2AZ94MCSBK2Wireless Charging Stand

Instruction Manual Specification Name:Wireless Charging Stand Model:M-CS-BK-2 Manufacturer：Peak Design Input:9V⎓2.25A Wireless Output: 5W/7.5W/10W/15W Accessory:200cm Recycled USB-C to USB-C cable Product overview 1.USB-C Input port. 2.Wireless charging area 3.Metal support bracket Usage guideline 1.Connect the USB-C end of the provided cable to the USB-C port on the unit, and USB-A end to the wall charger. 2.Wireless Charging: Put the mobile phone in the wireless charging position, you can charge the mobile phone. 3.Wireless charging protection: When there is a metal foreign body in the wireless charging position or due to high temperature will start protection, no output to ensure safety. Declaration of conformity 1.Frequency Range:114.4-148.2KHz; Power H-field: -10.25dBuA/m at 10m (for EU/UK); Frequency Range:356.8-369.6KHz(for EU/UK); Power H-field: -16.74dBuA/m at 10m (for EU/UK). 2.Hardware version of this product :V2.3, Software version: V0.30. 3.Hereby, [Peak Design ] declares that the radio equipment type[M-CS-BK-2] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.peakdesign.com/EU-certifi cation. 4.Hereby, [Peak Design ] declares that the radio equipment type[M-CS-BK-2] is in compliance with UK Radio Equipment Regulations (SI 2017/1206). The full text of the UK declaration of conformity is available at the following internet address: https://www.peakdesign.com/EU-certifi cation. RF Exposure Compliance This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. Cet équipement est conforme aux limites d’exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. FCC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. ISED compliance statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Security and Precaution • Some phone cases may block the wireless charging. • Do not place other materials, like metal objects, magnets, and magnetic stripe cards, between the mobile device and the wireless charger pad. • Check your mobile device’s battery percentage using the charging icon displayed on the screen of your phone. • When the mobile device is not placed on the charging area accurately, your mobile device may not charge properly. • Please do not expose this device to moisture or heat sources. • This is not a toy, not suitable for children under the age of 7.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Peak Design Ltd. Address 2325 3rd St., Suite 410, San Francisco, California 94107, United States Grantee Code 2AZ94 FCC ID 2AZ94MCSBK2 Authorized Contact Name Adrienne Rowell Contact Email [email protected] Contact Phone 1(310) 437-3404 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ Peak Design ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ Peak Design ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Signature: Date: 16 Jan 2024 Print Name: Adrienne Rowell Title: Engineering Project Manger *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 16 Jan 2024 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Peak Design Ltd. Company Name: Peak Design Ltd. Grantee Code: 2AZ94 FRN 0031022429 Contact Name: Adrienne Rowell Contact Name: Adrienne Rowell Address: 2325 3rd St., Suite 410, San Francisco, California 94107 United States Address: 2325 3rd St., Suite 410, San Francisco, California 94107 United States City/Province/Zip: City/Province/Zip: Telephone: 1 (310) 437-3404 Telephone: 1 (310) 437-3404 Fax: Fax: Email: [email protected] om Email: [email protected] m Applicable Equipment: FCC ID: 2AZ94MCSBK2 ATTN: Director of Certification: We, Peak Design understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, Peak Design acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Adrienne Rowell Name (Printed): Adrienne Rowell Title: Engineering Project Manger Title: Engineering Project Manger Signature: Signature:

Peak Design Date: 16 Jan 2024 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AZ94MCSBK2 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Peak Design This authorization is valid until further written notice from the applicant. Print Name: Adrienne Rowell Title: Engineering Project Manger Signature: On behalf of Company: Peak Design Ltd. Telephone: 1 (310) 437-3404 E-mail: [email protected]

Peak Design TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2AZ94MCSBK2 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applican t hereby reques t confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within 0 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. Delete any document that is NOT included in your application External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Adrienne Rowell Title: Engineering Project Manger Signature: On behalf of Company: Peak Design Ltd. Telephone:1 (310) 437-3404 E-mail: [email protected]

Peak Design Cover Letter-Wireless Charger Approval Date: 16 Jan 2024 Gentlemen: There’s a Wireless Charger that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, Wireless Charger, with its designed features and specified description, meets special requirements for KDB 680106 D01 section 5.2 requirements. Company: Peak Design Ltd. Product Name: Wireless Charging Stand Model Number: M-CS-BK-2 FCC ID: 2AZ94MCSBK2 KDB 680106 D01 Section 5.2 Requirements Product Technical Specification Result 1) Power transfer frequency is less that 1 MHz 114.4kHz to 148.2kHz (for 5W/7.5W/10W output) 356.8kHz to 369.6kHz (for 15W output) Complied 2) The output power from each transmitting element (e.g., coil) is less than or equal to 15 watts. 5W,7.5W,10W,15W Complied 3) A client device providing the maximum permitted load is placed in physical contact with the transmitter (i.e., the surfaces of the transmitter and client device enclosures need to be in physical contact) Complied 4) Only § 2.1091-Mobile exposure conditions applyFor inductive applications where the primary does not physically attach to the client, and it is intended for desktop use, the desktop guidance in KDB 680106 D01 may be applied Complied 5) The E-field and H-field strengths, at and beyond 20 cm surrounding the device surface, are demonstrated to be less than 50% of the applicable MPE limit, per KDB 447498, Table 1. These measurements shall be taken along the principal axes of the device, with one axis oriented along the direction of the estimated maximum field strength, and for three points per axis or until a 1/d (inverse distance from the emitter structure) field strength decay is observed. Symmetry considerations may be used for test reduction purposes. The device shall be operated in documented worst-case compliance scenarios (i.e., the ones that lead to the maximum field components), and while all the radiating structures (e.g., coils or antennas) that by design can simultaneously transmit are energized at their nominal maximum power. Please refer to RF exposure report Complied 6) For systems with more than one radiating structure, the conditions specified in (5) must be met when the system is fully loaded (i.e., clients absorbing maximum power available), and with all the radiating Please refer to RF exposure report Complied Peak Design structures operating at maximum power at the same time, as per design conditions. If the design allows one or more radiating structures to be powered at a higher level while other radiating structures are not powered, then those cases must be tested as well. For instance, a device may use three RF coils powered at 5 W, or one coil powered at 15 W: in this case, both scenarios shall be tested. Sincerely, Print Name: Adrienne Rowell Title: Engineering Project Manger Signature: On behalf of Company: Peak Design Ltd. Telephone: 1 (310) 437-3404 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 6 Appendix External Photos for SZCR2312004228AT FCC ID:2AZ94MCSBK2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 6 of 6 - End of the Appendix -

Printing in packaging box Printing in packaging box

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 3 Appendix Internal Photos for SZCR2312004228AT FCC ID:2AZ94MCSBK2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 3 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 3 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: : SZCR231200422802 Page: 1 of 10 Keny Xu EMC Laboratory Manager Human Exposure Report Application No.: SZCR2312004228AT Applicant: Peak Design Address of Applicant: 2325 3rd st Suite 410, San Francisco, California, 94107 United States Manufacturer: Peak Design Address of Manufacturer: 2325 3rd st Suite 410, San Francisco, California, 94107 United States Factory: E-Power Technology Global Co. Ltd. Address of Factory: 91, Ying Shen Road, Liang Ying Village, Chao Nan District, Shantou City, Guangdong Province, 515141, China. Equipment Under Test (EUT): EUT Name: Wireless Charging Stand Model No.: M-CS-BK-2 Trade Mark: Peak Design FCC ID: 2AZ94MCSBK2 Standards: 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1091 Date of Receipt: 2023-12-21 Date of Test: 2023-12-28 to 2024-01-16 Date of Issue: 2024-01-22 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422802 Page: 2 of 10 Revision Record Version Chapter Date Modifier Remark 01 2024-01-22 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422802 Page: 3 of 10 1 Contents 1 Contents ............................................................................................................................................. 3 2 General Information............................................................................................................................ 4 2.1 Details of E.U.T. ........................................................................................................................... 4 2.2 Description of Support Units ......................................................................................................... 4 2.3 Test Location ............................................................................................................................... 5 2.4 Test Facility .................................................................................................................................. 5 2.5 Deviation from Standards ............................................................................................................. 5 2.6 Abnormalities from Standard Conditions ....................................................................................... 5 3 Equipments Used during Test ........................................................................................................... 6 4 Test Results ........................................................................................................................................ 7 4.1 RF Exposure test ......................................................................................................................... 7 4.1.1 E.U.T. Operation ...................................................................................................................... 8 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422802 Page: 4 of 10 2 General Information 2.1 Details of E.U.T. Power supply: Input: DC 9V/2.25A Output:5W/7.5W/10W/15W Cable(s): Type-C cable: 200cm shielded Operation frequency: 114.4kHz to 148.2kHz (for 5W/7.5W/10W output) 356.8kHz to 369.6kHz (for 15W output) Modulation type: Load modulation Antenna type: Loop Antenna Remark:The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 2.2 Description of Support Units Description Manufacturer Model No. Serial No. E-loading SGS N/A REF. No.SEA42A00 E-loading Peak Design N/A Client supply iPhone 8 Apple A1863 REF. No.SEA16M00 Mobile Phone Nexus MRA58K REF. No.SEA16P00 Mobile Phone SAMSUNG SM-G9810 REF. No.SEA16K00 iPhone 13 Apple MLDYCH/A REF. No.SEA16Q00 Adapter XIAOMI MDY-12-ED REF. No.SEA05P06G SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422802 Page: 5 of 10 2.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 2.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI (Member No. 1937) The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen EMC laboratory have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1336 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1336. Test Firm Registration Number: 787754. • Innovation, Science and Economic Development Canada SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0006. IC#: 4620C. 2.5 Deviation from Standards None. 2.6 Abnormalities from Standard Conditions None. SGS-CSTC Standards Technical Services Co., Lt…

Text truncated - open the document above for the full version.

Justification statement for Antenna To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AZ94MCSBK2 Dear Sir/Madam, Only radiated measurements are used for EUT with FCC ID: 2AZ94MCSBK2 to show compliance with FCC limits for fundamental and spurious emissions. All measurements were performed radiated and therefore additional antenna gain documentation is not required. The detailed information for antenna as below shows: Design Specifications Typical Antenna Type Loop Antenna Working Frequency 114.4kHz to 148.2kHz 356.8kHz to 369.6kHz Overall Dimensions 43mm*21mm

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422801 Page: 1 of 38 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2312004228AT Applicant: Peak Design Address of Applicant: 2325 3rd st Suite 410, San Francisco, California, 94107 United States Manufacturer: Peak Design Address of Manufacturer: 2325 3rd st Suite 410, San Francisco, California, 94107 United States Factory: E-Power Technology Global Co. Ltd. Address of Factory: 91, Ying Shen Road, Liang Ying Village, Chao Nan District, Shantou City, Guangdong Province, 515141, China. Equipment Under Test (EUT): EUT Name: Wireless Charging Stand Model No.: M-CS-BK-2 Trade Mark: Peak Design FCC ID: 2AZ94MCSBK2 Standard(s) : 47 CFR Part 15, Subpart C Date of Receipt: 2023-12-21 Date of Test: 2023-12-28 to 2024-01-16 Date of Issue: 2024-01-22 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422801 Page: 2 of 38 Revision Record Version Chapter Date Modifier Remark 01 2024-01-22 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422801 Page: 3 of 38 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C ANSI C63.10 (2013) Section 6.9.2 47 CFR Part 15, Subpart C 15.215 Pass Conducted Emissions at AC Mains Power Port (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Restricted Bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Emissions (30MHz-1GHz) ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231200422801 Page: 4 of 38 3 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Test Summary ..................................................................................................................................... 3 3 Contents ............................................................................................................................................. 4 4 General Information............................................................................................................................ 6 4.1 Details of E.U.T. ........................................................................................................................... 6 4.2 Description of Support Units ......................................................................................................... 6 4.3 Measurement Uncertainty ............................................................................................................ 6 4.4 Test Location ............................................................................................................................... 7 4.5 Test Facility .................................................................................................................................. 7 4.6 Deviation from Standards ............................................................................................................. 7 4.7 Abnormalities from Standard Conditions ....................................................................................... 7 5 Equipment List ................................................................................................................................... 8 6 Radio Spectrum Technical Requirement ..........................................................................................10 6.1 Antenna Requirement .................................................................................................................10 6.1.1 Test Requirement: ..................................................................................................................10 6.1.2 Conclusion ..............................................................................................................................10 7 Radio Spectrum Matter Test Results ................................................................................................11 7.1 20dB Bandwidth ..........................................................................................................................11 7.1.1 E.U.T. Operation .....................................................................................................................11 7.1.2 Test Mode Description ............................................................................................................11 7.1.3 Test Setup Diagram ................................................................................................................11 7.1.4 Measurement Procedure and Data .........................................................................................12 7.2 Conducted Emissions at AC Mains Power Port (150kHz-30MHz) ................................................14 7.2.1 E.U.T. Operation .....................................................................................................................14 7.2.2 Test Mode Description .......................................................................…
