Need to speak to an expert? 1 (201) 379-4900 · RIF6.com/support · [email protected] Record Player TABLE OF CONTENTS 04 Important Safety Instructions 06 Description of Parts 08 Operating Instructions 12 Troubleshooting 14 Specifications 15 Warranty Information 15 Contact Us RECORD PLAYER | 4 IMPORTANT SAFETY INSTRUCTIONS • Make sure the record player is properly ventilated and air circulates freely around the unit. Do not place the unit on a thick carpet, bed, or any place where ventilation holes may be obstructed. Leave at least 4 inches of clearance around the unit. • Do not place the unit: –Near heat sources, radiators, or other heating sources; –In high temperatures, high humidity, or direct sunlight; –Where there is excess dirt and dust; –Near open windows or any place where water may get into the unit; –Near a strong magnetic field; –On an amplifier or receiver. • Before operating this unit, check the voltage to see if it is identical to the voltage of your local power supply. • Clean the unit with clean dry cloth. Do not use liquid or aerosol cleaners. • Clean LP records only with a dry and reliable cleaner. Do not use liquid or aerosol cleaners. • When removing the power plug from the wall outlet, always pull on the plug directly. Do not pull on the cord. • If the supply cord is damaged, turn off the unit immediately and unplug it from the wall outlet. Damaged cords must be replaced by the manufacturer or a similarly qualified person to avoid hazards. • To prevent possible hearing damage, avoid listening to high volume levels for long periods, or suddenly listening to high volume levels. • This appliance is intended for use by adults and experienced individuals. Children and individuals with reduced physical, sensory, or mental capability, or lack of experience and knowledge, should not operate the unit unless they are supervised by an adult or guardian responsible for their safety. Children should not play with this appliance. • We are not liable for any damage caused by non-compliance with these instructions or any other improper use or mishandling of this appliance. RECORD PLAYER | 5 IMPORTANT SAFETY INSTRUCTIONS This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/ TV technician for help. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC STATEMENT RECORD PLAYER | 6 DESCRIPTION OF PARTS LPBT AUX BTT MODE 1 2 3 4 5 6 8 9 7 DC 12VRCA OUTAUX INAUX OUT 151011 12 13 14 2021 22 23 16 17 18 19 RECORD PLAYER | 7 DESCRIPTION OF PARTS 1Turntable Platter 245rp Record Adapter – Use it when playing a 45rpm record with a cut out center 3Tonearm 4Tonearm Lift Lever 5LP Auto Stop On / Off Selection 6Speed Selection: 33.3 rpm, 45 rpm, and 78 rpm 7Tonearm Holder 8Ceramic Cartridge with Ruby Needle 9Speaker Grill 10Bluetooth Transferring Indicator 11Power/ Play / Volume Knob –Press and hold for 2-3 seconds to turn the unit ON or OFF –Turn left to decrease the volume; Turn right to increase the volume –Press to pause or resume playing 12Aux-In Indicator 13Bluetooth-In Indicator 14Mode Knob –Press to select a source: LP, Bluetooth In (BT), and Aux In if available –Press and hold for 2-3 seconds to select Bluetooth Output (BTT) –In Bluetooth-In mode, turn left and right to select the previous or the next track 15LP Indicator 16Dust Cover 17Hinge 18Cabinet 19Feet 20DC 12V Type C port 21RCA Output 22Aux-In Jack 23Aux-Out Jack RECORD PLAYER | 8 OPERATING INSTRUCTIONS Initial Setup 1. Place the unit on a flat and level surface that is stable and free from vibration. 2. Remove the cable tie that is holding the tonearm. 3. Connect the AC adapter to the power jack of the unit. Note: • This product should only be operated by the type of power source indicated on the rating label. • Plug the AC power adapter to a power outlet after assembly is completed. Before turning the power on, check that all the connections are correct. • Always turn off the power when connecting or disconnecting the unit. Amplifier Connection (If Required) • Use an RCA cable (not supplied) to connect the unit to the external amplifier (not supplied): –Connect the red plug to the R/H channel input. –Connect the white plug to the L/H channel input. Note: You may opt to listen to this unit using the built-in speakers or through the headphone jack. RECORD PLAYER | 9 OPERATING INSTRUCTIONS Playing a Record 1. Press and hold the Power Volume Knob (11) for 2-3 seconds to turn the unit on. 2. Press the Mode Knob (14) to set the unit to LP mode. The mode indicator will light up. 3. Set the Speed Switch to your desired speed. 4. Place a record on the turntable. If necessary, use the 45 RPM adapter. 5. Remove the stylus protector from the stylus assembly. Note: To avoid stylus damage, ensure that the included stylus guard is in place whenever the turntable is being moved or cleaned. 6. Release the tonearm Hold-Down Clip. Note: When the turntable is not i…
