2AZGL-BF-F9V2NTwo way radio



shen zhen shi de yue dian zi you xian gong si baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/4/21 FCC ID: 2AZGL-BF-F9V2N Subject: Declaration of compliance to the requirements of §15.121 We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. If you have any questions, please feel free to contact me. Sincerely, Name/Title： Xingwei Hu/Sales Manager Company: shen zhen shi de yue dian zi you xian gong si Address: baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102, China Phone: 13510018759 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021/4 /21 > Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AZGL-BF-F9V2N BF-F9V2N For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-proprietaryandsecretstradeterm confidentiality exhibits contain our information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring sensitivethat business information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Xingwei Hu/Sales Manager Company: shen zhen shi de yue dian zi you xian gong si Address: baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102, China Phone: 13510018759 Fax: N/A E-Mail: [email protected]

shen zhen shi de yue dian zi you xian gong si baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/4/21 To whom it may concern: We, shen zhen shi de yue dian zi you xian gong si the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AZGL-BF-F9V2N including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Xingwei Hu/Sales Manager Company: shen zhen shi de yue dian zi you xian gong si Address: baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102, China Phone: 13510018759 Fax: N/A E-Mail: [email protected]

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 4 EXTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 4 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 4 Fig.5 Fig.6 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 4 Fig.7 Fig.8

Label & Label Location Size: 35mm(L)*33mm(W) FCC ID: 2AZGL-BF-F9V2N WARNING: Modification of this device to receive cellular radiotelephone service signals is prohibited under FCC rules and Federal Law. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 5 INTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 5 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 5 Fig.5 Fig.6 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 5 Fig.7 Fig.8 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 5 of 5 Fig.9 Fig.10

Report No.:TZ210302073-E TEST REPORT FCC PART 15B Report Reference No. ..................... : TZ210302073-E Compiled by ( position+printed name+signature) .. : File administrators Nancy Li Name of the organization performing the tests ( position+printed name+signature) .. : Technique principal Hugo Chen Approved by ( position+printed name+signature) .. : Manager Andy Zhang Date of issue ..................................... : 2021/4/20 Representative Laboratory Name .... : Shenzhen Tongzhou Testing Co.,Ltd Address ............................................. : 1th Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Applicant’s name ............................ : shen zhen shi de yue dian zi you xian gong si Address ............................................. : baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102 China Test specification: Standard ........................................... : FCC Part 15B TRF Originator .................................. : Shenzhen Tongzhou Testing Co.,Ltd Master TRF ....................................... : Dated 2012-06 Shenzhen Tongzhou Testing Co.,Ltd All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Two way radio Trade Mark ....................................... : Baofeng Model/Type reference ....................... : BF-F9V2N Hardware Version ............................. : SRTSA.V07 Software Version .............................. : V1.0 FCC ID .............................................. : 2AZGL-BF-F9V2N Listed Models .................................. : N/A Operation Frequency ........................ : VHF:136-174MHz(Rx only) UHF:400-480MHz(Rx only) FM: 76-108MHz(Rx only) Power Supply..............................: DC 7.4V by adapter Adapter Information: Model: 480-10050-E.S Input: 100-240V~ 50/60Hz 0.25A Output: DC10V, 0.5A Result ................................................ : Pass Page 2 of 31 Report No.: TZ210302073-E T E S T R E P O R T Test Report No. : TZ210302073-E 2021/4/20 ______________________________________________________________________________________________ Date of issue Equipment under Test : Two way radio Model /Type : BF-F9V2N Listed Models : N/A Applicant : shen zhen shi de yue dian zi you xian gong si Address : baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102 China Manufacturer : shen zhen shi de yue dian zi you xian gong si Address : baoanqu xixiangjiedao tiezailu gonglegongyeyuanadong7louxice shenzhenshi baoanqu guangdong 518102 China Test Result Pass The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 31 Report No.: TZ210302073-E Contents 1. T E S T S T A N D A R D S .................................................................. 4 2. S U M M A R Y ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. Test Result Summary 6 3. T E S T E N V I R O N M E N T ............................................................... 7 3.1. Description of Test Facility 7 3.2. Environmental conditions 7 3.3. Statement of the measurement uncertainty 7 3.4. Equipments Used during the Test 8 4. T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 9 4.1. Radiated Emission Test 9 4.2. Conducted Emissions Test 13 4.3. Compliance For Scanning Receiver 16 4.4. Spurious Emission 18 5. T E S T S E T U P P H O T O S O F T H E E U T ........................................... 21 6. E X T E R N A L A N D I N T E R N AL P H O T O S O F T H E E U T ....................... 23 Page 4 of 31 Report No.: TZ210302073-E 1. T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15 Subpart B Unintentional Radiators ANSI C63.4-2014 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Page 5 of 31 Report No.: TZ210302073-E 2. S U M M A R Y 2.1. General Remarks Date of receipt of test sample : 2020/4/13 Testing commenced on : 2020/4/13 Testing concluded on : 2021/4/19 2.2. Equipment Under Test Power supply system utilised Power supply voltage ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 7.4V by adapter 2.3. Short description of the Equipment under Test (EUT) Two way radio. For more details, refer to the user’s manual of the EUT. 2.4. EUT operation mode The EUT has been tested under typical operating condition. Mode(s) Description Conect to GRP 1 Charging + Receiving(VHF) No 2 Charging + Receiving(UHF) No 3 Charging + Receiving(FM) No Test Sample ID: TZ210302073-1# 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement:  - supplied by the manufacturer ●- supplied by the lab  Adapter Model : 480-10050-E.S Input : 100-240V~ 50/60Hz 0.25A Output : DC10V, 0.5A Page 6 of 31 Report No.: TZ210302073-E 2.6. Related Submittal(s) / Grant (s) This test report is intended for BF-F9V2N filing to comply with the FCC Part 15, Subpart B Rules. 2.7. Modifications No modifications were implemented to meet testing criteria. 2.8. Test Result Summary Test…

Text truncated - open the document above for the full version.

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 2 TEST SETUP PHOTOS OF THE EUT Photograph – Conducted Emission Test Setup Photograph – Radiated Emission Test Setup-Below 1GHz Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AZGL-BF-F9V2N This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 2 Photograph – Radiated Emission Test Setup-Above 1GHz
