2AYLH-UDL0856-SLVLED DESK LAMP

USER MANUAL Item# 2311393 Model# UDL0856-SLV SAVE THESE INSTRUCTIONS For Customer Care, product operation information or problem resolution, call toll-free 1-877-654-1991. LED DESK LAMP with Wireless Charging & Mood Light Wireless Charging 5 Levels of Brightness Dimmer Function 3 Light Modes Warm/Natural/Bright Night Light Touch Control Chroma RGB Mood and Night Light Qi-Certified Wireless Charging Technology 2 Ultra-Brite, Long-Lasting LEDs (Up to 35,000 hours) Chroma RGB Color-Changing Mood & Night Light Night Light One-Touch Chroma RGB Mood Light Control 3 Light Modes Warm/Natural/Bright Power On/Off 5 Levels of Brightness Dimmer Function Wireless Charging (5V, 1.0 Amp) Charging Status LED Indicator (located near power adapter port) 3 Elevate your lifestyle! UltraBrite ® LED Desk Lamp with Wireless Charging and Mood Light User Manual SAVE THESE INSTRUCTIONS For Customer Care, production operation information or problem resolution, call toll-free 1-877-654-1991. IMPORTANT SAFETY INSTRUCTION WARNING - DO NOT EXPOSE THE ADAPTOR TO RAIN OR MOISTURE TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING!: USE THIS PRODUCT ONLY ON A FIRM, LEVEL SURFACE AND PREVENT ANY OBJECTS OR MATERIALS FROM COVERING THE LIGHT SOURCE AND/OR VENTILATION HOLES OF THE PRODUCT. PLEASE READ THE INSTRUCTIONS BEFORE OPERATING THIS PRODUCT. - LED module is not replaceable. - Do not break or pull out LED bulbs. - Indoor use only. - Do not look directly at the light. - LED module lamp head may get hot after several hours of continuous use, AVOID placing your hands directly on LED light panel. - Keep lamp away from materials that may burn. - If the power cord or adaptor is damaged, replace the power supply cord and adapter. Call Customer Care for assistance. 4 Operation Instructions: 1. Use this product only on a firm, level surface and prevent any objects or materials from covering the light source and/or ventilation holes of the product. 2. Connect the AC adapter input into the connector in the rear of the lamp. Plug the AC adapter into a standard household 120V AC outlet. Note: Use only with the supplied AC adapter to avoid damage or fire. 3. Touch On/Off to turn on the lamp. 4. Touch control button to adjust brightness. There are five levels of brightness. 5. Touch to switch between 3 light temperature modes: Warm, Natural, Bright light. 6. Touch to activate low level night light. 7. Touch once to activate Chroma RGB mood light. Touch once again to hold current color. Touch to deactivate Chroma RGB mood light. 8. Touch On/Off to turn off. Wireless Charging Specifications: Output: 1.0Amp, 5 Volt. Place the Qi compatible device over the wireless charging icon ( ). When the device begins charging, the device will indicate that charging is active. This feature will not charge all Qi compatible devices. Please refer to your device instructions for enabled capability. Device case or cover should be removed to ensure a stable connection. Charging Status LED Indicator (located near power adapter port) Without light - Wireless charging is on standby. With light - Wireless charging is active. Device will indicate charging is active. Fast flashing - Abnormal operation. Recheck device position, remove cover, or check Qi compatibility with your device. The ‘Qi’ symbol is a trademark of the Wireless Power Consortium. All rights reserved. 5 Elevate your lifestyle! Specifications: Light Bulbs: 56 LEDs + 7 RGB LEDs Brightness Levels: 5 Levels of Brightness Light Temperature Modes: 3 Modes (Warm/Natural/Bright Light) LED Life: 35,000 hours Wireless Charging pad: 1.0A (5V) Light Output (Lumens): 700LM Colour Rendering Index (CRI): 80 Ra Correlated Colour Temperature (CCT): Cold (5000K-6500K), Warm (2700K-3000K), Neutral (3000K-4500K) Watts: 10W Input Voltage: 100-240V 50/60Hz Power: DC 12V 1.5A Product Size: 10”L x 5.75”W x 16.77” H (254mm L x 146mm W x 426mm H) Product Weight: 1.43 lbs (0.65kg) Maintenance Instructions: 1. Read the instruction manual carefully before assembly or use in case of any risk. 2. Do not switch the light On/Off repeatedly in a short time to protect the lifetime of the LED. 3. LED module is not replaceable. Do not break or pull out LED bulbs. 4. Do not look directly at the light. 5. Keep lamp away from material that may burn. 6. Use a dry cloth for daily cleaning. 7. For product operation information or a problem resolution, call toll-free 1-877-654-1991. 6 Lamp FCC Instructions: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experience radio/TV technician for help. Lamp transformer FCC instructions: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer…
