2AYSC-E49710Gill Electronic Starter Device

Litania Sports Group, Inc
Gill Electronic Starter Device - FCC ID 2AYSC-E49710 - Litania Sports Group, Inc
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Feb 23, 2021
Application Purpose
Original Equipment
Date of Application
Feb 23, 2021
Equipment Note
Gill Electronic Starter Device
Frequency Range
915.00000000 - 915.00000000
Company
Litania Sports Group, Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Sound Selection ON/OFF Switch Clear LED Cover Trigger Battery Cover LED E49710–GillElectronic Starter Device; 1.0 Customer Instructions 01/07/2021 Customer Instructions Copyright © 2021 by Litania Sports Group, Inc. All rights reserved. Included: •Gill Starter Device •Phillips Head Screwdriver •Audio Cable •Timing System Cable •9V Battery •Protective Soft Carrying Case Gill Electronic Starter Device Features: •6 bright white LED’son both sides of unit for the flash to be seen from all angles •Trigger Guard •Tone and Gun Sound Selection •Timing System and Audio Jacks •Powered by one 9V Battery ON/OFF LED www.gillathletics.com 800-637-3090 Trigger Guard Timing Jack Audio Jack E49710 – Gill Electronic Starter Device; 1.0 Customer Instructions 01/07/2021 Customer Instructions Copyright © 2021 by Litania Sports Group, Inc. All rights reserved. Battery Cover Use Phillips head screwdriver to unscrew and open battery cover. Attach a 9V battery to the battery connector. Place battery into battery compartment and fasten cover. Battery Cover Screw Battery Cover Audio and Timing Jack Connect a megaphone or track speaker system using the supplied Audio Cable. Connect to Finish Lynx ®by using the supplied Timing Cable. Timing Jack Audio Jack ON and OFF SwitchSound Selection Switch LED will turn green to indicate that unit is ON Select between Tone or traditional Gun sound. www.gillathletics.com 800-637-3090 ON OFF ® E49710 – Gill Electronic Starter Device; 1.0 Customer Instructions 01/07/2021 Customer Instructions Copyright © 2021 by Litania Sports Group, Inc. All rights reserved. www.gillathletics.com 800-637-3090 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. This equipment has been tested and meets applicable limits for radio frequency (RF) exposure. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Cover Letter(s)

Litania Sports Group, Inc 601 Mercury Drive Champaign, IL 61822 Date: 02/03/21 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AYSC-E49710 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Dario Remenji Product Designer

Cover Letter(s)

Litania Sports Group, Inc 601 Mercury Drive Champaign, IL 61822 Date: 02/03/21 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AYSC-E49710 Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Dario Remenji Product Designer

External Photos

Reference No.: WTX21X01007938W Page 2 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX21X01007938W Page 3 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn EUT View 3 EUT View 4 Reference No.: WTX21X01007938W Page 4 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn EUT View 5 EUT View 6

ID Label/Location Info

Reference No.: WTX21X01007938W Page 1 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Internal Photos

Reference No.: WTX21X01007938W Page 5 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX21X01007938W Page 6 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTX21X01007938W Page 7 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Solder Board-Component View 4 Solder Board-Component View 5 Reference No.: WTX21X01007938W Page 8 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Solder Board-Component View 6 Antenna View

Test Report

Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Page 1 of 23 TEST REPORT Reference No. ....................: WTX21X01007938W FCC ID ............................... .: 2AYSC-E49710 Applicant .......................... .: Litania Sports Group, Inc Address ............................ .: 601 Mercury Drive, Champaign, IL 61822 Product Name .................. .: Gill Electronic Starter Device Test Model. ....................... .: E49710 Standards ......................... .: FCC Part 15.249 Date of Receipt sample ... .: Jan.25, 2021 Date of Test....................... .: Jan.25, 2021 to Feb.01, 2021 Date of Issue .................... .: Feb.01, 2021 Test Result ........................ .: Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Tested by: Reviewed By: Approved & Authorized By: Mike Shi / Project Engineer Lion Cai / RF Manager Silin Chen / Manager Reference No.: WTX21X01007938W Page 2 of 23 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................... 5 1.3 TEST METHODOLOGY ............................................................................................................................................. 5 1.4 TEST FACILITY ....................................................................................................................................................... 5 1.5 EUT SETUP AND TEST MODE ................................................................................................................................. 6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................. 6 1.7 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 7 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 9 3. ANTENNA REQUIREMENTS .............................................................................................................................. 10 3.1 STANDARD APPLICABLE ....................................................................................................................................... 10 3.2 TEST RESULT........................................................................................................................................................ 10 4. RADIATED EMISSIONS ....................................................................................................................................... 11 4.1 STANDARD APPLICABLE ....................................................................................................................................... 11 4.2 TEST PROCEDURE ................................................................................................................................................. 11 4.3 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 14 4.4 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 14 5. OUT OF BAND EMISSIONS ................................................................................................................................. 18 5.1 STANDARD APPLICABLE ....................................................................................................................................... 18 5.2 TEST PROCEDURE ................................................................................................................................................. 18 5.3 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 18 6. EMISSION BANDWIDTH ..................................................................................................................................... 20 6.1 STANDARD APPLICABLE ....................................................................................................................................... 20 6.2 TEST PROCEDURE ................................................................................................................................................. 20 6.3 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 20 7. CONDUCTED EMISSIONS .................................................................................................................................. 22 7.1 TEST PROCEDURE ................................................................................................................................................. 22 7.2 BASIC TEST SETUP BLOCK DIAGRAM ................................................................................................................... 22 7.3 TEST RECEIVER SETUP ....…

Text truncated - open the document above for the full version.

Test Setup Photos

Reference No.: WTX21X01007938W Page 9 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) Reference No.: WTX21X01007938W Page 10 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Radiation Emission Test Setup (Above 1GHz) ***** END OF REPORT *****

Contact Information

Applicant

Dario Remenji
[email protected]217-367-8438Fax: 217-367-8438

Test Firm

Waltek Testing Group (Shenzhen) Co., Ltd.Jandy So
[email protected]86 755 33663308Fax: 86-755-33663309

Technical Specifications

#Rule PartsFrequency RangePower Output
115C915 MHz - 915 MHz-
