2AYLN-S064OPS PC MODULE

PWR BUTTON MIC_IN TYPE-C HDMI SIMJAEDCIN LAN RESET WIFIWIFI LOCK USB2.0 USB3.0USB3.1 PWR_LED HDD_LED LINE_OUT Security Tips For using computer safely and effectively, please read the following carefully before using: • To avoid electric shock or product damage, each time you connect (not Plug-and-play) devices, please turn off the AC power. • Avoid using this product under temperature is too high or too low (Required temperature is as following: Storage temperature: -20~70 Celsius; Operating temperature: -5~45 Celsius; humidity: 10%~95%). • Do not use a damp cloth to clean your computer and prevent liquid dropping into the computer causing burns. • In order to avoid frequently switching the machine to cause unnecessary damage to the product, after shutting down, you should wait at least 30 seconds for power-on again. • To prevent product damage and malfunction, avoid strong shock and vibration to the product. Interface Instructions (Please refer to the " External View " above) S064 Series Simple User's Guide Rev 1.0 Contents External View • MIC_IN: This jack is used to connect an external microphone • LINE_OUT: This jack is used to connect to the front left and right channel speakers of the audio system • HDMI2.0: High-defintion multimedia display interface, backwards compatibility HDMI1.4 • USB2.0: USB 2.0 connectors, backwards compatibility USB 1.1 • USB3.0: USB 3.0 connector, backwards compatibility USB 2.0/1.1 • LAN: RJ-45 Ethernet network connector • PWR BUTTON: Pressing the power button, the machine will turn on • PWR_LED: Power indicator light • HDD_LED: HDD indicator light • RESET: Reset button • WIFI: WiFi antenna interface • USB3.1 Type-C: Type-C connector • USB3.1 Gen2 Type-A: USB 3.1 connector, backwards compatibility USB 3.0/2.0 • LOCK: LOCK button • SIM: SIM card slot • JAE: 80 PIN Extension Port • DCIN: DC Power interface BIOS Common Function The following scenario you need to run the BIOS Setup program: a. The System self-test error message appears on the screen, and enter the BIOS Setup; b. Based on customer characteristics you want to change the factory default settings. Describes the features common to sections below for BIOS only. Note: since the Board's BIOS version is continually upgraded so in this manual for a description of BIOS is for informational purposes only, we do not guarantee that this guide related content and consistency of your information. Enter the BIOS Setup program Please open the computer, post pictures you can see this information: At this point, press the (DEL) key to enter the BIOS Setup program, if you respond to the prompt before disappearing, and you still want to enter the program, turn off the computer and then restart the system open, or press (Crtl) + (Alt) + (Del) key to reboot. Start programs shortcut settings menu Turn the power on or reboot the system, post the picture you can see the following information: Press the "F11" key will pop up menus as shown in the figu e below, directly press the up and down arrow keys to their provisional designation needed to start the device, without the need to enter the BIOS Setup. Note: This illustration is for reference only, which may be defferent from the material object. The defintion of all the jumpers and sockets which are marked in the above picture, please refer to the following "Interface Instructions" part. 1. Package Checklist 2. Product Configu ation 3. Security Tips 4. External View 5. Interface Instructions 6. BIOS Common Function Disclaimer The intellectual property of this guide belongs to our company. The ownership of all of the products, including accessories and software etc. belong to our company. No one is permitted to copy, change, or translate without our written permission. We compiled this guide based on our careful attitude, but we can not guarantee the accuracy of the contents. This guide is purely technical documentation, without any hint or other meanings, and we won't commit users' misunderstanding of the typesetting error. Our products are in continuous improvement and updating, Therefore, we retain the right that we won't give notice to the users in future. All of the trademark in this guide belong to their own registered company. All of the products name is only for identification, its title belongs to its manufacturer or brand owner. Ver: 1.0 Date: July. 2020 P/N: Y5PF-A61866-00 Thank you for supporting environmental protection and energy saving! Processor- Intel® Whiskey Lake-U, TDP 15W Memory- 2 x SO-DIMM DDR4,Max. 32GB Storage - 1 x M.2 KEY M 2280 SATA SSD(SATA/NVME) - 1 x M.2 KEY B 2242 SSD Graphics- Intel® HD Graphics 6series Network- Intel Gigabit Ethernet Audio- Realtek ALC662 HD Audio IC Dispaly Connectors - 1 x HDMI 2.0 WIFI/BT- 1 x M.2 2230 WIFI/BT Module 3/4G - 1 x SIM card USB Connectors - 2 x USB3.1 Gen2 Type-A - 1 x USB3.0 Type-A - 1 x USB2.0 Type-A - 1 x USB3.1 Type-C (CC) JAE 80-pin - 1 x HDMI2.0 out - 3 x USB2.0 - 1 x USB3.0 - 1 x UART TTL Power input- 12-19V DC IN Dimensions- 119(L) x 180(W) x 30(H) mm Operating systems - Windows 10, Linux(Optional) Please select boot device: SATA: PM-Hitachi HTS3543216L9A300 USB: Generic-Multi-Card Enter Setup ↑ and ↓ to move selection ENTER to select boot device ESC to boot using defaults Press <DEL> to enter Setup,<F11>to popup menu Press <DEL> to enter Setup,<F11>to popup menu Package Checklist Thank you for choosing our products. Before using your product, please make sure your packaging is complete, if there have been damaged or you find a y shortage, please contact your agency as soon as possible. □ The Machine x 1 □ Simple User's Guide x 1 □ WiFi antennas x 2 □ Driver CD x 1 (Optional) Product Configu ation Rear IO Y5 PF-A61866-00 Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas. …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 External Photos for SZEM2011012189CR FCC ID: 2AYLN-S064 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 1 EUT Constructional Details Bluetooth, WIFI Antenna 1 WIFI Antenna 2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 Antenna Connecter 1 Antenna Connecter 2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4

Label Location

LiUYF Approved MODEL TITLE CheckedDesigner Label Placement S064-BENQ标贴模版-铭牌标贴 Copyright © Page 01JWIPC Technology Co.,Ltd 名称：铭牌标贴 用量：1PCS 料号：Y5PD-860980-00 尺寸：69*49+60*39mm OPS PC MODULE DC Input: 19V 4.74A Model Name: TEY21 Date of mfg: 2021.03.08 Serial No.: XXXXXXXXXXXXXXXXXXXXX PN:XX.XXXXX.XXX R R-41127671 www.bis.gov.in IS 13252(Part 1)/ IEC 60950-1 XXXXX/SDPPI/XXXX XXXX R-R-W2P-S064 A/S 연락처: +82 15883866 CCAH19LP0850T0 XXXXX-XX-XXXXX FCC ID:2AYLN-S064 Contains IC:1000M-AX200NG CAN ICES-003(B)/NMB-003(B) IFETEL ID:XXXXXXXXX-XXXX TRA REGISTERED NO: ER69829/19 DEALER NO: 0018841/09 R31740 RoHS Made in China/Сделано в китае/中國製造/중국 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,and (2) this device must accept any interference received,including interference that may cause undesired operation. Manufactured for Jwipc Technogogy Co., Ltd. (13/F., Building B, Haisong Edifice, Tairan 9th Road, Futian, Shenzhen, Guangdong, China) Manufactured by Dongguan Scd Technology Co., Ltd. No.1 The 2nd Street, Huihuang Industrial Zone, Xiekeng Village, Qingxi Town, Dongguan, 523000 Guangdong, China EU Importer:BenQ Europe B.V. (Meerenakkerweg 1-17, 5652 AR, Eindhoven, The Netherlands) UK Importer:BenQ UK Limited(7/10 Chandos Street,Cavendish Square,London WIG 9DQ). Contains FCC ID:PD9AX200NG Contains IC:1000M-AX200NG CAN ICES-003(B)/NMB-003(B) IFETEL ID:XXXXXXXXX-XXXX 39.00mm 60.00mm Arial Bold() 12PT :Arial Bold() 3.5PT :Arial Regular() 3.5PT Arial Regular 6PT Arial Regular() 4PT “中國製造”Regular() 4PT “중국”Noto Sans CJK Regular() 4PT Arial Regular() 4.5PT PN条码高度：3mm SN条码高度：3mm Code 128 Arial Regular() 3.5PT R-41127671 www.bis.gov.in IS 13252(Part 1)/ IEC 60950-1 XXXXX/SDPPI/XXXX XXXX R-R-W2P-S064 A/S 연락처: +82 15883866 CCAH19LP0850T0 XXXXX-XX-XXXXX TRA REGISTERED NO: ER69829/19 DEALER NO: 0018841/09 R31740 RoHS OPS PC MODULE DC Input: 19V 4.74A Model Name: TEY21 Date of mfg: 2021.03.08 Serial No.: XXXXXXXXXXXXXXXXXXXXX PN:XX.XXXXX.XXX R R-41127671 www.bis.gov.in IS 13252(Part 1)/ IEC 60950-1 XXXXX/SDPPI/XXXX XXXX R-R-W2P-S064 A/S 연락처: +82 15883866 CCAH19LP0850T0 XXXXX-XX-XXXXX FCC ID:2AYLN-S064 Contains IC:1000M-AX200NG CAN ICES-003(B)/NMB-003(B) IFETEL ID:XXXXXXXXX-XXXX TRA REGISTERED NO: ER69829/19 DEALER NO: 0018841/09 R31740 RoHS Made in China/Сделано в китае/中國製造/중국 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,and (2) this device must accept any interference received,including interference that may cause undesired operation. Manufactured for Jwipc Technogogy Co., Ltd. (13/F., Building B, Haisong Edifice, Tairan 9th Road, Futian, Shenzhen, Guangdong, China) Manufactured by Dongguan Scd Technology Co., Ltd. No.1 The 2nd Street, Huihuang Industrial Zone, Xiekeng Village, Qingxi Town, Dongguan, 523000 Guangdong, China EU Importer:BenQ Europe B.V. (Meerenakkerweg 1-17, 5652 AR, Eindhoven, The Netherlands) UK Importer:BenQ UK Limited(7/10 Chandos Street,Cavendish Square,London WIG 9DQ). 4 17.2 3.7 4.5 5.2 Arial Regular 3.5PT Arial Bold 3.5PT Arial Regular 3.5PT “연락처”Noto Sans CJK Regular 4PT Arial Regular 3.5PT Arial Regular 4PT Arial Regular 4PT 5 4.2 13 7.3 13.7 4.1 R 5.2 7.2 5.5

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 8 Internal Photos for SZEM2011012189CR FCC ID: 2AYLN-S064 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 8 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 8 of 8

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201101218906 Page: 1 of 11 Keny Xu EMC Laboratory Manager 1 Cover page RF Exposure Evaluation Report Application No.: SZEM2011012189CR Applicant: Jwipc Technology Co., Ltd. Address of Applicant: 13/F, Building B, Haisong Edifice, Tairan 9th Road, Futian District, Shenzhen, China Manufacturer: Jwipc Technology Co., Ltd. Address of Manufacturer: 13/F, Building B, Haisong Edifice, Tairan 9th Road, Futian District, Shenzhen, China Factory: Dongguan Scd Technology Co., Ltd. Address of Factory: No.1 The 2nd Street, Huihuang Industrial Zone, Xiekeng Village, Qingxi Town, Dongguan, 523000 Guangdong, China Equipment Under Test (EUT): Product Name: OPS PC MODULE Model No.: H064, S064, TEY21*, S0********, TEY21*-******** (*=A-Z, 0-9, character or blank)   Please refer to section 4.1 of this report which indicates which model was actually tested and which were electrically identical. FCC ID: 2AYLN-S064 Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 Date of Receipt: 2020-11-27 Date of Test: 2020-12-04 to 2020-12-21 Date of Issue: 2020-12-26 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201101218906 Page: 2 of 11 2 Version Revision Record Version Chapter Date Modifier Remark 01 2020-12-26 Original Authorized for issue by: Harry Wu/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201101218906 Page: 3 of 11 3 Contents Page 1 COVER PAGE ........................................................................................................................................ 1 2 VERSION ................................................................................................................................................ 2 3 CONTENTS ............................................................................................................................................ 3 4 GENERAL INFORMATION ..................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION .................................................................................................................................... 7 4.3 TEST FACILITY ...................................................................................................................................... 7 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 7 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................ 7 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER .............................................................................. 7 5 RF EXPOSURE EVALUATION ............................................................................................................... 8 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................. 8 5.1.1 Limits .......................................................................................................................................... 8 5.1.2 Test Procedure ........................................................................................................................... 8 4.1.3 EUT RF EXPOSURE EVALUATION ...................................................................................................... 9-11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201101218906 Page: 4 of 11 4 General Information 4.1 General Description of EUT Rated voltage: Input:DC19.0V, 4.74A For BT: Bluetooth Version: V5.1 Classic mode Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, Pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Antenna Type: Dipole Antenna Antenna Gain: Antenna 1&2: 5dBi For BLE: Bluetooth Version: V5.1 BLE mode Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Data Rate: 1Mb/s, 2Mb/s Antenna Type: Dipole Antenna Antenna Gain: Antenna 1&2: 5dBi For 2.4G Wifi Operation Frequency: 802.11b/g/n/ax(HT20/HE20): 2412MHz to 2462MHz 802.11n/ax(HT40/HE40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11ax: OFDM&OFDMA (1024QAM, 256QAM, 64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11802.11b/g/n(HT20)/ax(HE20): 11 802.11n(HT40)/ax(HE40):7 Channel Spacing: 5MHz Antenna Type: Dipole Antenna Antenna Gain: Antenna 1&2:5dBi For 5GHz Wifi DFS Function: Slaver SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201101218906 Page: 5 of 11 TPC Function: Not Support Antenna Type: Dipole Antenna Antenna Gain: Antenna 1&2:3dBi Operation Frequency: Band Mode Frequency Range(MHz) Number of channels UNII Band I 802.11a/n(HT20)/ac(VHT20)/ax(HE20) 5180-5240 4 802.11n(HT40)/ac(VHT40)/ax(HE40) 5190-5230 2 802.11ac(VHT80)/ax(HE80) 5210 1 UNII Band II-A 802.11a/n(HT20)/ac(VHT20)/ax(HE20) 5260-5320 4 802.11n(HT40)/ac(VHT40)/ax(HE40) 5270-5310 2 802.11ac(VHT80)/ax(HE80) 5290 1 802.11ac(VHT160)/ax(HE160) 5250 1 UNII Band II-C 802.11a/n(HT20)/ac(VHT20)/ax(HE20) 5500-5700 11 802.11n(HT40)/ac(VHT40)/ax(HE40) 5510-5670 5 802.11ac(VHT80)/ax(HE80) 5530-5630 2 802.11ac(VHT160)/ax(HE160) 5570 1 UNII Band III 802.11a/n(HT20)/ac(VHT20)/ax(HE20) 5745-5825 5 802.11n(HT40)/ac(VHT40)/ax(HE40) 5755-5895 2 802.11ac(VHT80)/ax(HE80) 5775 1 Modulation Type: 802.11a: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.…
