2AZHS-MRN027WLUSB NES/SNES classic mini wireless controller

Fast Installation and Startup Attention 1. Charging input power ra�ng: DC5V.500mA. 2. The built-in ba�ery is a rechargeable polymer lithium-ion ba�ery. 3. Do not use the product in direct sunlight or in damp condi�ons. 4. Do not disassemble the controller for any reason, so as not to make the ba�ery short-circuit or even burned. 5. The capacity of ba�ery is 250mA, which takes 2 hours for full charge. 6. It can be used con�nuously for about 100 hours. 7. Place the Controller in a recyclable container when it's no use. 2. Plug the USB receiver to PC or other game console, then press the START bu�on of Controller. SELECT START BA 1. Plug the USB receiver with NES adapter to NES Classic Mini Console, then press the START bu�on of Controller. Change the Input Mode Of USB Adapter Note: A�er the controllers are connected to the PC or Raspberry Pi gaming pla�orm via the USB receiver, if there is a incompa�bility , try to change the working mode of the controllers to Dinput or Xinput (Factory default). 1. Plug the USB receiver to PC USB Socket. 2. Press and hold the START+SELECT+A for 1s the USB Receiver will enter Direct Input mode; 3. Press and hold the START+SELECT+B for 1s the USB Receiver will enter XBOX Input mode; SELECT START BA Turbo Function Setting Turbo se�ng and cancel methods are as follows: Press and hold Select+A(B) at the same �me for 1 second, A(B) will have con�nue fire func�on. Cancel the Turbo func�on, you just need to press and hold Select+A (B) for 1 second again, the con�nue fire func�on of bu�on A(B) will be cancelled. The bu�ons A and B of the wireless controller can be set with Turbo func�on. In the game, if the bu�ons has turbo func�on, you cab keep pressing A or B without releasing the game ac�on and the turbo func�on will be executed automa�cally. SELECT START BA Turbo LED Return to the NES Games Menu By Controller Press the START+SELECT at the same �me on wireless controller, equivalent to Press RESET bu�on of the NES Classic Mini game. SELECT START BA RESET POWER RESET Controller Working States 1. Pairing Mode: Press and hold START+SELECT+UP for 1s un�l Red LED flashes quickly, which means the controller enter into pairing mode. and wai�ng for a new USB receiver to pairing. 2. Link Mode: If Controller and Receiver connect successfully, Red LED will light up. At this moment, you can play games. 3. Standby Mode: Without no opera�ons in 30s, Controller will enter into standby mode, and LED will turn off. Press any bu�on can wake it up. 4. Sleep Mode: without no opera�ons a�er 10 mins, Controller will enter into sleep mode only START bu�on can wake it up. 5. Power off: When the ba�ery in your controller are out, the controller will power off automa�cally. Detatils Description SELECT START BA USB Charging Port Two Fire Bu�ons D-Pad 8-way Start/Wakeup Select Bu�on Bu�on Link Indicate: Red LED Recharge Indicate: Blue LED USB Receiver NES Classic Mini Adapter ① NES Wireless Receiver: For NES Classic mini ② USB Wireless Receiver: For Windows XP/7/8/10, Mac OS, Linux, Raspberry Pi. Paring Controller With USB Adapter Step1: Press and hold the START+SELECT+UP for 1s un�l Red LED flashes quickly. Controller will enter into pairing mode. A�er Red LED does not flash quickly but stays on, which means the pairing between the receiver and controller is successful. Step2: Insert the receiver into the NES game console or PC USB port. SELECT START BA Red LED flash Press and hold the START+SELECT+UP for 1s 3. If without any opera�ons in 30s, Controller will enter into the standby mode. Red LED will turn off, You can ac�vate the Controller via pressing any bu�on. 4. Controller will enter into sleep mode if there is no opera�ons a�er 10 mins. You can only press the Start bu�on to wake up the controller. Package Contents Model :MRN027WL Charge by 5V 500mA Charger, Charge by computer USB 2.0port . Compa�bility: Charge method: Charge �me: About 2 hours. Ba�ery: 250mAH Working �me 100H Wireless transmission 2.4GHz wireless connec�on Wireless effec�ve: distance > 30 � NES Classic mini, Windows XP/7/8/10, Mac OS, Linux, Raspberry Pi hank you for purchasing the MICREAL product. Please read this [User Manual] carefully before using the product, and retain in for future use. If you have any ques�ons or sugges�ons about our products, please contact: [email protected]. T Low Battery and Charging Reminder SELECT START BA Red LED blink When the controller ba�ery capacity is less than 30%, The RED light will blink. It prompt you to charge the controller ba�ery. You can use the USB cable included in the package to connect to any standard USB power supply to charge the controller, When the controller is charging, the Blue LED will light up, A�er full charged the Blue LED will be off automa�c. Blue LED light for Charging. Red LED blink when low ba�ery USB NES/SNES classic mini wireless controller FCC泗.., .. 11, Changes or moo面主ions not express¥approved切theparty resporsltle for c001p1虹ecou l d vod the u年 authority to operate the equipment This equ1pmert has been tested and found to com�y妞hthe limits for a aass B d1gtaJ de如e,pursuantto Part 15 olthe FCC如les.These Im七aredesigned to怀widereasona啦叩ect,onagairst阻叩ful叮erfereocei1 a res亟bal1r6la阻,on . Ths equipment generates uses and can radiate radlO lrequercy energy and, 11 not installed and used in扛ordance讯hthe instructions, m可ca由eharmful int刮erenceto radio can mun立,ons Ho哟er, there IS no guarartee t比,rterfere心ev.,11 net occur ,n a particular 1r,;talal101t tt ths equpmert妇 cause harrrtul mt臼ferenceto radio or tel盯is1on缸eption,咘忙hcan be detemined切turningthe equipmert off and on, the氐eris encouraged to try to correct the interference by one or more of the follov.ing measu忘 －氏劝enta relocate the rec的ingantenna - I ncrease the separation be归nthe equipment and rece哼 -connect the equipment into an outlet on a c,rcurt dill<玄entfrom that to叩,chthe rec臼诧ris connected . -Consult the dealer or an expenenced radiofTV technician for help This如cecomples叩part 15 d the FCC …

Text truncated - open the document above for the full version.

MICREALDEVELOPMENTTECHNOLOGYLIMITED OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2021-04-07 Subject;RequestforLongTermConfidentiality FCCID:2AZHS-MRN027WL ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:WENKEYYANG Title:Productengineer

MICREALDEVELOPMENTTECHNOLOGYLIMITED A1118,No.288XiXiangAve.Baoan,Shenzhen,518102China. Statement Product:USBNES/SNESclassicminiwirelesscontroller Model:MRN027WL AdditionalModel:MR1809WL Trademark:N/A WeherebystatethatAllmodelsaboveareidenticalininteriorstructure,electricalcircuitsand components,andjustmodelnamesaredifferentforthemarketingrequirement. Yourassistanceonthismatterishighlyappreciated. Yourssincerely, Signature: Date:2021/04/20 Name:WENKEYYANG CompanyName:MICREALDEVELOPMENTTECHNOLOGYLIMITED Address:A1118,No.288XiXiangAve.Baoan,Shenzhen,518102China. Tel/Fax:+86-0755-29556930/+86-0755-29408460 E-Mail:[email protected]

MICREALDEVELOPMENTTECHNOLOGY LIMITED AgentAuthorization Company:MICREALDEVELOPMENTTECHNOLOGYLIMITED Address:A1118,No.288XiXiangAve.Baoan,Shenzhen,518102China ProductName:USBNES/SNESclassicminiwirelesscontroller ModelNumber(s):MRN027WL,MR1809WL ProductDescription:USBNES/SNESclassicminiwirelesscontroller WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2021-04-07 Name:WENKEYYANG Title:Productengineer Company:MICREALDEVELOPMENTTECHNOLOGYLIMITED

Page 1 of 4 Appendix B: Photographs of EUT Product: USB NES/SNES classic mini wireless controller Model: MRN027WL External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkandLocation Model:MRN027WL Label： Size:L*W=60*30mm USBNES/SNESclassicminiwirelesscontroller ModelNo.:MRN027WL FCCID:2AZHS-MRN027WL Thisdevicecomplieswithpart15oftheFCCrules. Operationissubjecttothefollowingtwoconditions (1)thisdevicemaynotcauseharmfulinterference, and(2)thisdevicemustacceptanyinterference received,includinginterferencethatmaycause undesiredoperation. Location

Page 1 of 5 Appendix B: Photographs of EUT Product: USB NES/SNES classic mini wireless controller Model: MRN027WL Internal Photos Page 2 of 5 Page 3 of 5 Antenna Page 4 of 5 Page 5 of 5

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AZHS-MRN027WL Product: USB NES/SNES classic mini wireless controller Model No.: MRN027WL Additional Model No.: MR1809WL Trade Mark: N/A Report No.: TCT210205E026 Issued Date: Feb. 26, 2021 Issued for: MICREAL DEVELOPMENT TECHNOLOGY LIMITED A1118, No.288 XiXiang Ave. Baoan, Shenzhen, 518102 China. Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT210205E026 Page 2 of 39 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 7 4.1. Test Environment and Mode ................................................................................. 7 4.2. Description of Support Units ................................................................................ 7 5. Facilities and Accreditations .................................................................. 8 5.1. Facilities ................................................................................................................. 8 5.2. Location ................................................................................................................. 8 5.3. Measurement Uncertainty ..................................................................................... 8 6. Test Results and Measurement Data ..................................................... 9 6.1. Antenna Requirement ........................................................................................... 9 6.2. Conducted Emission ........................................................................................... 10 6.3. Radiated Emission Measurement ...................................................................... 14 6.4. 20dB Occupied Bandwidth ................................................................................. 26 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT210205E026 Page 3 of 39 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: USB NES/SNES classic mini wireless controller Model No.: MRN027WL Additional Model No.: MR1809WL Trade Mark: N/A Applicant: MICREAL DEVELOPMENT TECHNOLOGY LIMITED Address: A1118, No.288 XiXiang Ave. Baoan, Shenzhen, 518102 China. Manufacturer: MICREAL DEVELOPMENT TECHNOLOGY LIMITED Address: A1118, No.288 XiXiang Ave. Baoan, Shenzhen, 518102 China. Date of Test: Feb. 08, 2021 – Feb. 25, 2021 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Feb. 25, 2021 Aaron Mo Reviewed By: Date: Feb. 26, 2021 Beryl Zhao Approved By: Date: Feb. 26, 2021 Tomsin Report No.: TCT210205E026 Page 4 of 39 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Field Strength of Fundamental §15.249 (a) PASS Spurious Emissions §15.249 (a) (d)/ §15.209 PASS Band Edge §15.249 (d)/ §15.205 PASS 20dB Occupied Bandwidth §15.215 (c) PASS Note: 1. Pass: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT210205E026 Page 5 of 39 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: USB NES/SNES classic mini wireless controller Model No.: MRN027WL Additional Model No.: MR1809WL Trade Mark: N/A Operation Frequency: 2402MHz - 2480MHz Number of Channel: 40 Modulation Technology: GFSK Antenna Type: PCB Antenna Antenna Gain: 0dBi Power Supply: Rechargeable Li-ion Battery DC 3.7V Remark: All models above are identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. Report No.: TCT210205E026 Page 6 of 39 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Operation Frequency Each of Channel Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 11 2424MHz 22 2446MHz 33 2468MHz 1 2404MHz 12 2426MHz 23 2448MHz 34 2470MHz 2 2406MHz 13 2428MHz 24 2450MHz 35 2472MHz 3 2408MHz 14 2430MHz 25 2452MHz 36 2474MHz 4 2410MHz 15 2432MHz 26 2454MHz 37 2476MHz 5 2412MHz 16 2434MHz 27 2456MHz 38 2478MHz 6 2414MHz 17 2436MHz 28 2458MHz 39 2480MHz 7 2416MHz 18 2438MHz 29 2460MHz 8 2418MHz 19 2440MHz 30 2462MHz 9 2420MHz 20…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: USB NES/SNES classic mini wireless controller Model: MRN027WL Radiated Emission Page 2 of 2 Conducted Emission
