2AZSU-H9WWireless Car Charger Mount

85MM 55MM EMAIL US: [email protected] IMPORTANT ! Life-Time Warranty! IF YOU NEED ASSISTANCE OR REPLACEMENT PARTS Shout it out and let more people hear your voice! Love Your Mount? [email protected] LIFE TIME WARRANTY Our Customer Service Team is waiting to assist you! Please reach out to us at Having Issues? WE WILL RESOLVE ALL ISSUES IN YOUR FAVOR, EVEN YEARS AFTER YOUR PURCHASE STEP 1 STEP 2 Unscrew the nut from the phone charger. Put the nut through the ball joint of the gooseneck. Push the ball joint onto the phone cradle. Tighten the screw nut to finish the holder installation. Choose the flat area and clean the surface. Press the holder and push the lock lever down to lock the phone holder. Plug the Type C Cable (include in package) into the charging port on bottom of cradle. Tear off the protective film. Press the button behind the holder to release the arm automatically. Put you phone in. Squeeze the arms until it holds. Plug the QC 3.0 adapter into the car. Make sure it is connect power. Finish！ ! Press the button behind the holder to release the arm. Quick Release Button Step 1 Step 2 Press the quick release button on the back of the phone holder to open both arms. Step 3 STEP 3 STEP 4 STEP 5 STEP 6 STEP 7 STEP 8 Put in the cell phone,then squeeze the arms until it holds. Make sure you rest the phone flat againest the holder completely. *Wireless Charging Status Indicator Metal obstruction detected Actively charging a device Finished the charging Red-light Bright Indicator ColorStatus Blue-light Flickers Blue-light Bright Wireless Car Charger Mount FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the follow ing two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentia l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televis ion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technic ian for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be insta lled and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

Wiiki-Tech Electronic Co.,Ltd Model Difference Product description: Wireless Car Charger Mount Model name: H9W h5sw Trade Name: FCC ID: 2AZSU-H9W All the model are the same circuit and RF module, only for model name. Regards Sincerely Client’s signature: Client’s name / title : Du Pengcheng (GM) Contact information / address: 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, CHINA

1/1 Com Ad d Prod Mod FC C We a 0819 abov Any beh a We d Carm relat to d carri same Na m Titl e Si gn mpany: Wi dress: 2-3/ DIST duct Nam del Numb C Identifie authorize L 93 Bellater ve named e individual alf and tak declare tha me, s/n, 0 ted to the discuss any ied out by e effect as me: Du Pen e: N/A nature of < iki-Tech El /F, A Blk, N TRICT, DON me: Wireles er: H9W h5sw er: 2AZSU LGAI Tech rra, Spain, equipment within LGA ke action on at authoriz 08193 Bel approval p y issues c y LGAI Te s acts of ou ngcheng applicant Letter o < Wiiki-Tec lectronic C NO.2 LONG NGGUAN, ss Car Cha -H9W nological C , to act o t. AI Technol n the appli ze LGAI Te laterra, Sp project to concerning echnologica ur own. t: of Auth ch Electron Co.,Ltd GTONG RD, CHINA rger Moun Center S.A on our beh logical Cen cation. echnologica pain, is a the Feder the app r al Center S horizati ic Co.,Ltd , XINHE CO t ., Ronda d half on all nter S.A. is al Center S llowed to al Commu oval appli c S.A. on ou D C ion > ONMMUNIT de la Font d matters c s authorize S.A., Ronda forward nication C cation. An ur behalf Date: 2021 C5266091_X8 TY, WANJI del Carme, concerning d to act on a de la Fon all inform ommissio n ny and all shall have -05-07 8_Ed.1 IANG , s/n, g the n our nt del ation n and acts e the

1/1 Offic Fed e 7435 Colum Subj e FCC To W Purs u (47C attac Abo v cons discl o comp It is corr e docu equip Sinc e Sign a Nam Title: e of Engine eral Commu 5 Oakland M mbia, MD 2 ect: Reques ID:2AZSU-H Whom It May uant to th CFR0.457, 0 chment(s) a ve mentione idered as osure of ab petitor an u our under s espondent d uments and pment auth erely, ature: e: Du Peng :N/A < eering Techn nications Co Mills Road 21046 st for Confid H9W y Concern, he provisio 0.459), we as confident Exhibits ID Label/Loca Attestation St External Photo Block Diagram Schematics Test Report Test Setup Ph User’s Manua Internal Photo Parts List / Tu RF Exposure I Operational D Cover Letter(s SDR Software ed docume proprietar y bove docum nfair advan standing th during cert those infor orization is cheng <Wiiki-Tec nology ommission dentiality ns of Sec t are reques tial docume ation tatement os m hotos l os une Up Info Description s) e / Security Inf nt contains y informatio ments migh ntage in the hat all mea tification rev rmation wil issued. h Electron tions 0.457 sting the C nt from pub Lon Co n fo s detailed s on in oper ht be harm market. surement t view proce l be availab ic Co.,Ltd 7 and 0.4 Commission blic disclosu g-Term nfidentiality S C No No No No No No system and ration of th mful to our test reports ess cannot ble for publ C5 > D 59 of Com to withho ure. Short-Term Confidentiality No No No No No equipment he equipm company s, FCC ID la be granted ic review o 266091_X10 Date: 2021-0 mmission's old the follo y t descriptio ent. The p and would abel format d as confid nce the gr a 0_Ed.1 05-07 rules owing n are public give t and ential ant of

EUT PHOTO(External Photos)

Label and label location Wireless Car Charger Mount FCC ID:2AZSU-H9W

EUT PHOTO(Internal Photos) RF chipset ※※※※※ END OF REPORT ※※※※※ ANT

FCC ID:2AZSU-H9W RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 26 2020 June. 25 2021 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 26 2020 June. 25 2021 6 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.110-0.205 0.72 0.71 0.70 0.71 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.110-0.205 0.71 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.110-0.205 0.13 0.13 0.14 0.14 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.110-0.205 0.14 1.63 7 Test Set-up Photo

Project No.: ZKT-2104161261E Page 1 of 21 FCC TEST REPORT FCC ID:2AZSU-H9W Report Number. .............................. : ZKT-2104161261E Date of Test ........................................ Apr. 18, 2021 to Apr. 29, 2021 Date of issue .................................... : Apr. 29, 2021 Total number of pages ...................... 21 Test Result ..................................... : PASS Testing Laboratory. ........................ : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : Wiiki-Tech Electronic Co.,Ltd Address .......................................... : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, CHINA Manufacturer's name ................... : Wiiki-Tech Electronic Co.,Ltd Address .......................................... : 2-3/F, A Blk, NO.2 LONGTONG RD, XINHE CONMMUNITY, WANJIANG DISTRICT, DONGGUAN, CHINA Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-107_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : Wireless Car Charger Mount Trademark ...................................... : Model/Type reference ...................... : H9W h5sw Ratings ............................................. : Input: DC 9V,1.67A Wireless: 15W Project No.: ZKT-2104161261E Page 2 of 21 Testing procedure and testing location: Testing Laboratory ................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-2104161261E Page 3 of 21 TABLE OF CONTENTS 1. VERSION ............................................................................................................................... 4 2. TEST SUMMARY ................................................................................................................. 5 2.1 TEST FACILITY .................................................................................................................................... 6 2.2 MEASUREMENT UNCERTAINTY .................................................................................................... 6 3. GENERAL INFORMATION ................................................................................................. 7 3.1 GENERAL DESCRIPTION OF EUT ................................................................................................. 7 3.2 Test mode .............................................................................................................................................. 7 3.3 Block Diagram of EUT Configuration ................................................................................................ 7 3.4 Test Conditions ..................................................................................................................................... 7 3.5 Description Of Support Units (Conducted Mode) ............................................................................ 8 3.6 EQUIPMENTS LIST FOR ALL TEST ITEMS .................................................................................. 9 4. CONDUCTED EMISSION TEST........................................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT ................................................................................ 10 4.1.1 POWER LINE CONDUCTED EMISSION Limits........................................................................ 10 4.1.2 TEST PROCEDURE ...................................................................................................................... 10 4.1.3 DEVIATION FROM TEST STANDARD ....................................................................................... 10 4.1.4 TEST SETUP ................................................................................................................................... 11 4.1.5 EUT OPERATING CONDITIONS ................................................................................................. 11 4.6 Test Result .......................................................................................................................................... 12 5. RADIATED EMISSION MEASUREMENT ........................................................................14 5.1 Radiated Emission Limits .................................................................................................................. 14 5.2 Anechoic Chamber Test Setup Diagram ........................................................................................ 15 5.3 Test Procedure ................................................................................................................................... 15 5.4 DEVIATION FROM TEST STANDARD ..........................................................................................…
