2AZBD-T3wireless keyboard

Shenzhen Huayu Hongxin Electronic Technology Co., Ltd. 2.4G wireless keyboard Ver7.0 版 TEL: 0755-23729814 FAX: 0755-23729624 2018/12/01 Page 1 2.4G Light-Up Keyboard/Mouse Manual (V7.0) Product overview 1. Compatible with USB1.1/2.0 standard 2. High quality BK2425 RF, 16 channel adaptive frequency hopping work, stable/low power consumption/strong anti-jamming ability, no direction 3. Ultra low power design (work =0.7mA, sleep=3uA) 4. Support 8*18 matrix, standard 104/107; 5. Supports FN + F1-F12 multimedia functions 6.Support low voltage alarm; Supports Caps Lock, Num Lock indicator lights, and LED status synchronization with host 7. Support Mouse/Keyboard set mode The code that Mode one: key combination code At the same time, short press "ESC" + "+/=" key for 1 second, the keyboard into the code mode (low voltage indicator light is long on), 20S insert receiver code successfully, LED immediately extinguished; Code failure, 20S after the keyboard exit code mode, LED out; Method two: on the code key code Press the key to code, the keyboard into code mode (low voltage indicator light is long), insert the receiver in 20S. Code success, LED immediately extinguished; Code failure, 20S after the keyboard exit code mode, LED out; Method three: software code Open the code matching software, insert the receiver into the USB interface, and automatically enter the code matching mode. Press the keyboard code matching key or "ESC" + "+/=" key for 1 second for code matching within 20 seconds. If the code matching is successful, the software will display < keyboard code matching is successful >; Otherwise, 20S after the launch of the code mode. Shenzhen Huayu Hongxin Electronic Technology Co., Ltd. 2.4G wireless keyboard Ver7.0 版 TEL: 0755-23729814 FAX: 0755-23729624 2018/12/01 Page 2 Functional description one Low voltage LED lamp: used to indicate low voltage and code status; At the same time in the maintenance can be used to prompt the problem points of defective products 1. Code status indication -- the keyboard enters the code mode, the low voltage LED is always on, the code is successful, the low voltage LED is extinguished 2. Low voltage status indicator -- when the battery is at low voltage, the low voltage LED flashes, the voltage is normal, the low voltage LED goes out 3. Abnormal function state indication: 1) Under normal circumstances -- power on, the indicator lights up and then goes off 2) Indicator light is not on -- the MCU is not working 3) Indicator light is always on -- RF is not working or EEPROM is not working II. Backlight function 1. The keyboard is powered on and the backlight panel is turned on by default. Press FN+ Scrlk to turn on/off the keyboard backlight 2. The brightness of the backlight is divided into three sections. The default is the second section. Press FN+Page Up to increase the backlight brightness and FN+Page Down to reduce the backlight brightness. 3. The backlight will automatically turn off when the keyboard and receiver are disconnected. 4. When the keyboard keys do not move, the backlight will be turned off after 2MIN. ** NUMLOCK + CAPS 2 LED states can be synchronized with host When the NUMLOCK/CAPS function is turned on, the LED will be on and indicate for 2MIN. If there are keys in 2MIN, the LED will be on for 2MIN again (the keys will be off after 2MIN release). If there are keys, the LED will continue to be on for 2MIN after the light is off Note: The low voltage indicator will flash 5 times after reaching the set value. When the key is pressed, the time will be reset for 2MIN until the power is exhausted Shenzhen Huayu Hongxin Electronic Technology Co., Ltd. 2.4G wireless keyboard Ver7.0 版 TEL: 0755-23729814 FAX: 0755-23729624 2018/12/01 Page 3 Total power consumption index Operating current (no backlight/backlight) 1.5mA/50MA Static current(keyrelease) 20uA Shenzhen Huayu Hongxin Electronic Technology Co., Ltd. 2.4G wireless keyboard Ver7.0 版 TEL: 0755-23729814 FAX: 0755-23729624 2018/12/01 Page 4 ● ● Keyboard matrix application description Large keyboard state 1. 104/107 key Matrix compatible with Yilong EMC83053, see "keyboard Matrix" on the next page for key arrangement 2. Description of multimedia functions of FN + F1-F12 Hold down FN and then press F1-F12. F1-F12 becomes the multimedia function key Default Hot key Default Hot key Default Hot key Default Hot key F1 Media F4 Mute F7 Play/Pause F10 E-mail F2 Volume- F5 PreTrack F8 CD Stop F11 My computer F3 Volume+ F6 NextTrack F9 web home F12 wwwFavorite Electrical characteristics IC_ CX5177 Keyboard IC_ CX5177 symbol Number VDD State Min Typical values Max Unit VDD Working voltage 2.3 3.0 4.5 V IDD Working current 3V Standby ≤3.0 uA Fosc system frequency 3V 1.0 MHz 2.4G RF IC _ BK2425 Symbol Number VDD State MIN values Max Unit VDD Working voltage 1.9 3.0 3.7 V IDD Working current 3V Word 23 mA Standby 3 uA Fosc System frequency 3V 16.0000 MHz Freq Working frequency band 2402 2480 MHz Rx Sens Receiving sensitivity -80 -87 dBm Shenzhen Huayu Hongxin Electronic Technology Co., Ltd. 2.4G wireless keyboard Ver7.0 版 TEL: 0755-23729814 FAX: 0755-23729624 2018/12/01 Page 5 ● ● RF product technical specification table（FCC，CE，KCC ） 1. Product Name : 2.4G Wireless Mouse/Keyboard 2. Rated Voltage and Current： DC 3V , 6mA 3. Frequency hopping method: FHSS 4. receiver sensitivity: -85dBm 5. Frequency Band : 2403.85MHz—2479.85MHz 6. Carrier Frequency : 2403.85 MHz 7. Channel Spacing: 1MHz 8. RF Output Power (ERP OR EIRP) : 0dBm 9. Modulation Type : GFSK 10. Duty Cycle : <10% 11. I.F.: 6 Mhz L.O.: 2601.6Mhz 12. Mode of operation (duplex , simplex): duplex 13. Bit Rate of Transmission : 2Mbps 14. Antenna Type: PCB Antenna 15. Antenna gain: -1~-2dBi 16. Operating Temperature Range: -20°C~ 55°C 17. Channel Bandwidth : 2MHz 18. Preset Target Market：EUROPE 19. Number of Channel: 16 1. 信道列表： Cha nnel 1 2 3 4 5 6 7 8 FRE（MHz） 2403.85 2407.85 2414.85 2419.85 2422.85 2426.85 2436.85 2439.85 Cha nnel 9 10 11 12 13 14 15 1…

Text truncated - open the document above for the full version.

Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Add: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Date: 2021-3-19 FCC ID: 2AZBD -T3 Dear Sir/Madam, We, Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: wireless keyboard Model no.: T3, T20, T30, T50, T61, T80, T82, T87, ZK-61, ZK-87 Sincerely, Name/Title： Xuejun Liu/Manager Company: Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Address: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Phone: 18244995516 Fax: / E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-3-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AZBD -T3 T3 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Xuejun Liu/Manager Company: Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Address: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Phone: 18244995516 Fax: / E-Mail: [email protected]

Shenzhen Junxingcheng Electronic Technology Co.,Ltd. F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-3-19 To whom it may concern: We, Shenzhen Junxingcheng Electronic Technology Co.,Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AZBD -T3 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Xuejun Liu/Manager Company: Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Address: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Phone: 18244995516 Fax: / E-Mail: [email protected]

GTSL202102000065 Product Name: wireless keyboard Test Model No.: T3 EUT Constructional Details External Photo Fig.1 Fig.2 GTSL202102000065 Fig.3 Fig.4 GTSL202102000065 Fig.5 Fig.6 GTSL202102000065 Fig.7

FCC ID: 2AZBD-T3 wireless keyboard Model No.: T3 FCC ID: 2AZBD-T3

GTSL202102000065 Product Name: wireless keyboard Test Model No.: T3 EUT Constructional Details Internal Photo Fig.1 Fig.2 Antenna GTSL202102000065 Fig.3 Fig.4

RF Exposure evaluation FCC ID: 2AZBD -T3 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK(Peak) Channel Channel 1 Channel 9 Channel 16 Target (dBm) -3.0 -4.0 -4.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW 2.4G 2.450 5 -2.0 0.6310 0.1975<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

Global United Technology Services Co., Ltd. Report No.: GTSL202102000065F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 34 TEST REPORT Applicant: Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Address of Applicant: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Manufacturer: Shenzhen Junxingcheng Electronic Technology Co.,Ltd. Address of Manufacturer: F308,block F,building 9,huachuangda culture and Technology Industrial Park,Hedong commercial city,49 District,Baoan District,Shenzhen China Equipment Under Test (EUT) Product Name: wireless keyboard Model No.: T3 Trade Mark: ZI YOU LANG FCC ID: 2AZBD -T3 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Feb.24,2021 Date of Test: Feb.24,2021- Mar.10,2021 Date of report issued: Mar.10,2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202102000065F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 34 2 Version Version No. Date Description 00 Mar.10,2021 Original Tested/Prepared By: Date: Mar.10,2021 Project Engineer Check By: Date: Mar.10,2021 Reviewer Report No.: GTSL202102000065F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 34 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY ....................................................................................................................................7 5.7 TEST LOCATION ..................................................................................................................................7 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 CONDUCTED OUTPUT POWER ............................................................................................................14 7.4 CHANNEL BANDWIDTH .......................................................................................................................15 7.5 POWER SPECTRAL DENSITY ..............................................................................................................17 7.6 BAND EDGES .....................................................................................................................................19 7.6.1 Conducted Emission Method ......................................................................................................19 7.6.2 Radiated Emission Method .........................................................................................................20 7.7 SPURIOUS EMISSION .........................................................................................................................23 7.7.1 Conducted Emission Method ......................................................................................................23 7.7.2 Radiated Emission Method .........................................................................................................26 8 TEST SETUP PHOTO .............................................................................................................................34 9 EUT CONSTRUCTIONAL DETAILS .......................…

Text truncated - open the document above for the full version.

GTSL202102000065 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 2 Product Name: wireless keyboard Test Model No.: T3 Test Setup Photo Radiated Emission GTSL202102000065 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 2 Conducted Emission ------End------
