2AZDO-BG013wireless charger

Wireless Charger-Quick Guide 01/Operation manual 1. Plug the charging cable into the wireless charger. 2. Attach the watch to the wireless charger，and when the charging icon is displayed on the watch pane， The watch starts charging wirelessly. 3. Remove the watchfrom the wireless char Product Name: Wireless Charger Product model:BG013 Product color: white Product material:ABS Input port: USB-A Input: 5v/0.8a Output: 2.5W(Max) Product size:OD28mm×7.7mm Cable length1m ger when charging is completed. 03/Safety tips 1.Do not put foreign metal objects in the charging area between the phone and wireless charger, which will lead to latent danger. 2.Do not put magnetic stripe cards (such as credit cards, telephone cards, bank cards, etc.) or some medical equipment (such as pacemakers or hearing aids) together with this product, which may cause damage to the magnetic stripe or abnormal operation of the equipment. 3.Do not apply heavy pressure and place it out of reach of children or animals. 4.Do not disassemble, refit and repair the wireless charger by oneself, otherwise it will not be able to carry out normal after-sale 02/ Notes It is recommended that the charging ambient temperature be lower than 28 degrees Celsius, as higher temperatures can lead to a decrease in charging efficiency. service. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Gabb Wireless Inc. FRN: 0030719868 Contact Name: Colin Cole Address: 4101 N Thanksgiving Way #300, Lehi, Utah 84043 USA Telephone No: (385)248-7798 Email: [email protected] Applicant: Company name: Gabb Wireless Inc. FRN: 0030719868 Product Description: wireless charger Grantee code: 2AZDO FCC ID: 2AZDO-BG013 Contact Name: Colin Cole Address: 4101 N Thanksgiving Way #300, Lehi, Utah 84043 USA Telephone No: 801 864 5552 Email: [email protected] [Gabb Wireless Inc.] certifies that, as of the date of this filing of the application with the TCB, [Gabb Wireless Inc.] is our designated US agent for service of process for the above referenced FCC ID. [Gabb Wireless Inc.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Gabb Wireless Inc.] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 06.08. 2026 Applicant’s Name: Colin Cole US Agent’s Name: Colin Cole Title: VP Product Title: VP Product Signature Signature

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Gabb Wireless Inc. Grantee code: 2AZDO FCC ID: 2AZDO-BG013 FRN: 0030719868 Contact Name: Colin Cole Address: 4101 N Thanksgiving Way #300, Lehi, Utah 84043 USA Telephone No: 801 864 5552 Fax No: 801 864 5552 Email: [email protected] i. [Gabb Wireless Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Gabb Wireless Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Gabb Wireless Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 06.08.2026 Applicant’s Name: Colin Cole Title: VP Product Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Gabb Wireless Inc. Code 00018768 Ed. 2 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A Device wireless charger Company name Gabb Wireless Inc. Grantee code 2AZDO FCC ID 2AZDO-BG013 FRN 0030719868 Contact name Colin Cole Address 4101 N Thanksgiving Way #300, Lehi, Utah 84043 USA Telephone number 801 864 5552 E-mail [email protected] Chipset/module information CP8051A Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A 3 # General Requirements (For Linux system) Yes / No or N/A Comments 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher N/A 3 RAM: 1 GB N/A 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; N/A After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software 4 Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Colin Cole Date: 6/8/2026 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

TCBCALLpágina1 FileFCCID:2AZDO-BG013 PleaseuploadanexhibitthatexplainshowdoestheTCBverifythenewagentinformation: 1-IstheaddressoftheagentavalidphysicalUSmailingaddress(notaUSpostofficebox,notavirtualmailbox,notP.O.Boxes,notavacantlot,notapublicbuilding, etc.) ○Wehavecheckediftheaddressexistsinarealandpotentialbuilding(Googlemaps)+officialUSregister,afterthisverificationandtheevidencebelowwecan guaranteethefollowing: notaUSpostofficebox notavirtualmailbox notP.O.Boxes notavacantlot notapublicbuilding(note) ►WecheckedtheFCCFRNSearchbasedontheinformationprovidedbythegrantee. Google: TCBCALLpágina2 TCBCALLpágina3 ►CONCLUSIONbyTCB:TheASOPdefinedandprovidedbygranteeisVALIDandconfirmed.Thereforetheexhibit"C5266091_X23_Ed1_US_Agent_Letter" includedinthefileisok. 2-IstheagentphysicallylocatedatthatvalidUSaddresssuchthattheagentcanbelegallyservedatthataddress? Yes,checkabove 3-Hasthelistedagentclearlyagreedinwritingtoserveastheagentforthegranteeatthataddress? Yes,itisincludedintheexhibit"C5266091_X23_Ed1_US_Agent_Letter"

C5266091_X10_Ed.2 1/1 Gabb Wireless Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 6/8/2026 Subject: Request for Confidentiality FCC ID: 2AZDO-BG013 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Colin Cole Title: VP Product

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Gabb Wireless Inc. Address: 4101 N Thanksgiving Way #300, Lehi, Utah 84043 USA Product Name: wireless charger Model Number: BG013 FCC Identifier: 2AZDO-BG013 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Colin Cole Date: 6/8/2026 Title: VP Product Signature of applicant:

Page1of4ReportNo.:MTi260507030-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(ExternalPhotos) Model:BG013 Page2of4ReportNo.:MTi260507030-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of4ReportNo.:MTi260507030-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page4of4ReportNo.:MTi260507030-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

19.19 mm

Page1of2ReportNo.:MTi260507030-0102 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(InternalPhotos) Model:BG013 Page2of2ReportNo.: MTi260507030-0102 Address:101, No. 7, Zone 2, XinxingIndustrialPark, Fuhai Avenue,Xinhe Community,Fuhai Street, Bao ’an District,Shenzhen,Guangdong,China. Tel: 0755-88850135-1439Mobile:131-4343-1439(Wechatsame number)Web: http://www.mtitest.cnE-mail:[email protected] Coil

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 1 of 15 TestReport ReportNo.:MTi260507030-0102E2 DateofIssue:2026-05-29 Applicant:GabbWirelessInc. Product:wirelesscharger Model(s):BG013 FCCID:2AZDO-BG013 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260507030-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page2of15 Tableofcontents 1GeneralDescription.............................................................................................................4 1.1DescriptionoftheEUT..........................................................................................................................4 1.2Descriptionoftestmodes......................................................................................................................4 1.3Descriptionofsupportunits...................................................................................................................5 2Measurementuncertainty...................................................................................................5 3Testfacilitiesandaccreditations.......................................................................................6 3.1Testlaboratory.......................................................................................................................................6 4Listoftestequipment..........................................................................................................7 5Testresult.............................................................................................................................8 5.2Testsetup..............................................................................................................................................9 5.3TestProcedures.....................................................................................................................................9 5.4Informationoftestequipment..............................................................................................................10 5.5Testresults...........................................................................................................................................11 PhotographsoftheTestSetup................................................................................................13 PhotographsoftheEUT...........................................................................................................14 TESTREPORT ReportNo.:MTi260507030-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 3 of 15 TestResultCertification ApplicantGabbWirelessInc. ApplicantAddress4101NThanksgivingWay#300,Lehi,Utah84043USA ManufacturerGabbWirelessInc. ManufacturerAddress4101NThanksgivingWay#300,Lehi,Utah84043USA FactoryShenzhenJibangTechnologyCo.,ltd FactoryAddress Building2,No.156HuawangRoad,Dalang,LonghuaNewDistrict, Shenzhen,Guangdong,China518109 Productdescription Productnamewirelesscharger TrademarkGabb ModelnameBG013 SeriesModel(s)N/A Standards 47CFRPART1,§1.1310 47CFRPART2.1091 TestmethodKDB680106D01WirelessPowerTransferv04 TestingInformation Dateoftest2026-05-22to2026-05-27 TestResultPass Preparedby:MaleahDeng Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260507030-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 4 of 15 1GeneralDescription 1.1DescriptionoftheEUT Productname:wirelesscharger Modelname:BG013 SeriesModel(s):N/A Modeldifference:N/A Electricalrating: Input:DC5V,0.8A WirelessOutput:2.5W Accessories:N/A Hardwareversion:OUP1902 Softwareversion:V8 Testsample(s)number:MTi260507030-01-R001 RFspecification Operatingfrequency range: 135-150kHz(AppleWatch);270-290kHz(GabbWatch) Modulationtype:ASK Antenna(s)type:CoilAntenna 1.2Descriptionoftestmodes AllthetestmodeswerecarriedoutwiththeEUTinnormaloperation,thefinaltestmodeofthe EUTwastheworsttestmodeforemissiontest,whichwasshowninthisreportanddefinedas: No.Emissiontestmodes Mode1WirelessOutput(AppleWtach(2.5W) Mode2WirelessOutput(GabbWatch(2.5W) Mode3Standby TESTREPORT ReportNo.:MTi260507030-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 5 of 15 1.3Descriptionofsupportunits TheEUThasbeentestedasanindependentunittogetherwithothernecessaryaccessoriesor supportunits.Thefollowingsupportunitsoraccessorieswereusedtoformarepresentativetest configurationduringthetests. Supportequipmentlist DescriptionModelSerialNo.Manufacturer USB-AHUAWEI CHARGE(10W) HW-050200C02K95212KA103561HUAWEI WatchAppleWatchSE/Apple WatchGW23/Gabb Supportcablelist DescriptionLength(m)FromTo //// 2Measurementuncertainty ParameterExpandedUncertainty Magneticfieldmeasurements(3kHz~10MHz)± 14.8 ％ Electricfieldmeasurements(3kHz~10MHz)±17.5% Thisuncertaintyrepresentsanexpandeduncertaintyexpressedatapproximatelythe95% confidencelevelusingacoveragefactorofk=2. TESTREPORT ReportNo.:MTi260507030-0102E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:m…

Text truncated - open the document above for the full version.

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 1 of 29 TestReport ReportNo.:MTi260507030-0102E1 Dateofissue:2026-05-29 Applicant:GabbWirelessInc. Product:wirelesscharger Model(s):BG013 FCCID:2AZDO-BG013 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260507030-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 2 of 29 Tableofcontents 1GeneralDescription.......................................................................................................................4 1.1DescriptionoftheEUT.........................................................................................................4 1.2Descriptionoftestmodes.....................................................................................................4 1.3EnvironmentalConditions.....................................................................................................5 1.4Descriptionofsupportunits..................................................................................................5 1.5Measurementuncertainty.....................................................................................................5 2SummaryofTestResult................................................................................................................6 3TestFacilitiesandaccreditations................................................................................................7 3.1Testlaboratory......................................................................................................................7 4Listoftestequipment....................................................................................................................8 5EvaluationResults(Evaluation).................................................................................................10 5.1Antennarequirement..........................................................................................................10 6RadioSpectrumMatterTestResults(RF).................................................................................11 6.1ConductedEmissionatACpowerline...............................................................................11 6.220dBOccupiedBandwidth.................................................................................................14 6.3Emissionsinfrequencybands(below30MHz)..................................................................18 6.4Emissionsinfrequencybands(30MHz-1GHz)................................................................23 Photographsofthetestsetup...........................................................................................................27 PhotographsoftheEUT.....................................................................................................................28 TESTREPORT ReportNo.:MTi260507030-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 3 of 29 TestResultCertification ApplicantGabbWirelessInc. ApplicantAddress4101NThanksgivingWay#300,Lehi,Utah84043USA ManufacturerGabbWirelessInc. Manufacturer Address 4101NThanksgivingWay#300,Lehi,Utah84043USA FactoryShenzhenJibangTechnologyCo.,ltd FactoryAddress Building2,No.156HuawangRoad,Dalang,LonghuaNewDistrict, Shenzhen,Guangdong,China518109 Productdescription Productnamewirelesscharger TrademarkGabb ModelnameBG013 SeriesModel(s)N/A Standards47CFRPart15C TestMethodANSIC63.10-2020+Cor.1-2023 TestingInformation Dateoftest2026-05-22to2026-05-27 TestresultPass Preparedby:MaleahDeng Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260507030-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 4 of 29 1GeneralDescription 1.1DescriptionoftheEUT Productname:wirelesscharger Modelname:BG013 SeriesModel(s):N/A Modeldifference:N/A Electricalrating: Input:DC5V,0.8A WirelessOutput:2.5W Accessories:N/A Hardwareversion:OUP1902 Softwareversion:V8 Testsample(s)number:MTi260507030-01-R001 RFspecification Operatingfrequency range: 135-150kHz(AppleWatch);270-290kHz(GabbWatch) Modulationtype:ASK Antenna(s)type:CoilAntenna 1.2Descriptionoftestmodes No.Emissiontestmodes Mode1WirelessOutput(AppleWtach(2.5W) Mode2WirelessOutput(GabbWatch(2.5W) Mode3Standby TESTREPORT ReportNo.:MTi260507030-0102E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 5 of 29 1.3EnvironmentalConditions Duringthemeasurementtheenvironmentalconditionswerewithinthelistedranges: Temperature:15°C~35°C Humidity:20%RH~75%RH Atmosphericpressure:98kPa~101kPa 1.4Descriptionofsupportunits TheEUThasbeentestedasanindependentunittogetherwithothernecessaryaccessoriesor supportunits.Thefollowingsupportunitsoraccessorieswereusedtoformarepresentativetest configurationduringthetests. Supportequipmentlist DescriptionModelSerialNo.Manufacturer USB-AHUAWEI CHARGE(10W) HW-050200C02K95212KA103561HUAWEI wirelesscharging load(AppleWatch) YBZ(V2.0.4)/YBZ GabbWatchGW23/Gabb Supportcablelist DescriptionLength(m)FromTo //// 1.5Measurementuncertainty MeasurementUncertai…

Text truncated - open the document above for the full version.

天夏 Page 1 of 3 承认 书 SPECIFICATION FOR APPROVAL 客 户 客 户 料 CUSTOMER: jibang 号： CUST P/N: 天 夏 料 号： TX P/N: 产 品 型 号 DESC: φ14.0*20.5-0.08*24P-15TS-8-25C 日 期 DATE: 2026/05/19 版 本： Version: A.0 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY 客户承认 CUSTOMER APPROVE 罗雄彬 luo xiongbing 张燕 zhang yan 罗勇军 luo yongjun 深圳市天夏科技有限公司 shenzhen tianxia technology co.,ltd E-mail：2321113770@qq 地址：深圳市宝安区33区C33科创园523-525室 Address: Room 523-525, C33 Innovation Park, District 33, Bao'an District, Shenzhen TEL：18718699959 .com 天夏 Page 2 of 3 版本变更历史 Version Change History 版本 Rev. 变 更 前 Before Change 变 更 后 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2026/05/19 罗勇军 天夏 Page 3 of 3 产 品 型 号： DESC φ14.0*20.5-0.08*24P-15TS-8-25CC SPECIFICATION Rev：A.0 客户CUST: 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM A 8.0±0.5 B25.0±0.5 C 14.0±1 D 20.5±1 1.Coil wire outlet runs parallel to the coil plane. 2.,φ7.7*24.7*2.5mmA round hard magnetic sheet is attached to the coil. Dimensions: Φ7.7 × 24.7 × 2.5 mm 3. The lead wire outlet position is shown in the figure (when the outlet faces upward, the deep notch is positioned at the bottom). 4.7.5*2.5 A 7.5 × 2.5 mm magnet 注：Note: is centered and mounted upright. 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 0.08*24 15Ts 顺时针 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 8.5 uH±10% 单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 11uH±10% 带磁片 100KHz/1.0V LCZ METER 1062B 拟制/日期PREPARED BY/DATE 审核/日期CHECKED BY/DATE 罗雄彬l u o x i o n g b i n g2026/05/19张燕z h a n g y a n2026/05/19 E 8 mm±3 F 3.00±1.0 G 2.6±1.0

Page1of3ReportNo.:MTi260…

Text truncated - open the document above for the full version.
