2AZBY-TLJZPAD3-4Touchscreen Keypad

Compatible TLJ Locks - TLJ Infinity - TLJ Identity - TLJ RezLok - Invisible by TLJ Contents Box Contents.......................................................................2 Installation............................................................................2 Guidance Symbols..............................................................3 Initial Setup...........................................................................4 Pairiing Zpas to Door Lock..................................................6 Operating Mode - Z-Wave™..............................................10 Operating Mode - DIY.........................................................11 Factory Rest........................................................................15 Users List............................................................................16 Troubleshooting..................................................................17 Page 1 Important Note compatible firmware is required for Zpad pairing. i ST3.5 * 16mmX6 M4 * 5mmX1 Zpad to bracket xing screw Bracket to wall xing screws Zpad panelRubber gasketMetal wall bracketAA battery securing clip Installation Box Contents Zpad panel Rubber gasket Metal wall bracket AA battery securing clip Zpad to bracket xing screw Bracket to wall xing screws 4 x AA batteries (not included) Page 2 Guidance Symbols 123 456 789 0 Return/Exit & Low Battery (blinks) Enter Digital Touch Pad Speaker 2 456 8 456 13 5 8 13 456 79 13 5 79 Add The plus symbol will illuminate when the user is inputting a new PIN, i.e. ‘Add new User PIN’ or ‘Create the Master PIN’ Delete The minus symbol will illuminate when the user is removing an exisiting PIN, i.e. ‘Delete User PIN’ or ‘Delete Admin User PIN’ Master The letter M symbol will illuminate when the user is required to input the Master PIN code, i.e. ‘Input Master to access the Menu’ Success The letter Y symbol will illuminate when the user has successfully completed an operation or changed a setting Failure The letter X symbol will illuminate when there has been an error such as inputting an incorrect User PIN or inputting an invalid setting parameter Page 3 Creating the Master PIN Code This must be performed after installation or following any factory reset. Programming the Zpad is not possible until a Master PIN Code has been created. Touch to wake 1 123 456 789 0 2 Input a 6 - 8 Digit Master PIN code Press the Enter button Important Note the Master PIN code must not be a simple combination or the Zpad will reject it i 123 456 789 0 3 Repeat, input the same PIN code again Press the Enter button Initial Setup If a Master Code is not created, the Zpad will timeout to save battery life. Touch to Wake and continue to create a Master Code. Page 4 Choosing the Operation Mode The Zpad has 2 dierent operations; Z-Wave (to be controlled and managed by a 3rd party platform via a gateway) & DIY (to be controlled and managed manually using the onboard menu) 12 1 1 = Z-Wave™ 2 = DIY Press required Important Note It is possible to change the operation mode later i If the operation mode is not chosen, the Zpad will timeout to save battery life and select option 1, Z-Wave™ mode by default. Page 5 i) Insert the metal key (provided with the TLJ lock) & rotate to retract the latch ii) Hold it in this position, notice the red LED illuminated on the TLJ lock iii) Present an RFID key card or key fob iv) Hold the card and key steady until the TLJ lock emmits a “beep” v) Release & remove the metal key and key card vi) Label the key card “Owner Card” be sure to keep it safe “beep” Important Note the Owner Card is used to control the lock as well as unlocking the door. Each lock can only have one Owner Card, but the same Owner Card can belong to more than one lock i O���� C�r� The Zpad requires a compatible paired door lock, and the door lock requires an Owner Card to do this. TLJ Innity Pairing Zpad to Door Lock Assigning an Owner Card Page 6 TLJ TLJ “beep” “beep” i) Insert the metal key (provided with the TLJ lock) & rotate to retract the latch ii) Hold it in this position, notice the red LED illuminated on the TLJ lock iii) Present an RFID key card or key fob iv) Hold the card and key steady until the TLJ lock emmits a “beep” v) Release & remove the metal key and key card vi) Label the key card “Owner Card” be sure to keep it safe TLJ Identity i) Remove the faceplate (fixed by 4 small grub screws) ii) Press & Hold the button, notice the red LED illuminated on the TLJ lock iii) Present an RFID key card or key fob iv) Hold the card steady until the TLJ lock emmits a “beep” v) Release the button and replace the faceplate vi) Label the key card “Owner Card” be sure to keep it safe TLJ Invisible HOLD Page 7 i) Press and hold the Enter key ii) The Zpad will beep x 2, release the Enter key iii) Input your Master PIN code & press the Enter Key iv) Zpad Menu mode now active, press 1 to enter Pair to Lock mode v) The Zpad LED’s will blink, awaiting nearby locks to request pairing. After 30 seconds of inactivity, the Zpad will return to Menu mode Page 8 “beep” i) Press & hold the privacy button located on the inside lever handle ii) Present an RFID key card or key fob iii) Hold the card and key steady until the TLJ lock emmits a “beep” iv) Release the button & remove the key card v) Label the key card “Owner Card” be sure to keep it safe TLJ RezLok The onboard Zpad Menu is used to access lock pairing mode. Entering Zpad into Lock Pairing Mode Menu Mode HOLD 123 456 789 0 HOLD i) Present & hold the ‘Owner Card’ to the lock ii) The lock will unlock initially but continue to hold the ‘Owner Card’ untill a “beep” “beep” is sounded and the LED’s begin to blink iii) Take away the ‘Owner Card’. The lock is now in pairing mode iv) Ensure the Zpad & Lock are within 2 meters proximity, allow 10-15 secs for pairing to complete v) When the Lock LED’s stop blinking & the Zpad returns to Menu mode then pairing is complete. Press Exit on the Zpad to close Menu mode. vi) In…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 TLJ Group Limited Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both TLJ USA (“Agent”) and TLJ Group Limited (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I Luke A Martin HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : TLJ Group Limited Contact Name : Luke A Martin Address : 68/78 Leads Road, HULL, East Yorkshire, HU7 0BY, United Kingdom Telephone No : +441482830334 Email : [email protected] Applicant FRN : 0030696678 Signature: _________________________________ Date: _______17 th _May 2023_________________ I Barry Saunders HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to all certification applications to the FCC submitted by above applicant and agree to immediately notify the FCC and Intertek if there is change in this representation. Agent Company Name : TLJ USA Contact Name : Barry Saunders Address : 24787 N. 90th Way Scottsdale, AZ 85255 United States Telephone No : (480) 312-3111 Email : [email protected] Agent FRN : 0033699638 Signature: ____________________________________ Date: ________17 th _May 2023__________________

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 TLJ Group Limited Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: TLJ Group Limited FCC ID: 2AZBY-TLJZPAD3-4 To whom it may concern, TLJ Group Limited (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ Luke A Martin Chief Technical Officer TLJ Group Limited 23 th March 2023

TLJ Group Limited 28 th February 2023 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement TLJ Group Limited FCC ID: 2AZBY-TLJZPAD3-4 To Whom It May Concern: We, TLJ Group Limited, hereby authorized Intertek Testing Services Shenzhen Ltd. Guangzhou Branch to act as our Agent for the purpose of preparing application for FCC ID number 2AZBY- TLJZPAD3-4 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 28 th April 2023. The Limited Agency Agreement expires on 28 th October 2023, unless sooner terminated or extended by written notice to Intertek Testing Services Shenzhen Ltd. Guangzhou Branch and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Mr Luke A Martin Chief Technical Officer

1(1) TLJ Group Limited 23 th March 2023 Attention: Application Examiner RE: Request for Confidentiality Applicant: TLJ Group Limited FCC ID: 2AZBY-TLJZPAD3-4 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by TLJ Group Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: TLJ Group Limited has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] If you have questions or need further information, please contact the undersigned. Sincerely, Mr Luke A Martin Chief Technical Officer TLJ Group Limited

FCC ID:2AMWOFSC-BT691 FCC ID:2ALPH-E104BT5032A

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230328018GZU FCC ID: 2AZBY-TLJZPAD3-4 Version: 06 November 2020 Page 1 of 3 FCC simultaneously transmitter-Mobile (MPE) RF Exposure Compliance Requirement Model no.: ZPAD3.4 1. Standard requirement Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀, H׀ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100000 -- -- 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ׀,H׀ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230328018GZU FCC ID: 2AZBY-TLJZPAD3-4 Version: 06 November 2020 Page 2 of 3 FCC simultaneously transmitter-Mobile (MPE) 2. MPE Calculation Method E (V/m)=(30*P*G) 0.5 /d Power Density: Pd(W/m 2 )=E 2 /377 E=Electric Field (V/m) P=Peak RF output Power (W) G=EUT Antenna numeric gain (numeric) d= Separation distance between radiator and human body (m) The formula can be changed to Pd= (30*P*G)/(377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. 3. Calculated Result and Limit Z-wave: E=93.5dBμV@3m(max. value provided by client) Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 908.4-916 -1.7 0.68 0.00013 0.6 Complies MPE ratio: 0.00013(mW/cm 2 )/0.6(mW/cm 2 ) = 0.000217 FSC-BT691 Bluetooth: Peak Output Power = -1.108dBm(max.value declared by client), antenna gain = 2dBi Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2402-2480 1.58 -1.108 0.77 0.00024 1 Complies MPE ratio: 0.00024 (mW/cm 2 )/1(mW/cm 2 ) = 0.00024 Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 230328018GZU FCC ID: 2AZBY-TLJZPAD3-4 Version: 06 November 2020 Page 3 of 3 FCC simultaneously transmitter-Mobile (MPE) E104-BT5032A: Peak Output Power = -35.23dBm(max.value declared by client), antenna gain = 1dBi Frequency (MHz) Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2402-2480 1.26 -35.23 0.0003 0.00000075 1 Complies MPE ratio: 0.00000075 (mW/cm 2 )/1(mW/cm 2 ) = 0.00000075 Sum of the MPE ratio for all simultaneously transmitting antennas: 0.000217+0.00024+0.00000075 = 0.00045775 < 1 According to MPE test Exclusion condition in KDB 447498 (D01) General RF Exposure Guidance D01 v06, the MPE report is not required. Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

TLJ Group Limited TEST REPORT SCOPE OF WORK EMC TESTING–ZPAD3.4 REPORT NUMBER 230328018GZU-001 ISSUE DATE [REVISED DATE] 05-June-2023 [---------------------] PAGES 34 DOCUMENT CONTROL NUMBER FCC Part 15.249-f © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 14 December 2022 Page 2 of 34 FCC Part 15.249-f Applicant Name & Address : TLJ Group Limited 68 / 78 Leads Road, Hull, East Yorkshire, HU7 0BY, UK Manufacturing Site : Same as Applicant Intertek Report No: FCC ID: 230328018GZU-001 2AZBY-TLJZPAD3-4 Test standards 47 CFR PART 15 Subpart C: 2021 section 15.249 Sample Description Product : Touchscreen Keypad Model No. : ZPAD3.4 Electrical Rating : DC 4×1.5V Battery Serial No. : Not Labeled Date Received : 28 March 2023 Date Test Conducted : 12 April 2023-05 June 2023 Prepared and Checked By Richard Liu Engineer Approved By: Dean Liu Project Engineer TEST REPORT Intertek Report No.: 230328018GZU-001 Version: 14 December 2022 Page 3 of 34 FCC Part 15.249-f CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION .............................................................................................. 5 2.1 PRODUCT DESCRIPTION ........................................................................................................ 5 2.2 RELATED SUBMITTAL(S) GRANTS ............................................................................................ 5 2.3 TEST METHODOLOGY ........................................................................................................... 5 2.4 TEST FACILITY ...................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION .................................................................................. 6 3.1 JUSTIFICATION ..................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE.................................................................................................. 7 3.3 SPECIAL ACCESSORIES ........................................................................................................... 7 3.4 MEASUREMENT UNCERTAINTY ............................................................................................... 7 3.5 EQUIPMENT MODIFICATION .................................................................................................. 8 3.6 SUPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 4.0 MEASUREMENT RESULTS ........................................................................................... 9 4.1 ANTENNA REQUIREMENT ...................................................................................................... 9 4.2 OCCUPIED BANDWIDTH ...................................................................................................... 10 4.3 RADIATED EMISSION .......................................................................................................... 12 4.4 BAND EDGES REQUIREMENT ................................................................................................ 26 4.5 CONDUCTED EMISSIONS AT MAINS TERMINALS ...................................................................... 33 5.0 TEST EQUIPMENT LIST ............................................................................................. 34 TEST REPORT Intertek Report No.: 230328018GZU-001 Version: 14 December 2022 Page 4 of 34 FCC Part 15.249-f 1.0 TEST RESULT SUMMARY Test Item Test Requirement Test Method Result Antenna Requirement FCC PART 15 C Section 15.203 FCC PART 15 C Section 15.203 PASS Occupied Bandwidth FCC PART 15 C section 15.215(c) ANSI C63.10: Clause 6.9 PASS Radiated Emission FCC PART 15 C section 15.249 (a), (d) ANSI C63.10: Clause 6.4, 6.5 & 6.6 PASS Band Edges Measurement FCC PART 15 C section 15.249 (d) ANSI C63.10: Clause 6.10 PASS Conducted Emissions at Mains Terminals FCC PART 15 C section 15.207 ANSI C63.10: Clause 6.2 N/A Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency.…

Text truncated - open the document above for the full version.

3.3cm 1 .7cm

Note:EUT is positioned at the center of the turntable to keep 3 m between the measurement antenna and EUT for the radiated emissions measurements Radiated Emission (Below 1GHz) Radiated Emission (Above 1GHz)
