FCC ID: 2AZOP-PWCMAG Model no: PWCMAG FCC warning This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 1 of 7 Appendix I: Photos of the EUT Product Name : Wireless charger Model Number : PWCMAG Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 2 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 3 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 4 of 7

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 5 of 7 Wireless Charger Antenna Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 6 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23021004-1E Page 7 of 7 END

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 1 of 19 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Lifeguard Press Inc. Address : 134 Beech Bend Rd. Bowling Green, KY 42101 Equipment under Test : Wireless charger Model No. : PWCMAG Trade Mark : N/A FCC ID : 2AZOP-PWCMAG Manufacturer : TAK MING TRADING COMPANY Address : 709 WAN LANHOUSE WAN TAU TONG ESTATE TAI PO NT Report No.: DDT-RE23021004-2E02 Issued Date: Apr. 06, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 2 of 19 Table of Contents Test report declares........................................................................................................3 1. General Information .................................................................................................................. 5 1.1. Description of equipment ......................................................................................................... 5 1.2. Assistant equipment used for test .......................................................................................... 5 1.3. Assess laboratory ..................................................................................................................... 5 1.4. Measurement uncertainty ........................................................................................................ 5 2. Equipment used during test .................................................................................................... 6 3. Method of Measurement .......................................................................................................... 7 3.1. Applicable standard .................................................................................................................. 7 3.2. Block diagram of test setup ..................................................................................................... 7 3.3. Test procedure .......................................................................................................................... 7 3.4. Equipment approval considerations: ...................................................................................... 8 3.5. E and H Field Strength ............................................................................................................. 9 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 3 of 19 Test Report Declare Assess Standard Used: FCC CFR 47 part1, 1.1307(b), 1.1310; KDB680106 DR03-44118 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No.: DDT-RE23021004-2E02 Date of Receipt: Mar. 13, 2023 Date of Test: Mar. 13, 2023 ~ Apr. 06, 2023 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Lifeguard Press Inc. Address : 134 Beech Bend Rd. Bowling Green, KY 42101 Equipment under Test : Wireless charger Model No. : PWCMAG Trade Name : N/A Manufacturer : TAK MING TRADING COMPANY Address : 709 WAN LANHOUSE WAN TAU TONG ESTATE TAI PO NT E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 4 of 19 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Apr. 06, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 5 of 19 1. General Information 1.1. Description of equipment Note: EUT is the abbreviation of equipment under test. 1.2. Assistant equipment used for test Description of Accessories Manufacturer Model number Serial No. Other Dummy load N/A N/A N/A N/A Phone APPLE Iphone 12 N/A N/A 1.3. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, R-20155, G-20118 1.4. Measurement uncertainty Test Item Uncertainty Uncertainty for H-Filed Strength 1.2 dB Uncertainty for E-Filed Strength 1.2 dB Note: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. EUT* Name : Wireless charger Model Number : PWCMAG EUT function description : Please reference user manual of this device Power supply : Powered by DC 5V 2A or 9V 2A external adapter Wireless charging Operation frequency : 110-205 kHz Antenna Type : Inductive loop coil antenna Sample Number : S23021004-02 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE23021004-2E02 Page 6 of 19 2. Equipment used during test Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval Electric and Magnetic Field Analyzer narda EHP-200A 170WX91016 Sep. 01, 2022 1 Year Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-RE230…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23021004-2E01 Page 1 of 23 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Lifeguard Press Inc. Address : 134 Beech Bend Rd. Bowling Green, KY 42101 Equipment under Test : Wireless charger Model No. : PWCMAG Trade Mark : N/A FCC ID : 2AZOP-PWCMAG Manufacturer : TAK MING TRADING COMPANY Address : 709 WAN LANHOUSE WAN TAU TONG ESTATE TAI PO NT Report No.: DDT-RE23021004-2E01 Issued Date: Apr. 06, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23021004-2E01 Page 2 of 23 Table of Contents Test report declares........................................................................................................3 1 Summary of Test Results ........................................................................................................ 5 2 General Test Information ......................................................................................................... 6 2.1. Description of EUT ................................................................................................................... 6 2.2. Accessories of EUT .................................................................................................................. 6 2.3. Assistant equipment used for test .......................................................................................... 6 2.4. Block diagram of EUT configuration for test ......................................................................... 6 2.5. Deviations of test standard ...................................................................................................... 6 2.6. Test environment conditions ................................................................................................... 7 2.7. Test laboratory .......................................................................................................................... 7 2.8. Measurement uncertainty ........................................................................................................ 7 3 Equipment Used During Test .................................................................................................. 8 4 20 dB Bandwidth ....................................................................................................................... 9 4.1. Block diagram of test setup ..................................................................................................... 9 4.2. Limits .......................................................................................................................................... 9 4.3. Test procedure .......................................................................................................................... 9 4.4. Test result .................................................................................................................................. 9 4.5. Original test data ..................................................................................................................... 10 5 Radiated Emission .................................................................................................................. 11 5.1. Block diagram of test setup ................................................................................................... 11 5.2. Limit .......................................................................................................................................... 12 5.3. Test procedure ........................................................................................................................ 12 5.4. Test result ................................................................................................................................ 13 6 Power Line Conducted Emission ......................................................................................... 18 6.1. Block diagram of test setup ................................................................................................... 18 6.2. Power line conducted emission limits .................................................................................. 18 6.3. Test procedure ........................................................................................................................ 18 6.4. Test result ................................................................................................................................ 19 7 Antenna Requirements .......................................................................................................... 22 8 Photos of the EUT .................................................................................................................. 23 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23021004-2E01 Page 3 of 23 Test Report Declare Test Standard Used: FCC Rules and Regulations Part 15 Subpart C Test procedure used: ANSI C63.10:2013 We Declare: The equipment described above is tested by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration tested the equipment complied with the standards specified above. The test results are contained in this test report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these tests. After test and evaluation, our opinion is that the equipment provided for test compliance with the requirement of the above FCC standards. Report No.: DDT-RE23021004-2E01 Date of Receipt: Mar. 13, 2023 Date of Test: Mar. 13, 2023 ~ Apr. 06, 2023 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be repro…

Text truncated - open the document above for the full version.

产 品 规 格 书 规格编号 202303024001 生效日期 2023/3/24 客户名称宝源威 产品类型功率线圈 顶智料号 TX-DZ4005.500.5--K6.5-L60（开单槽) 客户料号 【 □ 新版发行 , □ 版本修订】 【 本规范含目录共 7 页 】 【 RoHS Compliant Parts 】 编制审核批准 钟建立 / 马湘平 地址；东莞市塘厦镇新苑南路5号鑫博盛产业园A栋东面7楼 电话；13147097490 本承认书在客户收到30天内，请务必签章返回，逾期视为生产时按此承认书的标准执 行。 【客户核准】 日期: 承认状态： □完全承认 □条件承认 □拒绝承认 批准审核复检检查 说明: √ 产 品 规 格 书 客户名称宝源威客户料号 0 料号TX-DZ4005.500.5--K6.5-L60（开单槽)规格编号 202303024001 发行/修订记录 版本生效日期 变更内容/原因 核准 012023/3/24 新规格发行钟建立 编制审核批准 钟建立 / 马湘平 产 品 规 格 书 客户名称宝源威客户料号 0 料号TX-DZ4005.500.5--K6.5-L60（开单槽)规格编号 202303024001 版本 01 ♦、外形尺寸 (单位: mm) A40.0±1.5 B5.5±1.5 C38.5±1.5 D20.5±1.5 E60.0±2.0 F3.0±2.0 G1.5±0.3 备注 (1)线径: 0.08*24*2P漆包线 (2)绕线圈数10TS (3)起尾线是否交叉: 是 (4)线圈包8mm宽高温胶带 (5)线圈与磁片需粘贴居中 (6)磁片背白胶 ♦、电气特性: 参数规格测试条件测试仪器 L06.5±10%μH100KHz/1V■TH1816B Q>30100KHz/1V■TH1816B DCR<95mΩ@ 25°C■CH-502BC ♦、温度等级: 操作温度 -40°C~ 125°C ♦、材料清单: 序号品名材料规格供应商备注 1 磁片 40*5.5*0.5开单槽PC40磁材 2 铜线 0.08*24*2P 丙铜丝包线 3 高温胶带 8MM 环保胶带 4 锡 107H 千岛环保锡 5 胶白胶环保胶纸

1 Test Setup Photograph
