ChargingMat–Instructions Model:NS2627 CONTENTS: ChargingMat USBCable FEATURES 10WchargingpowerforSmartphonesandotherwirelesschargingenabled chargingdevices. Universalcompatibilityworkswithwirelessenableddevices Integratedsafetyfeatures–Overvoltage,Undervoltage,OverCurrent protection. Sleek,compactdesignwithnon-sliprubberbase. SAFETYINFORMATION ThisproductisonlysuitableforWirelessenabledchargingdevices DoNOTshortcircuitorburn ThisisNOTatoy Keepdryatalltimes.DoNOTimmerseinliquids Forindooruseonly DoNOTattempttodisassemble.Doesnotcontainserviceableparts Avoiddropping,shakingoranyhardimpactsontheproduct DoNOTattempttoplugforeignobjectsintotheproduct SETUP: 1.ThisproductisonlysuitableforWirelessenabledchargingdevices. 2. TakethesuppliedchargingcableandconnectittotheChargingMatthenconnect thecabletoaUSBApowersource,thiscanbethechargersuppliedwithyour smartphoneforexampleandthenswitchon. 3. Refertoyourwirelessenableddeviceandenablewirelesscharging–thismaybe inthebatterysettingsonyourdevice. 4.SimplyplaceyourdeviceinthecentreoftheChargingMattocommencecharging. 5.Ifchargingdoesnotcommenceimmediatelythenrepositionyourdeviceonthe ChargingMatuntilyourdevicebeginstocharge. 6.Whenyourdeviceisfullychargedswitchoffthepowersourceorremoveyour devicefromtheChargingMat. TECHNICALDETAILS Input:5V@2A/9V@2A Output:5V@1A/[email protected] TECHNICALSUPPORT Ifyouencounteraproblemwithyourproduct,pleasegotohttp:www.numskull.co.ukandclick TechnicalSupport.Fromthereyouwillbeabletoaccess“FrequentlyAskedQuestions”section,and contactdetails. Alternativelyyoucancontactusat: Email:[email protected] InternationalTelephone:+44(0)1707502280 ENVIRONMENTALPROTECTIONRECOMMENDATION Attheendofitsworkinglife,thisproductshouldnotbedisposedofwithstandardhouseholdwaste, butratherdroppedoffatacollectionpointforthedisposalofWasteElectricalandElectronic Equipment(WEEE)forrecycling. Thisisconfirmedbythesymbolfoundontheproduct,usermanualorpackaging.Dependingon theircharacteristics,thematerialsmayberecycled.Throughrecyclingandotherformsof processingWasteElectricalandElectronicEquipment,youcanmakeasignificantcontribution towardshelpingtoprotecttheenvironment.Pleasecontactyourlocalauthoritiesforinformation onthecollectionpointnearestyou. FCCSTATEMENT: ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation. Warning:Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoid theuser'sauthoritytooperatetheequipment. NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant toPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful interferenceinaresidentialinstallation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergy and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.If thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby turningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreof thefollowingmeasures: Reorientorrelocatethereceivingantenna. Increasetheseparationbetweentheequipmentandreceiver. Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. Consultthedealeroranexperiencedradio/TVtechnicianforhelp. FCCRadiationExposureStatement: ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironment.This equipmentshouldbeinstalledandoperatedwithminimumdistance20cmbetweentheradiator&yourbody. MadeinChina Email:[email protected] Visitwww.numskull.com

FCCID:2AZHE-NS2627

LabelLocationOnEUT Label ProductName:GhostbustersChargingMat ModelNo.:NS2627 FCCID:2AZHE-NS2627 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2AZHE-NS2627

version01 RubberRoadLtd DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:NS2627,NS2762 FCCID:2AZHE-NS2627 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna: N/A Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:RubberRoadLtd Address:AttimoreBarn,Ridgeway,WelwynGardenCity,Herts,AL72AD(UK) City:WelwynGarden ZIP/Postalcode:N.A. Country:UK Place:ModenaDate:4/28/2021 Signature:
