2AYXI-ASE1401CADScor System is to record heart sounds, murmurs and vibration for calculation of a patient specific score, indicating the risk of presence of coronary stenosis, as an aid in cardiac analysis and diagnosis

CADScor ® System User Manual Rx Only 2 1 Warranties and disclaimer The CADScor®System is covered by a general 1-year warranty from date of purchase, that covers faulty hardware, including the CADScor®Sensor, the CADScor®Docking station and the external power adaptor. Furthermore, Acarix guarantees that the CADScor®System will be operational for at least 1000 recordings in the warranty period. If, however the CADScor®System does not operate properly, please first consult the "Troubleshooting guide"-section 11 in this manual describing possible errors. Any claims on warranty should be addressed to Acarix directly or to the Acarix distributor in your country, who will initiate replacement or repair of faulty equipment. 1.1 Disclaimer The information given in this document is adapted to an international market of healthcare professionals, based on illustrations, symbols and text. The document is giving no specific references to religious preference, ethnic origin, gender or political viewpoints. Any such relation is considered an interpretation of which Acarix cannot be held reliable. The information is intended to ensure the safe and accurate operation of the CADScor ® System. 2 Copyright notice The contents of this document shall not be reproduced or communicated in any form to any third party without the prior written consent of Acarix. 3 3 Changes This document is subject to change without notice and you are urged to contact Acarix to verify whether the document has been changed. The manual relevant to the specific equipment model can also be downloaded from the Acarix website. You can locate the specific model number (REF number) on the back of the aluminium frame of the CADScor ® Docking station. While every effort is made to ensure the correctness of the information provided in this printed manual Acarix disclaims any liability for errors and omissions herein. The illustrations used in this manual may differ slightly from the appearance of the actual device, packaging materials or interface and reflects on-going efforts to improve safety, usability and clarify the overall instructions given. 4 Trademarks and Third-party software CADScor ® is a registered trademark owned by Acarix. Third party software license agreements are listed in the back of this manual. US-FDA revision 12.5, Mar. 20 th , 2021. From software version 4.0 US-FDA. Acarix Ryvangs Allé 81-83 DK-2900 Hellerup Denmark www.acarix.com 4 Table of content 1 Warranties and disclaimer ................ 2 1.1 Disclaimer ................................... 2 2 Copyright notice ............................... 2 3 Changes ........................................... 3 4 Trademarks and Third-party software 3 5 Introduction ..................................... 6 5.1 About this manual......................... 6 5.2 The CADScor ® System and the environment .......................................... 6 5.3 Product description ....................... 7 5.4 Intended use ............................... 8 5.5 Use of the CAD-score .................... 8 5.6 Risk-Benefit for use ...................... 10 5.7 Intended user profile .................... 11 5.8 Intended patient population ........... 11 5.9 Indications for use ....................... 12 5.10 Contra-indications for use .......... 13 5.11 Intended conditions of use ......... 14 5.12 Symbols used .......................... 15 5.13 Symbols on the CADScor ® System and in User manual ................................ 15 5.14 Warnings ................................ 16 5.15 Precautions ............................. 16 5.16 CADScor ® System unboxing ........ 18 5.17 The CADScor ® Sensor ............... 20 5.18 CADScor ® Docking station .......... 22 6 Installation of CADScor ® System ......23 6.1 Desktop model ............................ 23 6.2 CADScor ® System wall mounting .... 25 6.3 CADScor ® Patch box opening.......... 27 6.4 The CADScor ® Patch ..................... 28 6.5 The CADScor ® Patch, assembly ....... 29 6.6 Confirming correct sensor-patch assembly ............................................. 30 7 Setting up the CADScor ® System prior to use ....................................................31 7.1 CADScor ® Sensor ......................... 31 7.2 First time configuration of the CADScor ® Sensor ................................... 31 7.3 Setting language ......................... 34 7.4 Setting time ............................... 35 7.5 Setting date ............................... 36 7.6 Finishing Sensor SET-UP ............... 37 7.7 Universal access .......................... 37 7.8 CADScor ® Docking station.............. 39 7.9 Connecting/disconnecting power adapter to Docking station ...................... 40 7.10 Charging of the sensor battery ...... ............................................. 40 5 7.11 Docking station indication LED light ............................................. 41 7.12 Qualification of sensor ............... 42 7.13 Forced qualification................... 43 7.14 Re-setting sensor ..................... 44 8 Detection of heart sounds............... 45 8.1 Preparing the examination room .... 45 8.2 Preparing the sensor .................... 46 8.3 Preparing the patient ................... 47 8.4 Identifying the fourth left Inter Costal space (IC4-L) ....................................... 48 8.5 Attachment of patch to sensor ....... 51 8.6 Explaining of the recording procedure to patient ............................................. 52 8.7 Recording phase, patient risk factors . ................................................ 54 8.8 Recording phase, Start ................. 65 8.9 Recording phase, Main recording ....... ................................................ 66 8.10 Recording phase, cancelling ....... 67 8.11 Recording phase, CAD-scoring ....... ............................................. 68 8.12 Short diastole CAD-score ........... 69 8.13 QR-code for printing, archiving and sending a CADScor patient report............. 70 8.14 CA…

Text truncated - open the document above for the full version.

Page 1 of 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Monday, April 26 th , 2021 CADScor System Product notification inlay Notification This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Mon day, March 29 th , 20 21 ... Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Agent authorization letter for: Product name: CADScor sensor with FCC ID: 2AYXI-ASE1401 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AYXI-ASE1401, including signing of all documents relating to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from Acarix A/S. Please contact me if there is any information you may need. Sincerely, Claus Bo Vöge Christensen PhD, MBA, COO Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Tel: +45 2972 4411 Tel-con: +45 7026 5045, code 9958 136#. Email: [email protected] Web: www.acarix.com

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Mon day, March 29 th , 20 21 ... Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Consultant authorization letter for: Product name: CADScor sensor with FCC ID: 2AYXI-ASE1401 To whom it may concern: We, the undersigned, hereby authorize FORCE Technology, normally named FORCE, to act on our behalf relating to application for equipment authorization for FCC ID: 2AYXI-ASE1401. FORCE can receive and exchange data between the parties but cannot sign documents. This agreement expires when the Grant of Equipment Authorization has been issued. Please contact me if there is any information you may need. Sincerely, Claus Bo Vöge Christensen PhD, MBA, COO Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Tel: +45 2972 4411 Tel-con: +45 7026 5045, code 9958 136#. Email: [email protected] Web: www.acarix.com

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Mon day, March 29 th , 20 21 ... Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Confidentiality request for: Product name: CADScor sensor with FCC ID: 2AYXI-ASE1401 To Whom It May Concern: This letter serves as an official request for permanent confidentiality under FCC Rule, 47 CFR Part 0, Subpart C (Specific rule part §0.459). We have requested that the following attachments: Schematics, Circuit Description, Block diagrams, Operational descriptions, Parts lists and Tune-up procedures required to be submitted with this application is to be withheld from public review. These documents contain detailed system and equipment description and related information about the product which Acarix A/S considers being proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Acarix A/S considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Claus Bo Vöge Christensen PhD, MBA, COO Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Tel: +45 2972 4411 Tel-con: +45 7026 5045, code 9958 136#. Email: [email protected] Web: www.acarix.com

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Friday, March 26 th , 2021 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 USA Re: Label without the FCC identifier and compliance statement letter for: Product name: CADScor sensor with FCC ID 2AYXI-ASE1401. To whom it may concern: The text as defined in §15.19(a)(3) and §2.925(f) is too large to be placed on the label of the Device. Therefore, it will be placed in a prominent location of the User Guide/ Electronic Labelling. Sincerely, Claus Bo Vöge Christensen, PhD, MBA COO __________________________________________________________ Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Tel: +45 2972 4411 Tel-con: +45 7026 5045, code 9958 136#. Email: [email protected] Web: www.acarix.com

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Thursday, April 29 th , 2021 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Electronic Labelling Statement acc. to KDB 784748 D02 e labelling v01 Company name: Acarix A/S FCC ID: 2AYXI-ASE1401 FCC Part 15 Certification To whom it may concern: II. GUIDANCE FOR DEVICES WITH INTEGRATED SCREEN USING E-LABEL A. Information to be displayed 1. The FCC ID and/or the Declaration of Conformity (DoC) logo (if applicable). 2. Any other information required by specific rule to be provided on the surface of the product unless such information is permitted to be included in the User’s manual or other packaging inserts. B. Access to the required information on the e-label 1. Users must be able to access the information without requiring special access codes or permissions and, in all cases the information must be accessible in no more than three steps in a device’s menu.6 2. Devices must not require special accessories or supplemental plug-ins (e.g., the installation of a SIM/USIM card) to access the information. 3. Users must be provided specific instructions on how to access the information. The instructions must be included in the User’s manual, operating instructions, insert in the packaging materials, or other similar means.7 Alternately, the access information may be available on the product related website with instructions on how to access the website provided in the packaging material. 4. The equipment authorization application for the device must clearly include the instructions for accessing information as part of the exhibit showing the label information. Page 2 C. Labeling for Importation and Purchasing Products utilizing e-labels are required to have a physical label on the product at the time of importation, marketing and sales. For devices imported in bulk and not packaged individually, a removable adhesive label or, for devices in protective bags, a label on the bags is acceptable for this purpose. Any removable label shall be of a type intended to survive normal shipping and handling and must only be removed by the customer after purchase. For devices imported already in individual packages ready for sale, the information may alternatively be provided on the package. It shall contain: 1. The FCC ID and/or the DoC logo (if applicable); and 2. Any other information required by specific rule to be provided on the surface of the product unless such information is permitted to be included in the User’s manual or other packaging inserts. D. Other considerations 1. The above information must be programmed by the responsible party and the information must be secured in such a manner that third-parties cannot modify it. 2. All the applicable regulatory information required on the packaging or user instructions must be provided according to the rules even if it is displayed electronically. For example, hearing aid compatibility (HAC) ratings for the phones as specified in 47 C.F.R. § 20.19. 3. E-label displays may include regulatory information required to be placed in the User’s Manual or on the packaging as required by the rules. The following considerations must be taken into account for such information distribution. a. If the primary user manual or user guide is provided by other electronic media (e.g., CD, or online access) then as an option this information can also be provided as part of the e-label. b. The e-label format must clearly differentiate between the information required to be on the surface of the product and the information required for the User’s Manual or on the packaging. 4. Products subject to both certification and Declaration of Conformity or certification and Verification can use the e-label guidance by displaying both the FCC ID and an image of the FCC DoC Logo, or FCC ID and product identification as required by the rules. Sincerely, Signature Claus Bo Vöge Christensen, PhD, MBA COO Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark

Page 1 of 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Mon day, April 28 th , 20 21 CADScor System FCC ID in software Description of access to FCC ID in CADScor System sw. Implemented in the CADScor System software is a possibility to view the FCC ID. The FCC ID can be reached in two different ways; 1) Two click method By entering the Setting menu (one click “Enter setup” on display); Choose About (one click on “About” on display); View FCC ID 2) Button + One click method Triple-click on sensor button to go to Settings menu; Choose About (one click on “About” on display); View FCC ID.

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Tuesday, March 30 th , 2021 CADScor Sensor USB+RFID flex assy (A0471) top side: Page 2 CADScor Sensor USB+RFID flex assy (A0471) bottom side:

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Tuesday, March 30 th , 2021 CADScor Sensor P1054 flex and pushbutton flex assy (A0475) top side: Page 2 CADScor Sensor P1054 flex and pushbutton flex assy (A0475) bottom side:

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Tuesday, March 30 th , 2021 CADScor Sensor mainboard assy (A0473) top side: Page 2 CADScor Sensor mainboard assy (A0473) bottom side:

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Tuesday, March 30 th , 2021 CADScor Sensor mic pre-amp boards top side: Pre-amp heart assy A0733 Pre-amp psu assy A0734 Pre-amp amb+dummy assy A0735 Page 2 CADScor Sensor P1054 flex and pushbutton flex assy (A0475) bottom side: Pre-amp heart assy A0733 Pre-amp psu assy A0734 Pre-amp amb+dummy assy A0735

Page 1 Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Hellerup, Monday, March 29 th , 2021 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 USA Re: RF exposure information for: Product name: CADScor sensor with FCC ID 2AYXI-ASE1401. To whom it may concern: CADScor sensor is a portable device intended for use within 20 cm of humans and must demonstrate compliance to the either relevant SAR limits or demonstrate a maximum conducted output power less than the SAR exclusion thresholds pursuant to “KDB 447498 D01 General RF Exposure Guidance v06” at the specified distance to user and frequency range. The properties of CADScor sensor are as follows: • Maximum average conducted output power: 2.3 mW • Distance to user: < 50 mm • Frequency range: 13.110-14.010 MHz Maximum average conducted output power value is derived as: Supply input power to RFID interface subsystem x Max RFID duty cycle over 6 minutes = 2.8V x 81 mA x 1% = 2.3 mW Power threshold according to KDB 447498 4.3.1 c) 2): 442 mW The power threshold for SAR exclusion is respected hence CADScor sensor is compliant. Please contact me if there is any information you may need. Sincerely, Claus Bo Vöge Christensen, PhD, MBA COO __________________________________________________________ Acarix A/S Ryvangs Allé 81-83 DK-2900 Hellerup Denmark Tel: +45 2972 4411 Tel-con: +45 7026 5045, code 9958 136#. Email: [email protected] Web: www.acarix.com
