2AYPQKPDIGITAL LOCK

1、Smart Card Open Intelligent IC chip instead of traditional mechanical key, use the lock software to issue relative smart card to open ,specified door in specified time period. 2、No Need Web Setting management information through management software, using smart card to transfer data between lock and system to achieve hierarchical management and district management, easy to install and operate. 3、Real Time Open Record Black box inside the door lock can store the latest 990 door opening records (Including mechanical key open,emergency card open and turn handle open inside room), all opening records can download by handset unit. 4、American Standard Lock Body with Five Latch Adopt safety American standard lock body with five Lacth lock . The hiding wiring installation way can avoid damage of wires during door lock installation and using. 5、Alarming When the lock latch can not stretch out normally(door don’t close well), lock will have sound and light alarming to reminder guest or administrator to close the door; when guest are resting, they can stretch out the deadbolt and lock will reminder automatically by red light to indicate “No Disturb.” 6、KABA Keyway Cylinder with Two Line Pins Adopt KABA keyway high security cylinder, can use mechanical keys to open the door any time 7、Emergency Access Inside room can press down the handle to open the door in emergency situation to leave room. 8、Hierarchy Management According to management rights to issue different permission level management smart cards to make the hotel management be more reasonable. Technical Specification Registered Cards Number No limitation Static Current <15uA Reading Time <1s Dynamic Current <120mA Reading Range <3cm Lower Voltage Warning <4.8V (250 times at least) Sensor Frequency 13.56MHZ Working Temperature -20°C~50°C Working Voltage 4PCS LR6 alkaline batteries Working Humidity 20%-80% Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

External Photo

Internal Photo

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZEM201201701302 Page: 1 of 25 FCC ID: 2AYPQKP Kobe Jian EMC Laboratory Manager TEST REPORT Application No.: GZEM2012017013CR Applicant: ZHUHAI MITALY INNOVATIONS TECHNOLOGY CO., LTD Address of Applicant: 5F BLOCK 2, No.321 PINGBEI YI Rd., NANPING TECHNOLOGY PARK, XIANGZHOU DISTRICT, ZHUHAI GUANGDONG, CHINA Manufacturer: ZHUHAI MITALY INNOVATIONS TECHNOLOGY CO., LTD Address of Manufacturer: 5F BLOCK 2, No.321 PINGBEI YI Rd., NANPING TECHNOLOGY PARK, XIANGZHOU DISTRICT, ZHUHAI GUANGDONG, CHINA Factory: ZHUHAI MITALY INNOVATIONS TECHNOLOGY CO., LTD Address of Factory: 5F BLOCK 2, No.321 PINGBEI YI Rd., NANPING TECHNOLOGY PARK, XIANGZHOU DISTRICT, ZHUHAI GUANGDONG, CHINA Equipment Under Test (EUT): FCC ID: 2AYPQKP EUT Name: DIGITAL LOCK Model No.: M1-103, M1-112, M1-119, M1-129, M1-121, M1-130, HT-22, HT-23, HTY-600, HT-L1, HT-L2, RF-203, RF-212, RF-219, RF-229, RF-221, RF-230, NF-21T, N3T ¤ ¤ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: KEYPLUS Standard(s): 47 CFR Part 15, Subpart C 15.225 Date of Receipt: 2020-12-07 Date of Test: 2020-12-16 to 2020-12-24 Date of Issue: 2020-12-30 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZEM201201701302 Page: 2 of 25 Revision Record Version Chapter Date Modifier Remark 01 2020-12-30 Original Authorized for issue by: Tested By 2020-12-16 to 2020-12-24 Lily_Kuang /Project Engineer Date Checked By 2020-12-30 Ricky_Liu /Reviewer Date SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZEM201201701302 Page: 3 of 25 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.225 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Emission Mask 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.225(a)&(b)&(C ) Pass Frequency tolerance 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart C 15.225(e) Pass Radiated Emissions (9kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass ¤ Declaration of EUT Family Grouping: Model No.: M1-103, M1-112, M1-119, M1-129, M1-121, M1-130, HT-22, HT-23, HTY-600, HT-L1, HT- L2, RF-203, RF-212, RF-219, RF-229, RF-221, RF-230, NF-21T, N3T. According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference on the outer color. Therefore only one model M1-119 was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZEM201201701302 Page: 4 of 25 3 Contents Page 1 Cover Page .............................................................................................................................................. 1 2 Test Summary ........................................................................................................................................ 3 3 Contents ................................................................................................................................................. 4 4 General Information ............................................................................................................................... 5 4.1 Details of E.U.T................................................................................................................................ 5 4.2 Description of Support Units............................................................................................................. 5 4.3 Measurement Uncertainty ................................................................................................................ 5 4.4 Test Location ................................................................................................................................... 5 4.5 Test Facility ..................................................................................................................................... 6 4.6 Deviation from Standards ................................................................................................................. 7 4.7 Abnormalities from Standard Conditions .......................................................................................... 7 5 Equipment List ....................................................................................................................................... 8 6 Radio Spectrum Technical Requirement .............................................................................................. 9 6.1 Antenna Requirement ...................................................................................................................... 9 6.1.1 Test Requirement: ....................................................................................................................... 9 6.1.2 Conclusion .................................................................................................................................. 9 7 Radio Spectrum Matter Test Results................................................................................................... 10 7.1 20dB Bandwidth............................................................................................................................. 10 7.1.1 E.U.T. Operation.........…
