2AZB26430074203061Xampion BLE sensor module

SAFETY HTTPS://XAMPION.COM/SAFETY-NOTICE/ REQUIREMENTS SPECIFICATION HTTPS://XAMPION.COM/REQUIREMENTS-PECIFICATIONS/ FIND OUT MORE ABOUT ENFIESJPFR Safety notice Use this product only according instruction described in the user guide. FCC Part 15 Clause 15.21: “Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment” Contains small parts which may be a choking hazard. Not suitable for children under age 3. Do not dry the product in a microwave, oven, or with any other source of heat. It is safe to rinse the sensors and the Micro USB port under running water. Dry with cloth after rinsing and store in room temperature. Do not use any chemical for cleaning. Do not drop or allow the sensors to be immersed in water or other liquid. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Howev er, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Click here for Canada specic notice Symbol indicates that the item shall not be treated as household waste. Instead, it shall be handed over to the applicable collection point for recycling of electrical and electronic equipment. DISCLAIMER Progda Oy / Ltd and Xampion® disclaims any and all liabilities related to third parties’ products and  Menu enter search term services. Xampion Wearable Sports Tech for Future Champions Subscribe Headquarters Company Info Progda Oy Kaarikatu 8 20760 Piispanristi Kaarina, Finland ID: FI27611805 Contact [email protected] Get the latest news. (email)Subscribe Menu Terms & Policies Xampion® Service Terms of Use Xampion® Service Privacy Policy Xampion® Service General Terms and Conditions for Private Customers © Xampion 2021 We value your privacy. We use cookies to track anonymous information about our visitors to improve your experience. Find out more. Okay, thanks Menu ENFIESJPFR Additional safety notice for Canada CAN ICES-3 (B)/NMB-3(B) This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) l’appareil ne doit pas produire de brouillage; 2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Xampion Wearable Sports Tech for Future Champions Subscribe  Get the latest news. (email)Subscribe Menu Headquarters Company Info Progda Oy Kaarikatu 8 20760 Piispanristi Kaarina, Finland ID: FI27611805 Contact [email protected] Terms & Policies Xampion® Service Terms of Use Xampion® Service Privacy Policy Xampion® Service General Terms and Conditions for Private Customers © Xampion 2021 We value your privacy. We use cookies to track anonymous information about our visitors to improve your experience. Find out more. Okay, thanks Menu

Date (2021-05-18) Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID: Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Progda Oy/Ltd hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation (Operation description) Progda Oy/Ltd also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of period of 180 days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely,

Progda Oy/Ltd Kaarikatu 8 20760 Piispanristi Finland [email protected] Date (08/04/2021) TUV SUD America Inc. 10 Centennial Drive Peabody, MA 01960, USA Dear Sir or Madam, We, (Progda Oy/Ltd, Kaarikatu 8, 20760 Piispanristi, Finland) hereby authorize Andy Zhang and Marley Sealey of TUV SUD America, 10040 Mesa Rim Road, San Diego, CA, 92121 and to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Yours sincerely, Name: Tero Suominen Title: Chairman of the Board

Date (2021-05-18) Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Modular Approval Request FCC ID: 2AZB26430074203061 The following attestation addresses the requirements to support modular approval: Modular approval requirement Yes (provide brief statement)No * (a) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Yes, Progda Xampion PWB design included RF shield which cover all the BLE main module circuit components. (b) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes, The Xampion PWB design is based on Nordic semiconductor nRF52832 BLE microcontroller module with buffered modulation/data inputs. (c) The module must contain power supply regulation on the module Design included Li-Ion/Polymer battery charger circuit which regulates battery charging levels and LDO circuit to regulate output level accuracy. (d) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Antenna design included SMD mounted Ceramic chip Antenna. Chip antenna is tuned to operate most efficiency at Bluetooth frequencies. (e) The module must demonstrate compliance in a stand-alone configuration Yes, module can compliance at stand-alone configuration. (f) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Yes, Module will be having permanently affixed FCC ID label information laser engraved to the mechanic cover. (g) The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements Yes, Transmitter design is based on Nordic semiconductor nRF52832 BLE microcontroller module and same baseline has been comply approved in many similar designs. Modular approval requirement Yes (provide brief statement)No * (h) The module must comply with RF exposure requirements Our design baseline and Xampion design at FCC testing module comply with all RF exposure requirements. * Please provide a detailed explanation if the answer is “No.” Yours sincerely,

5mm

Exhibit 9 Internal Photos

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD Certification Exhibit IC: 27068-PROGDAHW3 ISED Canada’s Radio Standards Specification: RSS-102 Issue 5 TÜV SÜD Project Number: 72167778 Manufacturer: Progda Oy Ltd Model: Xampion BLE Sensor Module RF Exposure Model(s): Xampion BLE Sensor Module IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America Inc. Page 2 General Information: Applicant: Progda Oy Ltd Environment: General Population/Uncontrolled Exposure Exposure Conditions: Portable Technical Information: Minimum Test Separation Distance: 5 mm Highest Operating Frequency: 2480 MHz Antenna Type: SMD Chip Antenna Antenna Gain: -1.5 dBi Maximum Transmitter Conducted Power: 4.75 dBm, 2.99 mW Maximum Transmitter EIRP: 3.25 dBm, 2.11 mW Justification for SAR Test Exclusion: The SAR test exclusion thresholds are determined using IC RSS-102 Issue 5, section 2.5.1 Table 1. Maximum Conducted or Equivalent Isotropically Radiated power (EIRP): 2.99 mW The linear interpolated threshold of table 1 for 2480 MHz at a separation distance of 5 mm is determined as 3.9 mW. 2.99 mW < 3.9 mW SAR test exclusion is applied.

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD RESPONSIBLE FOR NAME DATE SIGNATURE Authorized Signatory Peter Walsh 2021 -May-20 Testing Thierry Jean Charles 2021-May-20 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD Product Service document control rules. FCC Accreditation Designation Number US1063 Tampa, FL Test Laboratory Innovation, Science, and Economic Development Canada Accreditation Site Number 2087A-2 Tampa, FL Test Laboratory EXECUTIVE SUMMARY Samples of this product were tested and found to be in compliance with 15.247 and ISED Canada’s RSS-247. A2LA Cert. No. 2955.15 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD America with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD America. No part of this document may be reproduced without the prior written approval of TÜV SÜD America. © TÜV SÜD. DISCLAIMER AND COPYRIGHT Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. Results of test not covered by our A2LA Accreditation Schedule are marked NUA (Not A2LA Accredited). Contents FCC and ISED Canada Testing of the Progda Oy Ltd Xampion BLE Sensor Module In accordance with FCC 47 CFR part 15.247 and ISED Canada’s Radio Standards Specifications RSS-247 Prepared for: Progda Oy Ltd Kaarikatu 8 20760 PIISPANRISTI FINLAND FCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 COMMERCIAL-IN-CONFIDENCE Document Number: TP72167778.201| Version Number: 02 Document Number: TP72167778.201 | Version Number: 02 COMMERCIAL-IN-CONFIDENCE Page 2 of 49 1Report Summary .........................................................................................................................3 1.1Report Modification Record ...........................................................................................................3 1.2Introduction ....................................................................................................................................3 1.3Brief Summary of Results .............................................................................................................6 1.4Product Information .......................................................................................................................7 1.5Declaration of Build Status ............................................................................................................8 1.6Product Information .......................................................................................................................9 1.7Deviations from the Standard ..................................................................................................... 10 1.8EUT Modification Record ........................................................................................................... 10 1.9Test Location .............................................................................................................................. 10 2Test Details ............................................................................................................................... 11 2.1Antenna Requirements............................................................................................................... 11 2.26 dB Bandwidth .......................................................................................................................... 12 2.399% Bandwidth .......................................................................................................................... 15 2.4Peak Output Power .................................................................................................................... 18 2.5Band-Edge Compliance of RF Conducted Emissions ............................................................... 21 2.6RF Conducted Spurious Emissions ........................................................................................... 24 2.7Radiated Spurious Emissions into Restricted Frequency Bands ............................................... 27 2.8Power Spectral Density .............................................................................................................. 34 2.9Power Line Conducted Emissions ............................................................................................. 37 2.10Duty Cycle of Test Mode of Operation ....................................................................................... 41 3Test Equipment Information ................................................................................................... 43 3.1General Test Equipment Used ................................................................................................... 43 4Diagram of Test Set-ups .......................................................................................................... 44 5Measurement Uncertainty ....................................................................................................... 48 6Accreditation, Disclaimers and Copyright............................................................................. 49 Document Number: TP72167778.201 | Version Number: 02 COMMERCIAL-IN-CONFIDENCE Page 3 of 49 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 2021-May-17 2 Updated antenna type information 2021-May-20 1.2 Introduction The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations Section 15.247 and Innovation Science and Economic Development Canada’s Radio Standards Specification RSS-247 for the tests documented herein. Document Number: TP72167778.201 | Version Number: 02 COMMERCI…

Text truncated - open the document above for the full version.

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD Certification Exhibit FCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 FCC Rule Part: 15.247 ISED Canada’s Radio Standards Specification: RSS-247 Project: 72167778 Manufacturer: Progda Oy Ltd Model: Xampion BLE Sensor Module Test Setup Photos Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 2 Figure 1: Radiated Emissions – Front View – below 30 MHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 3 Figure 2: Radiated Emissions – Back View – below 30 MHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 4 Figure 3: Radiated Emissions – Front View – 30 MHz – 1 GHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 5 Figure 4: Radiated Emissions – Back View – 30 MHz – 1 GHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 6 Figure 5: Radiated Emissions – Front View – above 1 GHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 7 Figure 6: Radiated Emissions – Back View – above 1 GHz Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 8 Figure 7: RF Conducted Emissions Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 9 Figure 8: Power Line Conducted Emissions – Front View Model: Xampion BLE Sensor ModuleFCC ID: 2AZB26430074203061 IC: 27068-PROGDAHW3 Project: 72167778 TÜV SÜD America, Inc. Page 10 Figure 9: Power Line Conducted Emissions – Rear View
