2021-06-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Eric Lin Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210500067001 Page: 2 of 100 REVISION HISTORY Revision Record Version Description Date Remark 00 Original 2021-06-15 / Authorized for issue by: Richard.Kong/ Project Engineer Eric.Lin/Reviewer Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210500067001 Page: 3 of 100 TEST SUMMARY Frequency Band Maximum Reported SAR(W/kg) Next to the mouth 1g SAR Extremity 10g SAR WCDMA Band II 0.714 1.473 WCDMA Band V 0.156 0.452 CDMA BC0 0.231 0.464 LTE Band 2 0.883 1.901 LTE Band 5 0.184 0.578 LTE Band 38 0.251 0.870 LTE Band 40a 0.193 0.812 LTE Band 40b 0.314 0.851 LTE Band 41 0.232 0.897 WI-FI (2.4GHz) 0.107 0.156 SAR Limited(W/kg) 1.6 4.0 Maximum Simultaneous Transmission SAR (W/kg) Scenario Next to the mouth 1g SAR Extremity 10g SAR Sum SAR 0.990 2.057 SPLSR NA NA SPLSR Limited 0.04 0.1 Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210500067001 Page: 4 of 100 CONTENTS 1 GENERAL INFORMATION .............................................................................................................................. 6 1.1 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 1.1.1 DUT Antenna Locations(Unit:mm) ....................................................................................................... 7 1.2 TEST SPECIFICATION ................................................................................................................................... 8 1.3 RF EXPOSURE LIMITS .................................................................................................................................. 9 1.4 TEST LOCATION ........................................................................................................................................ 10 1.5 TEST FACILITY .......................................................................................................................................... 10 2 LABORATORY ENVIRONMENT ................................................................................................................... 11 3 SAR MEASUREMENTS SYSTEM CONFIGURATION .................................................................................. 12 3.1 THE SAR MEASUREMENT SYSTEM ............................................................................................................ 12 3.2 ISOTROPIC E-FIELD PROBE EX3DV4 ......................................................................................................... 13 3.3 DATA ACQUISITION ELECTRONICS (DAE) ................................................................................................... 15 3.4 SAM TWIN PHANTOM ................................................................................................................................ 15 3.5 ELI PHANTOM ........................................................................................................................................... 16 3.6 DEVICE HOLDER FOR TRANSMITTERS ......................................................................................................... 17 3.7 MEASUREMENT PROCEDURE ...................................................................................................................... 18 3.7.1 Scanning procedure ........................................................................................................................... 18 3.7.2 Data Storage ...................................................................................................................................... 20 3.7.3 Data Evaluation by SEMCAD ............................................................................................................. 20 4 SAR MEASUREMENT VARIABILITY AND UNCERTAINTY ........................................................................ 22 4.1 SAR MEASUREMENT VARIABILITY ............................................................................................................... 22 4.2 SAR MEASUREMENT UNCERTAINTY ............................................................................................................ 23 5 DESCRIPTION OF TEST POSITION ............................................................................................................. 24 5.1 NEXT TO THE MOUTH EXPOSURE CONDITION ............................…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Report No.: KSEM210500067001 Appendix C Calibration certificate 1. Dipole D835V2 - SN 4d114(2019/06/11) D1900V2 - SN 5d136(2019/06/11) D2300V2 - SN1096(2019/03/08) D2450V2 - SN 817(2019/06/10) D2600V2 - SN 1158(2019/03/08) 2. DAE DAE4-SN 913(2021/04/21) 3. Probe EX3DV4-SN 3753(2020/06/25)

Dipole D835V2 SN 4d114 Head Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/11 -27.9 / 50.6 / 2020/6/10 -28.3 -1.43% 51.7 Body Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/11 -24.5 / 47.1 / 2020/6/10 -25.2 -2.86% 48.5 Dipole D1900V2 SN 5d136 Head Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/11 -24.3 / 50.5 / 2020/6/10 -25.0 -2.88% 51.9 Body Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/11 -22.7 / 47.1 / 2020/6/10 -23.1 -1.76% 48.2 Dipole D2300V2 SN 1096 Head Liquid Date of Measurement Return Loss(dB) % Impedance 2019/3/8 -25.6 / 49.4 / 2020/3/7 -26.3 -2.73% 50.2 Body Liquid Date of Measurement Return Loss(dB) % Impedance 2019/3/8 -23.6 / 45.2 / 2020/3/7 -24.3 -2.97% 46.7 Dipole D2450V2 SN 817 Head Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/10 -28.5 / 52.3 / 2020/6/9 -29.3 2.81% 54.3 Body Liquid Date of Measurement Return Loss(dB) % Impedance 2019/6/10 -26.6 / 48.7 / 2020/6/9 -27.5 3.38% 49.6 Dipole D2600V2 SN 1158 Head Liquid Date of Measurement Return Loss(dB) % Impedance 2019/3/8 -22.8 / 49.5 / 2020/3/7 -23.2 1.75% 50.6 Body Liquid Date of Measurement Return Loss(dB) % Impedance 2019/3/8 -23 / 46.2 / 2020/3/7 -23.7 3.04% 47.5

1. 99% & 26dB Bandwidth 1.1 Test Result Test Band: 2 _ 1.4MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 6 0 1.127 1.116 1.118 N/A PASS 16QAM 6 0 1.115 1.108 1.116 N/A PASS 1.2 Test Graph Test Band: 2 _ 1.4MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 6 0 1.318 1.332 1.324 N/A PASS 16QAM 6 0 1.343 1.328 1.307 N/A PASS 1.2 Test Graph Test Band: 2 _ 3MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 15 0 2.744 2.754 2.741 N/A PASS 16QAM 15 0 2.731 2.745 2.752 N/A PASS 1.2 Test Graph Test Band: 2 _ 3MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 15 0 3.047 3.049 3.060 N/A PASS 16QAM 15 0 3.057 3.049 3.036 N/A PASS 1.2 Test Graph Test Band: 2 _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.554 4.552 4.576 N/A PASS 16QAM 25 0 4.574 4.574 4.558 N/A PASS 1.2 Test Graph Test Band: 2 _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 5.081 5.061 5.116 N/A PASS 16QAM 25 0 5.120 5.103 5.073 N/A PASS 1.2 Test Graph Test Band: 2 _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 9.034 9.026 9.077 N/A PASS 16QAM 50 0 9.023 9.027 9.043 N/A PASS 1.2 Test Graph Test Band: 2 _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 10.009 10.021 10.068 N/A PASS 16QAM 50 0 9.950 9.952 10.028 N/A PASS 1.2 Test Graph Test Band: 2 _ 15MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 13.537 13.517 13.581 N/A PASS 16QAM 75 0 13.576 13.546 13.536 N/A PASS 1.2 Test Graph Test Band: 2 _ 15MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 14.907 14.971 14.924 N/A PASS 16QAM 75 0 14.909 14.820 15.001 N/A PASS 1.2 Test Graph Test Band: 2 _ 20MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 100 0 18.048 18.083 18.008 N/A PASS 16QAM 100 0 18.031 18.056 18.041 N/A PASS 1.2 Test Graph Test Band: 2 _ 20MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 100 0 19.818 19.804 19.656 N/A PASS 16QAM 100 0 19.749 19.785 19.777 N/A PASS 1.2 Test Graph

2. 99% & 26dB Bandwidth 2.1 Test Result Test Band: 5 _ 1.4MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 6 0 1.122 1.117 1.112 N/A PASS 16QAM 6 0 1.109 1.106 1.122 N/A PASS 2.2 Test Graph Test Band: 5 _ 1.4MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 6 0 1.348 1.357 1.349 N/A PASS 16QAM 6 0 1.330 1.307 1.336 N/A PASS 2.2 Test Graph Test Band: 5 _ 3MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 15 0 2.745 2.745 2.737 N/A PASS 16QAM 15 0 2.733 2.736 2.744 N/A PASS 2.2 Test Graph Test Band: 5 _ 3MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 15 0 3.062 3.091 3.072 N/A PASS 16QAM 15 0 3.060 3.054 3.075 N/A PASS 2.2 Test Graph Test Band: 5 _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.542 4.537 4.563 N/A PASS 16QAM 25 0 4.554 4.573 4.564 N/A PASS 2.2 Test Graph Test Band: 5 _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 5.066 5.091 5.057 N/A PASS 16QAM 25 0 5.108 5.083 5.097 N/A PASS 2.2 Test Graph Test Band: 5 _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 9.047 9.036 9.050 N/A PASS 16QAM 50 0 9.030 9.019 9.022 N/A PASS 2.2 Test Graph Test Band: 5 _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 10.001 10.011 10.033 N/A PASS 16QAM 50 0 10.034 9.904 10.019 N/A PASS 2.2 Test Graph 3. 99% & 26dB Bandwidth 3.1 Test Result Test Band: 38 _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.553 4.553 4.555 N/A PASS 16QAM 25 0 4.548 4.560 4.565 N/A PASS 3.2 Test Graph Test Band: 38 _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 5.057 5.387 5.110 N/A PASS 16QAM 25 0 5.298 5.095 5.871 N/A PASS 3.2 Test Graph Test Band: 38 _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 9.087 9.114 9.138 N/A PASS 16QAM 50 0 9.018 9.072 9.105 N/A PASS 3.2 Test Graph

Test Band: 38 _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 12.152 10.734 11.362 N/A PASS 16QAM 50 0 9.956 12.222 13.388 N/A PASS 3.2 Test Graph Test Band: 38 _ 15MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 13.561 13.582 13.642 N/A PASS 16QAM 75 0 13.630 13.634 13.643 N/A PASS 3.2 Test Graph Test Band: 38 _ 15MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 15.007 17.278 18.573 N/A PASS 16QAM 75 0 16.048 16.809 17.614 N/A PASS 3.2 Test Graph Test Band: 38 _ 20MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 100 0 18.072 18.118 18.100 N/A PASS 16QAM 100 0 18.080 18.083 18.056 N/A PASS 3.2 Test Graph Test Band: 38 _ 20MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 100 0 22.809 20.840 20.078 N/A PASS 16QAM 100 0 23.614 20.732 20.629 N/A PASS 3.2 Test Graph 4. 99% & 26dB Bandwidth 4.1 Test Result Test Band: 40a _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.566 4.557 4.559 N/A PASS 16QAM 25 0 4.549 4.550 4.565 N/A PASS 4.2 Test Graph Test Band: 40a _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 5.248 5.211 5.090 N/A PASS 16QAM 25 0 5.123 5.098 5.081 N/A PASS 4.2 Test Graph Test Band: 40a _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 / 9.095 / N/A PASS 16QAM 50 0 / 9.069 / N/A PASS 4.2 Test Graph Test Band: 40a _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 / 11.489 / N/A PASS 16QAM 50 0 / 10.003 / N/A PASS 4.2 Test Graph 5. 99% & 26dB Bandwidth 5.1 Test Result Test Band: 40b _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.565 4.553 4.565 N/A PASS 16QAM 25 0 4.549 4.551 4.573 N/A PASS 5.2 Test Graph Test Band: 40b _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH

QPSK 25 0 5.107 5.159 5.111 N/A PASS 16QAM 25 0 5.088 5.115 5.156 N/A PASS 5.2 Test Graph Test Band: 40b _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 / 9.091 / N/A PASS 16QAM 50 0 / 9.081 / N/A PASS 5.2 Test Graph Test Band: 40b _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 / 10.214 / N/A PASS 16QAM 50 0 / 10.087 / N/A PASS 5.2 Test Graph 6. 99% & 26dB Bandwidth 6.1 Test Result Test Band: 41 _ 5MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 4.547 4.549 4.554 N/A PASS 16QAM 25 0 4.550 4.560 4.546 N/A PASS 6.2 Test Graph Test Band: 41 _ 5MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 25 0 5.068 5.485 5.087 N/A PASS 16QAM 25 0 5.382 5.089 5.066 N/A PASS 6.2 Test Graph Test Band: 41 _ 10MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 9.088 9.115 9.061 N/A PASS 16QAM 50 0 9.025 9.067 9.052 N/A PASS 6.2 Test Graph Test Band: 41 _ 10MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 50 0 10.685 11.325 10.063 N/A PASS 16QAM 50 0 10.171 10.114 10.006 N/A PASS 6.2 Test Graph Test Band: 41 _ 15MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 13.566 13.572 13.564 N/A PASS 16QAM 75 0 13.628 13.621 13.558 N/A PASS 6.2 Test Graph Test Band: 41 _ 15MHz Bandwidth Test Mode RB Allocation 26dB Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 75 0 15.002 16.485 15.108 N/A PASS 16QAM 75 0 15.670 16.629 15.103 N/A PASS 6.2 Test Graph Test Band: 41 _ 20MHz Bandwidth Test Mode RB Allocation 99% Occupied Bandwidth (MHz) Limit Verdict Size Offset LCH MCH HCH QPSK 100 0 18.067 18.124 18.069 N/A PASS 16QAM 100 0 18.113 18.039 18.037 N/A PASS 6.2 Test Graph Test Band: 41 _ 20MHz B…
