2AZ7Q-AP12Cookie Magsafe Wireless Charger

Instruction manual Cookie Magsafe Wireless Charger Installation Steps Technical specifications Technical specifications 1. Please use qualified AC adapter connect the USB-C power cable. The AC adapter should be 5V 2.0A or 10W above, otherwise insufficient input electric current might cause unstable charging. Do not pull the power cable hard to avoid the power cable from breaking and falling off. Do not disassemble by yourself or throw it into fire or water to avoid short circuit and leakage. Do not use in severely high temperature, humidity or corrosive environments ot avoid leakage of electricity due to damage to the circuit. Frequently asked questions Charging is slow. The mobile phone itself or the external receiving coil allows the wireless charging current to be different, or the application running consumers a lot of power when mobile phone is charging. It is recommended to reduce or close the application. The phone is charging intermittently. If the charging current is not enough, please use a power adpter with sufficient power 5V 2.0A or 10W above. Charging fever. It is normal for the receiving coil or transmitter board to generate heat during wireless charging. If the plate is too warm, take your phone off the plate. The plate may switch off automatically if it is too hot. When the plate has cooled down, try charging again. The carger does not work. Do not put metal debris or magnetic cards on the charging area. If the product does not work due to overheating, please take off the phone and wait for cooling down temperature and try charging again. 2. Place the back of the charging device with magnetic attraction function to the product front, will attract eachother, and automatically align the charging position to start charging. : Cookie Magsafe Wireless Charger : QI : >= 75% : 5V/2A & 9V/2.2A : 5W / 7.5W / 10W / 15W(MAX) Name Standar Conversion Rate Input Output & tĂƌŶŝŶŐ ^ƚĂƚĞŵĞŶƚ ŚĂŶŐĞƐ Žƌ ŵŽĚŝĨŝĐĂƚŝŽŶƐ ŶŽƚ ĞdžƉƌĞƐƐůLJ ĂƉƉƌŽǀĞĚ ďLJ ƚŚĞ ƉĂƌƚLJ ƌĞƐƉŽŶƐŝďůĞ ĨŽƌ ĐŽŵƉůŝĂŶĐĞ ĐŽƵůĚ ǀŽŝĚ ƚŚĞ ƵƐĞƌ͛Ɛ ĂƵƚŚŽƌŝƚLJ ƚŽ ŽƉĞƌĂƚĞ ƚŚĞ ĞƋƵŝƉŵĞŶƚ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŚĂƐ ďĞĞŶ ƚĞƐƚĞĚ ĂŶĚ ĨŽƵŶĚ ƚŽ ĐŽŵƉůLJ ǁŝƚŚ ƚŚĞ ůŝŵŝƚƐ ĨŽƌ Ă ůĂƐƐ  ĚŝŐŝƚĂů ĚĞǀŝĐĞ͕ ƉƵƌƐƵĂŶƚ ƚŽ WĂƌƚ ϭρ ŽĨ ƚŚĞ & ZƵůĞƐ͘ dŚĞƐĞ ůŝŵŝƚƐ Ăƌ Ğ ĚĞƐŝŐŶĞĚ ƚŽ Ɖƌ ŽǀŝĚĞ ƌĞĂƐŽŶĂďůĞ ƉƌŽƚĞĐƚŝŽŶ ĂŐĂŝŶƐƚ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ŝŶ Ă ƌĞƐŝĚĞŶƚŝĂů ŝŶƐƚĂůůĂƚŝŽŶ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŐĞŶĞƌĂƚĞƐ ƵƐĞƐ ĂŶĚ ĐĂŶ ƌĂĚŝĂƚĞ ƌĂĚŝŽ ĨƌĞƋƵĞŶĐLJ ĞŶĞƌŐLJ ĂŶĚ͕ ŝĨ ŶŽƚ ŝŶƐƚĂůůĞĚ ĂŶĚ ƵƐĞĚ ŝŶ ĂĐĐŽƌĚĂŶĐĞ ǁŝƚŚ ƚŚĞ ŝŶƐƚƌƵĐƚŝŽŶƐ͕ ŵĂLJ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ ĐŽŵŵƵŶŝĐĂƚŝŽŶƐ͘ ,ŽǁĞǀĞƌ͕ ƚŚĞƌĞ ŝƐ ŶŽ ŐƵĂƌĂŶƚĞĞ ƚŚĂƚ ŝŶƚĞƌĨĞƌĞŶĐĞ ǁŝůů ŶŽƚ ŽĐĐƵƌ ŝŶ Ă ƉĂ ƌ ƚŝĐƵůĂƌ ŝŶƐƚĂůůĂƚŝŽŶ͘ /Ĩ ƚŚŝƐ ĞƋƵŝƉŵĞŶƚ ĚŽĞƐ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ Žƌ ƚĞůĞǀŝƐŝŽŶ ƌĞĐĞƉƚŝŽŶ͕ ǁŚŝĐŚ ĐĂŶ ďĞ ĚĞƚĞƌŵŝŶĞĚ ďLJ ƚƵƌŶŝŶŐ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŽĨĨ ĂŶĚ ŽŶ͕ ƚŚĞ ƵƐĞƌ ŝƐ ĞŶĐŽƵƌĂŐĞĚ ƚŽ ƚƌLJ ƚŽ ĐŽƌƌĞĐƚ ƚŚĞ ŝŶƚĞƌĨĞƌĞŶĐĞ ďLJ ŽŶĞ Žƌ ŵŽƌĞ ŽĨ ƚŚĞ ĨŽůůŽǁŝŶŐ ŵĞĂƐƵƌĞƐ͗ ‐‐ ZĞŽƌŝĞŶƚ Žƌ ƌĞůŽĐĂƚĞ ƚŚĞ ƌ ĞĐĞŝǀŝŶŐ ĂŶ ƚĞŶŶĂ͘ ‐‐ /ŶĐƌĞĂƐĞ ƚŚĞ ƐĞƉĂƌĂƚŝŽŶ ďĞƚǁĞĞŶ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ĂŶĚ ƌĞĐĞŝǀĞƌ͘ ‐‐ ŽŶŶĞĐƚ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŝŶƚŽ ĂŶ ŽƵƚůĞƚ ŽŶ Ă ĐŝƌĐƵŝƚ ĚŝĨĨĞƌĞŶƚ ĨƌŽŵ ƚŚĂƚ ƚŽ ǁŚŝĐŚ ƚŚĞ ƌĞĐĞŝǀĞƌ ŝƐ ĐŽŶŶĞĐƚĞĚ͘ ‐‐ ŽŶƐƵůƚ ƚŚĞ ĚĞĂůĞƌ Žƌ ĂŶ ĞdžƉĞƌŝĞŶĐĞĚ ƌĂĚŝŽͬds ƚĞĐŚŶŝĐŝĂŶ ĨŽƌ ŚĞůƉ͘ Z& džƉŽƐƵƌĞ͗  ĚŝƐƚĂŶĐĞ ŽĨ ϭρ Đŵ ƐŚĂůů ďĞ ŵĂŝŶƚĂŝŶĞĚ ďĞƚǁĞĞŶ ƚŚĞ ĂŶƚĞŶŶĂ ĂŶĚ ƵƐĞƌƐ͕ ĂŶĚ ƚŚĞ ƚƌĂŶƐŵŝƚƚĞƌ ŵĂLJ ŶŽƚ ďĞ ĐŽ‐ůŽĐĂƚĞĚ ǁŝƚŚ ĂŶLJ ŽƚŚĞƌ ƚƌĂŶƐŵŝƚƚĞƌ Žƌ ĂŶƚĞŶŶĂ͘ dŚŝƐĚĞǀŝĐĞĐŽŵƉůŝĞƐǁŝƚŚƉĂƌƚϭρŽĨƚŚĞ&ZƵůĞƐ͘KƉĞƌĂƚŝŽŶŝƐƐƵďũĞĐƚƚŽƚŚĞĨŽůůŽǁŝŶŐƚǁŽĐŽŶĚŝƚŝŽŶƐ͗ ;ϭͿdŚ ŝƐĚĞǀŝĐĞŵĂLJŶŽƚĐĂƵƐĞŚĂƌŵĨƵůŝŶƚĞƌĨĞƌĞŶĐĞ͕ĂŶĚ;ϮͿƚŚŝƐĚĞǀŝĐĞŵƵƐƚĂĐĐĞƉƚĂŶLJŝŶƚĞƌĨĞƌĞŶĐĞƌĞĐĞŝ ǀĞĚ͕ŝŶĐůƵĚŝŶŐŝŶƚĞƌĨĞƌĞŶĐĞƚŚĂƚŵĂLJĐĂƵƐĞƵŶĚĞƐŝƌĞĚŽƉĞƌĂƚŝŽŶ͘

Co m Ad d Chin Pr o Mo d Pr o We act We an d issu our Sig Na m Title Com mpany: Don dress: No.2 na 523409 oduct Name del Numbe oduct Desc authorize M on our beha declare tha d certificatio ues concern behalf shal nature: me: e: mpany: ngguan Qish 1, Chuangxi e: Cookie Ma er(s): AP12 ription: Coo MiCOM Lab alf on all ma at MiCOM L n of equipm ning the app ll have the s Scholar Ch sales man Dongguan Donggu Agen hi Industry Lim ng Road, Lin agsafe Wirel okie Magsaf bs Inc., 575 atters conce Labs Inc. is ment to the r proval applic same effect hen ager n Qishi Indus uan Qishi I nt Auth mited ngxia Industr ess Charger fe Wireless C Boulder Co erning the c allowed to f regulatory a cation. Any t as acts of stry Limited ndustry Lim horizat ry Zone, Liao r Charger ourt, Pleasa certification forward all i agencies as and all acts our own. d mited tion obu Town, Do anton, Califo of above na information s required a s carried ou Date: ongguan, Gu ornia 94566 amed equip related to t nd to discu ut by MiCOM Jun. 03, 20 uangdong, 6, USA, to pment. the approva ss any M Labs on 21 al

Office o Federa 7435 O Columb USA Subjec t FCC ID To Wh o Pursua are req u docume These d propriet might b It is ou r corresp docume authoriz Sincer e Signat u Name: Title: sa of Engineeri l Communic Oakland Mills bia, MD 210 t; Request f D: 2AZ7Q-AP om It May C nt to the pro uesting the ents from pu documents tary informa be harmful to Schema Block D Parts Lis Operatio Tune-up r understand pondence du ents and thi zation is iss ely, ure: Scholar Ch ales manag ing Techno cations Com s Road 046 for Confiden P12 Concern, ovisions of t Commissio ublic disclos contain det ation in ope o our comp atic Diagram iagram st onal Descri p Procedure ding that all uring the ce s informatio sued. en ger Donggua logy mmission ntiality the Commis on to withho sure indefin tailed syste ration of th e any and wo m ption e l measurem ertification re on will be av n Qishi Ind ssion’s rule old the follow nitely. m and equi e equipmen ould give co ment test rep eview proce vailable for dustry Limit s Title 47 S wing attach pment desc nt. The publ ompetitors a ports, FCC ess cannot public revi e ted Sections §0. hment(s) as criptions an ic disclosu r an unfair ad ID label for be granted ew once the Date: Jun. 457 and §0 confidentia d are consi re of these d vantage in mat and as confide n e grant of eq 03, 2021 0.459, we al dered as documents the market . ntial quipment .

Annex A External Photos Report No.:HK2104261282-1E/2E Page 1 of 4 Report No.:HK2104261282-1E/2E Page 2 of 4 Report No.:HK2104261282-1E/2E Page 3 of 4 Report No.:HK2104261282-1E/2E Page 4 of 4

FCC ID LABEL: Label Location FCC ID: 2AVQK-XRT260 Width: 2cm Long: 4cm FCC ID: 2AZ7Q-AP12 Product name: Cookie Magsafe Wireless Charger Model No.: AP12 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Annex B Internal Photo Report No.:HK2104261282-1E/2E Page 1 of 2 Antenna Report No.HK2104261282-1E/2E Page 2 of 2

Page 1 of 8 Report No.: HK2104261282-2E FCC TEST REPORT Test report On Behalf of Dongguan Qishi Industry Limited For Cookie Magsafe Wireless Charger Model No.: AP12 FCC ID: 2AZ7Q-AP12 Prepared for : Dongguan Qishi Industry Limited No.21, Chuangxing Road, Lingxia Industry Zone, Liaobu Town, Dongguan, Guangdong, China 523409 Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Date of Test: Apr. 26, 2021 ~ May. 21, 2021 Date of Report: May. 21, 2021 Report Number: HK2104261282-2E Page 2 of 8 Report No.: HK2104261282-2E Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 125 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1 Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03r01 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03r01 Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 All emissions,radiated(<30M)(9KHz-30MHz) ±4.26dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 8 Report No.: HK2104261282-2E 2.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Broadband Field Meter NARDA NBM-550 - Jun. 18, 2020 Jun. 17, 2021 Magnetic Field Meter NARDA ELT-400 1 – 400kHz Jun. 18, 2020 Jun. 17, 2021 Magnetic Probe NARDA HF-3061 300kHz – 30MHz Jun. 18, 2020 Jun. 17, 2021 Magnetic Probe NARDA HF-0191 27 – 1000MHz Jun. 18, 2020 Jun. 17, 2021 Broadband Field Meter NARDA NBM-550 - Jun. 18, 2020 Jun. 17, 2021 Electric Field Meter COMBINOVA EFM 2005Hz – 400kHz Jun. 18, 2020 Jun. 17, 2021 E-Field Probe NARDA EF-0391 100kHz – 3GHz Jun. 18, 2020 Jun. 17, 2021 E-Field Probe NARDA EF-6091 100MHz – 60GHz Jun. 18, 2020 Jun. 17, 2021 lsotropic Electric Field| Probe NARDA EP-601 511WX60706 Jun. 18, 2020 Jun. 17, 2021 NOTE: 1. The calibration interval of the above test instruments is 12 months Page 4 of 8 Report No.: HK2104261282-2E 3. MAXIMUM PERMISSIBLE EXPOSURE 3.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03r01 Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 8 Report No.: HK2104261282-2E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 TEST SETUP 4.2 RESULT OF MAXIMUM PERMISSIBLE EXPOSURE Page 6 of 8 Report No.: HK2104261282-2E For Full load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.33 1.54 1.16 1.34 1.18 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.22 0.34 0.18 0.36 0.27 1.63 For Half Load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.22 1.36 1.32 1.47 1.52 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.46 0.34 0.41 0.33 0.39 1.63 Page 7 of 8 Report No.: HK2104261282-2E For No load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.26 1.31 1.49 1.58 1.34 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.13 0.42 0.25 0.47 0.55 1.63 Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03r01, section 5, b). The aggregate H-field strengths at …

Text truncated - open the document above for the full version.

Page 1 of 20 Report No.: HK2104261282-1E FCC TEST REPORT Test report On Behalf of Dongguan Qishi Industry Limited For Cookie Magsafe Wireless Charger Model No.: AP12 FCC ID: 2AZ7Q-AP12 Prepared for : Dongguan Qishi Industry Limited No.21, Chuangxing Road, Lingxia Industry Zone, Liaobu Town, Dongguan, Guangdong, China 523409 Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Date of Test: Apr. 26, 2021 ~ May. 21, 2021 Date of Report: May. 21, 2021 Report Number: HK2104261282-1E Page 2 of 20 Report No.: HK2104261282-1E TEST RESULT CERTIFICATION Applicant’s name ................. : Dongguan Qishi Industry Limited Address ................................. : No.21, Chuangxing Road, Lingxia Industry Zone, Liaobu Town, Dongguan, Guangdong, China 523409 Manufacture's Name ............ : Dongguan Qishi Industry Limited Address ................................. : No.21, Chuangxing Road, Lingxia Industry Zone, Liaobu To wn, Dongguan, Guangdong, China 523409 Product description Trade Mark: 3DKNIGHT Product name ........................... : Cookie Magsafe Wireless Charger Model and/or type reference : AP12 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Apr. 26, 2021 ~ May. 21, 2021 Date of Issue ........................................... : May. 21, 2021 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou ) Page 3 of 20 Report No.: HK2104261282-1E Table of Contents Page 1 . Test Summary 5 1.1 . Test Procedures And Results 5 1.2 . Test Facility 5 1.3 . Measurement Uncertainty 5 2. General Information 6 2.1. General Description of EUT 6 2.2. Carrier Frequency of Channels 7 2.3. Operation of EUT during testing 7 2.4. Description of Test Setup 7 2.5. Measurement Instruments List 8 3. Conducted Emission Test 9 3.1. Block Diagram of Test Setup 9 3.2. Conducted Power Line Emission Limit 9 3.3. Test Procedure 9 4. Radia Ted Emissions 12 4.1. Block Diagram of Test Setup 12 4.2. Rules and specifications 13 4.3. Test Procedure 14 5.4. Test Result 14 5. Antenna Requirement 17 6. Photograph of Test 18 6.1. Radiated Emission 18 6.2. Conducted Emission 19 7. Photos of The EUT 20 Page 4 of 20 Report No.: HK2104261282-1E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release May. 21, 2021 Jason Zhou Page 5 of 20 Report No.: HK2104261282-1E 1. Test Summary 1.1. Test Procedures And Results DESCRIPTION OF TEST SECTION NUMBERRESULT CONDUCTED EMISSIONS TEST 15.207 COMPLIANT RADIATED EMISSION TEST 15.209 COMPLIANT ANTENNA REQUIREMENT 15.203 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. Test Facility Test Firm : Shenzhen HUAK Testing Technology Co., Ltd. Address 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 20 Report No.: HK2104261282-1E 2. General Information 2.1. General Description of EUT Equipment Cookie Magsafe Wireless Charger Model Name AP12 Serial No. N/A Model Difference N/A Trade Mark 3DKNIGHT FCC ID 2AZ7Q-AP12 Antenna Type Coil Antenna Antenna Gain 0dBi Operation frequency 125KHz Number of Channels 1 Modulation Type ASK Power Source Input: 5V/9V/12V Output: 5W/10W/15W Power Rating Input: 5V/9V/12V Output: 5W/10W/15W Page 7 of 20 Report No.: HK2104261282-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency 1 125KHz 2.3. Operation of EUT during testing Operating Mode The mode is used: Transmitting mode 2.4. Description of Test Setup Operation of EUT during testing: AC Plug Adapter information Model: HW-059200CHQ Input: 100-240V, 50-60Hz, 0.5A Output: 5VDC, 2A Mobile phone information Model: m2011k2c The sample was placed (0.8m（30MHz~1GHz）, 0.8m (9KHz~30MHz)) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. The worst case is X position. Adapter EUT Mobile phone Page 8 of 20 Report No.: HK2104261282-1E 2.5. Measurement Instruments List Item Equipment Manufacturer Model No.Serial No. Last Cal. Cal. Interval 1. L.I.S.N. Artificial Mains Network R&S ENV216 HKE-002 Jun. 18, 20201 Year 2. Receiver R&S ESCI 7 HKE-010 Jun. 18, 20201 Year 3. RF automatic control unit Tonscend JS0806-2 HKE-060 Jun. 18, 20201 Year 4. Spectrum analyzer R&S…

Text truncated - open the document above for the full version.

Test Model：AP12 Radiated Emission Conducted Emission
