2AZK3-TSC-421PWireless Home Camera

FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

TRUEN Co., Ltd. Attestation Statement Letter I Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023. 05. 04 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC Application for FCC ID: 2AZK3-TSC-421P TRUEN Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited for receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Applicant’s Signature: Applicant’s Name: Sunguk Lee

TRUEN Co., Ltd. Attestation Statement Letter II Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023. 05. 04 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC Application for FCC ID: 2AZK3-TSC-421P TRUEN Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Applicant’s Signature: Applicant’s Name: Sunguk Lee

FCC Attestation Statement US Agent For Service Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023.04.13 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC Application for FCC ID: 2AZK3-TSC-421P TRUEN certifies that, as of the date of the filing of the application, Marshall Electronics Inc. is our designated U.S. agent for service of process for the above reference FCC ID: 2AZK3-TSC-421P. TRUEN agrees to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceedings involving the equipment. Marshall Electronics Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for above referenced FCC ID. Designated U.S. Agent Information Name: Marshall Electronics Inc. Address: 20608 Madrona Ave., Torrance, CA 90503 Contact Person: Sladjana Stojanovic Telephone: 310-333-0606 ext 1177 Email: [email protected] FRN : 0024866451 Sincerely, Applicant’s Signature : Agent’s Signature: Sladjana Stojanovic Applicant’s Name: Sun Guk Lee Agent’s Name: Sladjana Stojanovic

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Confidentiality v03 Page 1 of 1 TRUEN Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AZK3-TSC-421P Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Type of Confidentiality Requested Exhibit Type ☐Short Term ☒Permanent Block Diagrams ☒Short Term External Photos ☒Short Term ☐Permanent* Internal Photos ☐Short Term ☒Permanent Operation Description ☐Short Term ☒Permanent Parts List/BOM ☐Short Term ☒Permanent Schematics ☒Short Term Test Setup Photos ☒Short Term ☐Permanent* User manual *Requires further justification before permanent confidentiality will be allowed. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of 180 (ie- “45”, “90” or “180”) days. Sincerely, Client’s signature: Client’s name & title: Sunguk Lee/ manager Contact information / address: TRUEN Co., Ltd./ Office 1309, Woolim e-Biz Center 1, 28, Digital-ro 33-gil, Guro-gu, Seoul, Republic of Korea

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Authorization v02 Page 1 of 1 TRUEN Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2023-05-04 SUBJECT: FCC Application for (FCC ID: 2AZK3-TSC-421P) To Whom It May Concern: We, the undersigned, hereby authorize Eun-Hye, Gwak in ICR Co.,Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by ICR Co.,Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, (Must be signed by the person that is listed on the FCC Website) Client’s signature: Client’s name & title: Sunguk Lee/ manager Contact information / address: TRUEN Co., Ltd./ Office 1309, Woolim e-Biz Center 1, 28, Digital-ro 33-gil, Guro-gu, Seoul, Republic of Korea

Exterior Photographs Front Top Rear Bottom Side 1 Side 2 Side 3 Side 4

Assembled : China Model : TSC-421P SN : TI0000001 FCC ID : 2AZK3-TSC-421P R-R-TRN-TSC-421P EGLOO 5V ... 1.0A —

Interior Photographs Interior Main Board - Front Top Main board - Rear Bottom Port Board -Front Top Port Board - Rear Bottom Sub Board -Front Top Sub Board - Rear Bottom Dipol Antenna Antenna connector part Antenna PORT

페이지(page) : ( 2 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231002-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 3 1.1 Applicant information ........................................................................................................................................ 3 1.2 Manufacturer Information ................................................................................................................................. 3 1.3 Test Laboratory Information ............................................................................................................................ 3 2. Equipment under Test(EUT) Information ................................................................................................................. 4 2.1 General Information ........................................................................................................................................... 4 2.2 Additional Information ...................................................................................................................................... 4 2.3 Mode of operation during the test .................................................................................................................. 4 2.4 Modifications of EUT ......................................................................................................................................... 4 3. Maximum Permissible Exposure ............................................................................................................................... 5 3.1 RF Exposure calculation .................................................................................................................................. 5 3.2 Result ..................................................................................................................................................................... 6 Revision History Issued Report No. Issued Date Revisions Effect Section ICRT-TR-E231002-0A 2023.05.04 Initial Issue All 페이지(page) : ( 3 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231002-0A 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant information Applicant TRUEN Co., Ltd. Address Office 1309, Woolim e-Biz Center 1, 28, Digital-ro 33-gil, Guro-gu, Seoul, Republic of Korea Contact Person Sunguk Lee Telephone No. - Fax No. - E-mail [email protected] 1.2 Manufacturer Information Manufacturer TRUEN Co., Ltd. Address Office 1309, Woolim e-Biz Center 1, 28, Digital-ro 33-gil, Guro-gu, Seoul, Republic of Korea 1.3 Test Laboratory Information Conducted tests were performed at Laboratory ICR Co., Ltd. Address 112, Hwanggeum 3-ro 7beon-gil, Hagun-ri, Yangchon-eup, Gimpo-si, Gyeonggi-do, Korea Telephone No. +82-2-6351-9002 Fax No. +82-2-6351-9007 RRA No. KR0165 KOLAS No. KT652 페이지(page) : ( 4 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231002-0A 2. Equipment under Test(EUT) Information 2.1 General Information Product Name Wireless Home Camera Brand Name - Model Name TSC-421P Additional Model Name - FCC ID 2AZK3-TSC-421P Power Supply DC 5.0 V 2.2 Additional Information Equipment Class DTS-Digital Transmission System Device Type Stand-alone Operating Frequency 2.4 ㎓ WLAN (802.11b/g/n(HT20)) 2 412 ㎒ ~ 2 462 ㎒ RF Output Power 2.4 ㎓ WLAN 802.11b 11.84 ㏈m 2.4 ㎓ WLAN 802.11g 13.31 ㏈m 2.4 ㎓ WLAN 802.11n20 14.42 ㏈m Number of Channel 2.4 ㎓ WLAN (802.11b/g/n(HT20)) 11 Modulation Type 2.4 ㎓ WLAN 802.11b DSSS 2.4 ㎓ WLAN 802.11g/n20 OFDM Antenna Type FPCB Antenna Antenna Gain 1.85 ㏈i Antenna Operating Mode Single antenna exists for each mode 2.3 Mode of operation during the test - The EUT is continuous transmission mode during the test with set at Low Channel, Middle Channel, and High Channel. To get a maximum radiated emission levels from the EUT, the EUT was moved throughout the XY, YZ, XZ planes. 2.4 Modifications of EUT - None 페이지(page) : ( 5 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231002-0A 3. Maximum Permissible Exposure 3.1 RF Exposure calculation According to the FCC rule §1.1310 the limit for General Population/Uncontrolled exposure is 1 ㎽/㎠ for the device operating 1 500 ㎒ ~ 100 000 ㎒. The electric field generated for a 1 ㎽/㎝² exposure is calculated as follows: E = √ (30 * P * G) / D, and S = E² / Z = E² / 377, because 1 ㎽/㎝² = 10 W/m² S = Power density in ㎽/㎝², Z = Impedance of free space, 377 Ω P = Power input to the external antenna (Output power from the EUT antenna port (㏈m) – cable loss (㏈)), E = Electric filed strength in V/m, G = Numeric antenna gain, and D = distance in meter Combing equations and rearranging the terms to express the distance as a function of the remaining variable D = √ (30 * P * G) / (377 *10 S) Changing to units of ㎽ and cm, using P (㎽) = P (W) / 1 000, d (㎝) = 0.01 * d (m) D = 0.282 * √ (P * G) / S 페이지(page) : ( 6 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231002-0A 3.2 Result According to above equation, the following result was obtained. Operating Mode Target Power W / tolerance Max tune up power Antenna Gain Safe Distance (㎝) Power Density (㎽/㎝²) @ 20 ㎝ Separation Limit (㎽/㎝²) (㏈m) (㎽) Log Linear 802.11b 11.84. ± 1.0 12.84 19.23 1.85 1.53 1.53 0.0058 6 1.00 802.11g 13.31. ± 1.0 14.31 26.98 1.81 0.0082 2 802.11 n20 14.42 ± 1.0 15.42 34.83 2.06 0.0106 2 According to above table, for Band(802.11b), safe distance, D = 0.282 * √ (34.83 * 1.53)/1.00 = 2.06 ㎝. For getting power density at 20 ㎝ separation in above table, following formula was used. S = P * G / (4π * R²) = (34.83 * 1.53 / (4 * π * 20 2 ) = 0.0106 2 - END -

페이지(page) : ( 2 )/( 총(Total) 63 ) ICRT-QPA-17-03 Rev.2 Report No. ICRT-TR-E231001-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .................................................................................. 4 1.1 Applicant information ........................................................................................................................................ 4 1.2 Manufacturer Information ................................................................................................................................. 4 1.3 Test Laboratory Information ............................................................................................................................ 4 2. Equipment under Test(EUT) Information ................................................................................................................. 5 2.1 General Information ........................................................................................................................................... 5 2.2 Additional Information ...................................................................................................................................... 5 2.3 Mode of operation during the test .................................................................................................................. 5 2.4 Modifications of EUT ......................................................................................................................................... 5 3. Test Summary ................................................................................................................................................................. 6 3.1 Test standards and results .............................................................................................................................. 6 3.2 Purpose of the test ............................................................................................................................................. 6 3.3 Test Methodology ............................................................................................................................................... 6 3.4 Configuration of Test System ......................................................................................................................... 6 3.5 Antenna requirement ......................................................................................................................................... 7 4. Used equipment on test ............................................................................................................................................... 8 5. 6 ㏈ Bandwidth .............................................................................................................................................................. 9 5.1 Operating environment ..................................................................................................................................... 9 5.2 Measurement method ........................................................................................................................................ 9 5.3 Test data ............................................................................................................................................................... 9 6. Maximum Conducted Output Power ....................................................................................................................... 16 6.1 Operating environment ................................................................................................................................... 16 6.2 Measurement method ...................................................................................................................................... 16 6.3 Test data ............................................................................................................................................................. 16 7. Power Spectral Density .............................................................................................................................................. 23 7.1 Operating environment ................................................................................................................................... 23 7.2 Measurement method ...................................................................................................................................... 23 7.3 Test data ............................................................................................................................................................. 23 8. Conducted Spurious Emission ................................................................................................................................ 30 8.1 Operating environment ................................................................................................................................... 30 8.2 Measurement method ...................................................................................................................................... 30 8.3 Test data ............................................................................................................................................................. 30 9. Radiated Spurious Emission .................................................................................................................................... 45 9.1 Operating environment ................................................................................................................................... 45 9.2 Measurement method ...................................................................................................................................... 45 9.3 Test setup ...........................................................................................................................................…

Text truncated - open the document above for the full version.

SPECIFICATION 深圳市天达通信有限公司 ShenZhenTianDaCommunicationCO.,LTD 5810GCA天线 产品承认书 客户高斯贝尔频段 2400-2500MHz 项目名称 5810GCA 版本A 项目料号 GS-58-1A-WI-A 颜色黑色 RF设计王新闯结构设计贺森林 日期 2020.09.15 客户确认： 装配是否符合贵司要求：□ OK □ NG 深圳市天达通信有限公司 ShenZhenTianDaCommunicationCO.,LTD. 深圳市宝安区71区留仙一路二巷26号百财科技园L 栋5E TEL:0755-22194566 FAX:0755-22194566 5EBuildingL,NO26Alley2BaicaiSciencePark, LiuxianRoad,71District,BaoanDistrict,Shenzhen TEL:0755-22194566 FAX:0755-22194566 ConfidentialInformation 保密要求 深圳市天达通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市达通信有限公司事先书面 同意时不允许透露给任何人或公司。 Page 2 目录 一、WIFI天线.........................................................................................................................3 1 、规格 .................................................................................................................................3 1.1 、电器规格 ......................................................................................................................3 1.1.1 、电性能指标 ...............................................................................................................3 1.1.2 、匹配电路图 ...............................................................................................................3 1.2 、测试 ..............................................................................................................................4 1.2.1 、无源测试数据 ...........................................................................................................4 1.2.1.1 、天线驻波图 ............................................................................................................4 1.2.1.2 、天线增益、效率 ....................................................................................................5 1.2.2 、整机有源测试数据 ...................................................................................................5 二、结构规格...........................................................................................................................5 2.1 、天线组成 ......................................................................................................................5 2.2 、工程图 .........................................................................................................................6 2.3 、尺寸测量 ......................................................................................................................6 三、结论....................................................................................................................................6 ConfidentialInformation 保密要求 深圳市天达通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市达通信有限公司事先书面 同意时不允许透露给任何人或公司。 Page 3 一、WIFI天线 1、规格 该承认书主要提供5810GCA项目WIFI天线电气和结构性能参数的测试状况。 下图是天达设计WIFI天线的图片。 1.1、电器规格 1.1.1、电性能指标 此天线工作频段为2400MHz—2500MHz，下面是天达设计和量产天线的电性能 指标。 WIFI 频段频率（MHz） VSWR 2.4G2400~2500 ≤2.0 1.1.2、匹配电路图 ConfidentialInformation 保密要求 深圳市天达通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市达通信有限公司事先书面 同意时不允许透露给任何人或公司。 Page 4 WIFI天线的匹配电路为主板原匹配，没有更改。 1.2、测试 1.2.1、无源测试 1.2.1.1、天线驻波测试（VSWR） ConfidentialInformation 保密要求 深圳市天达通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市达通信有限公司事先书面 同意时不允许透露给任何人或公司。 Page 5 1.2.1.2、天线增益、效率 1.2.2、整机有源测试数据 上面是整机的有源测试数据。 二、结构规格 2.1、天线组成 WIFI天线主要是由FPC+Cable线组成 ConfidentialInformation 保密要求 深圳市天达通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市达通信有限公司事先书面 同意时不允许透露给任何人或公司。 Page 6 2.2、工程图 2.3、尺寸测量 数量 重点尺寸 1234 21.60±0.2 21.6021.5921.6121.62 28.40±0.2 28.4128.4028.4128.39 75.00±1.0 75.0375.0575.1075.08 三、结论 此天线是在客户目前提供的样机上设计的，电气参数和结构尺寸已达到技术要求，请确认！

페이지(page) : ( 1 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. ICRT-TR-E231001-0A Test Setup Photo Test Setup Radiated measurement for below 1 ㎓ (Front side) Test Setup Radiated measurement for below 1 ㎓ (Rear side) 페이지(page) : ( 2 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. ICRT-TR-E231001-0A Test Setup Radiated measurement for Above 1 ㎓ (Front side) Test Setup Radiated measurement for Above 1 ㎓ (Rear side) 페이지(page) : ( 3 )/( 총 3 ) ICRT-QP-22-02 Rev.5 Report No. ICRT-TR-E231001-0A Test Setup Power Line Conducted Emission (Front) Test Setup Power Line Conducted Emission (Side)
