Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jan 21, 2021
Application Purpose: Original Equipment
Date of Application: Jan 21, 2021
Equipment Note: R/C CAR
Frequency Range: 2405.00000000 - 2475.00000000
Company: GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1:14 2.4G All-terrain Off-road Climbing Car 1.Know YourRemote Control 2.Instructions For Remote Controller and RC Car Installation 14+ 2 1 5 4 Forward Backward 3 The remote controller uses 2x1.5VAAbatteries (Not Included) CAR (Battery Included) Notes: Please take out the battery if not in use for a long period of time. 1 Turn Left/Turn Right 2 Indicator Light 3 Forward/Backward 4 Power Switch 5 High/Low Speed Switch USB Charging Instructions 1.Charge the battery before the first time you use it. The battery might discharge if not in use for a long period of time. However, overcharging might lead to a loss of battery life. 2.Inspect the charging cord, plug, housing and other parts on a regular basis. If you find something damaged, please immediately stop using it and fix the damagedpart. 3.Do not connect the RC truck to other power connectors, which are not recommended. Ensure that the USB charging cable connects to the original battery and allow for about3.5 hours to be fully charged, which will give about 30 minutes of playingtime. 4.Please use appropriate adapter for charging and do not use quick chargerinstead. 5.The appropriate adapter has an input of 100-240V 50-60Hz 0.2A and an outputof 5.0V 500mA 0.5-1.5A. 6.Connect the battery with the USB charging cable. Tocharge the battery, connect the USB charging cable to charging devices with USB interface, such as desktop, laptop, power bank, USB socket for USB adapter, etc. 3.Remote Control Driving 12 Forward 3 Turn Left Backward 4 Turn Right 5 Right Fine-tuning Left Fine-tuning High/Low Speed Switch *Please read this manual carefully before operation and keep it properly for future reference. Accessories: 1.USB Charging Cable 2.Rechargeable Battery Pack (included) 3.7V 6 FCCStatement WARNING: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

Cover Letter(s)

SCS-F019: Confidentiality Request Letter Page 1 of 3 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] W ebsite: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 3 Rev 7.0 GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD. 2021.1.14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: 2AYMI2020JJRC2 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name:CHUJIAN HUANG Title : Manager Contact information / address : No. 244,Huancui Road,Chenghai District, Shantou,Guangdong,China SCS-F019: Confidentiality Request Letter Page 3 of 3 Rev 7.0 i Permanent confidentiality may be requested in accordance with FCC KDB 726920

Cover Letter(s)

GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD. Declaration of Identical Product Hereby, Name of manufacturer: GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD. Address: No. 244,Huancui Road,Chenghai District, Shantou,Guangdong,China City: Shantou Country: China declares that: Product description: R/C CAR Type designation(s): C2,Q3,Q5,Q9,Q60,Q61,Q62,Q63,Q64,Q65,Q66,Q67,Q68,Q69,Q70,Q71,Q72, Q72B,Q73,Q75,Q76,Q77,Q78,Q79,Q80,Q81,Q82,Q83,Q84,Q85,Q86,Q87,Q88, Q89,Q90,Q91,Q92,Q93,Q95,Q96,Q97,Q98,Q99,Q100,Q101,Q102,Q103,Q105, Q106,Q107,Q108,Q109,Q110,Q112,Q113,Q115,Q116,Q117,Q118,Q119,Q120, Q121,Q122,Q123,Q124,Q125,Q126,Q127,Q128,Q129,Q130,Q131,Q132,Q133, Q81B,Q135,Q136,Q137,Q138,Q139,Q140,Q141,Q142,Q143,Q145,Q146,Q147, Q148,Q149,Q150,Q151,Q152,EC02,EC03,EC05,EC06,EC09,EC21,C6,C10,C11, C12,C13,1165A Trademark: N/A Family name is technically identical to: Product description: R/C CAR Type designation: Q111 Trademark: N/A Certificate number (if applicable) They are identical with the test model Q111 except appearance and model name for trading purpose. Date: 2021.1.14 City: Shantou Name: CHUJIAN HUANG Signature

External Photos

ID Label/Location Info

Label and Location

Internal Photos

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 26 Report Version 1 Test Report No.: RF2012WDG0245 TEST REPORT Applicant GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD. Address No. 244,Huancui Road,Chenghai District,Shantou,Guangdong,China Manufacturer or Supplier GUANGDONG JIANJIAN INTELLIGENT TECHNOLOGY CO., LTD. Address No. 244,Huancui Road,Chenghai District,Shantou,Guangdong,China Product: R/C CAR Brand Name: N/A Model: Q111 Additional Model & Model Difference C2,Q3,Q5 etc. See item 3.1 Date of tests: Dec. 17, 2020 ~ Jan. 10, 2021 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.249 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Evans He Project Engineer / EMC Department Approved by David Huang Supervisor / EMC Department Date: Jan. 12, 2021 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 26 Report Version 1 Test Report No.: RF2012WDG0245 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 3 1 SUMMARY OF TEST RESULTS .................................................................................................... 4 2 MEASUREMENT UNCERTAINTY ................................................................................................. 4 3 GENERAL INFORMATION ............................................................................................................ 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................... 5 3.2 DESCRIPTION OF TEST MODES ................................................................................................. 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................... 8 4. TEST TYPES AND RESULTS ........................................................................................................ 9 4.1 RADIATED EMISSION MEASUREMENT ...................................................................................... 9 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 9 4.1.2 TEST INSTRUMENTS ..................................................................................................... 10 4.1.3 TEST PROCEDURES ...................................................................................................... 11 4.1.4 DEVIATION FROM TEST STANDARD ............................................................................ 11 4.1.5 TEST SETUP ................................................................................................................... 12 4.1.6 EUT OPERATING CONDITIONS .................................................................................... 13 4.1.7 TEST RESULTS .............................................................................................................. 14 4.2 20DB BANDWIDTH MEASUREMENT ......................................................................................... 21 4.2.1 LIMITS OF 20DB BANDWIDTH MEASUREMENT ............................................................. 21 4.2.2 TEST INSTRUMENTS ......................................................................................................... 21 4.2.3 TEST PROCEDURE ............................................................................................................ 22 4.2.4 DEVIATION FROM TEST STANDARD ............................................................................... 22 4.2.5 TEST SETUP ....................................................................................................................... 22 4.2.6 EUT OPERATING CONDITIONS ........................................................................................ 22 4.2.7 TEST RESULTS ....................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos
