2AZTNRCR20LED-light for image processing

RandomDot-000 USER MANUAL RandomDot-000 ID #016729[C] Version 1.1.2021 MAJ:10 mai 2021 Please take a while to consider and read this brochure before using your new device. If you have any doubt, please contact EFFILUX. • Do not look directly or with any optical instrument the light beam • IP54 Classification : Protection against dust and water projections from all directions • Avoid any contact with the LED or with the projection lens • Use the device in an environment at 0°C to +50°C with no excessive moisture: high humidity and high temperature could damage the device • Do not use the device in an environment with oil fumes and steam • Do never try to fix any damages to the product by yourself • Make sure you are using a correct power supply before connecting the device • Do not inverse electrical polarity – check your connections and the conventions before turning on the power supply • Make sure you consider an adapted connector to link the device to the power supply • Make sure you are using a power supply with the 62368 standard for power supplies safety Any improper use voids the warranty For all maintenance operation, the product must be switched off. To handle the optical components, wearing gloves is strongly recommended. To clean the optical components, use compressed air duster if there is some dust. User security Maintenance RandomDot-000 USER MANUAL RandomDot-000 ID #016729[C] Version 1.1.2021 MAJ:10 mai 2021 To remove marks on the lens, wipe 1-2 drops of non-alcohol-based cleaning fluid in a gentle circular motion with a cleaning tissue. Always apply the fluid to a tissue rather than the lens itself. The product is supplied with a 24V constant voltage. Please be careful to use a voltage comprised between 22V and 29V. OPERATING THE PRODUCT RandomDot-000 is an industrial white LED pattern projector. It must be used only for projecting its pattern on a surface, excluding any other use. The LED driver inside the product is set to automatically pulse the LED. If you trigger light for a short pulse (< 25 ms), light is pulsed (LED are driven at 2,2A). If your pulse is longer, the driver automatically decreases LED current to 0,4A (18% of max current) to protect LED against failure. Maximum T ON = 25 ms Minimum T OFF = 25 ms Response rise time : 35 μs Response fall time : 30 μs Peak consumption : 44W Continuous mode consumption : 10W Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation STATUS LED LED color Designation Red Overtemperature security Activated when the temperature of the LED reaches 75°C Green Lighting ON Blue TRIG signal IN Electronical consideration RandomDot-000 USER MANUAL RandomDot-000 ID #016729[C] Version 1.1.2021 MAJ:10 mai 2021 ELECTRONICAL PINOUT POWER / GPIO – M12 8 PINS MALE CONNECTOR Pin number Cable color Contact arrangement Designation Details IN/OUT Voltage Reference 1 White M12 8 pins Male connector N/C / / 2 Brown +24V Power IN IN 0V 3 Green GPIO_IN2_ROBOT Optocoupler IN IN GPIO_GND 4 Yellow GPIO_GND Optocoupler IN GND IN GPIO_GND 5 Grey GPIO_VCC Supply for Optocoupler Output IN Chassis GND 6 Pink GPIO_OUT1_ISO Optocoupler OUT OUT Chassis GND 7 Blue 0V 0V IN/OUT 0V 8 Red GPIO_OUT2_ISO Optocoupler OUT OUT Chassis GND CAMERA – M12 8 PINS FEMALE CONNECTOR Pin number Cable color Contact arrangement Designation Details IN/OUT Voltage Reference 1 White M12 8 pins Female connector GPIO_OVERTEMP 1 = OK (24V) 0 = NOK (0V) OUT Chassis GND 2 Brown +24V Power OUT to camera OUT 0V 3 Green GPIO_IN2 Optocoupler OUT OUT Chassis GND 4 Yellow 0V 0V IN/OUT 0V 5 Grey +24V GPIO_VCC for camera (Supply for camera optocouplers) OUT 0V 6 Pink GPIO_OUT1 Lighting TRIG IN 0V 7 Blue 0V 0V IN/OUT 0V 8 Red GPIO_OUT2 Input IN 0V RandomDot-000 USER MANUAL RandomDot-000 ID #016729[C] Version 1.1.2021 MAJ:10 mai 2021 Color Temperature: 6000K Optical consideration Mechanical consideration The product is mounted with the C-mount lens VS Technology VS-1214H1 in addition to a custom lens made by EFFILUX. EFFILUX will deliver the product with the following optical configuration: - Horizontal projection angle : 62° - Vertical projection angle : 48° - Diagonal projection angle : 75° The focus and the aperture can be adjusted with manual settings of the C-mount lens. The projected pattern is a square random 50%-density cloud of dots The projection of this pattern depends on the settings of the objective and the additional lens. The working distance must be included between 500mm and 3000mm for a convenient use of the product Weight : 660g
