USER MANUAL CAEA-SRR-400 Contents Product introduction....................................................................................................................3 System structure .........................................................................................................................3 Functional specifications............................................................................................................4 BSD Function ............................................................................................................................4 LCAFunction..............................................................................................................................4 DOWFunction ...........................................................................................................................5 RCTA Function..........................................................................................................................5 RCW Function...........................................................................................................................6 External dimension....................................................................................................................6 Federal Communications Commission (FCC) Compliance Statement for USA-----------------7 RF Exposure Warning---------------------------------------------------------------------------------------7 Product introduction CAEA-SRR-400 is a middle range radar. This system uses two radars as the lateral and backward warning system. The system supports multiple functions, including BSD, LCA, DOW, RCTA and RCW. During the normal system operation, LEDs will be activated as an output when one or more warning conditions are satisfied. Moreover, LEDs will be constant on or flashing for different system warning levels. System structure Functional specifications BSD Function LCA Function DOW Function RCTA Function RCW Function External dimension Federal Communications Commission (FCC) Compliance Statement for USA This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. RF Exposure Warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This product may not be collocated or operated in conjunction with any other antenna or transmitter. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.

Report No.: 2104RSU051-UE External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2104RSU051-UE (3) EUT Photo (4) EUT Photo Report No.: 2104RSU051-UE (5) EUT Photo (6) EUT Photo

Report No.: 2104RSU051-UE Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2104RSU051-UE (3) EUT Photo (4) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2104RSU051-U2 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 06-26-2021 1 of 9 RF Exposure Evaluation Declaration FCC ID: 2AZN4-CAEASRR400 Applicant: Changjiang Automobile Electronic System Co., Ltd. Application Type: Certification Product: SRR Model No.: CAEA-SRR-400 Serial Model No.: SRR400 Brand Name: CAEA Test Rule(s): Part 95 Subpart M, Section 95.3385 Reviewed By: Vincent Yu Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2104RSU051-U2 2 of 9 Revision History Report No. Version Description Issue Date Note 2104RSU051-U2 Rev. 01 Initial Report 06-26-2021 Valid Report No.: 2104RSU051-U2 3 of 9 CONTENTS Description Page 1. GENERAL INFORMATION ................................................................................................... 4 1.1. Applicant ................................................................................................................ 4 1.2. Manufacturer ......................................................................................................... 4 1.3. Testing Facility ....................................................................................................... 4 2. PRODUCT INFORMATION ................................................................................................... 5 2.1. Equipment Description ........................................................................................... 5 3. RF EXPOSURE EVALUATION ............................................................................................. 6 3.1. Limits ..................................................................................................................... 6 3.2. Test Result ............................................................................................................ 8 Appendix - EUT Photograph ...................................................................................................... 9 Report No.: 2104RSU051-U2 4 of 9 1. GENERAL INFORMATION 1.1. Applicant Changjiang Automobile Electronic System Co., Ltd. No.289, Road12, Avenue2, Binhai Industrial Zone, Wenzhou, Zhejiang 325024, P.R.China 1.2. Manufacturer Changjiang Automobile Electronic System Co., Ltd. No.289, Road12, Avenue2, Binhai Industrial Zone, Wenzhou, Zhejiang 325024, P.R.China 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025, G-20034, C-20020, T-20020 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: L3261-190725 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2104RSU051-U2 5 of 9 2. PRODUCT INFORMATION 2.1. Equipment Description Product Name SRR Model No. CAEA-SRR-400 Serial Model No. SRR400 Working Frequency Range 76 ~ 77GHz Type of Modulation FMCW Emission Designator 518MN0N Working Voltage 12VDC Antenna Type Integrated antenna Remark: The different of models only for marketing different client. The PCB layout, circuit schematic, and RF performance of each model are the same. Report No.: 2104RSU051-U2 6 of 9 3. RF EXPOSURE EVALUATION 3.1. Limits FCC 95.3385 Regardless of the power density levels permitted under this subpart, devices operating under the provisions of this subpart are subject to the radiofrequency radiation exposure requirements specified in §§1.1307(b), 2.1091, and 2.1093 of this chapter, as appropriate. Applications for equipment authorization of devices operating under this section must contain a statement confirming compliance with these requirements for both fundamental emissions and unwanted emissions. Technical information showing the basis for this statement must be submitted to the Commission upon request. §2.1091 Radiofrequency radiation exposure evaluation: portable devices For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. §1.1310 Radiofrequency radiation exposure limits. Below sets forth limits for Maximum Permissible Exposure (MPE) to radiofrequency electromagnetic fields Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f2 6 30-300 61.4 0.163 1.0 6 300-1,500 -- -- f/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f2 30 30-300 27.5 0.073 0.2 30 300-1,500 -- -- f/1500 30 1,500-100,000 -- -- 1.0 30 f= Frequency in MHz * = Plane-wave equivalent power density Report No.: 2104RSU051-U2 7 of 9 Calculation Formula: Pd = (Pout*G)/(4*Pi*r 2 ) = E/(4*Pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW E = EIRP in mW G = gain of antenna in linear …

Text truncated - open the document above for the full version.

MRT Technology (Suzhou) Co., Ltd Report No.: 2104RSU051-U1 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 06-26-2021 1 of 27 FCC ID: 2AZN4-CAEASRR400 Applicant: Changjiang Automobile Electronic System Co., Ltd. Application Type: Certification Product: SRR Model No.: CAEA-SRR-400 Serial Model No.: SRR400 Brand Name: CAEA FCC Classification: Part 95 Vehicular Radar Systems FCC Rule Part(s): FCC Part 95, Subpart M Test Procedure(s): ANSI C63.10-2013 Test Date: April 24 ~ June 10, 2021 Reviewed By: Vincent Yu Approved By: Robin Wu MEASUREMENT REPORT FCC PART95 Subpart M The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2104RSU051-U1 2 of 27 Revision History Report No. Version Description Issue Date Note 2104RSU051-U1 Rev. 01 Initial Report 06-26-2021 Valid Report No.: 2104RSU051-U1 3 of 27 CONTENTS Description Page 1. GENERAL INFORMATION ..................................................................................................... 5 1.1. Applicant ....................................................................................................................... 5 1.2. Manufacturer ................................................................................................................ 5 1.3. Testing Facility .............................................................................................................. 5 2. PRODUCT INFORMATION ..................................................................................................... 6 2.1. Equipment Description .................................................................................................. 6 2.2. Test Mode .................................................................................................................... 6 2.3. Test Environment Condition .......................................................................................... 6 3. TEST EQUIPMENT CALIBRATION DATA .............................................................................. 7 4. MEASUREMENT UNCERTAINTY ........................................................................................... 8 5. TEST RESULT ........................................................................................................................ 9 5.1. Summary ...................................................................................................................... 9 5.2. EIRP ........................................................................................................................... 10 5.2.1. Test Limit ................................................................................................................ 10 5.2.2. Test Procedure........................................................................................................ 10 5.2.3. Test Setting ............................................................................................................. 10 5.2.4. Test Setup ................................................................................................................ 11 5.2.5. Test Result .............................................................................................................. 12 5.3. Occupied Bandwidth ................................................................................................... 13 5.3.1. Test Limit ................................................................................................................ 13 5.3.2. Test Procedure........................................................................................................ 13 5.3.3. Test Setting ............................................................................................................. 13 5.3.4. Test Setup ............................................................................................................... 13 5.3.5. Test Result .............................................................................................................. 14 5.4. Unwanted Emissions .................................................................................................. 15 5.4.1. Test Limit ................................................................................................................ 15 5.4.2. Test Procedure........................................................................................................ 15 5.4.3. Test Setting ............................................................................................................. 16 5.4.4. Test Setup ............................................................................................................... 17 5.4.5. Test Results ............................................................................................................ 19 5.5. Frequency Stability ..................................................................................................... 22 5.5.1. Test Limit ................................................................................................................ 22 5.5.2. Test Procedure........................................................................................................ 22 Report No.: 2104RSU051-U1 4 of 27 5.5.3. Test Setting ............................................................................................................. 22 5.5.4. Test Setup ............................................................................................................... 23 5.5.5. Test Result ...........................................................................…

Text truncated - open the document above for the full version.

Report No.: 2104RSU051-UT Test Setup Photograph Description: Radiated Emission Test Setup for Below 1GHz Description: Radiated Emission Test Setup for 1GHz ~ 18GHz Report No.: 2104RSU051-UT Description: Radiated Emission Test Setup for 18GHz ~ 40GHz Description: Radiated Emission Test Setup for 40GHz ~ 50GHz Report No.: 2104RSU051-UT Description: Radiated Emission Test Setup for 50GHz ~ 75GHz Description: Radiated Emission Test Setup for 75GHz ~ 110GHz Report No.: 2104RSU051-UT Description: Radiated Emission Test Setup for 110GHz ~ 140GHz Description: Radiated Emission Test Setup for Above 140GHz
