2AZBM-IAAF40Fluorimetric Immunoassay Analyzer

Copyright © 2022 GenBody Inc. The hardware and software referred to in this User Manual are protected under the copyright law. Unless used for making a software copy for approved use in accordance with the copyright law, no information contained in this User Manual may be reproduced in whole or in part without the prior written permission of GenBody Inc. The information and specifications in this User Manual are subject to change without notice. Table of Contents 1. Warnings and Precaution for Safety 1.1 Warnings and Precaution for Safety 1.2 Precautions for Installation the Product 1.3 Precautions before Use 1.4 Precautions during Use 1.5 Precautions for Storing and Managing the System after Use 2. Product Introduction 2.1 Intended Use 2.2 Principle of Analysis 2.3 Product Components 2.4 Parts Description 3. Installation and Start 3.1 Powering on the system 3.2 Powering off the system 4. Test 4.1 Enter LOT Information(QR-Code) 4.2 Incubation & Read 4.3 Read without Incubation 5. Test Result 6. Test Patient 6.1 List of patients 6.2 How to register new patient information and delete 6.3 Checking patients testing record 7. How to monitor test results 8. Setting 9. Other Information 9.1 System Specification 9.2 System Characteristics 9.3 Product Service 1. Warnings and Precaution for Safety 1.1 Warnings and Precaution for Safety 1.1.1 For safe use of the instrument please be sure to read the User Manual thoroughly. 1.1.2 This user manual only contains exterior cleaning method and does not contain information about calibration, repairing or maintenance. In the event of a problem with the instrument, please contact your Dealer or GenBody Inc. for service. 1.1.3 Do not disassemble, repair or modify the instrument. 1.1.4 GenBody Inc. shall not be liable for any malfunction or damage to the product caused by improper operation not covered in this manual. 1.2 Precautions for Installation the Product 1.2.1 Do not install in an unsafe place(Indoor use). 1.2.2 Do not install the instrument near flammable materials or contaminated areas. 1.2.3 Do not install the instrument near moist or direct sunlight, near heating appliances, or near magnets 1.2.3 Use the AC-DC adapter provided by GenBody Inc. 1.2.4 Connect the power cord to a grounded outlet. Ungrounded outlets may cause damage to equipment or electrical shock 1.2.5 Install the location of the outlet in an easily accessible location. In the event of an issue, disconnect the plug to completely disconnect the power. 1.2.6 When moving the instrument, do not drop or shock the instrument. 1.3 Precautions before Use 1.3.1 This instrument is for In Vitro Diagnostics Only. 1.3.2 This instrument should be used only for analysis purposes of GenBody Inc. diagnostic kit s. 1.3 .3 This instrument should be used by medical professionals such as doctors and medical experimental scientists. 1.3.4 Read this manual and the kit manual thoroughly before using it. 1.3.5 Check the instrument regularly for damage or contaminants. 1.3.6 Use in a well-ventilated and dry place. 1.3.7 Ensure that the battery is sufficient before using it. If not, charge it in advance before using it. 1.4 Precautions during Use 1.4.1 Do not shock or move during analysis. 1.4.2 When putting the test cartridge, place it flat into the tray and then close the tray. 1.4.3 Touch the button analysis after the tray is closed. 1.4.4 Do not press the touch screen too hard or operate with wet hands. 1.4.5 It is recommended to use Shield LAN Cable. 1.5 Precautions for Storing and Managing the System after Use 1.5.1 Used cartridges should be treated in accordance with the Medical Waste Disposal Act. 1.5.2 Do not store the instrument in a place affected by temperature, humidity, or wind and so on. 1.5.3 Store the instrument on a flat surface and avoid shock or vibration. 1.5.4 Do not place any objects on the touch screen. 1.5.5 Operation Temperature at -10°C ~ +50°C, <80% RH 1.5.6 Storage Temperature at -10°C ~ +40°C, <80% RH 2. Product Introduction 2.1 Intended Use This product is intended to be used for in vitro diagnostic medical instrument for human body specimen and the response level is analyzed numerically and the qualitative and quantitative data will be calculated. 2.2 Principle of Analysis Insert the sample and buffer solution into the cartridge and then open the tray and insert the cartridge into the instrument and press the start button. During the reaction time the instrument will be running the test and the optical module inside the instrument will acquire a reactive image area of the cassette. The color signal generated in the reaction area, including the test line, are converted to digital signal through various image processing and mathematical calculations. The converted digital signal will be displayed on the screen so that the user can judge or numerically confirmed the result. 2.3 Product Components 2.4 Parts Description a. Ethernet port (RJ45) b. USB port (C-type) c. USB ports (2.0 A-type 2EA) d. Reset switch e. Power charging port f. LCD display (touch screen) g. Power button h. Indicator LED i. Te s t instrument tray 3. Installation and Start 3.1 Powering on the system Press the power button on the lower front of the instrudment and then the instrument will illuminate red LED indicator and the instrument will start booting. Test menu on the main screen is composed as follows: Test Menu Description TEST Initiate tests quickly, see results RESULTS Review and manage saved results PATIENTS Check patient list, enter and edit patient information Start the test after checking the patient's test history ITEM MANAGER Added new items and lot SETTING Enter user information Language setting Screen setting Date and time setting Test results backup and delete Reset Lot information Instrument information and update Network setting 3.2 Powering off the system Press the power button for 2~3 seconds, press OK button if power off pop-up message appears on the screen to turn off the power completely. …

Text truncated - open the document above for the full version.

Item Cont ents Antenna Type Multilayer Chip Antenna Antenna peak gain 3.5 ㏈i Manufacturer / Model name AMOTECH / - Address of manufacturer 5BL-1Lot, 617, Namchon-Dong, Namdong-Gu, Incheon, Korea Antenna Length 0.6 mm Antenna Width 0.1 mm Antenna Information Multilayer Chip Antenna Length Width Ant-Type no.ALA621C4 Dimension2(W)x6(L)x1.2(H) mm Application Bluetooth Zigbee WLAN (IEEE 802.11 b/g) ISM 2.4GHz Wireless Devices Features Helical Structure Size (6.0*2.0*1.2mm 3 ) Easy Optimizing with external lumped matching components SMT Available under Pb-free Condition RoHSCompliant DATASHEET DocumentDatasheet TypeMultilayer Chip Antenna Application2.4GHz Part No.ALA621C4 Revision6.0 Notes The contents of this datasheet are subject to change without notice. Please confirm the specifications and delivery conditions when placing your order. AMOTECH AMOTECH Co., Ltd. Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 2 Rev. NoDateTitleContentsPage 6’10.01.19FormatChangeddocument format Table of Content Revision History 1.Specifications 3 1.1 Electrical Specifications 3 1.2 Mechanical Specifications 3 1.3 Appearance and Material 3 2. PCB Design for Test 4 2.1 Evaluation BoardDimension 4 2.2 PCB Design Guide 4 3. Measurement Result 5 3.1 Typical Measurement Result (VSWR/RL,Smithchart) 5 3.2 Typical Measurement Result(Gain, Radiation Pattern) 6 4. Reliability 7 5. Soldering Reflow Profile 7 6. Packaging 8 6.1 Carrier Tape Dimension 8 6.2 PackagingQuantity 8 6.3 Packaging Label 8 Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 3 NoItemSpec.Remark 1Frequency Range [GHz]2.4 ~2.485 2VSWRMax 3.0:1 3Peak Gain [dBi]typ. 3.5 4Total Avg. Gain [dBi]typ. -0.25 5Efficiency [%]typ. 94 6PolarizationLinear 7Impedance [Ω]Nominal 50 The results are measured on the 10x43mm 2 evaluation board(EVB). See Page 6. for more detail gain parameter NoItemSpec.Remark 1Dimensions (LxWxH)6.0x2.0x1.2 mm 3 2Unit Weighttyp. 46 mg 3Operating Temperature-35 ~ +85 °C 1.1 Electrical Specifications 1.2 Mechanical Specifications NoItemFunctionMaterial ①External ElectrodeSoldering, Input PortAg/Ni/Sn ② Direction indexIndication of Ceramic ③Model No. index-Ceramic ④Ceramic Body-Ceramic ⑤External ElectrodeSolderingAg/Ni/Sn 1.3 Appearance & Material 1. Specifications ③ ④ ⑤ ② ① 0.6±0.2 6.0±0.3 2.0±0.2 Side 1.2±0.2 (unit : mm) A40600 Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 4 2.1 Evaluation Board Dimension 2.2 PCB Design Guide 2. PCB Design for Test NoPin Assignment ① Feeding ②N.C Matching Component [unit : mm] Evaluation board size ~ 10x43 Fill Cut Area (GND Clearance) ~ 10x13 [PCB Solder Land] 50 Ohm Feeding Line SMA Connector Chip Antenna GND Matching Stage [Unit : mm] 7.0 1.1 2.2 4.8 ① ② Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 5 3.1 Typical Measurement Result (VSWR/RL, Smithchart) 3. Measurement Result The results are measured on the 10x43mm 2 evaluation board(EVB). NoMatching Value ①N.C ②2.7 nH ③ 2.2 nH ③① ② Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 6 [Azimuth plane @2.45GHz ] [Elevation1 plane @2.45GHz ] [Elevation2 plane @2.45GHz ] [3D Radiation Pattern] 3.2 Typical Measurement Result (Gain, Radiation Pattern) x y z -y Azimuth E1 E2 Peak Gain (dBi) Avg. Gain (dBi) Total Avg. Gain (dBi) Efficiency (%) Azimuth 2.60.7 -0.2594 Elevation 1 3.5-0.6 Elevation 2 2.0-1.7 Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 7 NoItemTest ConditionTest Requirements 1 Adhesive Strength of Termination 1.Applied force on SMT chip till detached point from PCB. 1. No mechanical damage by applied force 2. Strength (F) > 5 kgf 2 Thermal Shock (Cycle) 1. Step 1 : -40 ±3°C, 30 min Step 2 : +125 ±3°C, 30 min 2. Number of cycle : 30 1. No visual damage 2. Within electric spec (VSWR) 3 High Temperature Resistance 1. Temperature : +125 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 4 Low Temperature Resistance 1. Temperature : -40 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 5Humidity 1. Humidity : 85 % RH Temperature : +85 ±3°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) F SMD PAD PCB 4. Reliability 5. Soldering Reflow Profile Datasheet / Multilayer Chip Antenna / 2.4GHz ALA621C4 (Rev 6.0) 8 ItemSpec.ItemSpec.ItemSpec. A02.30±0.10P04.00 ±0.10E1.75±0.10 B06.40±0.10P14.00 ±0.10F7.50±0.10 K01.35±0.10P22.00 ±0.10W16.00±0.30 D01.55±0.05--t0.30±0.05 Item QuantityDimension Reel2,000eaΦ7” * 12mm Inner Box6,000ea (3 reel)185 * 185 * 68 (mm 3 ) Outer Box130,000ea (5 Inner Box)375 * 200 * 205 (mm 3 ) Outer Box260,000ea (10 Inner Box)390 * 375 * 205 (mm 3 ) 6.1 Carrier Tape Dimension 6.2 Packaging Quantity 6.3 Packaging Label 6. Packaging AMOTECH Co., Ltd. 5BL-1Lot, 617, Namchon-Dong, Namdong-Gu, Incheon, Korea Multilayer Chip Antenna P/N : ALA621C4 Lot No : Quantity : 2,000 pcs Date : 2010/01/19

UNITED STATES DESIGNATED AGENT LETTER Date: 2023.05.10 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: GenBody Inc. Company Name: Americas Compliance Consulting LLC dba iCertifi Grantee Code: 2AZBM FRN: 0033399411 Contact Name: Chom kyu, Chong Contact Name: Paul Preston Address: 3-18, Eopseong 2-gil, Seobuk-gu Address: 1001 SW Disk Drive, Suite 250 City/Province/Zip: Cheonan-si, Chungcheongnam-do/South korea/31077 City/Province/Zip: Bend, Oregon 97702, United States Telephone: +82-041-523-8990 Telephone: +1(866) 885-4575 Fax: +82-041-523-8994 Fax: Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: < 2AZBM-IAAF40 > We, GenBody Inc. and Americas Compliance Consulting LLC dba iCertifi understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, GenBody Inc. and Americas Compliance Consulting LLC dba iCertifi acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): GenBody Inc. Name (Printed): Paul Preston Title: CEO Title: President Signature: Signature:

GenBody Inc. 3- 18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea May 19, 2023 Feder al Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a)co mply with the relevant provisions of the certification program; b)m ake all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)ma ke claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)up on suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by GenBody Inc. 3- 18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endea vor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ens ure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)tak e appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)docum ent the actions taken. This authorization is valid until further written notice from the applicant. Sinc erely yours, (Sign) Name/Title : Chom kyu, Chong / CEO Company Name : GenBody Inc.

May 19, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID : 2AZBM-IAAF40 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, GenBody Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give GenBody Inc. temporary confidentiality of commercially sensitive information prior to product release. The r equested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDE NTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 - Short-Te r m 5 External Photos 6 Internal Photos 7 Te s t-Setup Photos 8 User’s Manual GenBody Inc. 3-18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely yours, (Sign) Name / Title : Chom kyu, Chong / CEO Company Name : GenBody Inc. GenBod y Inc. 3-18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea

GenBody Inc. 3-18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea Letter of Declaration Product Equality May 19, 2023 We, as a manufacturer, hereby declare that our product has variant model names as listed below. Variant model is totally same as basic model but the only difference is use. There is no difference in appearance, PCB board, and hardware, and only the measurement list of software to distinguish the analysis target is different. Sincerely yours, Name / Title : Chom kyu, Chong / CEO Company Name : GenBody Inc. Tel: +82-041-523-8990 E-mail: [email protected]

Model name : Confiscope F40 External photos of EUT Model name : Confiscope F40 Front view of EUT Rear view of EUT Model name : Confiscope F40 Top view of EUT Bottom view of EUT Model name : Confiscope F40 Side view of EUT

Confiscope F40 < Rear view of EUT > FCC ID : 2AZBM-IAAF40 IC : 27104-IAAF40 FCC ID : 2AZBM-IAAF40 IC : 27104-IAAF40

Model name : Confiscope F40 Internal photos of EUT Model name : Confiscope F40 Internal view of EUT Model name : Confiscope F40 Top view of Main PCB Bottom view of Main PCB Bluetooth, WiFi Antenna Model name : Confiscope F40 View of Bluetooth & WIFI Module (with Shielding) View of Bluetooth & WIFI Module (without Shielding) Bluetooth, WiFi Module Model name : Confiscope F40 Top view of SUB1 PCB Bottom view of SUB1 PCB Model name : Confiscope F40 Top view of SUB2 PCB Bottom view of SUB2 PCB Model name : Confiscope F40 Top view of SUB3 PCB Bottom view of SUB3 PCB Model name : Confiscope F40 Top view of SUB4 PCB Bottom view of SUB4 PCB Model name : Confiscope F40 Top view of SUB4 PCB Bottom view of SUB4 PCB Model name : Confiscope F40 view of SUB5 PCB

FCC ID: 2AZBM-IAAF40 According to KDB 447498 D04 Interim General RF Exposure Guidance v01 1.SAR-based Exemption A more comprehensive exemption, considering a variable power threshold that depends on both the separation distance and power, is provided in § 1.1307(b)(3)(i)(B). This exemption is applicable to the frequency range between 300 ㎒ and 6 ㎓, with test separation distances between 0.5 ㎝ and 40 ㎝, and for all RF sources in fixed, mobile, and portable device exposure conditions. Accordingly, a RF source is considered an RF exempt device if its available maximum time-averaged (matched conducted) power or its effective radiated power (ERP), whichever is greater, are below a specified threshold. This exemption threshold was derived based on general population 1-g SAR requirements and is detailed in Appendix C. 2.RF Exposure Test Exemptions for Single Source Mode Frequency Range (㎒) Minimum Separation Distance (㎝) Maximum Average Target Power (㏈m) Maximum Tune up (㏈) Maximum Average Output Power (㏈m) Antenna Gain (㏈i) ERP P th 1) (㎽) Ratio Result (㏈m) (㎽) WLAN 2 2 412 ~ 2 462 0.5 3 2 5 3.5 6.35 4.32 6.83 0.63 Pass Bluetooth 2 402 ~ 2 480 0.5 1 2 3 3.5 4.35 2.72 6.79 0.40 Pass Not e ; - Maximum average target power is the manufacturer’s declared rated power. - Maximum average output power(㏈m) = Maximum average target power(㏈m) + Maximum tune up(㏈). - ERP(㏈m) = Maximum average output power(㏈m) + Antenna gain(㏈i) - 2.15 - Bluetooth and WLAN 2 can’t simultaneous transmission at the same time. 1)A ccording to clause 2.1.1 General RF Exposure Test Exemption Considerations of KDB 447498 D04 Interim General RF Exposure Guidance v01, When 10-g extremity SAR applies, SAR test exemption may be considered by applying a factor of 2.5 to the SAR-based exemption thresholds. 2)T hreshold level calculation of each mode WLA N 2 10-g SAR threshold level is 2.733 ㎽, applying factor of 2.5 for 10-g extremity SAR, final threshold level is 6.83㎽. Bluetooth 10-g SAR threshold level is 2.717 ㎽, applying factor of 2.5 for 10-g extremity SAR, final threshold level is 6.79 ㎽. 3. Conclusion: No SAR is required.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 2 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents Page 1. General Information --------------------------------------------------------------------------------- 3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emissions ---- 10 3. 20 ㏈ Bandwidth & 99 % Bandwidth ---------------------------------------------------------- 33 4. Maximum Peak Conducted Output Power ---------------------------------------------------- 42 5. Carrier Frequency Separation ------------------------------------------------ -------------------- 44 6. Number of Hopping Frequencies ---------------------------------------------------------------- 46 7. Time of Occupancy(Dwell Time) ----------------------------------------------------------------- 48 8. AC Power Line Conducted Emission ----------------------------------------------------------- 56 9. Antenna Requirement ------------------------------------------------------------------------------ 61 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 3 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant FCC Applicant : GenBody Inc. FCC Address : 3-18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, South Korea, 31077 IC Applicant : GenBody Inc. IC Address : 3-18, Eopseong 2-gil, Seobuk-gu, Cheonan-si, Chungcheongnam-do, South Korea, 31077 Contact Person : Chong, Chom-kyu Phone No. : +82 41 523 8990 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Fluorimetric Immunoassay Analyzer Model Name Confiscope F40 Variant Model Names Confiscope F40V Serial Number CF4H2022KR00001, CF4H2022KR00002 Power Supply DC 7.2 V Frequency Range 2 402 ㎒ ~ 2 480 ㎒ (Bluetooth) Modulation Technique GFSK, π/4DQPSK, 8DPSK Number of Channels 79 channels (Bluetooth) Antenna Type Multilayer Chip Antenna Antenna Gain ※ 3.5 ㏈i H/W Version 1.0 S/W Version 0.1.3 FVIN N/A SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 4 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Information about the FHSS characteristics: 1.5.1. Pseudorandom Frequency Hopping Sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 1.5.2. Equal Hopping Frequency Use The channels of this system will be used equally over the long-term distribution of the hopsets. 1.5.3. Example of a 79 hopping sequence in data mode: 02, 05, 31, 24, 20, 10, 43, 36, 30, 23, 40, 06, 21, 50, 44, 09, 71, 78, 01, 13, 73, 07, 70, 72, 35, 62, 42, 11, 41, 08, 16, 29, 60, 15, 34, 61, 58, 04, 67, 12, 22, 53, 57, 18, 27, 76, 39, 32, 17, 77, 52, 33, 56, 46, 37, 47, 64, 49, 45, 38, 69, 14, 51, 26, 79, 19, 28, 65, 75, 54, 48, 03, 25, 66, 05, 16, 68, 74, 59, 63, 55 1.5.4. System Receiver Input Bandwidth Each channel bandwidth is 1 ㎒. The system receivers have input bandwidths that match the hopping channel bandwidths of their corresponding transmitters and shift frequencies in synchronization with the transmitted signals. 1.5.5. Equipment Description 15.247(a) (1) that the Rx input bandwidths shift frequencies in synchronization with the transmitted signals. 15.247(g): In accordance with the Bluetooth Industry Standard, the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) system. 15.247(h): In accordance with the Bluetooth Industry Standard, the system does not coordinate it channels selection/ hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 5 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.6. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator R&S SMA100B 106887 Oct. 13, 2022 Annual Oct. 13, 2023 Spectrum Analyzer R&S FSV30 103210 Dec. 07, 2022 Annual Dec. 07, 2023 Spectrum Analyzer Agilent N9020A MY53421758 Aug. 26, 2022 Annual Aug. 26, 2023 Bluetooth Tester TESCOM TC-3000C 3000C000560 Sep. 14, 2022 Annual Sep. 14, 2023 Directional Coupler KRYTAR 152613 122660 Jul. 06, 2022 Annual Jul. 06, 2023 BRIDGE COUPLER MARKI MICROWAVE INC CBR16-0012 1542 May 06, 2022 Annual May 06, 2023 High Pass Filter Wainwright Instrument GmbH WHKX3.0/18G-6SS 21 Jun. 09, 2022 Annual Jun. 09, 2023 High Pass Filter Wainwright Instrument GmbH WHNX7.5/26.5G-6SS 15 May 31, 2022 Annual May 31, 2023 Low Pass Filter Mini-Ci…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 30 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) Middle channel SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 31 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) High channel SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 32 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) Mode: 8DPSK_hopping function turned on Band edge compliance Low channel High channel SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 33 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 3. 20 ㏈ Bandwidth and 99 % Bandwidth 3.1. Test Setup EUT Directional Coupler Bluetooth Tester Spectrum Analyzer 3.2. Limit Limit: Not Applicable 3.3. Test Procedure 3.3.1. 20㏈ Bandwidth The test follows ANSI C63.10-2013. The 20㏈ bandwidth was measured with a spectrum analyzer connected to RF antenna connector (conducted measurement) while EUT was operating in transmit mode at the appropriate center frequency. Use the following spectrum analyzer setting: 1. Span = approximately 2 to 5 times the 20 ㏈ bandwidth. 2. RBW ≥ 1 % to 5 % of the 20 ㏈ bandwidth. 3. VBW ≥ 3 x RBW 4. Sweep = auto 5. Detector = peak 6. Trace = max hold The marker-to-peak function to set the mark to the peak of the emission. Use the marker-delta function to measure 20 ㏈ down one side of the emission. Reset the function, and move the marker to the other side of the emission, until it is (as close as possible to) even with the reference marker level. The marker-delta reading at this point is 20 ㏈ bandwidth of the emission. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003991 Page: 34 of 61 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 3.3.2. 99 % Bandwidth ● The span of the spectrum analyzer shall be set large enough to capture all products of the modulation process, including the emission skirts, around the carrier frequency, but small enough to avoid having other emissions (e.g. on adjacent channels) within the span. ● The detector of the spectrum analyzer shall be set to “Sample”. However, a peak, or peak hold, may be used in place of the sampling detector since this usually produces a wider bandwidth than the actual bandwidth (worst-case measurement). Use of a peak hold (or “Max Hold”) may be necessary to …
