2AYJK-BLITZ2Wireless Game Controller

FCC Caution. (1)§ 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Changes or modification warning Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:SUNBEYONDCONSULTINGLTD FRN:0033588823 ContactName:MrsYaniesLee Address:90CANALSTREET,4THFLOOROFFICENO.448,BOSTON,MA2114,UnitedStates Telephone:(309)822-2400 Email:[email protected] Applicant: Companyname:ShenzhenWarsongTechnologyCo.,Ltd. ProductDescription:WirelessGameController Granteecode:2AYJK FCCID:2AYJK-BLITZ2 FRN:0030331144 ContactName:JIANGKEFENG Address:Room1401,Building4,ChongwenGarden,No.1TanglingRoad,Fuguang Community,TaoyuanStreet,NanshanDistrict,Shenzhen,China Phone:18676397925 Fax:18676397925 Email:[email protected] [ShenzhenWarsongTechnologyCo.,Ltd.]certifiesthat,asofthedateofthis filingoftheapplicationwiththeTCB,[SUNBEYONDCONSULTINGLTD]isour designatedUSagentforserviceofprocessfortheabovereferencedFCCID. [ShenzhenWarsongTechnologyCo.,Ltd.]acceptstomaintainanagentforno lessthanoneyearafterthegranteehasterminatedallmarketingand importationortheconclusionofanycommissionrelatedproceedinginvolving equipment.[SUNBEYONDCONSULTINGLTD]accepts,asofthedateofthe filingoftheapplication,theobligationofthedesignatedUSagentforserviceof processfortheabovereferenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:August12,2024 Applicant’sName:JIANGKEFENGUSAgent’sName:MrsYaniesLee Title:managerTitle:President:ComplianceManager SignatureSignature

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-12 Signature Date Name / Title: Kefeng Jiang / Manager Company: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 Fax: +86-18676397925 E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AYJK-BLITZ2 BLITZ 2, BLITZ 2 PRO We, applicant Company Name: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-12 Signature Date Name / Title: Kefeng Jiang / Manager Company: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 Fax: +86-18676397925 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AYJK-BLITZ2 BLITZ 2, BLITZ 2 PRO For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-12 Signature Date Name / Title: Kefeng Jiang / Manager Company: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 Fax: +86-18676397925 E-Mail: [email protected]

Shenzhen Warsong Technology Co., Ltd. Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Date: August 12, 2024 FCC ID: 2AYJK-BLITZ2 Model Number: BLITZ 2, BLITZ 2 PRO To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Shenzhen Warsong Technology Co., Ltd. hereby declare that our product (Wireless Game Controller) Model Number: BLITZ 2, BLITZ 2 PRO board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Kefeng Jiang / Manager Company: Shenzhen Warsong Technology Co., Ltd. Address: Room 1401, Building 4, Chongwen Garden, No. 1 Tangling Road, Fuguang Community, Taoyuan Street, Nanshan District, Shenzhen, China Phone: +86-18676397925 Fax: +86-18676397925 E-Mail: [email protected]

FCCID:2AYJK-BLITZ2

FCCIDLABELINGANDLOCATION FCCIDLabel FCCIDLabelLocation Thelabelshownshallbepermanentlyaffixedataconspicuouslocationonthedeviceandbe readilyvisibletotheuseratthetimepurchase(Labelingrequirementsper2.925) WirelessGameController FCCID:2AYJK-BLITZ2

FCCID:2AYJK-BLITZ2 BT Antenna BTChip SLE C hi p SLE An t e nn a

FCC ID: 2AYJK-BLITZ2 RF EXPOSURE EVALUATION METHOD According to KDB 447498 D01 General RF Exposure Guidance v06, Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) EUT Specification EUT Wireless Game Controller Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.150GHz ~ 5.250GHz WLAN: 5.725GHz ~ 5.850GHz Others BT:2402-2480MHz SLE: 2402-2480MHz 2404-2478MHz 2405-2477MHz Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power BT LE: -8.124 dBm SLE: -1.239dBm Antenna gain (Max) 1.8dBi Evaluation applied MPE Evaluation SAR Evaluation FCC ID: 2AYJK-BLITZ2 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2AYJK-BLITZ2 Standalone Evaluation SLE+BLE Operating Mode Frequency Measured Power max. power Antenna Gain min. test separation distance [√f(GHz)] Result Limit (MHz) (dBm) (mW) (dBi) (mm) SLE - GFSK 2402 -2.131 0.61 1.8 5 1.550 0.2872 3 2441 -1.273 0.75 1.8 5 1.562 0.3528 3 2480 -1.239 0.75 1.8 5 1.575 0.3584 3 SLE - QPSK 2404 -3.797 0.42 1.8 5 1.550 0.1294 3 2442 -2.968 0.50 1.8 5 1.563 0.1578 3 2478 -2.909 0.51 1.8 5 1.574 0.1611 3 SLE - 8PSK 2405 -4.607 0.35 1.8 5 1.551 0.1074 3 2441 -3.569 0.44 1.8 5 1.562 0.1374 3 2477 -3.472 0.45 1.8 5 1.574 0.1415 3 BT - GFSK 2402 -9.562 0.11 1.8 5 1.550 0.0519 3 2440 -8.896 0.13 1.8 5 1.562 0.0610 3 2480 -8.124 0.15 1.8 5 1.575 0.0734 3 Remark: The worst-case gain of the antenna is 1.8dBi. 1.8dBi logarithmic terms convert to numeric result is nearly 1.51 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Simultaneous Transmission SAR Evaluation The [Σ of (the highest estimated SAR BT LE + estimated SAR SLE ) /1.60] = (0.0474 + 0.237 ) = 0.18 < 1.0 Conclusion: No SAR is required.
