2AZO8-GCNWireless Gamepad

Plug-N-Play: This wireless gamepad requires no drivers, simply plug in the 2.4GHz dongle to your device, switch on the controller and you’re ready to game. The built-in 400mAh rechargeable ba�ery rovides you with up to 10 hours of game �me. Well-built Layout and Bu�ons: Ergonomic and streamlined layout featuring a textured grip on both handles along with 2 Analog s�cks, 8 Way Direc�onal D-Pad, 4 Ac�on Bu�ons, 2 Triggers , 2 Shoulder Bu�ons, 4 Func�on Bu�ons, 4 LED Indicators and 2 Built-in Vibra�on Motors. Connec�on type: 2.4GHz wireless Opera�ng range: 8 meters Ba�ery: Built-in rechargeable 400mAh Play �me: Approx. 10 hours *Depending on usage pa�ern Charging �me: Approx. 2 hours Features and Specifica�ons Connect the receiver to any available USB port on your device and wait for five seconds. Press the “HOME” bu�on on the gamepad to switch ON the gamepad. All LEDs will flash during the pairing process. Once the pairing is completed, one of the LEDs will remain constant. To switch OFF the gamepad, Press L3 (Center of Le� Analog S�ck) + BACK bu�on. All LEDs will be switched off. Connec�on setup When the ba�ery power is too low, the Gamepad will automa�cally shut down. When the Gamepad is not paired with a device, it shuts-off automa�cally if it is inac�ve for thirty seconds. If the Gamepad is paired, it will shut-off a�er five minutes of inac�vity in order to conserve power. When the ba�ery is low, all LED indicators will blink quickly. Connect the gamepad to a standard, ac�ve USB port for charging. While the gamepad is charging, all LED indicators will flash. Once the ba�ery is fully charged, all LEDs will turn off. Charging and sleeping mode Wireless Gamepad Model: GCN-001AA-01 FCC ID: 2AZ08-GCN Never try to open the device to undertake any repairs or modifica�ons. Avoid contact with the main voltage. Do not short-circuit the product. The device is not approved for outdoor use. Please use it only in dry places. Protect it from high humidity, water and snow. Keep the device away from high temperatures. Do not expose the device to sudden changes in temperature or strong vibra�on, as this could damage the electronic components. Do not use the device for purpose other than those described in the user manual. This product is not a toy. Please follow the normal opera�on of standard ba�eries. If the gamepad has not been used for a long period, charge for a while. Safety instruc�ons This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s).Opera�on is subject to the following two condi�ons: this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. Any Changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condi�on without restric�on. Federal Communica�ons Commission No�ce Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons. However, there is no guarantee that interference will not occur in a par�cular installa�on. If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separa�on between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Micro Connectors, Inc Model Difference FCC ID: 2AZO8-GCN Model : GCN-001AA-01, GCN-002BB-02, GCN-003CC-03, GCN-004DD-04, GCN-005EE-05, GCN-006FF-06 All models have same circuits diagram, PCB Layout, construction and rated power, only different is the model name. Sincerely, Client’s signature: Client’s name & title: Tommy Hsu / Representative Contact information /address: 2700 McCone Avenue Hayward, CA 94545 USA

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Authorization v02 Page 1 of 1 Micro Connectors, Inc Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2021/5/6 SUBJECT: FCC Application for (FCC ID: 2AZO8-GCN) To Whom It May Concern: We, the undersigned, hereby authorize Liu Ze in Shenzhen United Testing Technology Co., Ltd. at 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, XixiangStr, Bao'an District, Shenzhen, China on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Hyperkin, inc on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Client’s signature: Client’s name & title: Tommy Hsu / Representative Contact information /address: 2700 McCone Avenue Hayward, CA 94545 USA

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Confidentiality v02 Page 1 of 1 Micro Connectors, Inc Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AZO8-GCN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Descriptionl Block.pdf Sch.pdf OPS.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of _(ie- “45”, “90” or “180”) days: Exhibit Type File Name Sincerely, Client’s signature: Client’s name & title: Tommy Hsu / Representative Contact information /address: 2700 McCone Avenue Hayward, CA 94545 USA

Label Location

ANT

Page 1 of 22 Report No.: UNIA20042212ER-01 FCC RADIO TEST REPORT FCC ID: 2AZO8-GCN Product ： Wireless Gamepad Trade Name： N/A Model Name： GCN-001AA-01 Series Model： GCN-002BB-02, GCN-003CC-03, GCN-004DD-04, GCN-005EE-05, GCN-006FF-06 Report No. ： UNIA20042212ER-01 Prepared for Micro Connectors, Inc. 2700 McCone Avenue Hayward, CA 94545 USA Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 22 Report No.: UNIA20042212ER-01 TEST RESULT CERTIFICATION Applicant’s name ................. : Micro Connectors, Inc. Address ................................. : 2700 McCone Avenue Hayward, CA 94545 USA Manufacture's Name ............ : Micro Connectors, Inc. Address ................................. : 2700 McCone Avenue Hayward, CA 94545 USA Product description Product name ............................ : Wireless Gamepad Trade Mark .......................... : N/A Model and/or type reference : GCN-001AA-01 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : Apr. 22 ~ 30. 2021 Date of Issue .......................................... : May 02, 2021 Test Result.............................................. : Pass Tested by: Kahn yang/Engineer Reviewer: Sherwin Qian/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 22 Report No.: UNIA20042212ER-01 Table of Contents Page 1. TEST SUMMARY 4 1.1 TEST PROCEDURES AND RESULTS 4 1.2 TEST FACILITY 4 1.3 MEASUREMENT UNCERTAINTY 4 2. GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 Carrier Frequency of Channels 5 2.3 Operation of EUT during testing 5 2.5 MEASUREMENT INSTRUMENTS LIST 6 3. CONDUCTED EMISSIONS TEST 7 3.1 Conducted Power Line Emission Limit 7 3.2 Test Setup 7 3.3 Test Procedure 7 3.4 Te s t Result 7 4. RADIATED EMISSION TEST 10 4.1 Radiation Limit 10 4.2 Test Setup 10 4.3 Test Procedure 11 4.4 Test Result 11 5. BAND EDGE 16 5.1 Limits 16 5.2 Test Procedure 16 5.3 Test Result 16 6. OCCUPIED BANDWIDTH MEASUREMENT 18 6.1 Test Setup 18 6.2 Test Procedure 18 6.3 Measurement Equipment Used 18 6.4 Test Result 18 7. ANTENNA REQUIREMENT 20 8. PHOTOGRAPH OF TEST 21 Page 4 of 22 Report No.: UNIA20042212ER-01 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST RESULT CONDUCTED EMISSIONS TEST COMPLIANT RADIATED EMISSION TEST COMPLIANT BAND EDGE COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT COMPLIANT ANTENNA REQUIREMENT COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L6494 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2017 General Requirements) for the Competence of testing Laboratories. Designation Number: CN1227 Test Firm Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. A2LA Certificate Number: 4747.01 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty = 2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz) = 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 5 of 22 Report No.: UNIA20042212ER-01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Gamepad Trade Mark N/A Test Model Name GCN-001AA-01 Sample ID UNIA20042212ER-1# Serial Model GCN-002BB-02, GCN-003CC-03, GCN-004DD-04, GCN-005EE-05, GCN-006FF-06 Model Difference All models have same circuits diagram, PCB Layout, construction and rated power, only different is the model name. FCC ID 2AZO8-GCN Antenna Type PCB Antenna Antenna Gain -6.17dBi Frequency Range 2405-2475MHz Number of Channels 3CH Modulation Type GFSK Power Source DC 3.7V from battery DC 5V/1A from Adapter Table for auxiliary equipment: 2.2 Carrier Frequency of Channels Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2405 01 2440 02 2475 2.3 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode Low Channel: 2405MHz Middle Channel: 2440MHz High Channel: 2475MHz The direction key can be adjusted up and down to switch different frequency signal. Equipment Description Manufacturer Model Serial Number Adapter BYD MDY-08-EV N/A Page 6 of 22 Report No.: UNIA20042212ER-01 2.5 MEASUREMENT INSTRUMENTS LIST Item Equipment Manufacturer Model No. Serial No. Calibrated until CONDUCTED EMISSIONS TEST 1 AMN Schwarzbeck NNLK8121 8121370 2021.09.05 2 AMN ETS 3810/2 00020199 2021.09.05 3 EMI TEST RECEIVER Rohde&Schwarz ESCI 101210 2021.09.05 4 AAN TESEQ T8-Cat6 38888 2021.09.05…
