2AZVO-0088MT12612.4 G remote control car

DATE : 2021-05-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shantou YouBang Toy Factory and Huize Industrial Zone, Lianxia Town, Chenghai District, Shantou City, Guangdong Province, China Signature: Name: XIAOBANG WANG Title: Manager Company: Shantou YouBang Toy Factory

DATE : 2021-05-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AZVO-0088MT1261 Product Name: 2.4 G remote control car Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: XIAOBANG WANG Title: Manager Company: Shantou YouBang Toy Factory

Differences Declaration To whom concern, We company Shantou YouBang Toy Factory hereby declares: The product models MT1261, 0088-TS, 0088-TSW, 0088-TP, 0088-TPW are identical in the same PCB layout, interior structure and electrical circuits, The differences are appearance color and model name for commercial purpose. Authorized signature: Name: XIAOBANG WANG Date: 2021-05-21

TX:

FCC ID: 2AZVO-0088MT1261

FCC ID: 2AZVO-0088MT1261 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 82.34dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1.0 So pt={ [10 82.34/20) /10 6 x 3] 2 /30x1}x1000 mW =0.0514mW So (0.0514mW /5mm)x √2.475= 0.016<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSL202105000114F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 22 TEST REPORT Applicant: Shantou YouBang Toy Factory Address of Applicant: Huize Industrial Zone, Lianxia Town, Chenghai District, Shantou City, Guangdong Province, China Manufacturer: Shantou YouBang Toy Factory Address of Manufacturer: Huize Industrial Zone, Lianxia Town, Chenghai District, Shantou City, Guangdong Province, China Equipment Under Test (EUT) Product Name: 2.4 G remote control car Model No.: MT1261, 0088-TS, 0088-TSW, 0088-TP, 0088-TPW FCC ID: 2AZVO-0088MT1261 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: May 17, 2021 Date of Test: May 18-20, 2021 Date of report issued: May 21, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202105000114F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 22 2 Version Version No. Date Description 00 May 21, 2021 Original Prepared By: Date: May 21, 2021 Project Engineer Check By: Date: May 21, 2021 Reviewer Report No.: GTSL202105000114F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 22 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 6 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 6 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 6 5.6 TEST FACILITY .................................................................................................................................... 6 5.7 TEST LOCATION ................................................................................................................................. 6 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 RADIATED EMISSION METHOD ........................................................................................................... 10 7.2.1 Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2 Spurious emissions .................................................................................................................... 13 7.2.3 Bandedge emissions.................................................................................................................. 18 7.3 20DB OCCUPY BANDWIDTH .............................................................................................................. 20 8 TEST SETUP PHOTO ............................................................................................................................ 22 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 22 Report No.: GTSL202105000114F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 22 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 N/A Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Remarks: 1…

Text truncated - open the document above for the full version.

Radiated Emission
