2AZ6I-ML650Lora modular

HyECO Smart Tech Co.,Ltd. 2021/6/30 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States Dear Sir/Madam, Re: Request for FCC module certification FCC ID: 2AZ6I-ML650 We hereby request a Modular certification for the FCC ID referenced above. The device meets the requirements below. •The module has metal case covering top and sides as its own RF shielding. The shielding at bottom is implemented by the GND copper plane in PCB substrate. Answer: Yes.Please see External Photo.pdf •The module has buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; Answer: Yes.8-bits microcontroller with 64kB flash memory and 4kB RAM as an embedded processor to buffer the data, it's controlled by the chip ASR6505. •The module has power supply regulation on the module; Answer: Yes.The power supply of this module can be in the range 3.0V to 3.6V. The digital part of this module is directly supplied by this power source, but the RF part is supplied by the internal DCDC regulator of ASR6505. •The module has demonstrated compliance in a stand-alone configuration; Answer ：Yes. please see test report •The module has a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); Answer: Yes. please see test report & Internal Photos. •The module will be labeled with its permanently affixed FCC ID label. Answer: Yes.The label position of module is clearly indicated. Please see the Label & Location.pdf •The module does comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; Answer: The module is compliant with all applicable FCC rules. Detail instructions are given in the User Manual •The module does comply with RF exposure requirements. Answer: Yes. This is a low power module. Sincerely, Name: Benkang Hu Title: Electronic engineer Company: HyECO Smart Tech Co.,Ltd. Telephone: 0512- 67612708 HyECO Smart Tech Co.,Ltd. FCC Modular definitions, From FCC KDB 996369 D01 Module Equip Auth Guide v02 A. Single-modular transmitter is a self-contained, physically delineated, component for which compliance can be demonstrated independent of the host operating conditions, and which complies with all eight requirements of Section 15.212(a)(1) as summarized below. See Section 15.212 for more detailed information, and Section 2.901 (and sub- sections that follow) for general certification requirements. B. Limited single-modular transmitter is a transmitter that does not meet all eight requirements listed in Section 15.212(a) (1), and compliance can be demonstrated only for specific host and applicable operating conditions in which the transmitter will be used. For example, manufacturers have flexibility with respect to requirements such as module shielding, buffered modulation/data inputs and power supply regulation. If one or more of these functions (shielding, buffered modulation/data inputs and power supply regulation) are provided by a specific host or hosts, then the module can be granted as a limited module that is limited to that specific host or hosts. The responsible party must demonstrate how it will retain control over the final installation of the device, such that compliance of the product is ensured by limiting the installation to a specific host or hosts, for example.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 2 External Photos Applicant: HyECO Smart Tech Co,Ltd. Address of Applicant: 12Beiqian Lane,Industrial Park,Suzhou,Jiangsu 215000,China Equipment Under Test (EUT): Product Name: Lora modular Model No.: ML650 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 2 End

Remark：The product is small to place the FCC statement on the product and it be placed in the user manual which the device is marketed Label location

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 2 Internal Photos Applicant: HyECO Smart Tech Co,Ltd. Address of Applicant: 12Beiqian Lane,Industrial Park,Suzhou,Jiangsu 215000,China Equipment Under Test (EUT): Product Name: Lora modular Model No.: ML650 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 2 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500420101 Page: 1 of 35 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: SHEM2105004201CR FCC ID: 2AZ6I-ML650 Applicant: HyECO Smart Tech Co,Ltd. Address of Applicant: 12Beiqian Lane,Industrial Park,Suzhou,Jiangsu 215000,China Manufacturer: HyECO Smart Tech Co,Ltd. Address of Manufacturer: 12Beiqian Lane,Industrial Park,Suzhou,Jiangsu 215000,China Equipment Under Test (EUT): EUT Name: Lora modular Model No.: ML650 Standard(s) : 47 CFR Part 15, Subpart C 15.249 Date of Receipt: 2021-05-12 Date of Test: 2021-05-12 to 2021-07-13 Date of Issue: 2021-07-13 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500420101 Page: 2 of 35 Revision Record Version Description Date Remark 00 Original 2021-07-13 / Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500420101 Page: 3 of 35 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.249 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Field Strength of the Fundamental Signal (15.249(a)) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.5&6.6 47 CFR Part 15, Subpart C 15.249(a) Pass Restricted Band Around Fundamental Frequency 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.205 & 15.249(d) & 15.209 Pass Radiated Emissions 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.209 & 15.249 (a),(d) Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500420101 Page: 4 of 35 3 Contents Page 1 COVER PAGE.............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T.................................................................................................................................. 5 4.2 CHANNEL LIST ........................................................................................................................................ 5 4.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 5 4.4 MEASUREMENT UNCERTAINTY ................................................................................................................ 6 4.5 TEST LOCATION ..................................................................................................................................... 7 4.6 TEST FACILITY ....................................................................................................................................... 7 4.7 DEVIATION FROM STANDARDS ................................................................................................................ 7 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 7 5 EQUIPMENT LIST ....................................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ................................................................................. 10 6.1 ANTENNA REQUIREMENT ...................................................................................................................... 10 7 RADIO SPECTRUM MATTER TEST RESULTS ...................................................................................... 11 7.1 20DB BANDWIDTH ................................................................................................................................ 11 7.2 FIELD STRENGTH OF THE FUNDAMENTAL SIGNAL (15.249(A)) ................................................................ 14 7.3 RESTRICTED BAND AROUND FUNDAMENTAL FREQUENCY ...................................................................... 18 7.4 RADIATED EMISSIONS .......................................................................................................................... 25 8 TEST SETUP PHOTOGRAPHS ................................................................................................................ 35 9 EUT CONSTRUCTIONAL DETAILS ......................................................................................................... 35 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210500420101 Page: 5 of 35 4 General Information 4.1 Details of E.U.T. Power supply: …
