1 AIROUND SMART HOME DIFFUSER 32 Manuale d’uso 5 User manual 21 Manual de usuario 37 Manual de utilização 53 Bedienungsanleitung 69 Manuel d’utilisation 85 دليل الاستخدام 101 使用手册 113 使用マニュアル 125 54 Acqua di Parma è dal 1916 il simbolo del più luminoso stile italiano. Uno stile che si riconosce dalla qualità, dalla creatività e dall’eleganza, da un saper vivere e saper fare esclusivamente italiani. Da sempre protagonista dell’arredamento di lusso e ambasciatrice dell’eccellenza italiana in tutto il mondo, Poltrona Frau coltiva fin dalle sue origini una cultura della pelle unica insieme al design e alla ricerca. Due realtà storiche, icone del Made in Italy si uniscono dando vita ad un oggetto all’avanguardia e ad una coinvolgente esperienza multisensoriale. Nasce così il primo Smart Home Diffuser progettato da GamFratesi tra domotica, estetica e innovazione. Un oggetto in cui le suggestive valenze tattili e visive della PELLE FRAU® incontrano la fresca luminosità delle fragranze della Home Collection di Acqua di Parma. Con la sua sofisticata presenza scenica, il diffusore domotico si ispira alla forma al cerchio, che appartiene da sempre al mondo di Acqua di Parma e alle sue iconiche cappelliere, traducendolo in un design organico, minimalista e leggero reso ancora più unico grazie alla sofisticata tecnologia per la programmazione che ne permette la perfetta fruizione olfattiva. L’innovazione di un’esperienza non solo olfattiva, nel segno del design, della tecnologia e della maestria artigianale italiana IL FUTURO DELLE PROFUMAZIONI D’AMBIENTE 76 IMPORTANTI ISTRUZIONI PER L’USO Il presente manuale contiene informazioni importanti per il corretto e sicuro utilizzo del vostro smart home diffuser. Si consiglia di seguire le varie fasi di montaggio e di conservare queste istruzioni anche per il futuro. • Posizionare il prodotto su una superficie piana, libera. Evitare di coprire/ostruire le prese d’aria posizionate sul fondo. • Il diffusore non deve essere esposto all’acqua o all’umidità. • Non collocare il diffusore in prossimità di fonti di calore (caminetti, radiatori ...). • Non collocare il diffusore in prossimità di fonti d’aria (ventilatori, condizionatori d’aria..). SMART HOME DIFFUSER Il diffusore consente di diffondere nell’ambiente fino a tre fragranze alternativamente. Se connesso ad una rete Internet WI-FI può essere gestito tramite cellulare, con un’apposita app, oppure dal computer accedendo al sito web dedicato. In alternativa, può anche essere utilizzato in modalità off-line grazie all’uso di appositi pulsanti. 98 la manutenzione del diffusore non devono essere eseguite da bambini senza supervisione. Per ricaricare l’apparecchio usare esclusivamente l’alimentatore fornito. Il diffusore è consigliato per profumare spazi di circa 30 m 2 . Per ottimizzare la diffusione posizionare l’apparecchio in una zona centrale della stanza. La diffusione e ventilazione non deve essere ostacolata, le aperture non devono essere ostruite. • Il diffusore è dotato di una batteria agli ioni di litio. • Non cercare di aprire l’involucro. Non inserire le dita all’interno dell’apparecchio. Non cercare di aprire i refill profumati. • Utilizzare il prodotto solo con i refill profumati originali. • Il diffusore elettrico ed i refill non devono essere lasciati alla portata di bambini o animali. Questo dispositivo può essere utilizzato da bambini di età pari o superiore a 8 anni e persone con capacità fisiche, sensoriali o mentali ridotte o mancanza di esperienza e conoscenza purchè sotto supervisione o dopo adeguata istruzione sull’ uso del diffusore in modo sicuro e dei pericoli coinvolti. I bambini non devono giocare con l’apparecchio. La pulizia e 1110 Posizionare la base (1) su un piano. Appoggiare il camino (2) sulla base, rimuovere il rivestimento in pelle dalla sua custodia in tessuto e posizionarlo sul camino. La presenza dei magneti aiuta il corretto posizionamento del rivestimento in pelle sul camino. Attenzione: Spostare sempre il diffusore prendendolo dalla base e non dalla parte superiore. MONTAGGIO - ASSEMBLAGGIO DEL DIFFUSORE 2 1 56 3 4 5A 4A CONTENUTO DELLA CAPPELLIERA: • Base e camino (1) (2) • Rivestimento in pelle (3) • 3 refill profumati (4 & 4A) • Cavo USB e alimentatore (5 & 5A) • Manuale d’uso (6) 1312 Il diffusore è dotato di una batteria ricaricabile pertanto può essere utilizzato anche senza filo. Al primo utilizzo la batteria deve essere completamente carica. Collegare il cavo di alimentazione (5) all’alimentatore (5A) e all’apposita presa USB tipo C (A) posta sulla base. Quando la batteria si sta caricando il led superiore destro (Z) del pulsante di accensione ON/OFF (B) lampeggia lentamente; quando la batteria è carica il led superiore destro (Z) rimane acceso. Quando il led lampeggia velocemente, significa che la batteria si sta scaricando è quindi opportuno ricollegare il diffusore al cavo di alimentazione. La batteria si carica in un tempo massimo di 3 ore. In caso di batteria carica, il diffusore può rimanere on-line ed essere utilizzato per circa 10 ore ad intensità media. Raggiunto il termine della vita utile della batteria visitare il sito www.acquadiparma.com nella sezione Airound Smart Home Diffuser per richiedere assistenza. COLLEGAMENTO E UTILIZZO DALLA PIATTAFORMA DI GESTIONE ON LINE Per connettere il device alla rete WI-FI, scaricare l’apposita applicazione Airound App sul vostro cellulare utilizzando il QRCODE sottostante. Seguire le istruzioni di registrazione fornite dall’ APP per configurare il vostro Smart Home Diffuser. Accendere il device premendo il pulsante ON/OFF (B). La luce del led inferiore (Y) del pulsante di accensione ON/OFF (B) rimane fissa per segnalare che il diffusore è acceso. Il led superiore sinistro (X) del tasto ON/OFF (B) inizia a lampeggiare. Non appena lo smart diffuser è correttamente collegato alla rete, questa luce rimane fissa. In questo momento il dispositivo è pronto per essere utilizzato attraverso l’applicazione. Ogni refill p…

Text truncated - open the document above for the full version.

This device contains license-exempt transmitter(s)/receiver(s) that comply with part 15 of the FCC Rules and Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. To ensure compliance with FCC and ISED RF exposure requirements this device must be installed to provide a minimum of 20cm between the device and people. Changes or modifications not expressly approved by Acqua di Parma could void the user’s authority to operate the equipment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Pour garantir la conformité aux exigences d’exposition RF de la FCC et d’ISED Canada, cet appareil doit être installé de manière à laisser un minimum de 20 cm entre l’appareil et les personnes. AIROUND SMART HOME DIFFUSER 87x140mm SMART DIFFUSER MANUAL ADDENDUM EN-FR.indd 5SMART DIFFUSER MANUAL ADDENDUM EN-FR.indd 515/06/21 16:5015/06/21 16:50

S M A RT H O M E D I F F U S E R 2 0 2 0 HATBOX CONTENT OVERVIEW 2 BUTTONS/DESCRIPTIONS 3 ON/OFFUSB SOCKET FRAGRANCE SELECTIONFRAGRANCE INTENSITY SLOTS RECAP ON OFF BUTTON 4 Segment Y to show if the device is powered with cab le AND SHOWS WHEN DEVICE IS ON Segment Z to show battery statusSegment X to show connectivity status : off = not s witched on, blinking = connecting, solid = connected ON OFF BUTTON ACTIVITY 5 POWER CONNECTIONThe yellow LED light (Y) in the bottom of the ON OFF button (B) is turned on when the device is powered with cable. If cable is connected and device is OFF led light i s FIXED If cable is connected and device is ON led light is BLINKING (to define with exalia blink frequency)If cable is NOT connected and device is ON led ligh t is BLINKING (to define with exalia blink frequency)If cable is NOT connected and device is OFF led lig ht is OFF BATTERYThe green LED light (Z) in the top right of the button is blinking when the battery is charging, and is turned on when the battery is c harged. When the battery is discharged the light is turned off. WIFI CONNECTIONThe yellow LED light in the top left (X) is blinking while the smart diffuser is trying to connect to the platform. This light will turn on when configuration is finished and the connection is achieved . In case of OFF line use when button On is pressed, the upper LED light (X) starts blinking to find wifi and then switches off - has no light RESTORE FACTORY SETTINGS 6 You can reset your smart diffuser by restoring the factory settings by pushing on the 3 buttons at the same time during 10 seconds.Then the yellow LED light in the upper part of the ON button (X) blinks again . OFF LINE MANAGEMENT – FRAGRANCE CHOICE 7 To select the desired fragrance, press the appropriate button (C) : once to select the fragrance in slot 1, twice to select the fragrance in slot 2, three times to select the fragrance in slot 3. The first, second or third LEDs will turn on each in correspondence to the fragrances in succession. When the fragrance in the refill is finished , the corresponding segment blinks and the scent is no longer dispensed. OFF LINE MANAGEMENT – INTENSITY CHOICE 8 To select the intensity of the fragrance, press the dedicated button (D) : once to select low fragrance diffusing intensity, twice for medium diffusing , three times for high intensity diffusion of the chosen fragrance. The first, the first and the second or all LEDs will tur n on respectively in correspondence to the low, medium and h igh fragrance levels selected. In this use mode, the device will automatically tur n off after an hour, unless it is stopped first by the user by pre ssing the OFF button (B).Every time user has finished with one fragrance or the device is switched off and back switched on, fragrance selection must b e done from scratch. FRAGRANCE AND INTENSITY LIGHT FUNCTIONINIG 9 Fragrance choice and fragrance intensity leds – will be light a nd have same behaviuors also when selection is done through app or we platform
