2AYU6-VIRL5000VVTR IRL BATTERY GRIP

User’s Manual Item: VIRL5000KIT Safety Precautions Before setting up and using your Power Grip Charger, basic safety precautions should always be followed including: 1. READ ALL INSTRUCTIONS BEFORE USING YOUR CHARGER. 2. This product is not a toy, do not allow children to play with it. Adult supervision is advised. 3. This product should not be exposed to extreme heat or fire. Do not store in a location with temperatures above 104°F. 4. Do not expose this product to any water, liquids, or excessive humidity. 5. Do not crush, throw or subject this product to extreme physical force. 6. Do not use this product if it appears to be cracked or damaged. 7. Do not use in wet or humid environments. Do not place on wet surfaces. 8. Please recycle or dispose of the product properly based on the laws and rules of your municipality. Contact local recycling facilities and/or the manufacturer of the product for further information. 9. To prevent damage to the product, always place it on a flat, even surface. 10. In order to avoid the risk of electric shock, never attempt to open your charger or repair it without the assistance of certified professionals. BATTERY WARNING: -The device is equipped with an integrated lithium ion battery. The battery cannot be replaced. Do not attempt to remove the battery from the device. -Do not dispose of in fire or expose to excessive heat. -Do not crush, puncture, incinerate, or short circuit external contacts. -Please recycle or dispose of the battery properly. Contact your local recycling facilities and/or the manufacturer for further information. CAUTION 1. READ ALL INSTRUCTIONS BEFORE USING YOUR CHARGER. 2. This product is not a toy, do not allow children to play with it. Adult supervision is advised. 3. This product should not be exposed to extreme heat or fire. Do not store in a location with temperatures above 104°F. 4. Do not expose this product to any water, liquids, or excessive humidity. 5. Do not crush, throw or subject this product to extreme physical force. 6. Do not use this product if it appears to be cracked or damaged. 7. Do not use in wet or humid environments. Do not place on wet surfaces. 8. Please recycle or dispose of the product properly based on the laws and rules of your municipality. Contact local recycling facilities and/or the manufacturer of the product for further information. 9. To prevent damage to the product, always place it on a flat, even surface. 10. In order to avoid the risk of electric shock, never attempt to open your charger or repair it without the assistance of certified professionals. Introduction Thank you for purchasing the Vivitar Power Grip Charger, item VIRL5000KIT. Use the included supplies to assemble an all-in-one tripod, phone mount, phone charger and more. Please read this manual carefully before using. Specications Power Grip Size: 12” x 1” Cable Type: USB-C, USB-A USB-C Charging Port: 5V 2A USB-A Charging Port: 5V 1A Battery: 5000mAh Lithium Polymer Bluetooth Version: 5.0 Thread Holes: 3/8” & 1/4“ Package Contents -1 Power Grip -1 Ball Head Mount -1 Smartphone Mount -1 Table Top Tripod -1 USB-A to USB-C Charging Cable -1 USB-C to USB-C Charging Cable -1 Micro-USB Cable -1 3/8” to 1/4” Adapter -Userʼs Manual with Warranty Information Charging Connect the USB-C cable end (rounded connector) into the power gripʼs USB-C charging port. Connect the other USB cable end (rectangular connector) to a standard USB port or wall adapter. Charging indicator lights will illuminate to show the charging status. Unplug once charging is complete. USB-C Port USB-A Port Charging Indicator Lights Tripod Stand and Phone Mounting The tripod stand and smartphone mount are included with your power grip. To assemble the tripod stand and smartphone mount, screw on the tripod stand to the bottom of the power grip, then attach the smartphone mount to the top of the power grip. Note: Attach your phone to the smartphone mount before assembly. Smartphone Mount Tripod Stand Bluetooth Connection Wirelessly connect your power grip to your smartphone to capture photos and videos using the capture button on your power grip. Press and hold the capture button to activate Bluetooth. Open the Bluetooth settings menu on your smartphone to turn on Bluetooth, then connect the device listed as “IRL 5000”. Press and hold the Capture button again to turn off Bluetooth. “IRL5000” Phone Charging You can charge your phone while it is attached to the smartphone mount. Use one of the included charging cables to connect your phone to the power gripʼs USB-A port. Notes: -Use your smartphoneʼs original charging cable if the charging cables included with the power grip are not compatible. -The USB-A port can be used as a miscellaneous power port. Ball Head Installation For 360° swivel motion, attach the ball head mount. Screw on the ball head mount (2) to the top of the power grip (1). Then, attach the smartphone mount (3) to the top of the ball head mount. Loosen the side screw when adjusting the ball head mount and tighten to keep stable. 1 2 3 External Attachments There are three threaded accessory mounts at the back of your power grip. If a male adapter is needed, use the included adapter to attach external devices such as lights, microphones, etc. Below is an illustrated example of how a video light attaches to the power grip. On the top of the phone mounting accessory is a cold shoe where you can mount a ring lights, flashes or accessories with similar mounting attachments. Adapter Cold Shoe Thread Holes FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the userʼs authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been teste…
