YF-MC-088 wireless door magnetic instruction manual Intelligent home security system is composed of intelligent home host and security alarm series sensors. The security alarm sensor series can be divided into magnetic door, curtain, gas detector, smoke detector, human body infrared detector, leakage sensor, etc. Wireless door magnetic sensors are used to detect whether doors, Windows, drawers, etc., are illegally opened or moved. Wireless door magnetic sensor comes with a wireless transmitter, when the host is protected under the state of the door or window is opened, the door magnetic sensor will take the initiative to send a wireless signal to the host, the host will take relevant measures after receiving the alarm signal, such as through the phone, SMS alarm to inform the owner in time, so as to prevent illegal entry, to defend the safety of the home. I. Specifications and parameters Wireless door magnetic sensor Ø transmitting frequency: 433.92 MHZ Ø launch distance: more than 100 meters (empty range), Ø movement distance: 10 mm Ø Static current : ua 4 or less Ø alarm current: 10 ma, or less This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction.
