2AZ92-MZEP08F22Magnetic car fast wireless charger

FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  -Reorient or relocate the receiving antenna.  -Increase the separation between the equipment and receiver.  -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  -Consult the dealer or an experienced radio/TV technician for help. IC Warning This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement The distance between user and Wireless charging mat should be no less than 20cm The distance between user and Wireless charging mat should be no less than 20cm La distance entre l'utilisateur et le tapis de chargement sans fil ne doit pas être inférieure à 10 cm

ShenZhen MaiZhan Technology Co.,Ltd Agent Authorization Company: ShenZhen MaiZhan Technology Co.,Ltd Address: Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Product Name: Magnetic car fast wireless charger Model Number(s): MZEP08, MZEP08A, MZEP08B, MZEP08C, MZEP08D MZEP08E, MZEP08F Product Description: Magnetic car fast wireless charger We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021/06/22 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO., LTD

Differences Description We ShenZhen MaiZhan Technology Co.,Ltd state: Product： Magnetic car fast wireless charger Model Name： MZEP08,MZEP08A,MZEP08B,MZEP08C, MZEP08D MZEP08E, MZEP08F Brand Name： N/A FCC ID: 2AZ92-MZEP08F22 The electrical circuit design, layout, components used and internal wiring for above models are identical, Onlydifferentin appearance color Signatory Date 2021-06-28 Signature Name: Jiankuai Li Title: Manager Company: Shenzhen STS Test Services Co., Ltd Address: 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District,Shenzhen,CHINA

2021.06.10 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li( Name of Agent company name and address, Name of Agent ) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. This appointment is valid until further until December 31, 2021 Sincerely, Name: Xuxiangyou Title:Manager E-mail: [email protected] Company: ShenZhen MaiZhan Technology Co.,Ltd

ShenZhen MaiZhan Technology Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021/06/22 Subject; Request for Confidentiality FCC ID: 2AZ92-MZEP08F22 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: Manager

Page 1 of 4 Report No.: STS2105168 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MZEP08 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2105168 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2105168 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2105168 Photo 7 Photo 8

FCC Label FCC Waring

Page 1 of 2 Report No.: STS2105168 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MZEP08 Photo 1 Photo 2 Photo 3 Antenna Page 2 of 2 Report No.: STS2105168

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] MPE TEST REPORT Report No:STS2105168H01 Issued for ShenZhen MaiZhan Technology Co.,Ltd Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Product Name: Magnetic car fast wireless charger Brand Name: N/A Model Name: MZEP08 Series Model: MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F FCC ID: 2AZ92-MZEP08F22 Test Standard: FCC CFR 47 part 1, 1.1310 S T L A B S Page 2 of 11 Report No.: STS2105168H01 TEST RESULT CERTIFICATION Applicant’s Name ...................: ShenZhen MaiZhan Technology Co.,Ltd Address ..................................: Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Manufacturer's Name .............: ShenZhen MaiZhan Technology Co.,Ltd Address ..................................: Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Product Description Product Name ........................: Magnetic car fast wireless charger Brand Name .........................: N/A Model Name ...........................: MZEP08 Series Model ..........................: MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F Standards ...............................: FCC CFR 47 part 1, 1.1310 Test Procedure .....................: 680106 D01 RF Exposure Wireless Charging Apps v03r01 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................: Date of receipt of test item ......: 01 June 2021 Date of performance of tests ..: 01 June 2021 ~ 09 June 2021 Date of Issue ..........................: 09 June 2021 Test Result .............................: Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean She) Authorized Signatory : (Vita Li) Page 3 of 11 Report No.: STS2105168H01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 1.3 GENERAL DESCRIPTION OF THE EUT 6 1.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 7 1.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 7 2. MAXIMUM PERMISSIBLE EXPOSURE 8 2.1 MAXIMUM PERMISSIBLE EXPOSURE 8 2.2 TEST PROCEDURE 9 2.3 TEST SETUP 9 2.4 TEST RESULTS 9 2.5 MAXIMUM PERMISSIBLE EXPOSURE 10 Page 4 of 11 Report No.: STS2105168H01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 09 June 2021 STS2105168H01 ALL Initial Issue Page 5 of 11 Report No.: STS2105168H01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03 Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainly 1 H-filed ±1.2μT 2 E-filed ±16% Page 6 of 11 Report No.: STS2105168H01 1.3 GENERAL DESCRIPTION OF THE EUT Product Name Magnetic car fast wireless charger Trade Name N/A Model Name MZEP08 Series Model MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F Model Difference Only different in appearance color Equipemnt Category Non-ISM frequency Antenna Type Please refer to the Note 2. Operating frequency 110.5-205KHz Modulation Type ASK, FSK Power Rating Input: DC 9V 3A/9V 2A/5V 3A Output: 15W/10W/7.5W/5W Hardware version number MZEP08-001X-V1.0 Software version number MZEP08-001E84FE Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. 2. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector NOTE 1 N/A MZEP08 Coil NA Antenna The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. Page 7 of 11 Report No.: STS2105168H01 1.4 EQUIPMENTS LIST FOR ALL TEST ITEMS Kind of Equipment Manufacturer Type No. Serial No. Last calibration Calibrated until Electromagnetic field strength analyzer Coliy Technology GmbH E300 13945 2010.10.19 2021.10.18 Three-dimensional omnidirectional electric field probe Coliy Technology GmbH EP0650 N/A 2010.10.19 2021.10.18 Three-dimensional omnidirectional magnetic field probe Coliy Technology GmbH HP0350 N/A 2010.10.19 2021.10.18 Three-dimensional omnidirectional electric and magnetic field combo probe Coliy Technology GmbH EHP150 N/A 2010.10.19 2021.10.18 Note: 1. The Three-dimensional omnidirectional electric field probe frequency rang is 100 KHz - 6.5 GHz, the Three-dimensional omnidirectional magnetic field probe frequency rang is 100 KHz - 35 MHz, and the Three-dimensional omnidirectional electric and magnetic field combo probe freque…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No.: STS2105168W01 Issued for ShenZhen MaiZhan Technology Co.,Ltd Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Product Name: Magnetic car fast wireless charger Brand Name: N/A Model Name: MZEP08 Series Model: MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F FCC ID: 2AZ92-MZEP08F22 Test Standard: FCC Part 15 Subpart C S T L A B S Page 2 of 21 Report No.: STS2105168W01 TEST RESULT CERTIFICATION Applicant’s Name ...................: ShenZhen MaiZhan Technology Co.,Ltd Address ..................................: Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Manufacturer's Name .............: ShenZhen MaiZhan Technology Co.,Ltd Address ..................................: Area A2, 8 / F, Building H, ChuangXinYunGu, No.48 PaoTai Road, Guangming District, Shenzhen, China. Product Description Product Name ........................: Magnetic car fast wireless charger Brand Name .........................: N/A Model Name ...........................: MZEP08 Series Model ..........................: MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F Test Standards ......................: FCC Part 15 Subpart C Test Procedure .......................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................... : Date of receipt of test item ......... : 01 June 2021 Date (s) of performance of tests : 01 June 2021 ~ 09 June 2021 Date of Issue ............................. : 09 June 2021 Test Result ................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean She) Authorized Signatory : (Vita Li) Page 3 of 21 Report No.: STS2105168W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 DESCRIPTION OF THE TEST MODES 7 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3. CONDUCTED EMISSION TEST RESULT (SECTION 15.207) 10 3.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.2 TEST PROCEDURE 11 3.3 TEST SETUP 11 3.4 EUT OPERATING CONDITIONS 11 3.5 TEST RESULTS 12 4. RADIATED& FIELD EMISSION TEST RESULT (SECTIOU 15.209) 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 14 4.3 TEST SETUP 15 4.4 TEST RESULTS 16 5. 20 DB BANDWIDTH TEST 20 5.1 LIMIT 20 5.2 TEST SETUP 20 5.3 TEST RESULTS 20 APPENDIX-PHOTOS OF TEST SETUP 21 Page 4 of 21 Report No.: STS2105168W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 09 June 2021 STS2105168W01 ALL Initial Issue Page 5 of 21 Report No.: STS2105168W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209(a) Radiated emission, Spurious Emission PASS 2.1049 20 dB Bandwidth PASS 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainly 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Page 6 of 21 Report No.: STS2105168W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Magnetic car fast wireless charger Trade Name N/A Model Name MZEP08 Series Model MZEP08A, MZEP08B, MZEP08C, MZEP08D, MZEP08E, MZEP08F Model Difference Only different in appearance color Channel List Please refer to the Note 2. Antenna Type Please refer to the Note 3. Equipemnt Category Non-ISM frequency Operating frequency 110.5-205KHz Modulation Type ASK, FSK Power Rating: Input: DC 9V 3A/9V 2A/5V 3A Output: 15W/10W/7.5W/5W Hardware version number MZEP08-001X-V1.0 Software version number MZEP08-001E84FE Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (KHz) Channel Frequency (KHz) 00 128 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector NOTE 1 N/A MZEP08 Coil N/A Antenna Page 7 of 21 Report No.: STS2105168W01 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mod…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AZ92-MZEP08F22 DCD Setup photo Model name: MZEP08 Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2AZ92-MZEP08F22 Radiation (30MHz-1000MHz)
