2AYUK-SM1703REMOTE CONTROL QUADCOPTER

SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY Agent Authorization Company: SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY Address: UNIT D 16/F ONE CAPITAL PLACE 21, LUARD ROAD WAN CHAI, Hong Kong Product Name: REMOTE CONTROL QUADCOPTER Model Number(s ): SM1703, SM1905, SM1903, SM1906, SM1916, SM1915, SM1917, SM1911, SM1912, SM1913, SM1907, SM1908, SM1909, S200, S300, S600, S700, S800, S900 Product Description: REMOTE CONTROL QUADCOPTER We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Feb. 01, 2021 Name: Zhou Liang Title: Manager Company: SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY

SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Feb. 01, 2021 Subject; Request for Confidentiality FCC ID: 2AYUK-SM1703 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zhou Liang Title: Manager

Model Difference Declaration To Whom It May Concern, We, SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY(REMOTE CONTROL QUADCOPTER); Model Number: SM1703, SM1905, SM1903, SM1906, SM1916, SM1915, SM1917, SM1911, SM1912, SM1913, SM1907, SM1908, SM1909, S200, S300, S600, S700, S800, S900; All model’s the function, s oftware and electric circuit are the same, only with a product color and model named different. Test sample model: SM1703. Please contact me if you have any question. Name: Zhou Liang Date: Feb. 01, 2021 Title: Manager Signature of applicant:

Annex A External Photos Report No.: HK2012024079-E Page 1 of 4 Report No.: HK2012024079-E Page 2 of 4 Report No.: HK2012024079-E Page 3 of 4 Report No.: HK2012024079-E Page 4 of 4

FCC ID LABEL: Ca. 5mm x 10mm Include in manual: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Location FCC ID: 2AYUK-SM1703

Annex B Internal Photos Report No.: HK2012024079-E Page 1 of 3 Report No.: HK2012024079-E Page 2 of 3 Antenna Report No.: HK2012024079-E Page 3 of 3

Page 1 of 27 Report No.: HK2012024079-E FCC TEST REPORT Test report On Behalf of SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY For REMOTE CONTROL QUADCOPTER Model No.: SM1703, SM1905, SM1903, SM1906, SM1916, SM1915, SM1917, SM1911, SM1912, SM1913, SM1907, SM1908, SM1909, S200, S300, S600, S700, S800, S900 FCC ID: 2AYUK-SM1703 Prepared for : SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY UNIT D 16/F ONE CAPITAL PLACE 21, LUARD ROAD WAN CHAI, Hong Kong Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Jan. 19, 2021 ~ Jan. 26, 2021 Date of Report: Jan. 26, 2021 Report Number: HK2012024079-E Page 2 of 27 Report No.: HK2012024079-E TEST RESULT CERTIFICATION Applicant’s name ................. : SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY Address .................................. : UNIT D 16/F ONE CAPITAL PLACE 21, LUARD ROAD WAN CHAI, Hong Kong Manufacture's Name ............ : SHANTOU CITY CHENGHAI DISTRICT SUMING TOYS FACTORY Address .................................. : UNIT D 16/F ONE CAPITAL PLACE 21, LUARD ROAD WAN CHAI, Hong Kong Product description Trade Mark: N/A Product name ........................... : REMOTE CONTROL QUADCOPTER Model and/or type reference : SM1703, SM1905, SM1903, SM1906, SM1916, SM1915, SM1917, SM1911, SM1912, SM1913, SM1907, SM1908, SM1909, S200, S300, S600, S700, S800, S900 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Jan. 19, 2021 ~ Jan. 26, 2021 Date of Issue ........................................... : Jan. 26, 2021 Test Result .............................................. : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 27 Report No.: HK2012024079-E Table of Contents Page 1 . TEST SUMMARY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 Carrier Frequency of Channels 7 2.3 Operation of EUT during testing 7 2.4 DESCRIPTION OF TEST SETUP 7 2.5 MEASUREMENT INSTRUMENTS LIST 8 3 . CONDUCTED EMISSIONS TEST 9 3.1 Conducted Power Line Emission Limit 9 3.2 Test Setup 9 3.3 Test Procedure 9 3.4 Test Result 10 4 RADIATED EMISSION TEST 12 4.1 Radiation Limit 12 4.2 Test Setup 12 4.3 Test Procedure 13 4.4 Test Result 13 5 BAND EDGE 19 5.1 Limits 19 5.2 Test Procedure 19 5.3 Test Result 20 6 OCCUPIED BANDWIDTH MEASUREMENT 22 6.1 Test Setup 22 6.2 Test Procedure 22 6.3 Measurement Equipment Used 22 6.4 Test Result 22 7 ANTENNA REQUIREMENT 24 8 PHOTOGRAPH OF TEST 25 8.1 Radiated Emission 25 8.2 Conducted Emission 26 9 PHOTOS OF THE EUT 27 Page 4 of 27 Report No.: HK2012024079-E ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release Jan. 26, 2021 Jason Zhou Page 5 of 27 Report No.: HK2012024079-E 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST RESULT CONDUCTED EMISSIONS TEST §15.207 COMPLIANT RADIATED EMISSION TEST §15.249 (a) (d)/ §15.209 COMPLIANT BAND EDGE §15.249 (a) (d)/ §15.209 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT §15.215 (c) COMPLIANT ANTENNA REQUIREMENT §15.203 COMPLIANT 1.2 TEST FACILITY Te s t F i r m ： Shenzhen HUAK Testing Technology Co., Ltd. Address ： 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 6 of 27 Report No.: HK2012024079-E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment REMOTE CONTROL QUADCOPTER Model Name SM1703 Serial Model SM1905, SM1903, SM1906, SM1916, SM1915, SM1917, SM1911, SM1912, SM1913, SM1907, SM1908, SM1909, S200, S300, S600, S700, S800, S900 Model Difference All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: SM1703 FCC ID 2AYUK-SM1703 Antenna Type Internal Antenna Antenna Gain 0dBi Equipment REMOTE CONTROL QUADCOPTER BT Operation frequency 2402MHz, 2439MHz, 2474MHz Number of Channels 3CH Modulation Type GFSK Power Source DC 5V from micro USB or DC 3.7V from Battery Power Rating DC 5V from micro USB or DC 3.7V from Battery Page 7 of 27 Report No.: HK2012024079-E 2.2 Carrier Frequency of Channels Description of Channel: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 1 2439 2 2474 2.3 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode Low Channel: 2402MHz Middle Channel: 2439MHz High Channel: 2474MHz 2.4 DESCRIPTION OF TEST SETUP Operation of EUT during conducted testing and below 1GHz Radiation testing: AC Plug Operation of EUT during Above1GHz and below 1GHz Radiation testing: ● Adapter information Model: HW-059200CHQ Input: 100-240V, 0.5A Output: 5VDC, 2A The sample was placed (0.8m below 1GHz, 1.5m above 1GHz) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain…

Text truncated - open the document above for the full version.

Test Model：SM1703 Radiated Emission Conducted Emission
