2AZLRQ7SFingerprint password smart lock

Q7S Fingerprint password smart lock User Manual Please read this instruction carefully before using it This instruction contains the service guide, please take good care of it Installation instructions Install the safety bar on the back panel, the square bar only needs to insert the bolt slot vertically, the opening pin can not be pulled out. Figure 1:indoor outdoor Take out the handle connecting pipe and connect the front panel wire to the front panel through the facade and lock body (the correct position of the wire is: the lock hole at the top of the door fan) and insert the square bar into the security door lock body, usually with a short end facing inward. Insert the front panel wire in the rear panel; 2.The rear panel insurance is aligned with the safety hole; 3.The handle knob is aligned inward and the rotary knob is aligned with the square s teel of the lock core. Do not tighten the screw too tight, move the rear panel, press the knob inward to turn the knob more freely before tightening the connecting screw. Install lithium battery, cover battery cover and install. Door Debug: Press the lock key motor to rotate freely, after the lock is finished, press the rear panel knob, turn freely without Carton condition is normal. If you rotate Catton, release the lock screw 1 circle up and down to move the lock until the knob rotates freely to turn the safety knob to pop up. ) Serial number Project Description 1 Working voltage 7V-8.4V 2 Alarm voltage Below 7.2 V: battery power 3 dormant static current <80|JA 4 Formula Fingerprint, aim, card 5 NFC 6 Mouth Micro USB interface (Charger charging battery) 7 Number of users managed 5 8 Number of ordinary users 295 9 Reference 100 10 100 11 Number of cards 100 12 Card Type and Type Mifare-l and ISO /IEC 11143-A compatibility 13 Lock (front panel) Lakes (CLOSE) 14 ^± lock (rear panel) (CLOSE) 15 (rear panel) Lakes (OPEN) Restoring Ex-factory Settings (Initialization System)- Operation on Power Up 1、 Remove all batteries from the intelligent lock and disconnect the power supply during testing. 2、 Multiple clicks on the rear panel switch lock key to allow the system to discharge completely. 3、 Press the rear panel lock key not to loosen, put in the intelligent lock battery. 4、 Wait for the system to prompt 5 keystroke sounds (release fingers within 5 times to cancel initialization). 5、 After pressing the key 5 times prompt "initialization, please wait" can loosen the finger, the system into initialization mode. 6、 When the system voice prompt "initialization success ", the system initialization is completed, all user electronic keys empty, enter open demonstration mode. Note: after initialization, the system administrator password is restored to "123456". After initialization, any fingerprint or card can be unlocked for customers to experience the lock function operation will not affect the direction of the motor, strength and rotation time settings, will save the previous settings parameters. Administrator action settings System parameter setting Restore factory settings (initialization system) 1. enter the system menu, the system prompts: User management press 1, Press 2 for system setup, Unlock parameters press 3, Restore factory setting by 4; 2、 Press "4" to select to restore factory settings, because the initialization hazard level is high, so in order to prevent misoperation, set up a reconfirmation menu, must be confirmed by the user, this time the button confirmed; 3, Enter the initialization interface, initialization process and power- on initialization operation, after initialization will restart the system. Unlock 1、 In dormant or wake-up state, the card entered into the card area to unlock; 2、 In dormant or wake-up state, put the finger into the fingerprint box to verify the unlock; 3、 Wake-up state will have entered the password input after the key to verify the unlock; 4、 Click the back panel to unlock the key (OPEN) to unlock; 5、 Dynamic password (WeChat Mini Program) unlock, please read the company's "dynamic password operation instructions ". Lock lock 1、 Click the lock key on the front panel in dormant or wake-up state. 2、 Click the back panel to close the lock. 3、 After the automatic delay lock is turned on, the countdown time of dormant state after unlocking will automatically turn off the lock. Electronic backlock Press the rear panel lock button 2 S, wait for the front panel to prompt "the door has entered the anti-lock mode" or "the door has withdrawn from the anti-lock mode ", enter the anti-lock can only be unlocked by the administrator, ordinary users can not unlock. Note: please use this function carefully. doorbell In dormant or wake-up state, click the front panel doorbell key (if there is no doorbell key, use the key reuse), this time will ring two doorbells, can not interrupt, many doorbells need to wait for the system to sleep and click the doorbell key again. Electricity alarm 1、 If the battery voltage is lower than the alarm voltage (default 7.2 V), it will prompt "low battery power ". 2, After the switch lock, if the battery voltage is lower than the alarm voltage (default 7.2 V), it will prompt "low battery power ". Warm Tip: need to replace the battery or charge the battery at this time, lest the battery depletion affect the switch lock. Battery charging and system emergency 1、 If the battery has been completely depleted and shut down, it is necessary to charge the battery with external USB power supply. When the voltage rises to the point where the lock can be unlocked, the input information is verified to unlock. 2、 After the battery is low, it needs to charge the battery, which can be charged with external USB or removed from the lithium battery. Warm Tip: do not press the lock key when re-discharging pool, otherwise it will enter initialization, resulting in system information emptying - Continuous validation error freeze When the lock body validates more than 5 times in 5 minutes, all operations are frozen…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Zhejiang Laiu Technology Co., Ltd. Address Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Grantee Code 2AZLR FCC ID 2AZLRQ7S Authorized Contact Name James .Lu Contact Email [email protected] Contact Phone 18005799412 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules -regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:2021/04/14 Print Name: James .Lu Title: Sales manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Zhejiang Laiu Technology Co., Ltd. Date: 04/14/2021 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AZLRQ7S To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Zhejiang Laiu Technology Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): James .Lu Title: Sales manager Signature: On behalf of Company: Zhejiang Laiu Technology Co., Ltd. Telephone: 18005799412

Zhejiang Laiu Technology Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Zhejiang Laiu Technology Co., Ltd. Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Regarding: Confidentiality Request regarding application for FCC ID : 2AZLRQ7S LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): James .Lu Title: Sales manager Company Name: Zhejiang Laiu Technology Co., Ltd.

Zhejiang Laiu Technology Co., Ltd. Current Date : 2021-04-14 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE (Zhejiang Laiu Technology Co., Ltd. ) HEREBY DECLARED THAT Product Description Fingerprint password smart lock Model No. A8-1,H5,E6,E8,E9,L8,L9,L9S,Q7,L3,L3S,RF2-13,LUM13,LUM17, LU01,LU02,LY01,LY02,LY03,LY04,LY05,LY06,LY07,LY08,LY09,LY10,LY11,LY12,LY13, LY14,LY15,LY16,LY17,LY18,LY19,LY20,LY21,LY22,LY23,LY24,LY25,LY26,LY27,LY28, LY29,LY30 Manufacturer’s Name Zhejiang Laiu Technology Co., Ltd. Manufacturer’s Address Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. Model No. (型号): Q7S Manufacturer’s Name (生产商名称): Zhejiang Laiu Technology Co., Ltd. Manufacturer’s Address（生产商商地址): Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Sincerely, Signature (签字): Printed Name (姓名): James .Lu Position/Title (职位): Sales manager Contact Number (联系电话): 18005799412

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 8 Page 1 of 8 External Photos Applicant: Zhejiang Laiu Technology Co., Ltd. Address of Applicant: Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Equipment Under Test (EUT): Product Name: Fingerprint password smart lock Model No.: Q7S SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 8 Page 2 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 8 Page 3 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 4 of 8 Page 4 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 5 of 8 Page 5 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 6 of 8 Page 6 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 7 of 8 Page 7 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 8 of 8 Page 8 of 8 End

FCC ID: 2AZLRQ7S Remark：It’s hard to put FCC statement on the product due to device’s irregular appearance. FCC statement will be placed in the user manual which the device is marketed.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 12 Page 1 of 12 Internal Photos Applicant: Zhejiang Laiu Technology Co., Ltd. Address of Applicant: Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Equipment Under Test (EUT): Product Name: Fingerprint password smart lock Model No.: Q7S SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 12 Page 2 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 12 Page 3 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 12 Page 4 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 12 Page 5 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 12 Page 6 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 12 Page 7 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 12 Page 8 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 12 Page 9 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 12 Page 10 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 12 Page 11 of 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 12 of 12 Page 12 of 12 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400296802 Page: 1 of 22 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: SHEM2104002968CR FCC ID: 2AZLRQ7S Applicant: Zhejiang Laiu Technology Co., Ltd. Address of Applicant: Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Manufacturer: Zhejiang Laiu Technology Co., Ltd. Address of Manufacturer: Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Factory: Zhejiang Laiu Technology Co., Ltd. Address of Factory: No.16 Yingui South Road Huachuan District Yongkang city Zhejiang Pro. China Equipment Under Test (EUT): EUT Name: Fingerprint password smart lock Model No.: Q7S,A8-1,H5,E6,E8,E9,L8,L9,L9S,Q7,L3,L3S,RF2-13,LUM13,LUM17, LU01,LU02,LY01,LY02,LY03,LY04,LY05,LY06,LY07,LY08,LY09,LY10, LY11,LY12,LY13,LY14,LY15,LY16,LY17,LY18,LY19,LY20,LY21,LY22, LY23, LY24,LY25,LY26,LY27,LY28,LY29,LY30 ¤ ¤ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Standard(s) : 47 CFR Part 15, Subpart C 15.225 Date of Receipt: 2021-04-07 Date of Test: 2021-04-14 to 2021-05-10 Date of Issue: 2021-05-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400296802 Page: 2 of 22 Revision Record Version Description Date Remark 00 Original 2021-05-12 / Authorized for issue by: Bill Wu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400296802 Page: 3 of 22 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.225 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Emission Mask 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.225(a)&(b)&( C ) Pass* Frequency tolerance 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart C 15.225(e) Pass Radiated Emissions(9kHz- 30MHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Radiated Emissions(30MHz- 1GHz) 47 CFR Part 15, Subpart C 15.225 ANSI C63.10 (2013) Section 6.4&6.5 47 CFR Part 15, Subpart C 15.225(d) & 15.209 Pass Note1*: The test level of the fundamental signal is below the limit of general spurious emission, so the test item doesn’t be performed. Declaration of EUT Family Grouping: Note2: There are series models mentioned in this report, and they are the similar in electrical and electronic characters. Only the model Q7S was tested since their differences were the model number and appearance. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210400296802 Page: 4 of 22 3 Contents Page 1 COVER PAGE.............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T.................................................................................................................................. 5 4.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY ................................................................................................................ 5 4.4 TEST LOCATION ..................................................................................................................................... 6 4.5 TEST FACILITY ....................................................................................................................................... 6 4.6 DEVIATION FROM STANDARDS ................................................................................................................ 6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 6 5 EQUIPMENT LIST ....................................................................................................................................... 7 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ................................................................................... 8 6.1 ANTENNA REQUIREMENT ........................................................................................................................ 8 7 RADIO SPECTRUM MATTER TEST RESULTS ........................................................................................ 9 7.1 20DB BANDWIDTH ........................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 5 Page 1 of 5 Test Setup Photos-FCC Applicant: Zhejiang Laiu Technology Co., Ltd. Address of Applicant: Second Floor, Building 1, No. 16, South Yingui Road, Chengxi New District, Yongkang, Zhejiang, China Equipment Under Test (EUT): Product Name: Fingerprint password smart lock Model No.: Q7S SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 5 Page 2 of 5 1 Contents Page 1 CONTENTS............................................................................................................... 2 2 EQUIPMENT UNDER TEST PICTURES ............................................................ 3 2.1 Radiated Emission Test Setup .......................................................................... 3 2.2 RF Conducted Test Setup ................................................................................. 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 5 Page 3 of 5 2 EQUIPMENT UNDER TEST PICTURES 2.1 Radiated Emission Test Setup Below 30MHz 30MHz to 1GHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 5 Page 4 of 5 Above 1GHz Zoom: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 5 Page 5 of 5 2.2 RF Conducted Test Setup End
