2AZ3T-SWAN-K1SWAN-K1

快速入门指南 Quick Start Guide SWAN-K1 V2.1 2021.6 请用type-C数据线连接您的充电头给遥控器充电。 组装机臂 / Assemble the arm 组装机翼 / Assemble the wing 请用充电器给电池充电。 Please connect your charger with a type-C data cable to charge the remote control. Please charge the battery with the charger. 1 充电 / Charging the Battery and Remote 2 组装飞行器/ Assemble the drone A A B B A-逆时针拧紧 A-Tighten counterclockwise. B-顺时针拧紧 B-Tighten clockwise. 黑桨帽 Black nut propeller 白桨帽 White nut propeller 标记 Marked Unmarked 无标记 Swan-K1机头方向 Aircraft head direction 长按开机/关机。 安装电池/ Install the battery 飞行模式切换 左摇杆 右摇杆 固定翼/旋翼切换 一键返航 Long press to start/shut down. Flight mode switch Left StickRight Stick Fixed wing / rotor switchOne-click return home 3 安装螺旋桨 / Attaching the Propellers 4 开启与关闭遥控器，安装飞行器电池/ Open and close the remote control,Install the battery 5 遥控器/ Remote Controller 在户外空旷环境，遥控器向左拨杆等待飞行器进入位置模式。飞行前请校准空速计和磁罗盘。 进入位置模式后，油门杆最低，航向杆最右解锁飞行器。电机转动后，请马上松开摇杆。 In an open outdoor environment, move the remote control to the left and wait for the aircraft to enter the position mode. Please calibrate the airspeed meter and compass before flying. After entering the position mode, the throttle stick is the lowest and the heading stick is the rightmost to unlock the aircraft. After the motor rotates, please release the joystick immediately. 定高模式定高模式位置模式 Altitude modeAltitude modePosition mode 7 位置模式 / Enter position mode 8 起飞前校准 / Calibrate 9 如何解锁（美国手）/ How to unlock(US hand) 6 摇杆操控飞行器/ Controlling the drone Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected 美国手旋翼模式 上升/下降上升/下降加速/减速 控制设置 Control 磁罗盘 Compass 空速计 Aipspeed 下降/爬升左转/右转向左/向右无左横滚/右横滚 美国手固定翼模式 American hand rotor mode Up/DownForward/ Backward Speed Up/ Slow down Fall/RiseTurn Left/RightTurn Left/ Right UselessRoll Left/ Roll Right American hand fixed wing model Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected FlightControlGeneral Rocker mode:America handJapanese hand Compass: Airspeed: Advanced Settings Calibrate （Tip：No compass calibrated) （Tip：No airspeed calibrated) Calibrate Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 定高模式旋翼模式电机锁定已连接 飞行设置控制设置通用设置 摇杆模式：美国手日本手 校准磁罗盘 校准空速计 高级设置 校准 （根据提示进行后续操作） （根据提示进行后续操作） 校准 Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected 上升 下降 Up Down 10 起飞与降落，固定翼/旋翼切换/ Take off and landing ,Fixed wing/rotor switch 水平地面 水平地面 Level ground Level ground 升高飞行器 降落 旋翼模式下操作飞行器升到30 米高度即可按遥控A按键切换 为固定翼模式。 再按一次遥控器的A按键，将切换回旋翼模式。 Take off Landing Operate the aircraft in rotor mode to rise to an altitude of more than 30 meters and press the remote control A button to switch to fixed wing mode. Press the A button on the remote control again to switch to the rotor mode . Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected 11 如何上锁（美国手）/ How to lock (US hands) 12 断开电源/ Disconnect the power Airspeed0.0m/sFlying speed 0.0m/sAltitude 0.0m/sHome distance 0.0m/sFlight time00:00 100% 17.4V 20 0.51 AltitudeRotorLockedconnected 飞行器降落在平地之后，将油门杆打到最低并保持几秒后电机停转。 After the aircraft lands on flat ground, hit the throttle stick to the lowest position and hold it for a few seconds before the motor stops. A A FCC Warning 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be operated with minimum distance 20cm from the body. IC Warning This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1)This device may not cause interference; (2)This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment should be operated with minimum distance 20cm from the body. CE Warning 1. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. 2. The operating temperature of the device can’t exceed 40 °C and shouldn’t be lower than -15 °C . 3. The device complies with RF specifications when the device used at 20cm from the body. Hereby, Shenzhen HEQ Intelligent Technology Co. LTD. declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to be used in all EU member states. This content is subject to change. Download the latest version from http:// www. hequavtech.com Copyright©2021 HEQ All Rights Reserved.

Shenzhen HEQ intelligent technology co. LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-07-05 Subject; Request for Long Term Confidentiality FCC ID: 2AZ3T-SWAN-K1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mingjun Dai Title: Hardware Supervisor

Shenzhen HEQ intelligent technology co. LTD Letter of Authorization Company: Shenzhen HEQ intelligent technology co. LTD Address: B1019, Tianhui building, east ring 1st Road, Fukang community, Longhua district, Shenzhen, Guangdong Product Name: SWAN-K1 Model Number: SWAN-K1 FCC Identifier: 2AZ3T-SWAN-K1 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Mingjun Dai Date: 2021-07-05 Title: Hardware Supervisor

7.EXTERANAL AND INTERNAL PHOTOS EXTERANAL PHOTOS M odel:SWAN-K1

label & location

INTERNAL PHOTOS Model:SWAN-K1

FCC ID: 2AZ3T-SWAN-K1 RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable Frequency range (MHz) Type Conducted Average Power (dBm) Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result 2420-2480 GFSK 4.08 5.00 0.0012 1.0000 Pass Note: 1) The maximum antenna gain is 2.74dBi 2) The exposure evaluation safety distance is 20cm.

Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 1 of 22 APPENDIX REPORT Project No. SHT2103084409EW Radio Specification GFSK Model No. SWAN-K1 Start test date 2021-05-25 Finish date 2021-05-25 Temperature 24.6°C Humidity 32% Test Engineer Hailey Chen Auditor Appendix clause Test item Result A Conducted Peak Output Power PASS B Power Spectral Density PASS C 6 dB Bandwidth PASS D 99% Occupied Bandwidth PASS E Duty Cycle PASS F Band edge and Spurious Emissions(coducted) PASS Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 2 of 22 Appendix A：Conducted Peak Output Power Type Channel Peak Output power (dBm) Average Output power (dBm) Limit (dBm) Result Antenna 0 Antenna 1 Total Antenna 0 Antenna 1 Total GFSK CH L 0.33 1.71 4.08 0.27 1.65 4.02 ≤30.00 Pass CH M -0.21 1.29 3.61 -0.26 1.24 3.56 CH H -0.64 0.91 3.21 -0.71 0.84 3.14 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 3 of 22 GFSK Antenna 0 CH L Date: 25.MAY.2021 09:16:02 CH M Date: 25.MAY.2021 09:20:32 CH H Date: 25.MAY.2021 09:23:29 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 4 of 22 GFSK Antenna 1 CH L Date: 25.MAY.2021 09:31:25 CH M Date: 25.MAY.2021 09:35:36 CH H Date: 25.MAY.2021 09:27:15 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 5 of 22 Appendix B：Power Spectral Density Type Channel Power Spectral Density (dBm/30KHz) Total Power Spectral Density (dBm/3KHz) Limit (dBm/ 3KHz) Result Antenna 0 Antenna 1 GFSK CH L -9.01 -7.62 -5.25 ≤8.00 Pass CH M -9.44 -7.99 -5.64 CH H -10.07 -8.46 -6.18 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 6 of 22 GFSK Antenna 0 CH L Date: 25.MAY.2021 09:16:43 CH M Date: 25.MAY.2021 09:21:08 CH H Date: 25.MAY.2021 09:24:08 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 7 of 22 GFSK Antenna 1 CH L Date: 25.MAY.2021 09:32:09 CH M Date: 25.MAY.2021 09:36:22 CH H Date: 25.MAY.2021 09:27:52 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 8 of 22 Appendix C：6dB Bandwidth Type Channel 6dB Bandwidth (MHz) Limit (kHz) Result Antenna 0 Antenna 1 GFSK CH L 1.056 1.068 ≥500 Pass CH M 1.062 1.059 CH H 1.062 1.050 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 9 of 22 GFSK Antenna 0 CH L Date: 25.MAY.2021 09:15:47 CH M Date: 25.MAY.2021 09:19:59 CH H Date: 25.MAY.2021 09:22:58 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 10 of 22 GFSK Antenna 1 CH L Date: 25.MAY.2021 09:30:50 CH M Date: 25.MAY.2021 09:34:58 CH H Date: 25.MAY.2021 09:26:44 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 11 of 22 Appendix D：99% Occupied Bandwidth Type Channel 99% Bandwidth (MHz) Limit (kHz) Result Antenna 0 Antenna 1 GFSK CH L 1.47 1.47 - Pass CH M 1.48 1.47 CH H 1.47 1.48 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 12 of 22 GFSK Antenna 0 CH L Date: 25.MAY.2021 09:15:00 CH M Date: 25.MAY.2021 09:20:17 CH H Date: 25.MAY.2021 09:23:14 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 13 of 22 GFSK Antenna 1 CH L Date: 25.MAY.2021 09:31:10 CH M Date: 25.MAY.2021 09:35:21 CH H Date: 25.MAY.2021 09:27:01 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 14 of 22 Appendix E：Duty Cycle Test Frequency （MHz） T on time for single burst (ms) T period (ms) Duty cycle 1/T on time (kHz) 2450 0.35 1.02 34.3% 2.9 Date: 25.MAY.2021 09:19:34 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 15 of 22 Appendix F：Band Edge and Spurious Emissions (Conducted) Test Item: Bandedge Antenna 0 CH L Date: 25.MAY.2021 09:17:38 CH H Date: 25.MAY.2021 09:24:23 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 16 of 22 Test Item: Bandedge Antenna 1 CH L Date: 25.MAY.2021 09:32:35 CH H Date: 25.MAY.2021 09:28:08 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 17 of 22 Test Item: SE Antenna 0 CH L Reference level Date: 25.MAY.2021 09:17:58 CH L 30MHz~1000MHz Date: 25.MAY.2021 09:18:19 CH L 1GHz~26GHz Date: 25.MAY.2021 09:18:42 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 18 of 22 CH M Reference level Date: 25.MAY.2021 09:21:29 CH M 30MHz~1000MHz Date: 25.MAY.2021 09:21:51 CH M 1GHz~26GHz Date: 25.MAY.2021 09:22:13 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 19 of 22 CH H Reference level Date: 25.MAY.2021 09:24:41 CH H 30MHz~1000MHz Date: 25.MAY.2021 09:25:02 CH H 1GHz~26GHz Date: 25.MAY.2021 09:25:24 Project No.: SHT2103084409EW Radio Specification: GFSK Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 20 of 22 Test Item: SE Antenna 1 CH L Reference level Date: 25.MAY.2021 09:33:00 CH L 30MHz~1000MHz Date: 25.MAY.2021 09:33:21 CH L 1GHz~26GHz Date: 25.MAY.2021 …

Text truncated - open the document above for the full version.

Page: 1 of 31 TEST REPORT Report No. ...................................... : CHTEW21060172 Report Verification: Project No.................................： SHT2103084409EW FCC ID ............................................. : 2AZ3T-SWAN-K1 Applicant’s name ........................... : Shenzhen HEQ intelligent technology co. LTD Address ............................................. : B1019, Tianhui building, east ring 1st Road, Fukang community, Longhua district, Shenzhen, Guangdong Test item description .................... : SWAN-K1 Trade Mark ....................................... : HEQ Model/Type reference ....................... : SWAN-K1 Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: May. 11, 2021 Date of testing.............................: May. 12, 2021- Jun. 21, 2021 Date of issue...............................: Jun. 22, 2021 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Silvia Li Supervised by (Position+Printed name+Signature): Project Engineer Aaron Fang Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW21060171 Page: 2 of 31 Issued: 2021-06-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 6 4.1. Test frequency list 6 4.2. Test mode 6 4.3. Support unit used in test configuration and system 6 4.4. Testing environmental condition 7 4.5. Measurement uncertainty 7 4.6. Equipment Used during the Test 8 5. TEST CONDITIONS AND RESULTS 9 5.1. Antenna Requirement 9 5.2. AC Conducted Emission 10 5.3. Peak Output Power 11 5.4. Power Spectral Density 12 5.5. 6dB bandwidth 13 5.6. 99% Occupied Bandwidth 14 5.7. Duty Cycle 15 5.8. Conducted Band edge and Spurious Emission 16 5.9. Radiated Band edge Emission 17 5.10. Radiated Spurious Emission 19 6. TEST SETUP PHOTOS 23 7. EXTERANAL AND INTERNAL PHOTOS 24 8. APPENDIX REPORT 31 Report No.: CHTEW21060171 Page: 3 of 31 Issued: 2021-06-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2021-06-22 Original Report No.: CHTEW21060171 Page: 4 of 31 Issued: 2021-06-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result 5.1 Antenna Requirement 15.203/15.247(c) PASS 5.2 AC Conducted Emission 15.207 N/A 5.3 Peak Output Power 15.247(b)(3) PASS 5.4 Power Spectral Density 15.247(e) PASS 5.5 6dB Bandwidth 15.247(a)(2) PASS 5.6 99% Occupied Bandwidth - PASS *1 5.7 Duty cycle - PASS *1 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS 5.9 Radiated Band Edge Emission 15.205/15.209 PASS 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW21060171 Page: 5 of 31 Issued: 2021-06-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3. SUMMARY 3.1. Client Information Applicant: Shenzhen HEQ intelligent technology co. LTD Address: B1019, Tianhui building, east ring 1st Road, Fukang community, Longhua district, Shenzhen, Guangdong Manufacturer: Shenzhen HEQ intelligent technology co. LTD Address: B1019, Tianhui building, east ring 1st Road, Fukang community, Longhua district, Shenzhen, Guangdong 3.2. Product Description Name of EUT: SWAN-K1 Trade Mark: HEQ Model No.: SWAN-K1 Listed Model(s): - Power supply: DC 14.8V Battery Information: DC 14.8V,6000mAh Adapter Information: - Hardware version: V1.3 Software version: V1.3 3.3. Radio Specification Description Modulation: GFSK Operation frequency: 2420-2480MHz Channel number: 3 Channel separation: 30MHz Antenna type: Whip antenna Antenna gain: 2.74dBi Report No.: CHTEW21060171 Page: 6 of 31 Issued: 2021-06-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3.4. Testing Laboratory Information Laboratory Name Shenzhen Huatongwei Intern…

Text truncated - open the document above for the full version.

6.TEST SETUP PHOTOS Radiated Emission Model:SWAN-K1
