2AZTO-THG1Throttle

Pure Outboard User Guide PREFACE We’re excited to introduce you to a revolutionary boating experience. This User Guide contains information needed for proper operation and system care of your Pure Outboard system. A thorough understanding of these instructions will help you maximize the performance and lifetime of your new Outboard system. Please read this User Guide and follow all system care procedures. If you have questions or concerns about the operation and care of this product, please contact Pure Watercraft. Should a problem arise with the product, please follow the troubleshooting procedures listed at the end of this User Guide. If the problem persists, contact Pure Watercraft. All information in this User Guide is based on the latest product information available at the time of publishing the User Guide. Pure Watercraft reserves the right to make changes at any time without notice or obligation. Please keep this User Guide readily available as a reference for anyone who operates the Pure Outboard system. We hope you enjoy your time on the water! Pure Watercraft Table of Contents 1.0 INTRODUCTION7 1.1 General Information7 1.2 Symbols7 2.0 SAFETY8 2.1 General Safety Information8 2.2 Pure Outboard Safety Instructions8 2.3 General Safety Instructions for Boat Operation9 2.4 Liability Warning10 3.0 SPECIFICATIONS11 4.0 SYSTEM COMPONENTS & FUNCTIONS12 4.1 System Overview12 4.2 Outboard14 4.2.1 Overview14 4.2.2 Outboard Energy Throughput17 4.2.3 Power Tilt/Trim17 4.2.4 Tilting18 4.2.5 Trimming19 4.2.6 Tilt Lock20 4.2.7 Manual Tilt/Trim Release21 4.2.8 Steering Lock23 4.3 Battery Pack25 4.3.1 Overview25 4.3.2 About the Battery Pack26 4.3.3 Battery Pack State of Health27 4.3.4 Battery Pack Cumulative Energy Output27 4.3.5 Additional Battery Pack care recommendations27 4.4 Charger28 4.4.1 Overview28 4.4.2 Compatible Power Outlets & Corresponding Cables30 4.4.3 Charging Status Light31 4.5 Throttle33 4.5.1 Overview33 4.5.2 Emergency Stop34 4.5.3 Start-in-Gear Protection35 4.5.4 Reverse Mode Power Reduction35 4.5.5 Auxiliary Power Output35 4.6 Throttle Display37 4.6.1 Description of Warnings42 4.6.2 Throttle Display During Charging48 4.7 Cables50 4.7.1 Pure Watercraft-Supplied Cables50 4.7.2 Cables Not Supplied by Pure Watercraft51 5.0 OUTBOARD OPERATION52 5.1 Before Startup52 5.2 Starting the System53 5.3 Maximizing Efficiency55 5.4 Power Derating55 5.5. Powering Off the System57 6.0 CHARGING58 6.1 Charging Battery Packs on the Boat58 6.1.1 Connecting a One-Battery Pack System to the Charger58 6.1.2 Connecting a System with Two or More Battery Packs to the Charger59 6.1.3 Charging Operation60 6.2 Charging Battery Packs Off of the Boat61 6.3 Charging Schedule61 6.4 Charging Duration62 7.0 MOBILE APP63 7.1 Mobile App Download and Account Creation63 7.2 Initial Pairing the Mobile App with the Outboard System63 7.3 Reconnecting the Mobile App with the Outboard System64 7.4 Mobile App Dashboard64 7.5 Trips & Trip Details66 7.6 System Lifetime Data67 7.7 Personalize System Settings67 7.8 Submit Service Requests & Feedback68 7.9 Software Updates69 7.10 Telemetry Data Transfer69 8.0 TRAILERING71 8.1 Transom Saver71 8.2 System Security During Transport72 9.0 STORAGE73 9.1 Storing the Batteries & Charger73 9.2 Storing the Outboard73 10.0 INSTALLATION75 10.1 Preparing for System Installation75 10.1.1 Selecting the Location for the Battery Pack(s)75 10.1.2 Selecting the Location for Mounting the Throttle76 10.1 3 Cable Routing Path76 10.2 Installing the Battery Pack(s)76 10.3 Running the Cables76 10.4 Installing the Outboard77 10.4.1 Necessary Tools:77 10.4.2 Drilling Mounting Holes78 10.4.3 Mounting the Outboard79 10.4.4 Connecting to the Steering – Starboard Side Cable82 10.4.5 Installing the Outboard on a Jackplate87 10.4.6 Installing or Replacing the Propeller87 10.5 Installing the Throttle91 10.5.1 Option 1: Top Mount91 10.5.2 Option 2: Side Mount93 10.6 Connecting the Auxiliary Power95 10.7 Connecting the Pure Outboard System Components96 10.8 Mounting the Charger97 11.0 SYSTEM CARE99 12.0 TROUBLESHOOTING101 13.0 WARRANTY103 14.0 DECLARATIONS AND NOTIFICATIONS103 14.1Conformance103 14.1.1FCC & ISED Certification103 14.1.2IP-X7 Standard104 14.2Product Disposals104 14.3California Proposition 65 Warning104 15.0 TERMS & TERMINOLOGY105 16.0 CONTACTING PURE WATERCRAFT106 17.0 LIST OF FIGURES IN THIS USER GUIDE106 1INTRODUCTION 1.1 General Information This is the User Guide for the safe installation, operation, and care of your Pure Outboard electric outboard system. It covers 1) safety information; 2) system specifications; 3) the system’s components and their functions; 4) how to operate and charge the system; 5) functions of the Mobile Application; 6) instructions for trailering and storage of the Outboard system; 7) installation instructions; 8) system care instructions; and 9) troubleshooting steps. All personnel involved in the installation, setup, operation, and care of this product should read and understand this User Guide, particularly its safety instructions. Substandard performance, property damage, personal injury, or death may result from not following these instructions. To ensure a long product lifetime, Pure Watercraft recommends that you use and care for the product according to the instructions described in this guide. Pure Watercraft assumes no liability for damage caused by operation contrary to what is specified in this User Guide. 1.2 Symbols The following symbols are used throughout the User Guide and on product labels. Indicates information that, if ignored, will result in death or serious injury. Indicates information that, if ignored, could possibly result in death or injury due to incorrect handling. Indicates information that, if ignored, could possibly result in injury or physical damage due to incorrect handling. Indicates information considered important, but not hazard-related. Indicates that the product contains high voltage. Indicates that the product contains lithium …

Text truncated - open the document above for the full version.

Pure Watercraft 2151 N Northlake Way #210 Seattle, WA 98103 Date: 11/30/22 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AZTO-THG1 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Ian Johnson Mechanical Engineer

Pure Watercraft 2151 N Northlake Way #210 Seattle, WA 98103 Date: 11/30/22 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AZTO-THG1 Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Ian Johnson Mechanical Engineer

Reference No.: WTX21X04041977W Page 2 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX21X04041977W Page 3 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX21X04041977W Page 4 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX21X04041977W Page 5 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTX21X04041977W Page 1 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX21X04041977W Page 5 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX21X04041977W Page 6 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTX21X04041977W Page 7 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 4 Solder Board-Component View 5

RF Exposure Requirements Product Description: Throttle Model No.: THG1 FCC ID: 2AZTO-THG1 According to the KDB 447498 D01 v06 section 4.3.1, for 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to one decimal place for comparison Calculation Result: Tx frequency range: 2402-2480MHz Min. test separation distance: 5mm Maximum Conducted Output Power: 0.519dBm Tune-Up output power: 1.0 dBm RF channel transmit frequency: 2440MHz Result: 0.4 Limit: 3.0 The exclusion thresholds is 0.4 < 3, so the transmitter complies with the RF exposure requirements and the SAR is not required.

ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page1of11 TestingReport CustomerName:PureWatercraft ProductName:PureOutboardThrottle SampleModel:THG1 ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-2021 IssueDate:2022.11.30 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page2of11 Version VersionNo.DateDescriptionFormulateApproval A02022.11.30Forthefirsttime,formulateJacksonEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesting.........................................................................7 3.TestResults......................................................................................................................................8 3.1Teststandard.........................................................................................................................8 3.2Testuncertainty.....................................................................................................................8 3.3Testdata................................................................................................................................9 3.3.1S11parameters...........................................................................................................9 3.3.2VSWRdata................................................................................................................9 3.3.3Typicalfreespaceefficiencyandgain......................................................................9 3.3.4Typicalfreespaceradiationpattern.........................................................................10 （Thefollowingisblank）..............................................................................................................11 ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page3of11 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address / Tel / E-mail / Equipment Alltheequipmentusedinthereportisfixedin 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page4of11 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date 16probe microwave chamber 3*3*2.5 RFI-LAB-RF -A00 SUNYIELD2021.3.152023.3.14 Network Analyzer E5071C RFI-LAB-RF -A02 Agilent 2022.5.132023.5.12 Network Analyzer E5071C RFI-LAB-RF -C02 KEYSIGHT2022.5.132023.5.12 1.4Testenvironment Temperature 23.8°C Humidity 60%RH Pressure 100.25kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page5of11 2.SampleInformation 2.1Clientinformation Name PureWatercraft. Address 2151NNorthlakeWay#210,Seattle,WA98103 Contacts / Tel / E-mail / 2.2DescriptionofEUT(S) ProductName PureOutboardThrottle SampleModel THG1 AntennaSize / AntennaType PCBantenna SerialNo. / TestItem VSWR;Antennagain;Efficiency;Radiationpattern FrequencyRange 2400MHZ-2500MHZ ReceivedDate 2022.11.23 TestDate 2022.11.24 Remark ThelengthoftheRFcableis80mm ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page6of11 2.3EUTappearance ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page7of11 2.4EUTsetupphotooffreespaceOTAtesting Planform Frontview ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page8of11 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern VSWR Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-2021 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty VSWR±0.3 Antennagain±1dB Radiationefficiency ± 10% ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 Page9of11 3.3Testdata 3.3.1S11parameters 3.3.2VSWRdata 3.3.3Typicalfreespaceefficiencyandgain Frequency/MHz 240024502500 VSWR 2.47602.00261.8405 Frequency/MHz 24002410242024302440245024602470248024902500 PeakGain/dBi 1.942.202.412.632.753.033.103.283.303.573.48 Efficiency/% 51.7153.4555.2657.0358.3862.0162.9464.2765.6668.1168.18 ReportNo.:RFI-LAB-RF-202211-KK38 QP030-E11 P…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 47 TEST REPORT Reference No. .................... : WTX21X04041977W FCC ID ................................ : 2AZTO-THG1 Applicant ........................... : Pure Watercraft Address ............................. : 2151 N Northlake Way #210, Seattle, WA 98103 Product Name ................... : Throttle Test Model. ........................ : THG1 Standards .......................... : FCC Part 15.247 Date of Receipt sample .... : Apr. 30, 2021 Date of Test........................ : Dec. 30, 2021 to Feb. 15, 2022 Date of Issue ..................... : Feb. 15, 2022 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Tested by: Reviewed By: Approved & Authorized By: Jack Huang / Project Engineer Jason Su / RF Manager Silin Chen / Manager Reference No.: WTX21X04041977W Page 2 of 47 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................... 5 1.3 TEST METHODOLOGY ............................................................................................................................................. 5 1.4 TEST FACILITY ....................................................................................................................................................... 5 1.5 EUT SETUP AND TEST MODE ................................................................................................................................. 6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 1.7 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 10 3. ANTENNA REQUIREMENT ................................................................................................................................ 11 3.1 STANDARD APPLICABLE ....................................................................................................................................... 11 3.2 EVALUATION INFORMATION ................................................................................................................................ 11 4. POWER SPECTRAL DENSITY ........................................................................................................................... 12 4.1 STANDARD APPLICABLE ....................................................................................................................................... 12 4.2 TEST SETUP BLOCK DIAGRAM ............................................................................................................................. 12 4.3 TEST PROCEDURE ................................................................................................................................................. 12 4.4 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 12 5. DTS BANDWIDTH ................................................................................................................................................. 13 5.1 STANDARD APPLICABLE ....................................................................................................................................... 13 5.2 TEST SETUP BLOCK DIAGRAM ............................................................................................................................. 13 5.3 TEST PROCEDURE ................................................................................................................................................. 13 5.4 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 13 6. RF OUTPUT POWER ............................................................................................................................................ 14 6.1 STANDARD APPLICABLE ....................................................................................................................................... 14 6.2 TEST SETUP BLOCK DIAGRAM ............................................................................................................................. 14 6.3 TEST PROCEDURE ................................................................................................................................................. 14 6.4 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 14 7. FIELD STRENGTH OF SPURIOUS EMISSIONS ............................................................................................. 15 7.1 STANDARD APPLICABLE ..............................................…

Text truncated - open the document above for the full version.

Reference No.: WTX21X04041977W Page 10 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) Reference No.: WTX21X04041977W Page 11 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (1GHz to 18GHz) Reference No.: WTX21X04041977W Page 12 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (Above 18GHz) ***** END OF REPORT *****
