G25M Label Printer User Manual Etikettendrucker Bedienungsanleitung Scan the QR Code to download the user manual to your smartphone Scannen Sie den QR-Code um die Bedienungsanleitung auf Ihr Smartphone herunterzuladen Website & Customer Service: us.supvan.com [email protected] Industry-leading thermal transfer printing technology If you have been using thermal transfer label printers, you know that they all print labels with a blank tape feed prior to the prints, wasting the tape and making the whole process inconvenient. However, this is not the case with the SUPVAN G-Series label printer. Being one-of-a-kind in the field, this printer does not leave any blank space when printing the label. The preci- sion-printing technology makes sure the prints appear in the center of the label. Saving tape paper while creating perfect pieces of thermal labels. Branchenführende Thermotransferdruck-Technologie Wenn Sie Thermotransfer-Etikettendrucker verwendet haben, wissen Sie, dass alle Etiketten vor dem Drucken mit einem leeren Bandeinzug gedruckt werden, wodurch das Band verschwendet wird und der gesamte Vorgang unprak- tisch wird. Dies ist jedoch beim SUPVAN Etikettendrucker der G-Serie nicht der Fall. Dieser Drucker ist einzigartig und druckt also keine unnötigen leeren Etiketten. Die Präzisionsdrucktech- nologie sorgt dafür, dass die gedruckten Inhalte in der Mitte des Etiketts erscheinen. Somit sparen Sie das Etikettenband und erstellen Sie perfekte Thermoetiketten. Please find one label tape stored inside the printer Ein im Drucker eingesetztes Etikettenband Checklist Checkliste 1 Printer 1 Drucker Contents Inhalt Checklist Install the Label Tape Display Information Smartphone App & PC Software Keys Features Troubleshooting Maintenance Safety Information, FCC & IC Warnings Warranty / Disclaimer Product Specifications Checkliste Installieren Sie das Etikettenband Schnittstelleninformationen Smartphone-App & PC-Software Tasten Besonderheiten Fehlerbehebung Wartung Sicherheitsinformationen Garantie / Haftungsausschluss Produktspezifikation English Deutsch 2 3 4 5 6 9 10 10 11-16 17 18 2 19 20 21 22 25 26 26 27 29 30 2 1 USB-C Cabel* 1 USB-C Kabel* Label Tape(s) Etikettenbänder * For charging and data transfer. See page 5 for computer software. * Zum Laden und zur Datenübertragung. Informationen zur Computersoftware finden Sie auf Seite 17. 1 AC Adapter 1 Netzteil Display InformationInstall the Label Tape 34 Pull to open the back cover, and push the label tape cassette all the way in. Please fully close the back cover for the printer to properly work. Label Size: Width x Length (mm). If the length is shown as [L], the current label tape is a continuous label tape, while the length of a single label will be set automatically according to the content inputted. To manually set the length, press . Line Indicator: Indicates the line of text on the current label being edited. Two lines of text can be entered on a single label. Case Indicator: Indicates capital letter or lower case letter input. Press [A/a] to shift between upper and lower cases. Bluetooth Indicator: Indicates Bluetooth is turned on, ready to connect to your smartphone and use with the “SUPRINT” App. Press [Fn], then press to enter Bluetooth setting. Language Indicator: Press [Fn] - [Lng] to change system language. Editing Format Indicator: In wrap-around label, flag label, terminal block label, and two size label editing mode, a diagram that indicates the current editing format will appear at here. In general label mode, no content will be displayed. 1/1 12*30 I EN Label Size Battery Level / Charging Status Input Text Language Indicator Line Indicator Bluetooth Indicator 1 Editing Format Indicator A Case Indicator Current Label / Total Labels in Current File When use, if label paper does not automatically roll out when print, please manually roll the tape to feed paper onto the print head. It will then roll automatically. To manually roll the label tape, turn to the other side of the cassette, rotate the green roller clockwise. The label paper will start to feed into the paper exit of the cassette. Push the cassette in and try print again. When not in use for a long time, please still keep the label tape inside the printer. This is to prevent the rubber roller (on top left from adhering onto the ceramic print head. If the rubber roller got stuck onto the print head, please gently pry it loose, before installing the label tape cassette back in. Long press to turn the printer on / Press to turn off. Set character size. Automatic / specified. Switch between horizontal / vertical label editing. Set the label length. Automatic / Specified. Press to enter print setting, press again to print. General label mode. Wrap-around label mode. Flag label mode. Terminal block label mode. Two size mode: edit two lines in different sizes. Settings for length, character size, font, alighment, style, frame, orientation, cutting mode, spacing, density, margins, save files, backlit, underline, factory reset, and Fn keys customization. Add new label with the format of the last label. Cannot add new label if the current input content is empty. Delete all. Backspace / Long press to delete current line. Cancel the current setting or content / Back to previous menu. Keys Smartphone App & PC Software Search for the “SUPRINT” App, or scan the QR Code on the left. SUPRINT 1. Long press to turn on the label maker with Bluetooth on. (The Bluetooth sign should appear on the top of the screen. If not, please press [Fn] and to enter Bluetooth settings.) 2. Turn on the Bluetooth on your smartphone. 3. Download and open the App on your smartphone. 4. Click “Connect Printer” and search for G25M to connect. (Android phones: If asked for location information permission, please allow the App to access the location information of the smartphone. This is only for the App to connect to the label printer. Otherwise the Bluetooth connection may not function.) Download the PC Edit…

Text truncated - open the document above for the full version.

Beijing Supvan Information Technology Co., Ltd. No.1 Gaoxin 5th Street,Huilongguan Town,Room 603,6th Floor,Building 1,Compound 1,Beijing Changping,Beijing,100085,CN Tel: +86 18519376422 Fax: +86 010-62968596-866 Email: [email protected] Attestation letter Date: 2026-06-10 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam, Our product Label Printer, model: G25M, FCC ID: 2AZW2-G25M, for marketing purpose, this product only supports BT:2402-2480MHz(GFSK,π/4-DQPSK, 8DPSK); BLE 1M.The other functions and modes were disabled to use by manufacturer in the software, the end user has no capability to activate it. Sincerely Yours, Signature: Liang Chao Manager

Beijing Supvan Information Technology Co., Ltd. No.1 Gaoxin 5th Street,HuilongguanTown,Room 603,6th Floor,Building 1,Compound 1,Beijing Changping,Beijing,100085,CN Tel: +86 18519376422 Fax: +86 010-62968596-866 Email: [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2026-06-10 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID:2AZW2-G25M Beijing Supvan Information Technology Co., Ltd. certifies that the equipment for which authorization is soughtis not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Liang Chao Manager

Beijing Supvan Information Technology Co., Ltd. No.1 Gaoxin 5th Street,HuilongguanTown,Room 603,6th Floor,Building 1,Compound 1,Beijing Changping,Beijing,100085,CN Tel: +86 18519376422 Fax: +86 010-62968596-866 Email: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 2026-06-10 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2AZW2-G25M Beijing Supvan Information Technology Co., Ltd.certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Signature ： Liang Chao Manager

U.S.AGENTLETTEROFATTESTATION Date: 2026-06-10 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2AZW2-G25M Beijing Supvan Information Technology Co., Ltd. certifies that, as of the date of the filing of the application, Iconsigh is our designated U.S. agent for service of process for the above referenced FCC ID. Beijing Supvan Information Technology Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: Beijing Supvan Information Technology Co., Ltd. Address: No.1 Gaoxin 5th Street,Huilongguan Town,Room 603,6th Floor,Building 1,Compound 1,Beijing Changping,Beijing,100085,CN FRN: 0030929582 Tel: +86 18519376422 Email: [email protected] Signed by (printed name): Liang Chao Signature:

BeijingSupvanInformationTechnologyCo.,Ltd. No.1Gaoxin5thStreet,HuilongguanTown,Room603,6thFloor,Building 1,Compound1,BeijingChangping,Beijing,100085,CN Tel:+8618519376422 Fax:+86010-62968596-866 Email:[email protected] QA-FR-170-B7/29/2014 FCCAuthorization Date:2026-06-10 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:AgentAuthorization Towhomitmayconcern: WeBeijingSupvanInformationTechnologyCo.,Ltd.,theundersigned,hereby authorizesBayAreaComplianceLaboratoriesCorp.(Shenzhen)toactonitsbehalfinall mattersrelatingtoapplicationforEquipmentauthorization,includingthesigningofall documentsrelatingtothesematters.AllactscarriedoutbyBayAreaCompliance LaboratoriesCorp.(Shenzhen)onourbehalfshallhavethesameeffectasourownaction. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits, thatincludesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988, 21U.S.C.862. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signature: LiangChao Manager

BeijingSupvanInformationTechnologyCo.,Ltd. No.1Gaoxin5thStreet,HuilongguanTown,Room603,6thFloor,Building 1,Compound1,BeijingChangping,Beijing,100085,CN Tel:+8618519376422 Fax:+86010-62968596-866 Email:[email protected] FCCConfidentialAuthorization Date:2026-06-10 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:ConfidentialityRequestregardingapplicationforcertificationof FCCID:2AZW2-G25M InaccordancewithSections0.457and0.459oftheCommission’sRules,BeijingSupvan InformationTechnologyCo.,Ltd.herebyrequestslong-termconfidentialtreatmentof informationaccompanyingthisapplicationasoutlinedbelow: BlockDiagram Schematics OperationDescription Theabovematerialscontainproprietaryandconfidentialinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsprovidesunjustified benefitstoitscompetitorsinthemarket. SincerelyYours, Signature: LiangChao Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-EXP Page 1 of 5 EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-EXP Page 2 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-EXP Page 3 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-EXP Page 4 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-EXP Page 5 of 5

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: 2601R02935E-RF FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 1 of 12 EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 2 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 3 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 4 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 5 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 6 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 7 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 8 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 9 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 10 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 11 of 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RF-INP Page 12 of 12 Antenna

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601R02935E-RFA TR-EM-RF011 Page 29 of 77 Version 4.2 RF EXPOSURE EVALUATION Applicable Standard According to FCC §2.1093 and §1.1307(b) (1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D01 General RF Exposure Guidance v06. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where 1. f(GHz) is the RF channel transmit frequency in GHz. 2. Power and distance are rounded to the nearest mW and mm before calculation. 3. The result is rounded to one decimal place for comparison. 4. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test Exclusion. Measurement Result For worst case: Mode Frequency (MHz) Max tune- up conducted power # (dBm) Max tune- up conducted power # (mW) Distance (mm) Calculated value Threshold (1-g SAR) SAR Test Exclusion BLE2402-24802 1.5850.53Yes Result: Compliant

ANTENNA TEST REPORT Manufacturer: Beijing Supvan Information Technology Co., Ltd. Address: No.1 Gaoxin 5th Street,Huilongguan Town,Room 603,6th Floor，Building 1,Compound 1,Beijing Changping,Beijing,100085,CN Product Name: Bluetooth antenna Product Model: G25M antenna Report Number: 2603S20996E-RF-OT Date Of Issue: 2026/4/16 Reviewed By : Title: Approved By: Luke Yuan OTA Test Supervisor Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) Room 101 & 201, Building 2, 256 Pingdong Road, Dalang Town, Dongguan City, Guangdong, China Tel: +86-769-83085888 www.ccttt.com.cn China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 2 of 14 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the Room 01 & 201, Building 2, 256 Pingdong Road, Dalang Town, Dongguan City, Guangdong, China. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. Each test item follows the test standard(s) without deviation. China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 3 of 14 CONTENTS DOCUMENT REVISION HISTORY........................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 2. TEST CONFIGURATIONS ...................................................................................................... 6 2.1 TEST ENVIRONMENT ........................................................................................................................... 6 2.2 TEST EQUIPMENT ................................................................................................................................ 6 2.3 TEST SPECIFICATION ........................................................................................................................... 6 2.4 TEST UNCERTAINTY ............................................................................................................................ 7 2.5 TEST MEASUREMENT SYSTEM ............................................................................................................ 8 2.6 TEST SETUP .......................................................................................................................................... 8 2.6.1 Antenna Gain, Efficiency and Radiation Pattern Test Setup ............................................................ 8 3. TEST RESULTS ......................................................................................................................... 9 3.1 GAIN AND EFFICIENCY ........................................................................................................................ 9 3.2 RADIATION PATTERN ........................................................................................................................ 10 4. EUT PHOTOGRAPHS ............................................................................................................ 13 5. TEST SETUP PHOTOGRAPHS ............................................................................................ 14 China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 4 of 14 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2603S20996E-RF-OT Original Report 2026/4/16 China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 5 of 14 1. GENERAL INFORMATION Product Name: Bluetooth antenna Product Model: G25M antenna Antenna Type: PCB Test Items: Gain; Efficiency; 3D Pattern Test Frequency (MHz): 2402, 2440, 2480 Sample Number: 3JFM-1 EUT Received Date: 2026/4/2 EUT Received Status: Good China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 6 of 14 2. TEST CONFIGURATIONS 2.1 Test Environment Temperature (°C) 26.8 Humidity (%RH) 60.2 Atmospheric Pressure (kPa) 100.5 Tester Make Zeng Test Date 2026/4/14 2.2 Test Equipment Manufacturer Description Model Serial Number Calibration Date Calibrate Due Date R&S Vector Network Analyzer ZNB-8 1311601044104250 2026/2/7 2027/2/6 R&S Cross-Pol.Vivald i-ANT TC-TA18 200256 N/A N/A R&S Switch Controller OSP320 1528.3111K02\10 1442 N/A N/A R&S Switch Controller OSP320 1528.3105K03\10 1666 N/A N/A maturo Turntable controllers NCD/536/ 3082..01 N/A N/A N/A R&S Test Software AMS32 11.40.00 N/A N/A R&S Test System TS8991 N/A N/A N/A * Statement of Traceability: China Certification ICT Co., Ltd (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). 2.3 Test Specification IEEE Std 149-2021 China Certification ICT Co., Ltd (Dongguan) Report No.: 2603S20996E-RF-OT Report Template: RF-OTA-ANT-A/0 Page 7 of 14 2.4 Test Uncertainty Otherwise required by the applicant or Product Regulations, Decision Rule in this report did not consider the uncertainty. The extended uncertainty given in this report is obtained by combining the standard uncertainty times the coverage factor K…
