2AYL3SL22831063Hearing aid

Zhongshan Xiaolan Town Senlan Electronic Factory

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 05, 2021
Application Purpose: Original Equipment
Date of Application: May 05, 2021
Equipment Note: Hearing aid
Frequency Range: 2402.00000000 - 2480.00000000
Company: Zhongshan Xiaolan Town Senlan Electronic Factory
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZEM2101000048CR FCC ID: 2AYL3SL22831063 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Internal Photos for SZEM2101000048CR FCC ID: 2AYL3SL22831063 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 EUT Constructional Details Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3

RF Exposure Info

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM210100004804 Page: 1 of 7 Keny Xu EMC Laboratory Manager 1 Cover page SAR Evaluation Report Application No.: SZEM2101000048CR Applicant: Zhongshan Xiaolan Town Senlan Electronic Factory Address of Applicant: 4/F, Plant 3, Chenjian Industrial Village, No.39 East Juchen Road, Xiaolan Town, Zhongshan City, Guangdong Province, P.R.China Manufacturer: Zhongshan Xiaolan Town Senlan Electronic Factory Address of Manufacturer: 4/F, Plant 3, Chenjian Industrial Village, No.39 East Juchen Road, Xiaolan Town, Zhongshan City, Guangdong Province, P.R.China Factory: Zhongshan Xiaolan Town Senlan Electronic Factory Address of Factory: 4/F, Plant 3, Chenjian Industrial Village, No.39 East Juchen Road, Xiaolan Town, Zhongshan City, Guangdong Province, P.R.China Equipment Under Test (EUT): EUT Name: Hearing aid Model No.: A-360 FCC ID: 2AYL3SL22831063 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2021-01-04 Date of Test: 2021-01-08 to 2021-02-04 Date of Issue: 2021-02-08 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM210100004804 Page: 2 of 7 2 Version Revision Record Version Chapter Date Modifier Remark 01 2021-02-08 Original Authorized for issue by: Damon Su/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM210100004804 Page: 3 of 7 3 Contents Page 1 COVER PAGE .............................................................................................................................................. 1 2 VERSION ...................................................................................................................................................... 2 3 CONTENTS .................................................................................................................................................. 3 4 GENERAL INFORMATION .......................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION ...................................................................................................................................... 5 4.3 TEST FACILITY ........................................................................................................................................ 5 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ............................................................................. 5 5 SAR EVALUATION ...................................................................................................................................... 6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................ 6 5.1.1 Standard Requirement ..................................................................................................................... 6 5.1.2 Limits ................................................................................................................................................ 6 5.1.3 EUT RF Exposure ......................................................................................................................... 6-7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM210100004804 Page: 4 of 7 4 General Information 4.1 General Description of EUT Power supply: DC 3.7V by lithium battery. For BT: Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: Ceramic Antenna Antenna Gain: 2.0dBi For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 Dual mode Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: Ceramic Antenna Antenna Gain: 2.0dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM210100004804 Page: 5 of 7 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has be…
