FCC ID : 2AYK3-AURAMATE RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 1.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in 20cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 1.2 Measurement Result Mode Max Measured power (dBm) Max tune-up power (dBm) Antenna gain Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2.4G WIF 14.43 15 1.49 1.41 0.0112 1 5G WIFI 16.21 18 1.37 1.37 0.0172 1 ----------------THE END OF REPORT---------------

5 5HSRUW1R(6:3DJHRI9HU TEST REPORT Product Name ˖ Smart scanner Model Number ˖ AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLU S, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 FCC ID ˖2AYK3-AURAMATE Prepared for : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES201028031W02 Date(s) of Tests : Nov. 2, 2020 to Dec. 16, 2020 Date of issue : Dec. 17, 2020 $Ҽ㔤⸱$ 5 5HSRUW1R(6:3DJHRI9HU 1 TEST RESULT CERTIFICATION Applicant : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China Manufacturer : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China EUT : Smart scanner Model Name : AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLUS, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 Trademark : CZUR Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart E PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.407 The test results of this report relate only to the tested sample identified in this report. Date of Test : Nov. 2, 2020 to Dec. 16, 2020 Prepared by : Tracy Hu /Editor Reviewer : Sewen Guo /Supervisor Approve & Authorized Signer : Lisa Wang/Manager 5 5HSRUW1R(6:3DJHRI9HU TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ....................................................................................................... 2 2 EUT TECHNICAL DESCRIPTION ..................................................................................................... 4 3 SUMMARY OF TEST RESULT .......................................................................................................... 6 4 TEST METHODOLOGY ..................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ....................................................................................... 7 4.3 DESCRIPTION OF TEST MODES .............................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................. 11 5.1 FACILITIES ............................................................................................................................... 11 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................ 11 6 TEST SYSTEM UNCERTAINTY ...................................................................................................... 12 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................... 13 7.1 RADIO FREQUENCY TEST SETUP ......................................................................................... 13 7.2 RADIO FREQUENCY TEST SETUP ......................................................................................... 13 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................. 15 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ...................................................... 16 7.5 SUPPORT EQUIPMENT ........................................................................................................... 16 8 TEST REQUIREMENTS................................................................................................................... 17 8.1 BANDWIDTH MEASUREMENT ............................................................................................... 17 8.2 MAXIMUM CONDUCTED OUTPUT POWER ........................................................................... 50 8.3 MAXIMUM PEAK POWER DENSITY ....................................................................................... 55 8.4 FREQUENCY STABILITY ......................................................................................................... 81 8.5 UNDESIRABLE RADIATED SPURIOUS EMISSION ................................................................ 88 8.6 POWER LINE CONDUCTED EMISSIONS ............................................................................. 112 8.7 ANTENNA APPLICATION ....................................................................................................... 115 5 5HSRUW1R(6:3DJHRI9HU 2 EUT TECHNICAL DESCRIPTION Characteristics Description Product: Smart scanner Model Number: AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLUS, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 Sample Number: 2# Date of Received : Nov. 1, 2020 Wifi Type: Wifi 5G with 5150MHz-5250MHz Band Wifi…

Text truncated - open the document above for the full version.

Report No.ES201028031W03 Page 1 of 21 Ver.1.0 TEST REPORT Product Name : Smart scanner Model Number : AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLUS, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 FCC ID ： 2AYK3-AURAMATE Prepared for : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES201028032W03 Date(s) of Tests : Nov. 2, 2020 to Dec. 16, 2020 Date of issue : Dec. 17, 2020 $二维码$ Report No.ES201028031W03 Page 2 of 21 Ver.1.0 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ......................................................................... 3 2. EUT DESCRIPTION.............................................................................................. 4 3. SUMMARY OF TEST RESULT ............................................................................ 6 4. TEST METHODOLOGY ........................................................................................ 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ...................................................................... 7 4.3 DESCRIPTION OF TEST MODES ........................................................................... 8 5. FACILITIES AND ACCREDITATIONS ............................................................... 10 5.1 FACILITIES ..................................................................................................... 10 5.2 EQUIPMENT ................................................................................................... 10 5.3 LABORATORY ACCREDITATIONS AND LISTINGS ................................................... 10 6. SETUP OF EQUIPMENT UNDER TEST ............................................................ 11 6.1 SETUP CONFIGURATION OF EUT ....................................................................... 11 6.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL: ...................... 11 6.3 SUPPORT EQUIPMENT ..................................................................................... 12 7. DYNAMIC FREQUENCY SELECTION REQUIREMENTS ................................. 13 7.1 A PPLICABLE STANDARD .................................................................................. 13 7.2 C ONFORMANCE L IMIT ..................................................................................... 13 7.3 T EST C ONFIGURATION .................................................................................... 13 7.4 T EST PARAMETERS OF DFS TEST SIGNAL ......................................................... 14 7.5 T RANSMITTER OUTPUT POWER ........................................................................ 15 7.6 O PERATION MODES AND REQUIREMENT TEST ITEMS .......................................... 16 7.7 TEST PROCEDURE .......................................................................................... 16 8. TEST RESULT .................................................................................................... 17 8.1 DETAILED TEST RESULTS ........................................................................ 17 8.2 R ADAR W AVEFORM ........................................................................................ 18 8.3 I N -S ERVICE M ONITORING ................................................................................ 20 Report No.ES201028031W03 Page 3 of 21 Ver.1.0 1. TEST RESULT CERTIFICATION Applicant : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China Manufacturer : CZUR TECH CO.,LTD. Address : Room 1001, Block A, Chuangye Building, No.21 Huoju Road, High-tech Park, Dalian, Liaoning, China EUT : Smart scanner Model Name : AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLUS, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 Trademark : CZUR Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart E PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.407. The test results of this report relate only to the tested sample identified in this report. Date of Test : August 20, 2020 to November 30, 2020 Prepared by: Sewen Guo /Editor Reviewer: Joe Xia /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No.ES201028031W03 Page 4 of 21 Ver.1.0 2. EUT DESCRIPTION Characteristics Description Product: Smart scanner Model Number: AURA MATE, AURA MATE PRO, AURA MATE X, AURA MATE PLUS, AURA MATE X PRO, ETS 0600, ETS 0601, ETS 0602, ETS 0603, ETS 0604, ETS 0605, ETS 0606, ETS 0607, ETS 0608, ETS 0609, ETS 0610, ETS 0611, ETS 0612, ETS 0613, ETS 0614, ETS 0615, ETS 0616, ETS 0617, ETS 0618, ETS 0619 Sample Number: 2# Date of Received : Nov. 1, 2020 Wifi Type: Wifi 5G with 5150MHz-5250MHz Band Wifi 5G with 5250MHz-5350MHz Band Wifi 5G with 5725MHz-5850MHz Band WLAN Supported: 802.11a 802.11n(20MHz channel bandwidth) 802.11n(40MHz channel bandwidth) 802.11ac(20MHz channel bandwidth) 802.11ac(40MHz channel bandwidth) 802.11ac(80MHz channel bandwidth) Data Rate : 802.11a:54/48/36/24/18/12/9/6Mbps 802.11n:…

Text truncated - open the document above for the full version.

Setup photos Conducted Spurious Emissions Radiated Spurious Emissions(30MHz-1GHz) Radiated Spurious Emissions(above 1GHz)
