2AYPB-FM001Rechargeable Motorized Blinds Remote Control

. FM ZhuYe ① Blind (include header and bottom bar) ② Receiver (include rechargeable battery) ③ Charger ④ Spanner (for ⑥-2,apply only to products less than 30 inches in width) ⑤ Remote controler ⑥-1 Mounting bracket width ≤ 39 inches, 2 brackets 39 inches ＜width ≤ 65 inches, 3 brackets width ＞ 65 inches, 4 brackets ⑥-2 Mounting spring lever(apply only to products less than 30 inches in width) ⑦ Solar panel (for ②) Note:The extension cord at the bottom is used to adjust the length of the blind. FM001-433 . Mark installation location Make hole Install ⑥-1 Mark installation location Install ⑥-1 Adjust the length of ① Install ⑥-1Install ① Operate ② or ⑤ to fully extend the blind. Adjust the length of ① note:The extension cord at the bottom is used to adjust the length of the blind. Operate ② or ⑤ to fully extend the blind.Then pull out the cord and tie the knots (two knots must be tied in the same place to prevent slipping out of the hole) at the desired length to match the length of your window. It is recommended not to cut the cord off completely so that you can loosen the knot and restore the length of the blind again when you apply it to other windows. Adjust the length of ① Adjust the length of ① Adjust the length of ① cut the extension cord off ⑦ Solar panel is an optional, find a suitable place to paste the installation according to the actual situation of the window,then connect to ② The motor inside this product is driven by lithium battery. The lithium battery is in a controller on the top of product.There are operation buttons on the controller.The controller can be connected to a remote control to operate and removed to charge. 1) Blind's slats width : 25mm 2) In the case of continuous testing, run about 240 cycles(raise-lower) on one charge 3) Lithium Battery capacity: 4000mAh 4) Lithium battery voltage is 3.7V 5) Lithium battery charging voltage IS 5.0V 6) Lithium battery control switch charging interface, Android 5P 7) Frequency:433MHZ 1) Remote controls can be bound to or unbound to products at will. 2) After binding to multiple products, you can select to control all products at same time on one remote control, or you can just operate a single product . 3)Long press press FCC Caution： Thi s device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) t his device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital devic e, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not i nstalled and used in accordance with the instruct ions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not o ccur in a particular installation. If this equipment does cause harmful interference to radio or tele vision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Th e device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restricti on.

Rev 11/20/07 (CHANGSHU CHENMING HIGH-TECH INTERNATIONAL TRADING CO., LTD.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AYPB- FM001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Zhiying Jin)

Lazata Technology Co. LTD Model Difference 2021-01-07 EUT NAME: Rechargeable Motorized Blinds MODEL : FM001-433W, FM001-433 All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature Client’s name / title : Zhiying Jin / Manager Contact information / address: No.4235, 4/F, Hardware Market, No.9, Baixue Road, Mocheng Subdistrict, Changshu City, Jiangsu Province, China

(CHANGSHU CHENMING HIGH-TECH INTERNATIONAL TRADING CO., LTD.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2021/01/07 SUBJECT: FCC Application for FCC ID: 2AYPB- FM001 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Zhiying Jin)

External Photos

Size:25*15mm Rechargeable Motorized Blinds FCC ID: 2AYPB- FM001 Label location

Internal Photos Antenna

No.：BCTC/RF-EMC-005 Page: 1 of 33 Edition：A.3 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2012145609E Applicant: CHANGSHU CHENMING HIGH-TECH INTERNATIONAL TRADING CO., LTD. Product Name: Rechargeable Motorized Blinds Remote Control Model/Type Ref.: FM001-433W Tested Date: 2020-12-25 to 2021-01-07 Issued Date: 2021-01-07 Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 2 of 33 Edition：A.3 FCC ID: 2AYPB- FM001 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Rechargeable Motorized Blinds Remote Control Trademark: FM Zhu Ye Model/Type Ref.: FM001-433W FM001-433 Prepared For: CHANGSHU CHENMING HIGH-TECH INTERNATIONAL TRADING CO., LTD. Address: No.4235, 4/F, Hardware Market, No.9, Baixue Road, Mocheng Subdistrict, Changshu City, Jiangsu Province, China Manufacturer: CHANGSHU HIGH-TECH ENERGY-SAVING DORWIN CO., LTD Address: 29 Mingzhu Road, Yanxiang Industrial Development Zone, Changshu City, Jiangsu Province, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Tangwei, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2020-12-25 Sample tested Date: 2020-12-25 to 2021-01-07 Issue Date: 2021-01-07 Report No.: BCTC2012145609E Test Standards FCC Part15.231 ANSI C63.10-2013 Test Results PASS Tested by: Approved by: Lei Chen/Project Handler Zero Zhou/Reviewer Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 3 of 33 Edition：A.3 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................ 5 2. TEST SUMMARY ..................................................... 6 3. MEASUREMENT UNCERTAINTY ....................................... 7 4. PRODUCT INFORMATION AND TEST SETUP............................ 8 4.1 Product Information ..................................................... 8 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 9 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................. 9 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 10 5.1 Test Facility ........................................................... 10 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................ 12 6.1 Block Diagram Of Test Setup ............................................ 12 6.2 Limit ................................................................. 12 6.3 Test procedure ........................................................ 12 6.4 EUT operating Conditions ............................................... 13 6.5 Test Result ........................................................... 13 7. RADIATED EMISSIONS .............................................. 14 7.1 Block Diagram Of Test Setup ............................................ 14 7.2 Limit ................................................................. 15 7.3 Test procedure ........................................................ 16 7.4 EUT operating Conditions ............................................... 18 7.5 Test Result ........................................................... 19 8. BANDWIDTH TEST .................................................. 23 8.1 Block Diagram Of Test Setup ............................................ 23 8.2 Limit ................................................................. 23 8.3 Test procedure ........................................................ 23 8.4 EUT operating Conditions ............................................... 23 8.5 Test Result ........................................................... 24 9. CALCULATION OF AVERAGE FACTOR ................................ 25 10. DWEELL TIME....................................................... 28 10.1 Block Diagram Of Test Setup .......................................... 28 10.2 Limit ................................................................ 28 10.3 Test procedure ....................................................... 28 10.4 Test Result .......................................................... 29 11. ANTENNA REQUIREMENT ........................................... 30 11.1 STANDARD REQUIREMENT .......................................... 30 11.2 EUT ANTENNA ...................................................... 30 Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 4 of 33 Edition：A.3 12. EUT PHOTOGRAPHS ................................................ 31 13. EUT TEST SETUP PHOTOGRAPHS .................................... 32 (Note: N/A means not applicable) Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 5 of 33 Edition：A.3 1. VERSION Report No. Issue Date Description Approved BCTC2012145609E 2021-01-07 Original Valid Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 6 of 33 Edition：A.3 2. TEST SUMMARY The Product has been tested according to the following specifications: No. Test Parameter Clause No Results 1 Conducted Emission §15.207 N/A 2 Fundamental &Radiated Spurious Emission Measurement 15.209,15.231b PASS 3 Occupy Bandwidth 15.231c PASS 4 Dwell time 15.231a PASS 5 Antenna Requirement 15.203 PASS Report No.: BCTC2012145609E No.：BCTC/RF-EMC-005 Page: 7 of 33 Edition：A.3 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage fact…
