IOTTEMP  IoT Temperature Sensor User Guide Saucon Technologies IOTTEMP Page 2 User Guide for IOT Temperature Sensor Copyright © 2020 by Saucon Technologies, Inc. All rights reserved. This publication may not be reproduced in whole or in part, without prior written permission from Saucon Technologies, Inc. Saucon Technologies, Inc. makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Saucon Technologies, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Saucon Technologies, Inc. to notify any person or organization of such revision or changes. Revision History: Revision Date Description A 08/14/2020 Initial Release Trademarks Saucon Technologies, Saucon TDS, the Saucon Technologies logo, and the Saucon TDS logo are trademarks of Saucon Technologies, Inc. Windows is a registered trademark of Microsoft in the U.S. and other countries. Other trademarks and trade names mentioned in this publication belong to their respective owners. World Headquarters Saucon Technologies, Inc. 2455 Baglyos Circle Bethlehem, PA 18020 (484) 241-2500 Fax (484) 895-0341 Technical Support Country By Email By Phone U.S and Canada [email protected] (484) 241-2515 Internet Address: http://www.saucontds.com Saucon Technologies IOTTEMP Page 3 FCC / ISED Declaration of Conformity This device contains license-exempt transmitters(s) / receiver(s) that comply with Innovation, Science, and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. Caution: Unauthorized modifications or changes not expressly approved by Saucon Technologies, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause interference harmful to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer, or an experienced radio / TV technician for help. FCC / ISED Déclaration de Conformité L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio ex- empts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Attention: des modifications non autorisées ou des changements non expressément approuvés par Saucon Technologies, Inc. peuvent annuler la conformité aux règles réglementaires et, par conséquent, votre autorisation d'utiliser cet équipement. Cet équipement génère, utilise et peut émettre de l’énergie radiofréquence et, s’il n’est pas installé et utilisé conformément aux instructions du fabricant, il peut provoquer des interférences nuisibles aux communications radio. Cependant, il n'y a aucune garantie que des interférences ne se produiront pas dans une installation particulière. Si cet équipement cause des interférences nuisibles à la réception de la radio ou de la télévision, ce qui peut être déterminé en éteignant et en rallumant l'équipement, l'utilisateur est encouragé à essayer de corriger les interférences par une ou plusieurs des mesures suivantes: • Réorientez ou déplacez l'antenne de réception. • Augmenter la distance entre l'équipement et le récepteur. • Connectez l'équipement à une prise sur un circuit différent de celui sur lequel le récepteur est connecté. • Consultez le revendeur ou un technicien radio / TV expérimenté pour obtenir de l'aide. Saucon Technologies IOTTEMP Page 4 Table of Contents: IOTTEMP  ....................................................................................................................... 1 IoT Temperature Sensor .................................................................................................. 1 User Guide ...................................................................................................................... 1 Revision History: ........................................................................................................ 2 Technical Support ....................................................................................................... 2 Declaration of Conformity ................................................. Error! Bookmark not defined. FCC / ISED Compliance Statements ....................... Error! Bookmark not defined. Chapter 1: Product Description and Specifications ........................................................... 5 Product Description .................................................................................................... 5 Package Contents ........................................................................................................ 5 Parts to be supplied by End User ................................................................................ 5 Chapter 2: Installation/Power ..................................…

Text truncated - open the document above for the full version.

pcbauthletter_170808 Saucon Technologies 2455 Baglyos Circle Bethlehem, PA 18020 Date: January 19, 2021 RE: Authorization Letter for FCC ID: 2AYQW-IOTTEMP To whom it may concern: We, the undersigned, hereby authorize PCT EST Engineering Laboratory, LLC, to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. All acts carried out by PCTEST Engineering Laboratory, LLC on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, Signature William French Founder Saucon Technologies

fccconfidentiality_180103 Saucon Technologies 2455 Baglyos Circle Bethlehem, PA 18020 Date: January 19, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: 2AYQW-IOTTEMP To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Saucon Technologies hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The requested Permanent Confidential exhibits are listed as follows: CONFIDENTIAL LIST Exhibit Description Permanent 1 Parts Lists and Tune-Up Procedure 2 Schematics 3 Operational Description / Theory of Operation 4 Block Diagram The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Signature, William French Founder Saucon Technologies

Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP External Photos EUT Type: IoT Temperature Beacon Page 1 of 3 © 2021 PCTEST V 9.0 02/01/2019 E X T E R N A L P H O T O G R A P H S Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP External Photos EUT Type: IoT Temperature Beacon Page 2 of 3 © 2021 PCTEST V 9.0 02/01/2019 Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP External Photos EUT Type: IoT Temperature Beacon Page 3 of 3 © 2021 PCTEST V 9.0 02/01/2019

IoT Temperature Sensor Label Information & Photos Page 1 of 1 The IoT Temperature Sensor label is permanently affixed to the top edge of the base of the equipment and readily visible to the purchaser at time of purchase and during normal installation and use. Text is formed with a thermal transfer ink and sandwiched between two protective layers of PET (Polyethylene Terephthalate): the backing and laminate covering the text. Acrylic adhesive permanently attaches the label to the equipment enclosure. Brother, as the manufacturer of this material, has completed durability testing that includes Adhesion, Water Resistance, Chemical Resistance, Abrasion Resistance, Temperature Resistance, Fade Resistance, Oil Resistance, and Autoclave Resistance.

Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP Internal Photos EUT Type: IoT Temperature Beacon Page 1 of 3 © 2021 PCTEST V 9.0 02/01/2019 I N T E R N A L P H O T O G R A P H S Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP Internal Photos EUT Type: IoT Temperature Beacon Page 2 of 3 © 2021 PCTEST V 9.0 02/01/2019 Saucon Technologies, Inc. FCC ID: 2AYQW-IOTTEMP Model: IOTTEMP Internal Photos EUT Type: IoT Temperature Beacon Page 3 of 3 © 2021 PCTEST V 9.0 02/01/2019

FCC ID: 2AYQW-IOTTEMP MAXIMUM PERMISSIBLE EXPOSURE REPORT Approved by: Technical Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 6 1M2012080194.03.2AYQW 12/11/2020-12/16/2020 IoT Temperature Beacon © 2021 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. Applicant Name: Saucon Technologies, Inc. 2455 Baglyos Circle Bethlehem, PA 18020 Date of Testing: 12/11/2020-12/16/2020 Test Site/Location: PCTEST Lab. Columbia, MD, USA Test Report Serial No.: 1M2012080194.03.2AYQW FCC ID: 2AYQW-IOT T EMP APPLICANT: Saucon Technologies, Inc. EUT Type: IoT Temperature Beacon FCC Classification: Part 15 Low Power Communication Device Transmitter (DXX) FCC Rule Part: FCC Part 1 (§1.1310) and Part 2 (§2.1091) Test Procedure(s): KDB 447498 D01 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC KDB 447498 D01. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctest.com RF EXPOSURE EVALUATION Maximal Permissible Exposure [MPE] FCC ID: 2AYQW-IOTTEMP MAXIMUM PERMISSIBLE EXPOSURE REPORT Approved by: Technical Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 6 1M2012080194.03.2AYQW 12/11/2020-12/16/2020 IoT Temperature Beacon © 2021 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. T A B L E O F C O N T E N T S 1.0 RF EXPOSURE EVALUATION – MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................ 3 1.1 Introduction ............................................................................................................................................ 3 1.2 EUT Description ..................................................................................................................................... 3 1.3 Procedure .............................................................................................................................................. 4 1.4 Summary of Results............................................................................................................................... 5 2.0 CONCLUSION ................................................................................................................................. 6 FCC ID: 2AYQW-IOTTEMP MAXIMUM PERMISSIBLE EXPOSURE REPORT Approved by: Technical Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 6 1M2012080194.03.2AYQW 12/11/2020-12/16/2020 IoT Temperature Beacon © 2021 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. 1.0 R F E X P O S U R E E V A L U A T I O N – M A X I M U M P E R M I S S I B L E E X P O S U R E ( M P E ) 1.1 Introduction This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC Rules and Regulations and RSS-102 of Industry Canada. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310 and RSS-102: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures (f = frequency) 30-300 61.4 0.163 1.0 6 300-1500 ... ... f/300 6 1500-100,000 ... ... 5.0 6 (B) Limits For General Population / Uncontrolled Exposure (f = frequency) 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 Table 1-1. Limits for Maximum Permissible Exposure (MPE) 1.2 EUT Description The Saucon Technologies FCC ID: 2 A Y Q W-I O T T E M P is a IOT Temperature Beacon containing a low power communication device transmitter that the EUT uses to connect to another device. The EUT has a removable battery (non-rechargeable) to power itself. FCC ID: 2AYQW-IOTTEMP MAXIMUM PERMISSIBLE EXPOSURE REPORT Approved by: Technical Manager Test Report S/N: Test Dates: EUT Type: Page 4 of 6 1M2012080194.03.2AYQW 12/11/2020-12/16/2020 IoT Temperature Beacon © 2021 PCTEST V 9.0 02/01/2019 All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission i…
