2AZ56115715Smart Tool Holder

www.wto-tools.com 1 Operating Instruction Smart Driven Tool Holders with QuickFlex® Type DNI Type DNE B85000 en 2 B85000 en Introduction © 2022 WTO Werkzeug-Einrichtungen GmbH. All rights reserved. This document may not be copied or reproduced in whole or in part, or transferred to any other media or language, by any means, without the prior written permission of WTO Werkzeug- Einrichtungen GmbH. Operating Instruction for Smart Driven Tool Holders with QuickFlex® can be downloaded in several languages. Translation de Translation es Translation fr Translation it Translation jp Translation ko Translation ru Translation tw Translation zh Translation cz www.wto-tools.com 3 General WTO Smart Driven Precision Tool Holders (smart DTH) are high quality products with low maintenance requirements. A smart DTH includes the electronic unit WTO SC 002. Please follow these instructions to maintain a high accuracy and a long service life. This manual contains important safety directions and instructions for product setup and operation. Keep for further reference Product identification Product type and article numbers are printed on the product. Refer to this when contacting WTO. Validity of this manual This manual applies to the smart DTH with QuickFlex®, Chapter 3 describes the naming rules. 4 B85000 en Content 1 SAFETY 6 1.1 General 6 1.2 Purpose 7 1.3 Limits of use 7 1.4 Areas of responsibility 8 1.5 Hazard of use 9 1.6 Unpacking 10 1.7 Power-off magnet 10 1.8 Battery 11 2 QUICK START GUIDE 12 3 PRODUCT DESCRIPTION 13 4 SYSTEM COMPONENT DESCRIPTION 14 5 ELECTRONIC UNIT WTO SC 002 15 5.1 Intended use 15 5.2 Symbols on the WTO SC 002 16 5.3 Control unit 16 5.4 Power unit 17 6 OPERATING ADVICE FOR ELECTRONIC UNIT WTO SC 002 18 6.1 Insert battery 18 6.2 Exchange battery 19 6.3 Updating the Firmware 20 6.4 Energy saving mode 20 6.5 Activate electronic unit 20 7 MECHANICAL INSTRUCTIONS 21 7.1 Installation and operation advice 21 7.2 Break in period 22 7.3 Changing the cutting tool 23 7.4 Changing the QuickFlex® adapter 24 7.5 smart DTH with internal coolant supply 25 7.6 Plug smart DTH coolant nozzle to use for IC only 25 7.7 Ball nozzle options 26 7.8 Copper pipe fitting options 26 www.wto-tools.com 5 7.9 Collet solutions for smart DTH with internal coolant supply 27 7.10 Adjusting the projection length of the cutting tool 27 7.11 One-hand wrench 27 7.12 Available ER collet nuts for QuickFlex® 28 7.13 Turret centerline alignment 29 7.14 Duty cycle ratio 30 7.15 Service interval 30 8 CARE AND CLEANING 31 9 STORAGE AND TRANSPORT 32 9.1 Storage 32 9.2 Shipment 32 9.3 Shipping claims 32 10 CONFORMITY FOR ELECTRONIC COMPONENTS 33 10.1 EU Declaration of conformity 33 10.2 FCC Compliance statement (USA) 34 10.3 Industry Canada compliance statement (Canada) 35 10.4 Japan 36 11 WARRANTY 37 12 DISPOSAL 37 13 TECHNICAL DATA OF ELECTRONIC COMPONENTS 38 14 SMART DTH TOLERANCES 39 6 B85000 en 1 Safety 1.1 General Description The following instructions should enable the person responsible for the product and the person who actually uses the equipment to anticipate and avoid operational hazards. The person responsible for the product must ensure that all users understand these instructions and adhere to them. Generalities When operating and using our smart DTH, observe the safety regulations of the regional associations and the safety laws and guidelines of the respective state and/or the European Union. Above such regulations, observe the safety instructions of the manufacturer of your machine tool. About warning messages Warning messages are an essential part of product safety. They appear wherever hazards or hazardous situations can occur. For user safety, all safety instructions and safety messages shall be strictly observed and followed. Therefore, the manual must always be available to all product users. DANGER, WARNING, CAUTION and NOTICE are standardized signal words for identifying levels of hazards and risks related to personal injury and property damage. For your safety it is important to read and fully understand the table below with the different signal words and their definitions. Supplementary safety information symbols may be placed within a warning message as well as supplementary information. DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor or moderate injury. NOTICE Important information which must be adhered to in practice as it enables the product to be used in a technically correct and efficient manner. www.wto-tools.com 7 1.2 Purpose Permitted use To prepare Smart Driven Tool Holders with QuickFlex® for operation. Adverse use • Use of the product without instruction • Use outside of the intended limits • Disabling safety systems • Removal of hazard notices • Opening the product using tools, e.g., screwdriver, unless specifically instructed for certain functions • Modification or conversion of the product • Use after misappropriation • Use of products with obviously recognizable damages or defects • Use with accessories from other manufacturers without the prior approval of WTO WARNING Adverse use can lead to injury, malfunction and damage. It is the task of the person responsible for the equipment to inform the user about hazards and how to counteract them. The product is not to be operated until the user has been instructed on how to work with it. 1.3 Limits of use Environment Suitable for use under rough conditions, ref. technical data. Not suitable for use in aggressive or explosive environments. 8 B85000 en 1.4 Areas of responsibility Manufacturer of the product WTO is responsible for supplying the product, including the operating instruction and original accessories, in a complete…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/26/2023 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AZ56115715 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Karlheinz Jansen Technical Director WTO Werkzeug-Einrichtungen GmbH

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/26/2023 Request for Permanent Confidentiality Company name: WTO Werkzeug-Einrichtungen GmbH FCC ID: 2AZ56115715 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 WTO Werkzeug-Einrichtungen GmbH hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which WTO Werkzeug-Einrichtungen GmbH considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, WTO Werkzeug-Einrichtungen considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature Karlheinz Jansen Technical Director WTO Werkzeug-Einrichtungen GmbH Auf der oberen Au 45 D-77797 Ohlsbach

Date: 2023-01-26 Federal Communication Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Statement of re-use of original test results of approved radio modules according to KDB 996369 D02 Module Q and A v01 Q1(a) Reference of new FCC ID application: Applicant: WTO Werkzeug-Einrichtungen GmbH FCC ID: 2AZ56115715 We, the undersigned, hereby declare that our radio device hosts the following approved radio module(s) Grantee: TAIYO YUDEN CO., LTD. Type of Module: Single Modular FCC ID: RYYEYSKBN Report Reference TRpt DTS_No 12510206S-A-R3 The module(s) is/are installed according to the installation instructions of the module manufacturer(s) without modification. The original module test report(s) accurately represent all conducted measured test results under the new conditions. All radiated measurements according to the applicable radio standard(s), the rf-exposure and simultaneous transmission evaluation are performed and reported for the entire host. Sincerely, Signature Karlheinz Jansen Technical Director WTO Werkzeug-Einrichtungen GmbH

FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 EUT: WTO SC 002 (mounted on tool holder) FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232

FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 EUT: WTO SC 002 (mounted on tool holder) – Label placement

FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 Bluetooth module top view FCC ID: 2AZ56115715 IC: 27343‐115715 HVIN: WTO SC 002 G0M‐2112‐1232 Bluetooth module bottom view

Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 15 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1091 ISED RSS-102 Maximum permissible exposure Report Reference No G0M-2112-1232-TFC091MP-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Test Firm Designation Number: DE0008 Applicant WTO Werkzeug-Einrichtungen GmbH Address Neuer Hohdammweg 1 77797 Ohlsbach Germany Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1091 ISED RSS-102 Non-Standard Test Method None Equipment under Test (EUT): Product Description SDTH Controller Model(s) WTO SC 002 Additional Model(s) None Brand Name(s) WTO Hardware Version(s) K / EH40 Software Version(s) 2.3.00 FCC ID 2AZ56115715 IC 27343-115715 Test Result PASSED Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 15 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2022-08-08 Initial Release Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 15 Additional Variants (not tested and not evaluated variants) Not-tested Variant Description 1 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH40 Software Version 2.3.00 2 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH10 Software Version 2.3.00 3 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH10 Software Version 2.3.00 4 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH30 Software Version 2.3.00 5 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH30 Software Version 2.3.00 6 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH50 Software Version 2.3.00 7 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH50 Software Version 2.3.00 8 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH63 Software Version 2.3.00 9 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH63 Software Version 2.3.00 Comment: Those named additional variants above have not been tested. Those additional variants of the series have been declared by the manufacturer. The test report explicitly states that those variants were neither tested nor assessed nor evaluated. Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 15 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power EUT Equipment Under Test MPE Maximum Permissible Exposure Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 15 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 7 1.1 Reference Documents ................................................................................................................................... 8 1.2 Power density radiation sources.................................................................................................................... 9 1.3 Field strength radiation sources .................................................................................................................... 9 1.4 Concurrent Sources ...................................................................................................................................... 9 2 Result Summary ............................................................................................................................... 10 3 RF-Exposure classification ............................................................................................................ 11 4 RF-Exposure limits .......................................................................................................................... 12 5 RF-Exposure Evaluation ................................................................................................................. 13 6 Single Source Evaluation Results - FCC ...................................................................................... 14 7 Single Source Evaluation Results - ISED ..................................................................................... 15 Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 15 1 Equipment (Test Item) Under Test Description SDTH Controller Model WTO SC 002 Additional Model(s) None Brand Name(s) WTO Serial Number(s) L22-000021-1.5 Test Sample ID 40521 Hardware Version(s) K / EH40 Software Version(s) 2.3.00 PMN WTO SC 002 HVIN WTO SC 002 FVIN 2.3.0 HMN n/a FCC ID 2AZ56115715 IC 27343-115715 Equipment type End Product Environment General public Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 15 1.1 Reference Documents Document Type Document No. Issued by Date Radio test report 12510206S-A-R3 FCC Part 15 Subpart C: 2018 12510206S-A-R3 UL Japan, Inc. Shonan EMC Lab. 2018-11-16 Test Report No.: G0M-2112-1232-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 15 1.2 Power density radiation sources Mode Operating Frequency [MH…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 30 EMC TEST REPORT Title 47 CFR Part 15B, ISED ICES-003 Issue 7 Report Reference No G0M-2112-1232-EF0115B-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA - Registration number: 1983.01 (ISED) ISED wireless device testing laboratory: CN 3470A DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant WTO Werkzeug-Einrichtungen GmbH Address Neuer Hohdammweg 1 77797 Ohlsbach Germany Test Specification Standard(s) Title 47 CFR Part 15 Subpart B ISED ICES-Gen Issue 1 ; Amendment 1 (February 2021) ISED ICES-003 Issue 7 ANSI C63.4:2014+A1:2017 Non-Standard Test Method None Equipment under Test (EUT): Product Description SDTH Controller Model(s) WTO SC 002 Additional Model(s) None Brand Name(s) WTO Hardware Version(s) K / EH40 Software Version(s) 2.3.00 FCC-ID 2AZ56115715 IC 27343-115715 Test Result PASSED Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 30 Additional Variants (not tested and not evaluated variants) Not-tested Variant Description 1 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH40 Software Version 2.3.00 2 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH10 Software Version 2.3.00 3 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH10 Software Version 2.3.00 4 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH30 Software Version 2.3.00 5 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH30 Software Version 2.3.00 6 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH50 Software Version 2.3.00 7 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH50 Software Version 2.3.00 8 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH63 Software Version 2.3.00 9 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH63 Software Version 2.3.00 Comment: Those named additional variants above have not been tested. Those additional variants of the series have been declared by the manufacturer. The test report explicitly states that those variants were neither tested nor assessed nor evaluated. Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 30 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada T NOM Nominal operating temperature V NOM Nominal supply voltage Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 30 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2022-07-25 Initial Release - Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 30 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 7 1.1 Equipment Ports ............................................................................................................................................ 8 1.2 Equipment Photos - Internal .......................................................................................................................... 9 1.3 Equipment Photos - External ....................................................................................................................... 13 1.4 Support Equipment ...................................................................................................................................... 17 1.5 Operational Modes ...................................................................................................................................... 17 1.6 EUT Configuration ....................................................................................................................................... 17 1.7 Sample emission level calculation ............................................................................................................... 18 2 Result Summary ............................................................................................................................... 19 2.1 Test Conditions and Results - Radiated emissions acc. to ANSI C63.4 ...................................................... 20 3 Measurement Uncertainty .............................................................................................................. 30 Test Report No.: G0M-2112-1232-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 30 1 Equipment (Test Item) Under Test Description SDTH Controller Intended Use Smart Driven Tool Holders Controller The electronic unit type WTO SC 002 enables the transmission of sensor data of tool holders based on Bluetooth® low energy 5.0 technology. This enables condition monitoring and predictive maintenance Model WTO SC 002 Additional Model(s) None Brand Name(s) WTO Hardware Version(s) K / EH40 Software Version(s) 2.3.00 Number of tested samples 1 Sample Identification EUT # Sample-ID Serial Number EUT 1 37517 L22-000021-1.2 EUT Dimensions [cm] 4.2 x 3.5 x 1.95 FCC-ID 2AZ56115715 IC 27343-115715 Class Cla…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 37 RADIO REPORT FCC 47 CFR Part 15C ISED Canada RSS-247 Digital transmission systems operating within the 2400.0 MHz - 2483.5 MHz band Report Reference No G0M-2112-1232-TFC247BL-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant WTO Werkzeug-Einrichtungen GmbH Address Neuer Hohdammweg 1 77797 Ohlsbach Germany Test Specification 47 CFR Part 15C RSS-247, Issue 2, 2017-02 RSS-Gen, Issue 5, Amendment 2, 2021-02 Non-Standard Test Method None Equipment under Test (EUT): Product Description SDTH Controller Model(s) WTO SC 002 Additional Model(s) None Brand Name(s) WTO Hardware Version(s) K / EH40 Software Version(s) 2.3.00 FCC ID 2AZ56115715 IC 27343-115715 Test Result PASSED Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 37 ADDITIONAL VARIANTS Additional Variants (not tested and not evaluated variants) Not-tested Variant Description 1 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH40 Software Version 2.3.00 2 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH10 Software Version 2.3.00 3 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH10 Software Version 2.3.00 4 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH30 Software Version 2.3.00 5 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH30 Software Version 2.3.00 6 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH50 Software Version 2.3.00 7 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH50 Software Version 2.3.00 8 Product Type Description SDTH Controller Model name WTO SC 002 Brand name WTO Hardware Version K / EH63 Software Version 2.3.00 9 Product Type Description SDTH Controller Model name WTO SC 002 Brand name Coromant Capto® DTH Plus Hardware Version K / EH63 Software Version 2.3.00 Comment: Those named additional variants above have not been tested. Those additional variants of the series have been declared by the manufacturer. The test report explicitly states that those variants were neither tested nor assessed nor evaluated. Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 37 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2022-08-23 Initial Release Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 37 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada RBW Resolution bandwidth RMS Root mean square VBW Video bandwidth V NOM Nominal supply voltage Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 37 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 7 1.1 Photos – Equipment External ........................................................................................................................ 8 1.2 Photos – Equipment Internal ....................................................................................................................... 12 1.3 Support Equipment ...................................................................................................................................... 15 1.4 Test Modes ................................................................................................................................................. 16 1.5 Test Frequencies ......................................................................................................................................... 17 1.6 Sample emission level calculation ............................................................................................................... 18 2 Result Summary ............................................................................................................................... 19 3 Test Conditions and Results .......................................................................................................... 20 3.1 Test Conditions and Results - Transmitter radiated emissions ................................................................... 20 3.2 Test Conditions and Results - Receiver radiated emissions ....................................................................... 25 ANNEX A Transmitter spurious emissions ....................................................................................................... 29 ANNEX B Receiver spurious emissions ........................................................................................................... 34 Test Report No.: G0M-2112-1232-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 37 1 Equipment (Test Item) Under Test Description SDTH Controller Model WTO SC 002 Additional Model(s) None Brand Name(s) WTO Serial Number(s) L22-000021-1.5 Test Sample ID 40521 Hardware Version(s) K / EH40 Software Version(s) 2.3.00 PMN WTO SC 002 HVIN WTO SC 002 FVIN 2.3.0 HMN…

Text truncated - open the document above for the full version.

27-Feb.2019 Ver.1.0 TAIYO YUDEN CO., LTD. TAIYO YUDEN CO., LTD. 1/30 EYSKBNZWB Bluetooth ® low energy Module Bluetooth ® 5.0 low energy EYSKBNZWB Data Report The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TAIYO YUDEN CO., LTD. is under license. 27-Feb.2019 Ver.1.0 TAIYO YUDEN CO., LTD. TAIYO YUDEN CO., LTD. 2/30 EYSKBNZWB Document constituent list Control name Control No. Document Page General Items HD-AG-A171172 1/6 - 6/6 Absolute maximum ratings HD-AM-A171172 1/1 Electrical characteristics HD-AE-A171172 1/4 - 4/4 Circuit schematic HD-MC-A171172 1/4 - 4/4 Outline / Appearance HD-AD-A171172 1/1 Pin Layout HD-BA-A171172 1/3 - 3/3 Handling Precaution HQ-BA-537 1/2 - 2/2 Packaging Specification HD-BB-A171172 1/3 - 3/3 Antenna application note 1/3 - 3/3 Design guide 1/1 Precautions HQ-BK-002_02 1/2 - 2/2 Revision History 27-Feb.-2019 > Ver.1.0 Release 27-Feb.2019 Ver.1.0 TAIYO YUDEN CO., LTD. TAIYO YUDEN CO., LTD. 3/30 EYSKBNZWB Control No. HD-AG-A171172 (1/6) Control name General Items 1. Scope This specification (“Specification”) applies to the hybrid IC “EYSKBNZWB”, a Bluetooth ® 5.0 low energy module (“Product”) manufactured by TAIYO YUDEN Co., Ltd. (“TAIYO YUDEN”) 2. Description a) User Code : EYSKBNZWB Type : EYSKBN *User Code may be changed for mass production or other cases. Note: Please use the User Code (EYSKBNZWB) to order this product b) Chip : Nordic nRF52840 (1MB Flash, 256kB RAM) c) Function : Radio frequency transceiver Module. Bluetooth®5.0 conformity. d) Application : IoT devices, Health & Fitness Equipment, Sensor, Toys e) Structure : Hybrid IC loaded with silicon monolithic semiconductor Containment of hazardous substance in this Product Can meet with RoHS compliance (Pb, Cd, Hg, Cr+6, PBB, PBDE) f) Outline : 63-pin Land Grid Array g) Marking : Part Number, Lot Nu…

Text truncated - open the document above for the full version.
