Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 External photos Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003
Size Location
Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 Internal photos Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 RF Antenna RF Chip Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003 Report No.: NTC2101263FV00 FCC ID: 2AYP9-KMHSB003
Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2101263F-1 FCC ID: 2AYP9-KMHSB003 RF EXPOSURE EVALUATION EUT Specification EUT 32 inch 2.1 Channel Soundbar Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz; Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 0.619dBm(1.15mW) Antenna gain -0.68dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2101263F-1 FCC ID: 2AYP9-KMHSB003 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in MW G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) Tolerance Max Tune-UP power (mW) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) Test Mode: GFSK Low 2402 -2.051 ±0.5 0.70 1.19e-4 1 Middle 2441 -4.333 ±0.5 0.41 6.97e-5 1 High 2480 -6.545 ±0.5 0.25 4.25e-5 1 Test Mode: π/4-DQPSK Low 2402 0.137 ±0.5 1.16 1.97e-4 1 Middle 2441 -2.095 ±0.5 0.69 1.17e-4 1 High 2480 -4.289 ±0.5 0.42 7.14e-5 1 Test Mode: 8DPSK Low 2402 0.619 ±0.5 1.29 2.19e-4 1 Middle 2441 -1.484 ±0.5 0.80 1.36e-4 1 High 2480 -3.601 ±0.5 0.49 8.34e-5 1
