2AZTM05-0069BLE Gateway Antenna

Gateway Antenna Installation and Users Manual Rev 1 13/05/2021 Introduction The Vantage Gateway Antenna is used in conjunction with the Vantage Bluetooth Low Energy reader (aka SmartTrack). The Gateway Antenna receives signals from BLE beacons and then sends them to the SmartTrack. The reader interprets the signals and passes these along with timestamps to the main Vantage on-site server. Connecting the Gateway Antenna to the SmartTrack Connecting the Gateway Antenna to the SmartTrack is easy. A single connection is made from the back of the Gateway Antenna (through the gland on the bottom and via the removable panel) to the SmartTrack. It is important to wire the SmartTrack device first and then run the wiring to the Gateway Antenna. This is due to the USB-A connector’s inability to slide through the waterproof gland on the bottom of the SmartTrack device. Product Name:BLE Gateway Antenna Model Name:05-0069 FCC ID:2AZTM05-0069 Fig 1. Connection diagram Remove the face of the SmartTrack and connect thecable with the USB-A connector to the USB port on the SBC (single-board-computer). Fig 2. USB-A Connected to SBC Next, run the cable with the USB Mini connector fromthe inside of the SmartTrack through the waterproof gland. Fig 3. Cable running through gland with USB Mini Now, open the access panel on the back of the GatewayAntenna. Push the USB Mini connector through the waterproof gland on theGateway Antenna and connect it to the USB female connector on the antenna. Fig 4. Usb Mini connected to PCB in Gateway Antenna Finally, close up the access panel and ensure a tightfit to keep water out of the antenna Fig 5. Closed Access Panel in back of Gateway Antenna Operations Operation is automatic. No changes need to be made to the SmartTrack or the Gateway Antenna for it to work. The firmware that is pre-loaded on the SmartTrack already accepts the incoming signals from the Gateway Antenna. FCC Part 15.21 information for user You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC Part 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation
