2AZF3-PRTFOXMINI PRINTER

Scan the QR code to download the app or search for PRTFOX in the app store PRTFOX Default name： PRTFOX-xxxxxxxxx AndriodIOS PRTFOX default password： 12345678 PRTFOX Product instructions 7 （product serial number） On/off function Charging function This product uses the type-c interface to charge, and the input voltage is 5V- 1A. The indicator light is red when it isturned off and charged, and it goes out when it is full. 1 2 ① Power/Print button② Status Indicator③ 4 IFI indicator 4 ① ② ③ 5 Ink cartridge cover open button 5 6 Charging port 6 Auxiliary roller Synchronous wheel Cartridge nozzle opening Nozzle protection cover Ink tank cover Press and hold the power/print button on the side of the product for 3 seconds, the indicator light turns on and enters the startup state (the indicator light changes from white to green, and the printer is ready). 8 Reset hole(Forced shutdown by fine needle insertion) Install and remove ink cartridges 1.Press the ink cartridge cover open button to open the ink cartridge cover (the indicator light turns red). 2. Insert the ink cartridge into the ink cartridge compartment diagonally from above. (The direction of the ink cartridge nozzle is shown in the figure) 3 4. Close the ink cartridge cover, and the indicator light turns green again. 3. Align the ink cartridge with the inkjet opening and insert it until it completely enters the ink cartridge compartment. 9 *Please remove the cartridge holder first 1. If the printer does not print within 10 minutes,cover the nozzle protective cover. Printer maintenance 2. When not in use for more than 10 minutes, take out the ink cartridge from the printer and put the protective clip on it. 5 Printing steps 1、打开手机WIFI选择PRTFOX-XXXXX(产品序列号），输入 密码连接产品。 2、扫描说明书中的二维码（P1）下载APP。 3、打开APP，输入内容，点击打印按键。 4、打开底部喷头保护盖，按一下侧面打印（开机）按钮。 5、将打印机喷头放在打印表面匀速滑动打印机。 4 1. Turn on the mobile phone WIFI and select PRTFOX-XXXXX (product serial number), enter the password to connect to the product. 2. Scan the QR code (P1) in the manual to download the APP. 3. Open the APP, enter the content, and click the print button. 4. Open the nozzle protective cover at the bottom and press the side print (power on) button. 5. Place the printer nozzle on the printing surface and slide the printer at a constant speed. Please keep the synchronization wheel rolling on the printing surface when printing. 10 Precautions 6 Please keep the product and ink cartridges away from children. Do not wipe the inside of the product when using a moist cloth to wipe the device. When the ink gets into your eyes accidentally, please wash with plenty of water immediately. If you have any symptoms, please go to the hospital for help immediately. Status indicator 7 statusThree-color light status S t a t u s I n d i c a t o r power onwhite light on Readygreen light on Data receiving is complete, waiting for printing, printing blue light on Printer error (the upper cover of the ink cartridge is opened) red light on Warning (the print head cover is opened and the battery is low) Red light flashes (0.5 seconds on and 0.5 seconds off) printer dormant Green light flashes (1 second on and 3 seconds off) The firmware is being upgradedyellow light on Firmware upgrade failedred light on Charging instructions red light on (Only when turned off and charging) W I F I i n d i c a t o r power onwhite light on The phone is not connected or the router is not connected blue light on The phone is connected or the router is connected green light on dormant or firmware upgradeNo display Initialization or operation errorred light on 3. If fine white lines appear during printing, please wipe the nozzle with a paper towel or soft cloth sprayed with 95% alcohol. 11 NO.NameQuantity 1PRTFOXprinter1unit 2ink cartridges1pc 3power line1pc Packing list 8 Dear customers Thank you for purchasing the products of Zhuhai Bentsai PrintingTechnology Co.,Ltd. In order to guarantee the use safety of the product and your legitimate interests , please read the following carefully. This product is a precision grade instrument. In case of any abnormality and the device failure, please check it according to the instructions in the manual or contact our customer service center. Do not handle it by yourself. Terms of service 1.This product implements the national three-guarantee regulations for products, and implements a one-year warranty period. The start date of the warranty period is subject to the product invoice date. 2.During the warranty period,if the product is innormal use and maintenance for failure caused by machine parts and materials andprocess, the company will provide free repair and replacement parts. 3.Except for wearing parts(ink cartridges , power line are not covered by the warranty). Disclaimer Any of the following conditions is not covered by the warranty: 1.Damage caused by improper transportation, use, storage and maintenance 2.It is not repaired by the maintenance department designated by the company,or assembled disassembled and repaired by user. 3.Parts or consumables used are not from the factory of the company and cause damage. 4.No warranty card and valid certificate or they are altered 5.Beyond warranty period. 6.Damage caused by force majeure. The warranty provisions 9 12 Customer service hotline：+86-756-8979060 Zhuhai Bentsai PrintingTechnology Co.,Ltd www.bentsai.net FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guaran…

Text truncated - open the document above for the full version.

Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX

FCC ID LABEL: Label Location: FCC ID: 2 AZF3-PRTFOX Product Na me: MINI PRINT ER Model Na me: PRTFOX This device complies with Part 15 of the FCC Rules. Operation is subject to the follo wing two conditions: (1)This device may not cause har mful interference, and (2)This device must accept any interference received, including interference that may cau se undesired operation. Long: 3cm Width: 2cm

Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX Model: PRTFOX PCB Antenna

MPE ESTIMATION FCC ID: 2AZF3-PRTFOX 1. Limit for Portable Equipment Exposure Frequency 1-g SAR 100MHz-6GHz 3.0 For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the followi ng: [(max. power of channel, i ncludi ng tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz 2. Estimation Result Mode Frequency (MHz) PK Output Power(dBm) Output Power(mW) Test Separation Distance (mm) Measurement Result 1-g SAR 11b 2412 8.88 7.73 5 2.4009 3.0 2437 8.70 7.41 5 2.3134 3.0 2462 8.66 7.35 5 2.3064 3.0 11g 2412 7.69 5.87 5 1.8232 3.0 2437 7.57 5.71 5 1.7827 3.0 2462 7.55 5.69 5 1.7855 3.0 11n/HT20 2412 7.38 5.47 5 1.6990 3.0 2437 7.36 5.45 5 1.7015 3.0 2462 7.30 5.37 5 1.6851 3.0 Note: PK Output Power = Conducted Power. Conducted Power see the test report UNIA21011905ER-04. ------The End------

Page 1 of 68 Report No.: UNIA21011905ER-04 FCC RADIO TEST REPORT FCC ID: 2AZF3-PRTFOX Product： MINI PRINTER Trade Name： Main Model： PRTFOX Additional Model： B10, B11, B12, B13, B15, B16, B17, B18 Report No.： UNIA21011905ER-04 Prepared for Zhuhai BENTSAI Printing Technology Co., LTD. Zone B, 2F, Building 1, No.115, Huawei Road, Xiangzhou District, Zhuhai, China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 68 Report No.: UNIA21011905ER-04 TEST RESULT CERTIFICATION Applicant .............................. : Zhuhai BENTSAI Printing Technology Co., LTD. Address ................................. : Zone B, 2F, Building 1, No.115, Huawei Road, Xiangzhou District, Zhuhai, China Manufacturer ........................ : Zhuhai BENTSAI Printing Technology Co., LTD. Address ................................. : Zone B, 2F, Building 1, No.115, Huawei Road, Xiangzhou District, Zhuhai, China Product description Product Name .............................. : MINI PRINTER Trade Mark ............................ : Model Name .......................... : PRTFOX, B10, B11, B12, B13, B15, B16, B17, B18 Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ..........................................: Date (s) of performance of tests .............: Feb. 22, 2021 ~ Mar. 15, 2021 Date of Issue ........................................: Apr. 13, 2021 Test Result ............................................: Pass Prepared by: Bob liao/Editor Reviewer: Kahn yang/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 68 Report No.: UNIA21011905ER-04 Table of Contents Page 1 TEST SUMMARY 5 2 GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 CARRIER FREQUENCY OF CHANNELS 9 2.3 TEST MODE 9 2.4 TEST SETUP 9 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.6 MEASUREMENT INSTRUMENTS LIST 11 3 CONDUCTED EMISSION 12 3.1 TEST LIMIT 12 3.2 TEST SETUP 12 3.3 TEST PROCEDURE 13 3.4 TEST RESULT 13 4 RADIATED EMISSION 16 4.1 TEST LIMIT 16 4.2 TEST SETUP 17 4.3 TEST PROCEDURE 18 4.4 TEST RESULT 18 5 OCCUPIED BANDWIDTH 36 5.1 TEST LIMIT 36 5.2 TEST PROCEDURE 36 5.3 EQUIPMENT USED 36 5.4 TEST RESULT 36 6 POWER SPECTRAL DENSITY 43 6.1 TEST LIMIT 43 6.2 TEST PROCEDURE 43 6.3 EQUIPMENT USED 43 6.4 TEST RESULT 43 7 PEAK OUTPUT POWER 50 7.1 TEST LIMIT 50 7.2 TEST PROCEDURE 50 7.3 EQUIPMENT USED 50 7.4 TEST RESULT 50 8 OUT OF BAND EMISSIONS 51 8.1 TEST LIMIT 51 Page 4 of 68 Report No.: UNIA21011905ER-04 Table of Contents Page 8.2 TEST SETUP 51 8.3 TEST PROCEDURE 51 8.4 TEST RESULT 51 9 ANTENNA REQUIREMENT 66 10 PHOTO OF TEST 67 10.1 RADIATED EMISSION 67 10.2 CONDUCTED EMISSION 68 Page 5 of 68 Report No.: UNIA21011905ER-04 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 COMPLIANT RADIATED EMISSION FCC Part 15.209(a) COMPLIANT OCCUPIED BANDWIDTH FCC Part 15.247(a)(2) COMPLIANT POWER SPECTRAL DENSITY FCC Part 15.247(e) COMPLIANT PEAK OUTPUT POWER FCC Part 15.247(b) COMPLIANT OUT OF BAND EMISSIONS FCC Part 15.247(d) COMPLIANT CONDUCTED SPURIOUS EMISSION FCC Part 15.247(d) COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT Page 6 of 68 Report No.: UNIA21011905ER-04 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 7 of 68 Report No.: UNIA21011905ER-04 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k = 2, providing a level of confidence of approximately 95%. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 26000MHz 4.13 Page 8 of 68 Report No.: UNIA21011905ER-04 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: MINI PRINTER Trade Mark: Main Model: PRTFOX Additional Model: B10, B11, B12, B13, B15, B16, B17, B18 Model Difference: All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: PRTFOX. FCC ID: 2AZF3-PRTFOX Operation Frequency: 802.11b/g/n20: 2412~2462 MHz Number of Channels: 802.11b/g/n20: 11CH Modulation Type: CCK, OFDM, DBPSK, DAPSK Antenna Typ…

Text truncated - open the document above for the full version.

Model: PRTFOX Radiated Emission test Model: PRTFOX Conducted Emission test
