2AZSS-PB100Magnetic wireless power bank

Magnetic Wireless Portable Power Bank,MagHome 5000mah Charger With USB-C And Lighting Cable ,Metal Bracket ForiPhone 12/ iPhone 12Pro /12 Pro Max Please Read This User Manual Completely And Keep It Properly Schematic Display of Product (appearance and por t instruction) Function Description 1.15W Magnetic wireless quick charging,Strong magnetic makes it easy to charging you phone 2.Suppor ting PD+QC20W quick charging of Such mainstream products as PPS、PD3.0、PD2.0、SCP、FCP、QC3.0,ets. 3.Superior Safety: safety system i ncludes foreign object detection, shor t circuit protection, temperature control, and more. 4.Sync input and output f or protable charging Power i ndicators 1.Checking remaining power : User instruciton 1.After clicking the switch button, the mobile power indicator will display the current power value. After 3 seconds, the working red light will display, indicating that the power bank has star ted to work , and the power bank will be close to the phone, and the blue light will indicate the star t of wireless charging. 2.Connect one end of the charging cable to the Type-C output por t,and the other end to the mobile phone or other digital devices. At t his time ,the device can be charged Precautions 1.If this device is Not used for a longtime,please charge it at least ever y 3 months 2.It might produce slight heat during charging,which is normal as long as it's below 55°C 3.Please don’t charge big power devices to protect the device from being damaged due to too big a power 4.Please don’t use the charger in any humid environment or in thunderstorm weather 5.Don’t clean the charger ith intensive chemicals or detergents,etc. 6.Children must use it under the guidance of adults Tips 1.Improper use of the product may cause damage to it or may endanger personal and proper ty safety 2. A consumer shall be liable for all consequences for any personal proper y damages resulted from any of his/her improper use of this product against the product user manual,and maghome shall bear no legal liability 3.This product suppor t quick charging.To obtain a better quick charging experience,please use official or cer tified OEM charging chord Statement of hazardous sustance with electronic information products O:Indicaties that contents of Mhe toxic and hazardoussubstances in all homogeneous materials are below the limit r equirements specified byGB/T 26572 standard X:Indicates that contents of the toxic and hazardous substances exceed the limit r equirements specified in GB/T 26572 standard in at least one homogeneus material of the par t Icon descripition The 10-year icon refers to the “effective life of environmental protection” not the product quality assurance period. Electronic products all contain toxic and harmful substances such as lead,mer cury and cadmium. Once they are overused .toxic and harmful sustances may leak or mutate,cause pollution to the environment,or cause serious damage to people and property.The term of “environmental protection use” means that all electronic products will be required to use within this effective period. We will no longer e responsible for the quality of the products due to the safety risks that arise after the safe use period Warning Please follow the above safety instructions otherwise it will cause fire,electric shock,damage or other damage Guangzhou GuDuo Network Technology Co., Ltd Add:No.66, Fengze East Road, Nansha District, Guangzhou Executive Standard:Q/SSCZ 012-0220 Copyright@2017-2021 Guangzhou GuDuo Network Technology Co., Ltd All Rights Reserved Designed by MaghomeMade in China Product parmeters Name:Magnetic Wireless Power Bank Model:PB100 Material:ABS+PC Capacity:5000Mah Type-C Input: Lightning Input: Wireless Output:15W(Max) Type-C Output: Executive Standard： Q/SSCZ 012-0220 Working Temperatur :-10°C~40°C Size: L115mm*W68mm*H11mm Weight:138g 5V⎓3A ,9V⎓2.2A ,12V⎓1.6A ,20W Max 5V⎓3A ,9V⎓2A ,12V⎓1.5A 5V⎓2.1A ,10.5W Max MAGHOME PRODUCT MANUAL irelessW On/Off LED USB-C (In/Out) Lighting （In） FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the follow ing two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentia l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televis ion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technic ian for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be insta lled and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

C5266091_X8_Ed.1 1/1 Letter of Authorization < Guangzhou GuDuo Network Technology Co., Ltd > Company: Guangzhou GuDuo Network Technology Co., Ltd Address: No.66, Fengze East Road, Nansha District, Guangzhou City, China Product Name: Magnetic wireless power bank Model Number: PB100 FCC Identifier: 2AZSS-PB100 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Li zhichao Date: 2021-05-12 Title: N/A Signature of applicant:

C5266091_X10_Ed.1 1/1 <Guangzhou GuDuo Network Technology Co., Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-05-12 Subject: Request for Confidentiality FCC ID:2AZSS-PB100 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Nam e: Li zhichao Title: N/A

EUT PHOTO(External Photos)

Label and label location Magnetic wireless power bank FCC ID:2AZSS-PB100

EUT PHOTO(Internal Photos) RF chipset ※※※※※ END OF REPORT ※※※※※ ANT

FCC ID:2AZSS-PB100 RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (6) The aggregate H-field strengths anywhere at or beyond 10cm to 1cm at iteration, i.e. at a distance of 10cm,9cm,8cm,.....1cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (1-10 cm from all sides and 1-10 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 26 2020 June. 25 2021 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 26 2020 June. 25 2021 6 Test Result E-Filed Strength at 10 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.71 0.71 0.71 0.72 614 E-Filed Strength at 10 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.72 614 E-Filed Strength at 9 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.72 0.73 0.73 0.74 614 E-Filed Strength at 9 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.74 614 E-Filed Strength at 8 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.75 0.75 0.77 0.77 614 E-Filed Strength at 8 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.76 614 E-Filed Strength at 7 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.79 0.79 0.80 0.81 614 E-Filed Strength at 7 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.81 614 E-Filed Strength at 6 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.86 0.87 0.87 0.86 614 E-Filed Strength at 6 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.87 614 E-Filed Strength at 5 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.91 0.92 0.91 0.92 614 E-Filed Strength at 5 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.92 614 E-Filed Strength at 4 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.95 0.95 0.96 0.95 614 E-Filed Strength at 4 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.96 614 E-Filed Strength at 3 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.98 0.98 0.97 0.97 614 E-Filed Strength at 3 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.98 614 E-Filed Strength at 2 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 1.02 1.03 1.04 1.03 614 E-Filed Strength at 2 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 1.04 614 E-Filed Strength at 1 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 1.06 1.08 1.08 1.07 614 E-Filed Strength at 1 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 1.07 614 H-Filed Strength at 10 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.110-0.205 0.12 0.13 0.12 0.12 1.63 H-Filed Strength at 10 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.110-0.205 0.13 1.63 H-Filed Strength at 9 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C…
