2AZI3-TH11Indoor Bluetooth Thermometer and Hygrometer

CoveredEquipmentAttestationLetter ForCertificationServiceintheUSA FederalCommunicationsCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 Towhomitmayconcern PursuanttoSection2.911(d)(5)(i)-(ii)oftheCommission’sRules(47C.F.R.)weattestasfollows fortheproductlistedbelow: FCCIDModelname 2AZI3-TH11TH11 We, Applicant CompanyName:SHENZHENKERUISMARTTECHNOLOGYCO., LTD. Address:Room1501,T2,JinlitongBuilding,No.1100, XingyeRoad,Xin'anStreet,Bao'anDistrict, Shenzhen,Guangdong,China Phone:18688736545 certifythattheequipmentforwhichauthorizationissoughtisnot“covered”equipment prohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCC rules.Thisincludesthecybersecurityandanti-virussoftwareproducedorprovidedby KasperskyLab,Inc.oranyofit’ssuccessorsandassignees. Wecertifythat,asofthedateofthefilingoftheapplication,theapplicantisnotidentifiedon theCoveredListasanentityproducing“covered”equipment. Ifyouhaveanyquestions,pleasefeelfreetocontactusattheaddressshownbelow. Sincerely, SignatureDate:2026-7-10 PrintedNameofSignee:LiGui/MarketingManager Company:SHENZHENKERUISMARTTECHNOLOGYCO.,LTD. Address:Room1501,T2,JinlitongBuilding,No.1100,XingyeRoad,Xin'anStreet,Bao'an District,Shenzhen,Guangdong,China Phone:18688736545Fax:0755-29960979 Email:[email protected]

ConfidentialityRequestLetter ForCertificationServiceintheUSA FederalCommunicationsCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 Towhomitmayconcern PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)andSection §552(b)(4)oftheFreedomofInformationAct,werequestconfidentialityforthe documentationofthefollowingproducts: FCCIDModelname 2AZI3-TH11TH11 Fortheproductslistedabove,werequestpermanentconfidentialityforallapplicableexhibits asthereare:  theOperationalDescription  theBlockDiagram theSchematics Theabovelistedexhibitscontaintradesecretsandproprietaryinformationthatcouldbeof benefittoourcompetitors. Ifyouhaveanyquestions,pleasefeelfreetocontactusattheaddressshownbelow. Sincerely, Signature Date:2026-7-10 PrintedNameofSignee:LiGui/MarketingManager Company:SHENZHENKERUISMARTTECHNOLOGYCO.,LTD. Address:Room1501,T2,JinlitongBuilding,No.1100,XingyeRoad,Xin'anStreet,Bao'an District,Shenzhen,Guangdong,China Phone:18688736545Fax:0755-29960979 Email:[email protected]

FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Appendix I Label Appendix II Label Location

FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Photo 9 Appearance of PCB Photo 10 Appearance of PCB BLE ANT FCC ID:2AZI3-TH11 www.cotecna-toby.com TB-RF-073-3.1 Photo 11 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202606-0287-4 Page: 1 of 8 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: 2AZI3-TH11 Report No. : TBR-C-202606-0287-4 Applicant : SHENZHEN KERUI SMART TECHNOLOGY CO.,LTD Equipment Under Test (EUT) EUT Name : Indoor Bluetooth Thermometer and Hygrometer Model No. : TH11 Series Model No. : N/A Brand Name : SECRUI Sample ID : HC-C-202606-0287-01-01 Receipt Date : 2026-06-26 Test Date : 2026-06-26 to 2026-07-10 Issue Date : 2026-07-10 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gold zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202606-0287-4 Page: 2 of 8 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. METHOD OF MEASUREMENT FOR FCC............................................................................ 7 5. TEST RESULT............................................................................................................................ 8 Report No.: TBR-C-202606-0287-4 Page: 3 of 8 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202606-0287-4 Rev.01 Initial issue of report 2026-07-10 Report No.: TBR-C-202606-0287-4 Page: 4 of 8 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : SHENZHEN KERUI SMART TECHNOLOGY CO.,LTD Address : Room 1501, T2, Jinlitong Building, No. 1100, Xingye Road, Xin'an Street, Bao'an District, Shenzhen, Guangdong,china Manufacturer : SHENZHEN KERUI SMART TECHNOLOGY CO.,LTD Address : Room 1501, T2, Jinlitong Building, No. 1100, Xingye Road, Xin'an Street, Bao'an District, Shenzhen, Guangdong,china 1.2 General Description of EUT (Equipment Under Test) EUT Name : Indoor Bluetooth Thermometer and Hygrometer Models No. : TH11 Model Different : N/A Product Description : Operation Frequency: Bluetooth LE: 2402MHz~2480MHz Modulation Type: Bluetooth LE: GFSK Antenna Gain: -4.36dBi PCB Antenna Power Rating : DC 3V Software Version : V2.3 Hardware Version : TH11-V1.1 Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: TBR-C-202606-0287-4 Page: 5 of 8 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202606-0287-4 Page: 6 of 8 www.cotecna-toby.com TB-RF-073-3.1 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredited Test Site Number: 854351. Designation Number: CN1223. IC Registration No.: (11950A) The Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. The site registration: Site# 11950A. CAB identifier: CN0056. Report No.: TBR-C-202606-0287-4 Page: 7 of 8 www.cotecna-toby.com TB-RF-073-3.1 4. Method of Measurement for FCC 4.1 EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 4.2 Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the…

Text truncated - open the document above for the full version.

2026-6-26 1 SHENZHENKERUISMARTTECHNOLOGYCO.,LTD 1.TestEquipment&Condition 1.1NetworkAnalyzers:KEYSIGHTP5002A 1.2CommunicationsTestSet:R&SCMW500 1.33DChamberTestSystem:64Probetestingsystem Room1501,T2,JinlitongBuilding,No.1100,XingyeRoad,Xin'anStreet, Bao'anDistrict,Shenzhen,Guangdong,china 2026-6-26 2 2.Mechanicalinstruction 2026-6-26 3 3.2Ddirectiondiagram 2026-6-26 4 2026-6-26 5 2026-6-26 6 4.Gain&Efficiency&3DPattern Frequency ID Frequency (MHz) 24002410242024302440245024602470248024902500 Gain(dBi) -4.36-4.45-4.73-4.74-5.21-5.28-5.13-4.98-5.02-5.18-5.20 Efficiency (DB) -9.33-9.38-9.55-9.58-9.82-10.1-10-9.94-9.95-9.92-9.91 2026-6-26 7 2026-6-26 8 5.VSWR

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 1 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: Indoor Bluetooth Thermometer and Hygrometer Test Model: TH11 Sample ID: HC-C-202606-0287-01-01 Environmental Conditions Temperature: 24.6°C Relative Humidity: 52.6% Test Voltage: DC 3V Test Engineer: Gold zhang Note: For a more detailed features description, please refer to the report TBR-C-202606-0287-3 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 2 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ............................................................................................................................................ 6 3. -6dB Bandwidth ............................................................................................................................................................................. 9 4. Occupied Channel Bandwidth .................................................................................................................................................... 12 5. Maximum Power Spectral Density Level ................................................................................................................................... 15 6. Band Edge ................................................................................................................................................................................... 18 7. Conducted RF Spurious Emission ............................................................................................................................................. 21 8. Restrict Band ............................................................................................................................................................................... 25 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 3 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 100 0 0 NVNT BLE 1Mbps 2440 Ant1 100 0 0 NVNT BLE 1Mbps 2480 Ant1 100 0 0 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 4 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 5 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 6 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 3.181 30 Pass NVNT BLE 1Mbps 2440 Ant1 3.364 30 Pass NVNT BLE 1Mbps 2480 Ant1 3.3 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 7 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 8 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Power NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 9 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1Mbps 2402 Ant1 1.06 0.5 Pass NVNT BLE 1Mbps 2440 Ant1 1.11 0.5 Pass NVNT BLE 1Mbps 2480 Ant1 1.28 0.5 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 10 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 Test Graphs -6dB Bandwidth NVNT BLE 1Mbps 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202606-0287-3 Page: 11 of 27 FCC ID: 2AZI3-TH11 TB-RF-073-3.1 -6dB Bandwidth NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: T…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202606-0287-3 Page: 1 of 30 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2AZI3-TH11 Report No. : TBR-C-202606-0287-3 Applicant : SHENZHEN KERUI SMART TECHNOLOGY CO.,LTD Equipment Under Test (EUT) EUT Name : Indoor Bluetooth Thermometer and Hygrometer Model No. : TH11 Series Model No. : N/A Brand Name : SECRUI Sample ID : HC-C-202606-0287-01-01&HC-C-202606-0287-02-01 Receipt Date : 2026-06-26 Test Date : 2026-06-26 to 2026-07-10 Issue Date : 2026-07-10 Standards : FCC Part 15 Subpart C 15.247 Test Method : KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Gold zhang Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202606-0287-3 Page: 2 of 30 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION ...................................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup........................................................................................................................... 13 5.3 Test Procedure .................................................................................................................. 13 5.4 Deviation From Test Standard......................................................................................... 14 5.5 EUT Operating Mode ........................................................................................................ 14 5.6 Test Data............................................................................................................................. 14 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 15 6.1 Test Standard and Limit ................................................................................................... 15 6.2 Test Setup........................................................................................................................... 16 6.3 Test Procedure .................................................................................................................. 17 6.4 Deviation From Test Standard......................................................................................... 18 6.5 EUT Operating Mode ........................................................................................................ 18 6.6 Test Data............................................................................................................................. 18 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 19 7.1 Test Standard and Limit ................................................................................................... 19 7.2 Test Setup........................................................................................................................... 19 7.3 Test Procedure .................................................................................................................. 20 7.4 Deviation From Test Standard......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data............................................................................................................................. 20 8. BANDWIDTH TEST................................................................................................................. 21 8.1 Test Standard and Limit .......................................…

Text truncated - open the document above for the full version.

Report No.: TBR-C-202606-0287-3 Page: 12 of 30 www.cotecna-toby.com TB-RF-073-3.1 4. Test Equipment and Test Site Test Site No. Test Site Manufacturer Specification Used TB-EMCSR001 Shielding Chamber #1 YIHENG 7.5*4.0*3.0（m） X TB-EMCSR002 Shielding Chamber #2 YIHENG 8.0*4.0*3.0（m） √ TB-EMCCA001 3m Anechoic Chamber #A ETS 9.0*6.0*6.0（m） X TB-EMCCB002 3m Anechoic Chamber #B YIHENG 9.0*6.0*6.0（m） √ Radiation Emission Test(B Site) Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Due Date Spectrum Analyzer Agilent N9020A MY49100060 Aug. 27, 2025 Aug. 26, 2026 Spectrum Analyzer Rohde & Schwarz FSV40-N 102197 May. 15, 2026 May. 14, 2027 EMI Test Receiver Rohde & Schwarz ESU-8 100472/008 Jan. 30, 2026 Jan. 29, 2027 Bilog Antenna SCHWARZBECK VULB 9168 1225 Oct. 18, 2025 Oct. 17, 2027 Horn Antenna SCHWARZBECK BBHA 9120 D 2463 May. 15, 2026 May. 14, 2027 Horn Antenna SCHWARZBECK BBHA 9170 1118 Jan. 31, 2026 Jan. 30, 2028 HF Amplifier Tonscend TAP9E6343 AP21C806117 May. 15, 2026 May. 14, 2027 HF Amplifier Tonscend TAP051845 AP21C806141 Aug. 27, 2025 Aug. 26, 2026 HF Amplifier Tonscend TAP0184050 AP21C806129 Aug. 27, 2025 Aug. 26, 2026 Pre-amplifier HP 8449B 3008A00849 Feb. 02, 2026 Feb.01, 2027 Highpass Filter CD HPM-6.4/18G --- N/A N/A Highpass Filter CD HPM-2.8/18G --- N/A N/A Highpass Filter XINBO XBLBQ- HTA67(8-25G) 22052702-1 N/A N/A Antenna Conducted Emission Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Due Date Spectrum Analyzer Rohde & Schwarz FSV40-N 102197 May. 15, 2026 May. 14, 2027 MXA Signal Analyzer KEYSIGHT N9020B MY60110172 Aug. 27, 2025 Aug. 26, 2026 MXA Signal Analyzer Agilent N9020A MY47380425 Aug. 27, 2025 Aug. 26, 2026 Vector Signal Generator Agilent N5182A MY50141294 Aug. 27, 2025 Aug. 26, 2026 Analog Signal Generator Agilent N5181A MY48180463 Aug. 27, 2025 Aug. 26, 2026 Vector Signal Generator KEYSIGHT N5182B MY59101429 Aug. 27, 2025 Aug. 26, 2026 Analog Signal Generator KEYSIGHT N5173B MY61252685 Aug. 27, 2025 Aug. 26, 2026 RF Control Unit Tonsced JS0806-2 21F8060439 Aug. 27, 2025 Aug. 26, 2026 Power Control Box Tonsced JS0806-4ADC 21C8060387 N/A N/A RF Power Sensor DARE!! Instruments RadiPowerRPR3 006W 17I00015SNO26 Aug. 27, 2025 Aug. 26, 2026 17I00015SNO29 Aug. 27, 2025 Aug. 26, 2026 17I00015SNO31 Aug. 27, 2025 Aug. 26, 2026 17I00015SNO33 Aug. 27, 2025 Aug. 26, 2026 Wideband Radio Comunication Tester Rohde & Schwarz CMW500 144382 Aug. 27, 2025 Aug. 26, 2026 Universal Radio Communication Tester Rohde&Schwarz CMW500 168796 Jan. 30, 2026 Jan. 29, 2027 Temperature and Humidity Chamber ZhengHang ZH-QTH-225D ZH2107290 May. 15, 2026 May. 14, 2027 Report No.: TBR-C-202606-0287-3 Page: 13 of 30 www.cotecna-toby.com TB-RF-073-3.1 5. Conducted Emission 5.1 Test Standard and Limit 5.1.1 Test Standard FCC Part 15.207 5.1.2 Test Limit Frequency Maximum RF Line Voltage (dBV) Quasi-peak Level Average Level 150kHz~500kHz 66 ~ 56 * 56 ~ 46 * 500kHz~5MHz 56 46 5MHz~30MHz 60 50 Notes: (1) *Decreasing linearly with logarithm of the frequency. (2) The lower limit shall apply at the transition frequencies. (3) The limit decrease in line with the logarithm of the frequency in the range of 0.15 to 0.50MHz. 5.2 Test Setup 5.3 Test Procedure ●The EUT was placed 0.8 meters from the horizontal ground plane with EUT being connected to the power mains through a line impedance stabilization network (LISN). All other support equipments powered from additional LISN(s). The LISN provide 50 Ohm/ 50uH of coupling impedance for the measuring instrument. ●Interconnecting cables that hang closer than 40 cm to the ground plane shall be folded back and forth in the center forming a bundle 30 to 40 cm long. ●I/O cables that are not connected to a peripheral shall be bundled in the center. The end of the cable may be terminated, if required, using the correct terminating impedance. The overall length shall not exceed 1 m. ●LISN at least 80 cm from nearest part of EUT chassis. ●The bandwidth of EMI test receiver is set at 9 kHz, and the test frequency band is from 0.15MHz to 30MHz. Report No.: TBR-C-202606-0287-3 Page: 14 of 30 www.cotecna-toby.com TB-RF-073-3.1 5.4 Deviation From Test Standard No deviation 5.5 EUT Operating Mode Please refer to the description of test mode. 5.6 Test Data N/A Report No.: TBR-C-202606-0287-3 Page: 15 of 30 www.cotecna-toby.com TB-RF-073-3.1 6. Radiated and Conducted Unwanted Emissions 6.1 Test Standard and Limit 6.1.1 Test Standard FCC Part 15.209 & FCC Part 15.247(d) 6.1.2 Test Limit General field strength limits at frequencies Below 30MHz Frequency (MHz) Field Strength (μA/m)* Field Strength (microvolt/meter)** Measurement Distance (meters) 0.009~0.490 6.37/F (F in kHz) 2400/F(KHz) 300 0.490~1.705 63.7/F (F in kHz) 24000/F(KHz) 30 1.705~30.0 0.08 30 30 Note: 1, The emission limits for the ranges 9-90 kHz and 110-490 kHz are based on measurements employing a linear average detector. 2, *is for RSS Standard, **is for FCC Standard. General field strength limits at frequencies above 30 MHz Frequency (MHz) Field strength (μV/m at 3 m) Measurement Distance (meters) 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 General field strength limits at frequencies Above 1000MHz Frequency (MHz) Distance of 3m (dBuV/m) Peak Average Above 1000 74 54 Note: (1) The tighter limit applies at the band edges. (2) Emission Level(dBuV/m)=20log Emission Level(uV/m) In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated device is operating, the RF power that is produced shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided that the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of root- mean-square averaging over a time interval, as permitted under section 5.4(d), the attenuation require…

Text truncated - open the document above for the full version.

Report No.: TBR-C-202606-0287-3 Page: 23 of 30 www.cotecna-toby.com TB-RF-073-3.1 9. Peak Output Power 9.1 Test Standard and Limit 9.1.1 Test Standard FCC Part 15.247(b)(3) 9.1.2 Test Limit Test Item Limit Frequency Range(MHz) Peak Output Power not exceed 1 W or 30dBm 2400~2483.5 E.I.R.P not exceed 4 W or 36dBm 9.2 Test Setup 9.3 Test Procedure ---RBW≥DTS bandwidth ●The following procedure shall be used when an instrument with a resolution bandwidth that is greater than the DTS bandwidth is available to perform the measurement: a) Set the RBW≥DTS bandwidth. b) Set VBW≥[3*RBW]. c) Set span≥[3*RBW]. d) Sweep time = auto couple. e) Detector = peak. f) Trace mode = max hold. g) Allow trace to fully stabilize. h) Use peak marker function to determine the peak amplitude level. 9.4 Deviation From Test Standard No deviation 9.5 EUT Operating Mode Please refer to the description of test mode. 9.6 Test Data Please refer to the external appendix report of BLE. Report No.: TBR-C-202606-0287-3 Page: 24 of 30 www.cotecna-toby.com TB-RF-073-3.1 10. Power Spectral Density 10.1 Test Standard and Limit 10.1.1 Test Standard FCC Part 15.247(e) 10.1.2 Test Limit Test Item Limit Frequency Range(MHz) Power Spectral Density 8dBm(in any 3 kHz) 2400~2483.5 10.2 Test Setup 10.3 Test Procedure ●The following procedure shall be used if maximum peak conducted output power was used to determine compliance, and it is optional if the maximum conducted (average) output power was used to determine compliance: a) Set analyzer center frequency to DTS channel center frequency. b) Set the span to 1.5 times the DTS bandwidth. c) Set the RBW to 3 kHz≤RBW≤100 kHz. d) Set the VBW ≥[3*RBW]. e) Detector = peak. f) Sweep time = auto couple. g) Trace mode = max hold. h) Allow trace to fully stabilize. i) Use the peak marker function to determine the maximum amplitude level within the RBW. j) If measured value exceeds requirement, then reduce RBW (but no less than 3 kHz) and repeat. 10.4 Deviation From Test Standard No deviation 10.5 Antenna Connected Construction Please refer to the description of test mode. 10.6 Test Data Please refer to the external appendix report of BLE. Report N…

Text truncated - open the document above for the full version.
