2AZ5U-M-15Uumao 10W Invisinle Fast Wireless Charging

Uumao10W Invisible Fast Wireless Charging 1,Product Description: This product is a wireless charging transmitter for standard QI. The minimum distance is 5MM. The maximum distance is 30MM. 2,Scenes To Be Used: Suitable for installation under thick desktops. Suitable for marble, wood, glass and other non-metallic non-conductive tables. 3,Charging Parameters: TYPE-C input: 12V (please use the donated12V3A adapter) Wireless output power: 10W/7.5W/5W, USB wired output power: 5V2A Effective charging distance: 5MM-30MM 4,How To Install: No drilling or tools required, you can peel off the double-sided tape on the wireless charging surface and quickly install and paste it on the lower surface of the table. Will not cause permanent damage to your desktop or counter-(optional mounting screws also included). After installing the wireless charger, use the signal detector to find the signal. 5,Wireless Charging Signal Detector: When the wireless charging signal is detected,The lamp beads will light up.The brightest place is where the signal is strongest. 6,Safety Protection: It has safety protection functions such as overcharge, overcurrent, and overtemperature. 7,Warn: 1. Do not charge at a distance less than 5MM. If the receiving distance is less than 5MM, the charging and receiving equipment may be damaged. 2. Do not charge at a distance greater than 30MM. More than 30MM. It may cause Apple 12 to fail to charge. Or the phone case is too thick to charge. 3. Do not use metal or other conductors that are impermeable to electromagnetic waves. 4. Do not charge the product near or near a heat source; 5. Do not pour water or other liquids into the interface of this product, causing damage to the product; Do not allow children or animals to chew or swallow the device. 6. Do not disassemble, modify or repair the equipment. 7. Do not place magnetic stripe cards (including credit cards, phone cards, passbooks and registration cards) near the charging equipment. In order to avoid the generated magnetic field from damaging the magnetic stripe card and damaging the device. FCC Statement This device complies with part 15 of the FCC Rules. Operation is Subject To the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not explicitly approved by the party responsible for compliance could void the user's authority to operate this equipment. Note: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected.

Shenzhen Lazy Cat Communication Technology Co., Ltd. Agent Authorization Company: Shenzhen Lazy Cat Communication Technology Co., Ltd. Address: Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Product Name: Uumao 10W Invisinle Fast Wireless Charging Trade Mark: UUMAO Model Number(s): M-15, Y0513, Y-30, 5015-Y, 15-Y, Y-29, Y-28, Y-27, Y-26, Y-25, Y-24, Y-23, Y-22, 5016-Y, 5018-Y, 5019-Y, 5020-Y FCC ID: 2AZ5U-M-15 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-03-31 Name: Wei Dong Chen Title: R&D Director Company: Shenzhen Lazy Cat Communication Technology Co., Ltd.

Shenzhen Lazy Cat Communication Technology Co., Ltd. Add: Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Tel: +86 15112301905 Date: 2022-03-31 Dear Sir/Madam, We, Shenzhen Lazy Cat Communication Technology Co., Ltd. Hereby declares the following statement , PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these models: Product name: Uumao 10W Invisinle Fast Wireless Charging Models No.: M-15, Y0513, Y-30, 5015-Y, 15-Y, Y-29, Y-28, Y-27, Y-26, Y-25, Y-24, Y-23, Y-22, 5016-Y, 5018-Y, 5019-Y, 5020-Y Sincerely, Client’s name / title : Wei Dong Chen / R&D Director Company: Shenzhen Lazy Cat Communication Technology Co., Ltd. Address: Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Tel: +86 15112301905 E-Mail: [email protected]

Shenzhen Lazy Cat Communication Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-03-31 Subject; Request for Confidentiality FCC ID: 2AZ5U-M-15 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Wei Dong Chen Title: R&D Director

Page 1 of 4 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7

Page 1 of 1 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Label and Location Size: L: 3.0cm*W: 1.0cm Label Location Uumao 10W Invisinle Fast Wireless Charging Model No.: M-15 FCC ID : 2AZ5U-M-15

Page 1 of 3 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Coil Antenna Page 2 of 3 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6

Page 1 of 10 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity RF Exposure Evaluation Report 1. Product Information FCC ID: 2AZ5U-M-15 Number of tested samples 2 Sample number 220221003A-1, 220221003A-2 Product Name Uumao 10W Invisinle Fast Wireless Charging Test Model M-15 Additional Model No. Y0513, Y-30, 5015-Y, 15-Y, Y-29, Y-28, Y-27, Y-26, Y-25, Y-24, Y-23, Y-22, 5016-Y, 5018-Y, 5019-Y, 5020-Y Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply Input: DC 12V, 3000mA USB Output: DC 5V, 2A Wireless Output: 5W/7.5W/10W Modulation Type Continuous Wave Frequency Range 110~205KHz Antenna Type Coil Antenna Hardware version / Software version / Accessories / Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device 2. Evaluation Method Per KDB 680106 D01 Section 3. RF Exposure Requirements; 1) Consumer wireless power transfer devices approved under Part 18 in some cases have to demonstrate compliance with RF exposure requirements. The potential for exposure must be assessed according to the operating configurations of the wireless system and the exposure conditions of users and bystanders. RF exposure must be evaluated with the client device(s) being charged by the primary at maximum output power. The RF exposure requirements must be determined in conjunction with the device operating characteristics, according to the mobile and portable exposure requirements in Section 2.1091 and Section 2.1093 of the rules. SAR and MPE limits do not cover the frequency range for wireless power transfer applications which operate below 100 kHz and 300 kHz respectively; therefore, RF exposure compliance needs to be determined with respect to 1.1307 (c) and (d) of the FCC rules. 2) Based on the design and implementation of the power transfer application, it must be clearly identified if mobile or portable RF exposure conditions apply. Devices that are installed to provide separation of at least 20 cm from users and bystanders may qualify for mobile exposure conditions. For some conditions where users and bystanders may be exposed at closer than 20 cm, section 2.1091(d) (4) of the rules may Page 2 of 10 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity apply. 3) For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of 15 cm. E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63 A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. 4) Portable exposure conditions from 100 kHz to 6 GHz are determined with respect to SAR requirements. Existing SAR systems and test procedures are generally intended for measurements above 100 MHz. While numerical modeling can be an alternative, the constraints of substantial computational resources at low frequencies could introduce further limitations. Under these circumstances, including operations below 100 kHz, the Commission may consider a combination of analytical analysis, field strength, radiated and conducted power measurements, in conjunction with some limited numerical modeling to assess compliance. 5) Depending on the operating frequency, existing SAR and MPE measurement procedures may be adapted to evaluate wireless power transfer devices for compliance with respect to mobile or portable exposure conditions. If the grantee or its test lab have any questions regarding RF exposure evaluation they should contact the FCC Laboratory with sufficient system operating configuration details to determine if RF exposure evaluation is necessary and, if required, how to apply specific test procedures. Below 100 MHz, when SAR testing is required and the device is operating at close proximity to persons, information on device design, implementation, operating configurations, exposure conditions of users and bystanders are needed to determine the evaluation and testing requirements. In addition, the influence of nearby objects may also need consideration according to the wireless power transfer system implementation; for example, the effects of placing the device, its coils or radiating elements on or near metallic surfaces 3. Evaluation Limit 3.1 Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 680106 D01 RF Exposure Wireless Charging Apps v03: RF Exposure Considerations for Low Power Consumer Wireless Power Transfer Applications FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices FCC CFR 47 part 18.107:Indusial, Scientific, and Medical Equipment Page 3 of 10 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com…

Text truncated - open the document above for the full version.

Page 1 of 23 FCC ID: 2AZ5U-M-15 Report No.: LCS220302101AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Shenzhen Lazy Cat Communication Technology Co., Ltd. Uumao 10W Invisinle Fast Wireless Charging Test Model: M-15 Additional Model No.: Please Refer to Page 6 Prepared for : Shenzhen Lazy Cat Communication Technology Co., Ltd. Address : Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 04, 2022 Number of tested samples : 2 Serial number : 220302101A-1, 220302101A-2 Date of Test : March 04, 2022 ~ March 12, 2022 Date of Report : March 14, 2022 Page 2 of 23 FCC ID: 2AZ5U-M-15 Report No.: LCS220302101AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15C Report Reference No. ................. : LCS220302101AEA Date Of Issue .................................. : March 14, 2022 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Shenzhen Lazy Cat Communication Technology Co., Ltd. Address ........................................... : Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Test Specification Standard ......................................... : FCC CFR 47 PART 15C Test Report Form No. ..................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .................. : Uumao 10W Invisinle Fast Wireless Charging Trade Mark ..................................... : UUMAO Test Model ...................................... : M-15 Power Supply ................................. : Input: DC 12V, 3000mA USB Output: DC 5V, 2A Wireless Output: 5W/7.5W/10W Result ........................................... : Positive Compiled by: Supervised by: Approved by: Jin Wang/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 23 FCC ID: 2AZ5U-M-15 Report No.: LCS220302101AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS220302101AEA March 14, 2022 Date of issue Test Model.............................. : M-15 EUT......................................... : Uumao 10W Invisinle Fast Wireless Charging Applicant............................... : Shenzhen Lazy Cat Communication Technology Co., Ltd. Address.................................. : Room 612, Building 16A, Jie Wei Industrial Park, Pinghu Street, Longgang District, Shenzhen China Telephone............................... : / Fax.......................................... : / Manufacturer........................ : shenzhenshilanmaotongxunkejiyouxiangongsi Address................................... : guangdongshengshenzhenshilonggangqupinghujiedaoshangmu gushequjieweigongyechengsanqichangfangAdong610 Telephone............................... : / Fax.......................................... : / Factory................................... : shenzhenshilanmaotongxunkejiyouxiangongsi Address................................... : guangdongshengshenzhenshilonggangqupinghujiedaoshangmu gushequjieweigongyechengsanqichangfangAdong610 Telephone............................... : / Fax.......................................... : / Page 4 of 23 FCC ID: 2AZ5U-M-15 Report No.: LCS220302101AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 March 14, 2022 Initial Issue --- Page 5 of 23 FCC ID: 2AZ5U-M-15 Report No.: LCS220302101AEA Shenzhen LCS Compliance Testing Laboratory Lt…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A Photographs of Test Setup Conducted Emission-AC adapter charge mode Radiated Emission below 30MHz Page 2 of 2 FCC ID: 2AZ5U-M-15 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Radiated Emission Below 1 GHz
